Syrene SR71_SB01011 - Broom HOOVER - Free user manual and instructions

Brand	Hoover
Model	Syrene SR71_SB01011
Product type	Corded bagless stick vacuum cleaner
Power supply	220-240 V, 50/60 Hz
Filtration system	Washable HEPA filter + mesh filter + sponge motor filter
Dustbin capacity	Bagless dustbin (cassette type)
Included brushes	Combined hard floor/carpet brush (GP) + parquet brush (depending on model)
Main functions	Selectable hard floor and carpet mode via pedal, powerful suction, cord rewind, portable mode with clip
Maintenance	Regular cleaning of the HEPA filter (washable) and mesh, emptying the dustbin after each use
Safety	Household use only, do not vacuum liquids, hot or sharp objects, unplug before maintenance
Recommended spare parts	Pre-motor filter (ref. 35601773), pro carpet/hard floor brush (G233PE), parquet brush (G87PC), turbo brush (J48)
Compliance	European directives 2014/35/EU, 2014/30/EU, 2011/65/EU
Manufacturer	CANDY HOOVER GROUP s.r.l., Via Privata Eden Fumagalli, 20861 Brugherio (MB) Italy
Cord length	Approximately 6 m (estimate)
Weight	Approximately 4.5 kg (estimate)

Frequently Asked Questions - Syrene SR71_SB01011 HOOVER

How to empty the dustbin?

Turn off and unplug the vacuum. Open the dustbin hatch by pressing the release button, remove the bagless cassette, then turn the dustbin lid to separate it and empty the contents into a trash can. Do not wash the dustbin with water.

How to clean the <b>HEPA filter</b>?

Remove the mesh by turning it in the opposite direction, then gently tap the HEPA filter to remove dust. Wash it under lukewarm (not hot) water from the inside until the water runs clear, shake off excess water and let it dry for 24 hours before reinstalling.

Can this vacuum be used to pick up water?

No, this vacuum is designed only for dry cleaning. Never vacuum liquids, as this could damage the appliance and pose an electrical hazard.

How to change the brush mode for <b>hard floor</b> or <b>carpet</b>?

Press the pedal on the combined brush. For hard floor, the brushes lower to protect the floor; for carpet, they lift for deep cleaning.

What to do if the vacuum does not turn on?

Check that the appliance is plugged into a working outlet. Inspect the power cord for any damage. If the problem persists, contact an authorized Hoover repairer.

How to maintain the <b>power cord</b>?

Do not step on the cord or bend it excessively. To store it, use the provided hooks: wrap it around the upper and lower hooks, then secure with the integrated clip. Never pull the cord to unplug.

What <b>accessories</b> are available?

In addition to the combined brush, specialized brushes such as the parquet brush, professional carpet and hard floor brush, and turbo brush are available as options. Only use original Hoover accessories.

How to know if the <b>filter</b> needs cleaning?

If suction power decreases or the dustbin fills quickly, the filter is likely clogged. Inspect and clean the HEPA filter and mesh as instructed. Hoover recommends checking the filters after each dustbin emptying.

Can I use the vacuum on <b>stairs</b>?

Yes, but always place the vacuum below you to avoid dropping it. Never place it on a step higher than you.

Where are the <b>serial numbers</b> to order parts?

The model number is on the appliance's rating plate. To order spare parts, contact your Hoover dealer or Hoover spare parts service, quoting the model number.

USER MANUAL Syrene SR71_SB01011 HOOVER

HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER HOOVER

Illustration showing a sequence of steps to draw or store objects, including hand positioning, cleaning, and packaging.

Diagram illustrating four different mechanical or electrical states with labeled components and a 24-hour time indicator.

“CATTUE” 100% (27)% “CATTUE: DUS-40, WAT-30, WAT-25, WAT-20, WAT-15, WAT-10”

INSTRUCTIONS FOR SAFE USE

This appliance should only be used for domestic cleaning, as described in this user guide. Please ensure that this guide is fully understood before operating the appliance.

Do not leave the appliance plugged in. Always switch off and remove the plug from the socket after use, or before cleaning the appliance or any maintenance task.

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

If the power cord is damaged stop using the appliance immediately. To avoid a safety hazard, an authorised HOOVER service engineer must replace the power cord.

Keep hands, feet, loose clothing and hair away from rotating brushes.

Use only attachments, consumables or spares recommended or supplied by HOOVER.

Static electricity: Some carpets can cause a small build up of static electricity. Any static discharge is not hazardous to health.

Do not use your appliance out of doors or on any wet surface or for wet pick up.

Do not pick up hard or sharp objects, matches, hot ashes, cigarette ends or other similar items.

Do not spray with or pick up flammable liquids, cleaning fluids, aerosols or their vapours.

Do not run over the power cord when using your appliance or remove the plug by pulling on the power cord.

Do not continue to use your appliance if it appears faulty.

HOOVER service: To ensure the continued safe and efficient operation of this appliance we recommend that any servicing or repairs are only carried out by an authorised HOOVER service engineer.

Do not stand on or wrap the cord around arms or legs when using your appliance.

Do not use the appliance to clean animals or people.

Do not position the appliance above you when cleaning the stairs.

The Environment

The symbol on this appliance indicates that this appliance may not be treated as household waste. Instead it must be handed over to the applicable collection point for the recycling of electrical and electronic equipment. Disposal must be carried out in accordance with local environmental regulations for waste disposal. For more detailed information about treatment, recovery and recycling of this appliance, please contact your local city office, your household and waste disposal service or the shop where you purchased the appliance.

This appliance complies with the European Directives 2014/35/EU, 2014/30/EU and 2011/65/EU.

CANDY HOOVER GROUP s.r.l. Via Privata Eden Fumagalli, 20861 Brugherio (MB) Italy

GETTING TO KNOW YOUR CLEANER

A. Handle
B. Permanent Exhaust Filter
C. ON/OFF Button
D. Bin Door
E. Bin Door Realease Button
F. Carpet and Hard Floor Nozzle** (GP)
G. Screw
H. Carry Handle
I. Rotating Upper Cord Hook
J. Power Cord
K. Lower Cord Hook
L. Bin Cover
M. Filter Mesh
N. HEPA Filter
O. Dust Bin
P. Parquet Nozzle*

GETTING TO KNOW YOUR CLEANER

Remove all components from the packaging.

• Assemble the cleaner handle and fix in position with the supplied screw. [1,2]
• Open the bin door and check if the dust bin is correctly fitted.
• Ensure the pre-motor sponge filter is correctly fitted. [11]
  • Fit the Carpet and Floor Nozzle. [3]

USING YOUR CLEANER

POWER CORD STORAGE

1. Before use undo integrated clip, turn top hook and release power cord. [5]
2. During use as a stick cleaner clip power cord into back of main handle. [6]
   After use, unclip power cord from handle and wind it around storage hooks before securing with integrated clip.

CONTROLS

1. On/Off switch. Push to switch On. Push again to switch Off. [7]

CLEANER MAINTENANCE

IMPORTANT: Switch cleaner Off and remove plug from electricity supply before removing the bin.

a) Lay the cleaner on a flat surface, pull back the door release button and remove the transparent door. [8.1]
b) Remove the bagless cassette.[8.2]
c) Remove the bin cover by rotating the container and bin cover in opposite directions. [9.1]
d) Empty the debris from the container into a bin. [9.2] Check if it is necessary to clean the relative filters, as described in the "Maintaining the bagless filters" section.
e) To refit the bagless cassette and the filters to the product, simply repeat all steps in reverse. [9.3]

NOTE: Hoover recommends to inspect and wash if necessary, the cassette and the filters after each full container, see maintaining filters section.

MAINTAINING THE BAGLESS FILTERS

a) To access the washable HEPA filter, rotate the mesh filter in the opposite direction from the cassette upper closure and remove the mesh. [10.1]
b) Gently tap filters to release excess dust.
c) Wipe clean the mesh filter and wash thoroughly the HEPA filter from the inside under hand warm water until the water runs clean. [10.2]
d) Remove excess water by shaking and leave to dry for 24 hours. Refit filters to the cleaner only when completely dry. [10.3]

DO NOT USE HOT WATER OR DETERGENTS.

IMPORTANT: Ensure the bagless filters, mesh and HEPA, are fitted before use.

SPECIALITIES

NOZZLES

1. Carpet & Floor nozzle
   Press the Floor type selector pedal on the nozzle [4] to select the ideal cleaning mode for the floor type.
   Hard Floor – Brushes are lowered to protect the floor.
   Carpet – Brushes are raised for the deepest clean.
2. Parquet nozzle* for wooden and delicate floors.

ACCESSORIES

To obtain the best performance and energy efficiency #1 it is recommended that the correct nozzles are used for the main cleaning operations. These nozzles are indicated in the diagrams by the letters GP, HF or CA.

A nozzle type GP can be used to clean both carpet and hard floor.

A nozzle type HF is suitable for use only on hard floor.

A nozzle of type CA is suitable for use only on carpet.

*Certain Models Only **Nozzle design may vary according to models

GB

The other nozzles are accessories for specialist cleaning tasks and are recommended for occasional use only.

It is important to note that this vacuum cleaner is supplied with an Energy Label as required by European Regulation (EU) 665/2013.

If the label shows a red prohibition circle on the left covering the carpet symbol, then this indicates that the vacuum cleaner is not suitable use on carpets.

If the label shows a red prohibition circle on the right covering the hard floor symbol, then this indicates that the vacuum cleaner is not suitable for use on hard floors.

1 NOTE: Dust pick up ability carpet, dust pick up ability hard floor, and energy efficiency in accord with Commission Regulations (EU) 665/2013 and (EU) 666/2013.

USER CHECKLIST

Should you have a problem with your product, complete the simple user checklist before calling the Hoover customer service.

• Is there a working electricity supply to the product? Check with another electrical product.
  • Is the dust bin full? Inspect and empty.
• Is the product inlet blocked? Check by removing the dust bin and checking the dust bin inlet.
• Is the filter blocked? Check by removing and clean.

IMPORTANT INFORMATION

HOOVER spares and Consumables

Always replace parts with genuine HOOVER spares. These are available from your local HOOVER dealer or direct from Hoover. When ordering parts always quote your model number.

Consumables

Pre-Motor Filter S20 35601773

Carpet & Floor Pro Nozzle

G233PE 35601672

Parquet Extra Nozzle

G87PC 35600655

Grand Turbo Nozzle

J48 35601151

Quality

HOOVER's factories have been independently assessed for quality. Our products are made using a quality system which meets the requirements of ISO 9001.

Your Guarantee

The guarantee conditions for this appliance are as defined by our representative in the country in which it is sold. Details regarding these conditions can be obtained from the dealer from whom the appliance was purchased. The bill of sale or receipt must be produced when making any claim under the terms of this guarantee.

Subject to change without notice.

"Certain Models Only

** Certain models only, nozzles may vary according to model
