USER MANUAL UPB10K4S2U Tripp Lite

Register your product for quicker service and ultimate peace of mind.

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.triplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.triplite.com/support

Copyright © 2017 Tripp Lite. All rights reserved.

General Safety Instructions

• Make sure the power bank is fully charged prior to use.
• Please use a cable suitable for your device when charging it with the power bank.
• When charging the power bank, it is recommended you use the included USB Micro-B cable.
• Under a low-battery condition, the LEDs will turn off while charging a device. Recharge the power bank as soon as possible to avoid shortening the battery life.
• The battery should be charged at least every three months to avoid shortening the battery life.
• It is recommended to disconnect the charging device upon being fully charged to avoid further use of battery.
• When the power bank enters protection mode (LEDs turn off and power bank will not charge) caused by issues such as a short circuit, use an external charger to charge it and bring it back to normal operation.
• Keep the power bank away from fire, and avoid temperatures above 113^ ( 45^ ).
• Do not get the power bank wet or immerse it in water.
• Do not wash the power bank with corrosive cleaner.
• Do not squeeze or puncture the power bank so as to avoid electrolyte leakage of lithium-ion battery.
• Do not attempt to disassemble, modify or fix this device on your own.
• Do not use a damaged cable or power charger to charge the power bank.
• Please recycle this device at an appointed disposal location for lithium-ion batteries.

Product Features

• Charge multiple phones, tablets or other mobile devices on the go, without the need for a power outlet
• Dual USB ports provide up to 5V 1A and 5V 2.4A of power respectively, for the simultaneous charging of mobile devices
• USB 5V 2.4A port features built-in auto-sensing functionality for optimal compatibility with connected devices
• Sleek, portable design is perfect for on-the-go use
• 10,400mAh capacity lets you charge at maximum power draw for hours
• 4 battery power LEDs show remaining battery capacity
  Automatic power-off turns off the LEDs when not in use
• Short circuit, overvoltage, overcurrent, overcharge and overdischarge protection for safe, reliable charging

Package Contents

UPB-10K4-S2U
- 3 ft. USB Micro-B Cable
Owner's Manual

System Requirements

• Smartphone, tablet or other mobile USB device

Optional Accessories

M100-Series USB to Lightning Cables
U030-Series USB 2.0 A to 5-Pin Mini-B Cables
U038-Series USB 2.0 A to USB Type-C Cables
- UR05C-Series Micro-B Charge-Only Cables
U326-Series USB 3.0 A to Micro-B Cables
- U420-003 USB 3.1 Gen 1 (5 Gbps) Type-C M/M Cable

USB Device Charging Instructions

Notes:

Before charging your devices for the first time, you should first fully charge the power bank
- There is a power button located on top of the power bank. When pressed once, the LEDs will illuminate to indicate how much battery capacity is left. When held down, this button turns off the LEDs and stops any device charging.
- When charging a USB device, the LEDs illuminate to indicate the battery capacity level

LED Status Battery Capacity
● ● ● ●	100-75%
● ● ● ○	50-75%
● ● ○ ○	25-50%
● ○ ○ ○	1-25%
○ ○ ○ ○	0%

1. Connect your mobile devices to the USB-A ports on the power bank using the included USB Micro-B cable or a USB cable suitable for your device.
2. The devices will begin charging, with the LEDs operating per the above notes.

Power Bank Charging Instructions

Notes:

• There is a power button located on top of the power bank. When pressed once, the LEDs will illuminate to indicate how much battery capacity is left. When held down, this button turns off the LEDs and stops any device charging.
• When charging the power bank, the LED indicator lights will illuminate to indicate the level of battery capacity

LED Status Battery Capacity
● ● ● ●	100%
● ● ● ●	75-99%
● ● ● ○	50-75%
● ● ○ ○	25-50%
● ○ ○ ○	1-25%

$$ \bullet = l i t; \circ = u n l i t; \text {f l a s h i n g} $$

1. Using the included USB Micro-B cable, connect the Micro-B port on the power bank to the USB-A port on a computer or USB charger.
2. The device will begin charging, with the LEDs operating per the above notes.

Specifications

Input 5V 2A
Output per Port USB 1: 5V 1A; USB 2: 5V 2.4A
Max Output 5V 2.4A
Ripple and Noise ≤180mVp-p
Operating Temperature Range 32° to 113°F (0° to 45°C)
Storage Temperature Range 5° to 113°F (-15° to 45°C)
Relative Humidity 0 to 90%, Non-Condensing
Color Black
Dimensions (L x W x H) 5.5 x 2.5 x 1 in. (139 x 63 x 25 mm)
Weight 0.6 lb. (288 g)
Overcurrent Protection Yes
Overvoltage Protection Yes
Overcharge Protection Yes
Overdischarge Protection	Yes
Short Circuit Protection Yes
Efficiency	≥ 79.28%

Warranty and Product Registration

1-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment, which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTYES, EXPRESS OR IMPLIED, INCLUDING WARRANTYES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser. EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

Product Registration

Visit www.triplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Trip Lite product!

• No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

FCC Notice, Class B

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.

WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste

Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended.

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.

Manufacturing Excellence.

1111 W. 35th Street, Chicago, IL 60609 USA • www.triplite.com/support

UPB-10K4-S2U
- Cable USB Micro-B de 91 cm [3 pies]

1111 W. 35th Street, Chicago, IL 60609 USA • www.triplite.com/support

Manufacturing Excellence.

1111 W. 35th Street, Chicago, IL 60609 USA • www.triplite.com/support

PykoBODCTBO N0JIb30BaTeJЯ

BheuHn aKKymyIaTOp eMKocTbIO 10 400 mA·U co cDBoeHHbIM nopToM dJa 3apAdk Mo6NlBhBIX yCTpoiCTB

Modélb:UPB-10K4-S2U

English 1 • Espanol 5 • Français 9

1111 W. 35th Street, Chicago, IL 60609 USA · www.triplite.com/support

OxpanaIeTcA ABTOPCKIM npabOM © 2017 Tripp Lite. IpepeetaKa zanpeuaetca.

06uyeka3aHnnoTexnke 6e3oNaChOCTN

• PeneH NaHApIOM NcNoB3OBAHH BHeuHnAaKkMyJrTOp DOnJIeH 6bITb NpIoHocTbIO 3apJxHeH.
• Pn3aapKe TOrO ININHOro yCTpoiCTBa OTRBHeUHero AKKyMnyTOpa IcNoIb3yIte NoXOJaIuN dIra 3TOrO Ka6eIb.
• Pn3ap4aKe BHeHrero aKKyMnyIaTopa peKoMeHdyeTcNcNoIb3ObaT Ka6eJIb c pa3beMoM USB Micro-B, noCTabIaRbMyB KOMIIeKTE C HIM.
• Pn H3KOM yopBHe 3apda 6aTapeu CBeToIOHbIe INHmKaTOpbI OTKlOuaOTc BO BpeM 3apAKn yCtpoCTBa.Bo n36exAHne cokpaueHH cPoka cnYkb6bI 6aTapeu CNeDyET KaK MoXHO cKopee NDo3apAHTb BHeUHNI AKKMyJrTop.
  Bo n36eKaHne cokpauehenc poka cnkykb6bl 6batape ee cneydt zapkaT he pexe oDnHO pa3a B TpI Meca.
  -Полионтбюзаряжehhoeустбо рекомендуетс оTKлчаьтб оБатер BOИЗбжане paCXOДOBAHЯе HeheprnM.
  B cnuyae nepexoanda BheuHero aKkymyIaTopa B 3aunTHbI peXMM (pnp KOTOPOM CBeTOIOHbIe INDnKaTOpblpeCTaIOT ropeTB, a npoueez 3apAnKn ppeKpaauaetc), BbI3BaHOrO TaKIMN npo6JeMaMn KaK KopOTKe 3ambKaHne, cIeNyET 3apAHTb erO c NMOUBO BHeuHero 3apAnHO yCTPOJCTBa N BOCCTAHOBITb HopMaJIbHbI peXMM erO pa60Tb.
  BHeuHnAkkymyIaTOp cIeMyET 6peBy oT ORHaN He OJOnyckaTb erO HarpeBaHnIO To TempePaTy p Bblwe 45^
  He donyckatb HAMOKAHNAKKMylTopa N he norpykaTbe Bvody.
• He cIeJeTy eMbTb akKymyIaTOp C nCIOJIb3OBAHmE aRpeCCBnBbIX CpeCTB OUHCTKN.
• He onnyckatb cdaBnBaHna nn npokalbIbAHn aKKyMylTopa Bo n36exKaHne yTeuKn 3NeKTPoINTa n3 HoHHo-lntHeBoi 6atapen.
• He nbTaIteCb pa36npaTb daHHoe yCTpoiCTBO, a TaKKe peMOHTnpoBaT b erO IIN BHOCTB n3MeHeHnB erO KOHCTpyKUHO camOCTOATEJbHO.
• He cneIyET noIb3OBA TbCB HeuCnpaBbIM Ka6eIeM nn 3apAHyBm ycTpoIcTBOM nIa3apAKn aKKyMnyTopa.
• yTnIM3npyTe daHnoe yCTPOBCTBO B yCTaHOBHeHOM MecTe dIy TnIM3aUN NOnHNO-JInTNBeBbIX 6aTapei.

XapakTeepnCTnKn npoodykTa

• 06ecneuBaet 3apRky HeckoIbKnx TenefoHOB, PnAHIeTOB ININ DpyrNX Mo6NJIbHbIX UCTPOiCTB DIBXKeHH 6e3 HEO6xOIMOCnT INX NODKIIHOeHnK CcTeBOMy IcTOHNYIITAHNI
  CnB0eHbIe npTb USB oecneuBAIO TnTaHme 5 B/1 A u 5 B/2,4 A cooTBetCTBeHHO Ia OndOBpeMeHHO 3apAKn MoBnBbHx yctpOiCTB
• Iopr USB 5V 2.4A IMeet BCTpoehnyo fhykuiIO abTomatueckoro OOn3HaBaHnI NOKIIouaembix yctpoiCTB dIra o6ecneHnI ONTIMAbHoCObMECTUMOCTN CHHM
  KoMaKaTHaNoTaNbHcKoHCTpyKUINdeAJIbHOIOXOHTIINCnOJIb3OBAHmBIOe3kax
• EMKoCTb 10 400 MA-ч пОЗьоЯгп рОиИЗВоДиNT bЗаряду yСТроICT b MaMaКсIMалььНоМоцHOCt b TteЧЕнe HeCKOЛьКИx YacOB
• 4 cBetoIIOIDbIX INHIMKaTopa 3Heprn6aTapeN OTo6paKaIoTe ee octatoUHyMoUHOCTb
  -ФункцаabTomatueckoro OTKJIUOeHnI\PiTaHnI OTKJIUOaET CBeToIMNoHbIe INHdNKaTOpbl Ha TO BpeM, noka yCTpoiCTBO He NcnoJIb3yeTcR
• 3aunita ot KopoTko 3ambikahn, noBbIeHHoro HaprJKeHn, nepepy3kn n0 Toky, n36bItoHoro 3apra n upe3MepHoro pa3pda o6ecneuBaet 6e3oNaChoct b n HaedKHOct npoecca 3apdKn

CopexHMOe ynaKOBKn

• YctpoiCTBO moD. UPB-10K4-S2U
• USB-Ka6eIb Ka6eIb c pa3bemamm USB Micro-B
  PykoBOOCTBOIIOb3oBaTeJIa

CnCTeMHbIe Tpe6ObaHna

• CmapTfoh,ПланшетИллдругоу устовс разбемOM USB

OngnohaNbHbIe KOMnNeKtYuOuIe

• Ka6eMn cepm M100 cpa3bemamm USB n Lightning
  Ka6eIncepmU030cpa3bemamnUSB2.0A n5-KoHTaKTHbIM Mini-B
  Ka6einn cepinn U038 cpa3bemamn USB 2.0 An USB Type-C
  Ka6eenn cepnn UR05C paa3bemamn Micro-B (ToIbko IJIa 3apJdKn)
• Ka6eHn cepm U326 cpa3bemamu USB 3.0 A n Micro-B
  Ka6eBbU420-003 cpa3bEmamu USB 3.1 Gen 1 (5 Gbps) Type-C (wTeKepe/TeKeep)

Yka3aHnno 3apAKe USB-ycTropoIcTB
