USER MANUAL NSI6DG9900SR SAMSUNG

Electric Range User manual NSI6D*99******2 English WARNING To reduce the risk of tipping the range, the range must be secured by a properly installed Anti-Tip device. AFTER THE RANGE HAS BEEN INSTALLED, CONFIRM THAT THE ANTI-TIP DEVICE HAS BEEN PROPERLY INSTALLED AND VERIFY THAT THE ANTI-TIP DEVICE IS PROPERLY ENGAGED. Refer to the installation manual for instructions. a) If the Anti-Tip device is not installed, a child or adult can tip the range and be killed. b) Verify that the Anti-Tip device has been properly installed and engaged at the rear right (or rear left) of the range bottom. c) If you move the range and then move it back into place, ensure the Anti-Tip device is re-engaged at the right or left rear of the range bottom. d) Do not operate the range without the Anti-Tip device in place and engaged. e) Failure to do so can result in death or serious burns to children or adults. WARNING Do not step, lean, or sit on the doors of the range. You can cause the range to tip, resulting in burns or serious injuries. Conrm that the Anti-Tip device is installed properly. Then, to verify that the Anti-Tip device is engaged, grasp the top rear edge of the range and carefully attempt to tilt it forward. The Anti-Tip device should prevent the range from tilting forward more than a few inches. If you pull the range out from the wall for any reason, make sure the Anti-Tip device is properly engaged when you push the range back against the wall. If it is not, there is a risk of the range tipping over and causing injury if you or a child stand, sit, or lean on the open door. Never completely remove the leveling legs. If you remove the leveling legs, the range will not be secured to the Anti-Tip device properly. Anti-tip deviceEnglish 3 Regulatory Notice

CAUTION FCC CAUTION: Any changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of FCC Rules. Operation is Subject to following two conditions:

1) This device may not cause harmful interference, and

2) This device must accept any interference received

including interference that cause undesired operation. For products sold in the US and Canadian markets, only channels 1–11 are available. You cannot select any other channels. Radio Apparatus Notice CAUTION Any changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The remote enable equipment installed on this product complies with Part 15 of FCC Rules and Innovation, Science and Economic Development Canada’s license-exempt RSS(s). Operation is Subject to following two conditions:

1) This equipment may not cause harmful

2) This equipment must accept any interference

received including interference that cause undesired operation. For products available in the US/Canadian markets, only channels 1

11 are available. You cannot select any other channels.4 English Regulatory Notice Radio Apparatus STATEMENT: This equipment has been tested and found to comply within the limits for a Class B digital device, pursuant to

part 15 of the FCC Rules and Canadian ICES-003. These

limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorienting or relocating the receiving antenna

• Increasing the separation between the equipment and receiver

• Connecting the equipment to an outlet that is on a different circuit than the radio or TV

• Consulting the dealer or an experienced radio/TV technician for help. FCC STATEMENT: This equipment has been tested and found to comply within the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorienting or relocating the receiving antenna

• Increasing the separation between the equipment and receiver

• Connecting the equipment to an outlet that is on a different circuit than the radio or TV.

• Consulting the dealer or an experienced radio/TV technician for help.English 5 FCC RADIATION EXPOSURE STATEMENT: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated so there is at least 8 inches (20 cm) between the radiator and your body. This device and its antenna(s) must not be co- located or operated in conjunction with any other antenna or transmitter.

The term “IC” before the radio certication number only signies that Industry Canada technical specications were met. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. This Class B digital apparatus complies with Canadian ICES-003. For products sold in the US and Canadian markets, only channels 1–11 are available. You cannot select any other channels. IC RADIATION EXPOSURE STATEMENT: This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated so there is at least 8 inches (20 cm) between the radiator and your body. This device and its antenna(s) must not be co-located or operated in conjunction with any other antenna or transmitter. RADIATION EXPOSURE STATEMENT: This equipment complies with FCC and IC RSS- 102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated so there is at least 8 inches (20 cm) between the radiator and your body. This device and its antenna(s) must not be co-located or operated in conjunction with any other antenna or transmitter.6 English Contents Operating the oven 32 The control panel 32 Display 33 Display mode 33 Timer 34 Auto Open door 34 Oven cooking 35 Setting the mode 35 Setting the temperature 36 Setting the Cooking options (Cook Time, Delay Start) 36 Basic baking and broiling instructions 37 Using the oven racks 38 Temperature probe 40 Cooking mode 41 Camera In Oven (applicable models only) 49 Smart control 50 Voice control 51 Settings 52 Special features 53 Maintaining your appliance 55 Self-cleaning 55 Steam-cleaning 57 Care and cleaning of the oven 58 Care and cleaning of the glass cooktop 60 Removing and reinstalling the oven door 61 Removing and reinstalling the storage drawer 63 Changing the oven light 63 Troubleshooting 64 Troubleshooting 64 Information codes 68 Warranty (U.S.A) 70 Warranty (CANADA) 72

Open Source Announcement 73 Contents Important safety instructions 7 What you need to know about safety instructions 7 California Proposition 65 Warning 7 For your safety 8 Induction cooktop elements 10 Electrical safety 11 Child safety 12 Oven 12 Remote Operation 13 Self-cleaning ovens 14 Ventilating hood 14 Glass/Ceramic cooking surfaces 15 Critical installation warnings 15 Critical usage warning 16 Usage cautions 19 Critical cleaning warnings 21 Battery usage 22 Introducing your new range 23 Overview 23 What’s included with your range 23 Before you begin 24 Energy saving tips 24 Surface cooking 24 About induction cooktop cooking 24 How to set the appliance for cooktop cooking 26 Before using the cooktop 28 Cookware for induction cooking zones 29 Using the correct size cookware 29 Pot and pan sizes 29 Operating noises 30 Using suitable induction cookware 30 Temperature detection 31 Suggested settings for cooking specic foods 31 Protecting the cooktop 32English 7 Important safety instructions

SAVE THESE INSTRUCTIONS

CAUTION To reduce the risk of re, explosion, electric shock, or personal injury when using your range, follow these basic safety precautions. Do NOT attempt. Do NOT disassemble. Do NOT touch. Follow directions explicitly. Unplug the power plug from the wall socket. Make sure the machine is grounded to prevent electric shock. Call a Samsung service center for help. Note These warning signs are here to prevent injury to you and others. Please follow them explicitly. After reading this section, keep it in a safe place for future reference.

CALIFORNIA PROPOSITION 65 WARNING

WARNING Cancer and Reproductive Harm - www.P65Warnings.ca.gov Important safety instructions Read and follow all instructions before using your range to prevent the risk of re, electric shock, personal injury, or damage when using the range. This guide does not cover all possible conditions that may occur. Always contact your service agent or the manufacturer about problems that you do not understand.

WHAT YOU NEED TO KNOW ABOUT

SAFETY INSTRUCTIONS Warnings and Important safety instructions in this manual do not cover all possible conditions and situations that may occur. It is your responsibility to use common sense, caution, and care when installing, maintaining, and operating your oven. Important safety symbols and precautions What the icons and signs in this user manual mean: WARNING Hazards or unsafe practices that may result in severe personal injury or death. CAUTION Hazards or unsafe practices that may result in minor personal injury or property damage.8 English Important safety instructions Important safety instructions

SAVE THESE INSTRUCTIONS

When using electrical appliances, you should follow basic safety precautions, including the following: CAUTION

• Use this appliance only for its intended purpose as described in this Owner’s Manual.

• Potentially hot surfaces include the cooktop, areas facing the cooktop, the oven vent opening, surfaces near the opening, and crevices around the oven door. Be sure your appliance is properly installed and grounded by a qualied technician. User servicing - Do not repair or replace any part of the appliance unless specically recommended in this manual. All other servicing should be referred to a qualied technician. Always disconnect the power to the appliance before servicing by removing the fuse or switching off the circuit breaker.

• Do not enter the oven.

• Do not store items of interest to children in cabinets above the range or on the back guard of the range. Children climbing on the range to reach items could be seriously injured.

• Do not leave children alone. Never leave children alone or unattended in an area where this appliance is in use. They should never be allowed to sit or stand on any part of the appliance.

• Never use your appliance for warming or heating the room.

• Do not use water on grease res. Turn off the oven to avoid spreading the ames. Smother the re or ames by closing the door or use a dry chemical, baking soda, or foam-type extinguisher.

• Avoid scratching or striking the glass doors, the cooktop, or the control panel. Doing so may lead to glass breakage. Do not cook on a product with broken glass. Shock, re, or cuts may occur. Important safety instructionsEnglish 9 Important safety instructions

SAVE THESE INSTRUCTIONS

• Use only dry potholders. Placing moist or damp potholders on hot surfaces may result in burns from steam. Do not let the potholder touch hot heating elements. Do not use a towel or other bulky cloth.

• Teach children not to play with the controls or any other part of the range.

• For your safety, do not use high-pressure water cleaners or steam jet cleaners to clean any part of the range.

• If the power cord is damaged, it must be replaced by the manufacturer, its service agent, or similarly qualied persons to avoid creating a hazard.

• The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Do not lean on the range as you may turn the control knobs inattentively.

• If there is a re in the oven during self-cleaning, turn the oven off and wait for the re to go out. Do not force the door open. The introduction of fresh air at self-cleaning temperatures may lead to a burst of ame from the oven. Failure to follow these instructions may result in severe burns.

• If the oven is heavily soiled with oil, self-clean the oven before using the oven again. Leaving the oil in place creates a risk of re.

• Wipe up heavy soil on the oven bottom with a paper towel or rag before self-cleaning. Self-cleaning the oven when there is heavy soil on the oven bottom requires longer cleaning cycles and produces more smoke.

• Storage in or on the appliance. Do not store ammable materials in the oven or near the surface units. Be sure all packing materials are removed from the appliance before operating it. Keep plastics, clothes, and paper away from parts of the appliance that may become hot.

• Wear proper apparel. Never wear loose-tting or hanging garments while using the appliance.10 English Important safety instructions Important safety instructions

SAVE THESE INSTRUCTIONS

• Never leave surface elements unattended at high heat settings - Boilovers cause smoking and greasy spillovers that may ignite. A pan that has boiled dry may melt.

• Metallic objects such as knives, forks, spoons, and lids should not be placed on the Induction Cooktop surface since they can get hot.

• When preparing aming foods under a ventilating hood, turn the fan on.

• Use care when touching the cooktop. The glass surface of the cooktop will retain heat after the controls have been turned off.

• Always turn the surface units off before removing cookware.

• Keep an eye on foods being fried at high or medium high heat settings.

• Be careful when placing spoons or other stirring utensils on the glass cooktop surface when it is in use. They may become hot and could cause burns.

• Do not lift the cooktop. Lifting the cooktop can lead to damage and improper operation of the range.

• Never use the glass cooktop surface as a cutting board.

• Do not operate the cooktop without cookware.

• Appliance is not intended to be operated by means of an external timer or separate remote-control system.

INDUCTION COOKTOP ELEMENTS

• Be sure you know which touch control operates each surface heating unit. Place a pan of food on the unit before turning it on, and turn the unit off before removing the pan.

• Use proper pan sizes - This appliance is equipped with surface units of different sizes. Select pots and pans that have at bottoms large enough to cover the surface area of the heating element. Using undersized cookware will expose a portion of the heating element to direct contact and may result in the ignition of clothing. Matching the size of the pot or pan to the burner will also improve efciency.

• Cookware handles should be turned inward and not extend over adjacent surface elements - To reduce the risk of burns, ignition of ammable materials, and spillage due to unintentional contact with the cookware, cookware handles should be positioned so that they are turned inward, and do not extend over adjacent surface units.

• Glazed cookware - Only certain types of glass, glass/ceramic, ceramic, earthenware, or other glazed cookware are suitable for range-top service without breaking due to the sudden change in temperature. Important safety instructionsEnglish 11 Important safety instructions

SAVE THESE INSTRUCTIONS

WARNING If the surface is cracked, switch off and unplug the appliance to avoid the possibility of electrical shock. Do not use your cooktop until the glass surface has been replaced. WARNING

• Ensure that the appliance is switched off before replacing the lamp to avoid the possibility of electric shock.

• The range should not be placed on a base. ELECTRICAL SAFETY

• Proper Installation - Be sure your appliance is properly installed and grounded by a qualied technician.

• The appliance should be serviced only by qualied service personnel. Repairs carried out by unqualied individuals may cause injury or a serious malfunction. If your appliance is in need of repair, contact a Samsung authorized service center. Failure to follow these instructions may result in damage and void the warranty.

• Flush-mounted appliances may be operated only after they have been installed in cabinets and workplaces that conform to the relevant standards. This ensures that the appliances are installed in compliance with the appropriate safety standards.

• If your appliance malfunctions or if fractures, cracks, or splits appear: - switch off all cooking zones. - unplug the range from the AC wall outlet. - contact your local Samsung service center.12 English Important safety instructions Important safety instructions

SAVE THESE INSTRUCTIONS

• DO NOT TOUCH THE HEATING ELEMENTS OR INTERIOR SURFACES OF THE OVEN. Heating elements may be hot even though they are dark in color. Interior surfaces of an oven become hot enough to cause burns. During and after use, do not touch, let clothing, or other ammable materials contact the heating elements or interior surfaces of the oven until they have had sufcient time to cool. Other surfaces of the appliance may become hot enough to cause burns. Among these surfaces are oven vent openings and surfaces near these openings, the oven door, and the window of the oven door.

• Do not heat unopened food containers. The build-up of pressure may cause the container to burst and result in injury.

• Do not use the oven to dry newspapers. If overheated, newspapers can catch on re.

• Do not use the oven for a storage area. Items stored in an oven can ignite. CHILD SAFETY WARNING

• This appliance is not intended for use by young children or inrm persons without the adequate supervision of a responsible adult.

• Young children should be supervised to ensure that they do not play with the appliance.

• Keep children away from the door when opening or closing it as they may bump themselves on the door or catch their ngers in the door.

• The cooking zones will become hot when you cook. To keep small children from being burned, always keep them away from the appliance while you are cooking.

• During self-cleaning, the surfaces may get hotter than usual. Keep small children away from the range when it is in the self-cleaning mode. WARNING Accessible parts may become hot during use. To avoid burns, young children should be kept away. Important safety instructionsEnglish 13 Important safety instructions

SAVE THESE INSTRUCTIONS

CAUTION Do not attempt to operate the oven during a power failure. If the power fails, always turn the oven off. If the oven is not turned off and the power returns, the oven may begin to operate again. Food left unattended could catch re or spoil. REMOTE OPERATION This appliance is congurable to allow remote operation at any time.

• Do not store any ammable materials or temperature sensitive items inside, on top or near surface units of the appliance.

• Use care when opening the door. Let hot air or steam escape before you remove food from or put food into the oven.

• Protective liners. Do not use aluminum foil to line the oven bottoms, except as suggested in the manual. Improper installation of these liners may result in a risk of electric shock or re.

• Keep oven vent ducts unobstructed. The oven vent is located above the right rear surface unit. This area could become hot during oven use. Never block this vent or place plastic or heat-sensitive items on it.

• Placement of oven racks. Always place oven racks in the desired location while the oven is cool. If the rack must be moved while the oven is hot, use potholders. Do not let the potholders come in contact with the hot heating element in the oven.

• Do not allow aluminum foil or a meat probe to contact the heating elements.

• During use, the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven.

• Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass. They can scratch the surface, which may result in the glass shattering.14 English Important safety instructions Important safety instructions

SAVE THESE INSTRUCTIONS

• Before operating the self-clean cycle, wipe grease and food soils from the oven. Excessive amounts of grease may ignite, leading to smoke damage to your home.

• Do not use any commercial oven cleaner or oven liner protective coating of any kind in or on the outside of the oven.

• Remove the nickel oven shelves from the oven before you begin the self-cleaning cycle or they may discolor.

• If the self-cleaning mode malfunctions, turn the oven off and disconnect the power supply. Have it serviced by a qualied technician.

• Excess spillage must be removed before you run the self- cleaning cycle.

• Opening a window or turning on a ventilation fan or hood is recommended during and after self-cleaning. VENTILATING HOOD

• Clean ventilating hoods frequently. Do not let grease accumulate on the hood or lter.

• When aming foods under the hood, turn the fan on. SELFCLEANING OVENS Do not clean the door gasket. The door gasket is essential for a good seal. Care should be taken not to rub, damage, or move the gasket.

• Never keep pet birds in the kitchen. Birds are extremely sensitive to the fumes released during an oven self-clean cycle. Fumes may be harmful or fatal to birds. Move birds to a well-ventilated room.

• Clean only the parts listed in this manual in the self-clean cycle. Before self-cleaning the oven, remove the partition, rack, utensils, and any food. Important safety instructionsEnglish 15 Important safety instructions

SAVE THESE INSTRUCTIONS

• This appliance must be installed by a qualied technician or service company. - Failing to have a qualied technician install the range may result in electric shock, re, an explosion, problems with the product, or injury.

• Unpack the oven, remove all packaging material and examine the oven for any damage, such as dents on the interior or exterior of the oven, broken door latches, cracks in the door, or a door that is not lined up correctly. If there is any damage, do not operate the oven and notify your dealer immediately.

• Plug the power cord into a properly grounded outlet with the proper conguration. Your oven should be the only item connected to this circuit.

• Keep all packaging materials out of the reach of children. Children may use them for play and injure themselves.

• Install your appliance on a hard, level oor that can support its weight. - Failing to do so may result in abnormal vibrations, noise, or problems with the product.

GLASS/CERAMIC COOKING SURFACES

• DO NOT TOUCH SURFACE UNITS OR AREAS NEAR UNITS. Surface units may be hot even though they are dark in color. Areas near surface units may become hot enough to cause burns. During and after use, do not touch, or let clothing or other ammable materials contact the surface units or areas near the units until they have had sufcient time to cool. Among these areas are the cooktop and the facing of the cooktop.

• Do not cook on a broken cooktop. If the cooktop should break, cleaning solutions and spillovers may penetrate the broken cooktop and create a risk of electric shock. Contact a qualied technician immediately. Clean the cooktop with caution. If a wet sponge or cloth is used to wipe spills on a hot cooking area, be careful to avoid steam burns. Some cleaners can produce noxious fumes if applied to a hot surface.16 English Important safety instructions Important safety instructions

SAVE THESE INSTRUCTIONS

• If the appliance is ooded by any liquid, please contact your nearest Samsung service center. Failing to do so may result in electric shock or re.

• If the appliance produces a strange noise, a burning smell, or smoke, unplug the power plug immediately and contact your nearest Samsung service center. - Failing to do so may result in electric shock or re.

• In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate the area immediately. Do not touch the power cord. Do not touch the appliance. - A spark may result in an explosion or re.

• This appliance must be properly grounded.

• Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line. - This may result in electric shock, re, an explosion, or problems with the product.

• Do not cut or remove the ground prong from the power cord under any circumstances.

• Connect the oven to a circuit that provides the correct amperage.

• Do not install this appliance in a humid, oily or dusty location, or in a location exposed to direct sunlight or water (rain drops). - This may result in electric shock or re.

• Do not use a damaged power cord or loose wall socket. - This may result in electric shock or re.

• Do not pull or excessively bend the power cord.

• Do not twist or tie the power cord.

• Do not hook the power cord over a metal object, place a heavy object on the power cord, or insert the power cord between objects. - This may result in electric shock or re. If the power cord is damaged, contact your nearest Samsung service center. Important safety instructionsEnglish 17 Important safety instructions

SAVE THESE INSTRUCTIONS

• Do not attempt to repair, disassemble, or modify the appliance yourself. - Since a high voltage current enters the product chassis, it may result in electric shock or re. - When a repair is needed, contact your nearest Samsung service center.

• If any foreign substance, such as water has entered the appliance, contact your nearest Samsung service center. - Failing to do so may result in electric shock or re.

• Do not touch the power cord with wet hands. - This may result in electric shock.

• Do not turn the appliance off while an operation is in progress. - This may cause a spark and result in electric shock or re.

• Keep all packaging materials well out of the reach of children, as packaging materials can be dangerous to children. - If a child places a plastic bag over its head, the child can suffocate.

• Take care not to contact the oven door, heating elements, or any of the other hot parts with your body while cooking or just after cooking. - Failing to do so may result in burns.

• If materials inside the oven should ignite, keep the oven door closed, turn the oven off and disconnect the power cord, or shut off power at the fuse or circuit breaker panel. If the door is opened, the re may spread.

• Always observe safety precautions when using your oven. Never try to repair the oven on your own - there is dangerous voltage inside. If the oven needs to be repaired, contact an authorized Samsung service center near you.

• If you use the appliance when it is contaminated by foreign substance, such as food waste, it may result in a problem with the appliance.

• Take care when removing the wrapping from food taken out of the appliance. - If the food is hot, hot steam may be emitted abruptly when you remove the wrapping and this may result in burns.18 English Important safety instructions Important safety instructions

SAVE THESE INSTRUCTIONS

• Do not store or use the oven outdoors.

• Never use this appliance for purposes other than cooking. - Using the appliance for any purpose other than cooking may result in re.

• Open the cap or stopper of sealed containers (herb tonic tea bottle, baby bottle, milk bottle, and so on) before heating them. Make a hole in food items that have shells (eggs, chestnuts, etc) with a knife before cooking them. - Failing to do so may result in burns or injury.

• Never heat plastic or paper containers and do not use them for cooking. - Failing to do so may result in re.

• Do not heat food wrapped in paper from magazines, newspapers, etc. - This may result in re.

• Do not open the door when the food in the oven is burning. - If you open the door, it causes an inow of oxygen and may cause the food to ignite.

• Do not let children or any person with reduced physical, sensory, or mental capabilities use this appliance unsupervised.

• Make sure that the appliance’s controls and cooking areas are out of the reach of children. - Failing to do so may result in electric shock, burns, or injury.

• Do not touch the inside of the appliance immediately after cooking. The inside of the appliance will be hot. - Failing to do so may result in burns.

• Do not use or place ammable sprays or objects near the oven. - Flammable items or sprays can cause res or an explosion.

• Do not insert ngers, foreign substances, or metal objects, such as pins or needles into inlets, outlets, or holes. If foreign substances are inserted into any of these holes, contact your product provider or nearest Samsung service center.

• Do not tamper with or make any adjustments or repairs to the door. Under no circumstances should you remove the door or outer shell of the oven. Important safety instructionsEnglish 19 Important safety instructions

SAVE THESE INSTRUCTIONS

USAGE CAUTIONS CAUTION

• If the surface is cracked, turn the appliance off. - Failing to do so may result in electric shock.

• Dishes and containers can become hot. Handle with care.

• Hot foods and steam can cause burns. Carefully remove container coverings, directing the steam away from your hands and face.

• Remove lids from baby food jars before heating. After heating baby food, stir well to distribute the heat evenly. Always test the temperature by tasting before feeding the baby. The glass jar or the surface of the food may appear to be cooler than the interior, which can be hot enough to burn an infant’s mouth.

• Take care as beverages or food may be very hot after heating. - Especially when feeding a child. Check that it has cooled sufciently.

• Do not apply excessive pressure to the door or the inside of the appliance. Do not strike the door or the inside or the appliance. - Hanging on to the door may result in the product falling and cause serious injury. - If the door is damaged, do not use the appliance. Contact a Samsung service center.

• Do not hold food in your bare hands during or immediately after cooking. - Use cooking gloves. The food may be very hot and you could burn yourself. - As the handle and oven surfaces may be hot enough to cause burns after cooking, use cooking gloves to protect your hands from burns.20 English Important safety instructions Important safety instructions

SAVE THESE INSTRUCTIONS

• Do not put your face or body close to the appliance while cooking or when opening the door just after cooking. - Take care that children do not come too close to the appliance. - Failing to do so may result in children burning themselves.

• Do not place food or heavy objects over the edge of the oven door. - If you open the door, the food or object may fall and this may result in burns or injury.

• Do not abruptly cool the door, the inside of the appliance, or a dish by pouring water over it during or just after cooking. - This may result in damage to the appliance. The steam or water spray may result in burns or injury.

• Do not operate while empty except for self-cleaning.

• Do not defrost frozen beverages in narrow-necked bottles. The bottles can break.

• Do not scratch the glass of the oven door with a sharp object. - This may result in the glass being damaged or broken.

• Do not store anything directly on top of the appliance when it is in operation.

• Take care when heating liquids, such as water or other beverages. - Make sure to stir during or after cooking. - Avoid using a slippery container with a narrow neck. - Wait at least 30 seconds after heating before removing the heated liquid. - Failing to do so may result in an abrupt overow of the contents and cause burns.

• Do not stand on top of the appliance or place objects (such as laundry, an oven cover, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. - Items, such as a cloth, may get caught in the door. - This may result in electric shock, re, problems with the product, or injury.

• Do not operate the appliance with wet hands. - This may result in electric shock.

• Do not spray volatile substances, such as insecticide onto the surface of the appliance. - As well as being harmful to humans, it may also result in electric shock, re, or problems with the product. Important safety instructionsEnglish 21 Important safety instructions

SAVE THESE INSTRUCTIONS

• Do not use sealed containers. Remove seals and lids before cooking. Sealed containers can explode due to the build up of pressure even after the oven has been turned off.

• Take care that food you are cooking in the oven does not come into contact with the heating element. - This may result in re.

• Do not overheat food. - Overheating food may result in re.

CRITICAL CLEANING WARNINGS

• Do not clean the appliance by spraying water directly on to it.

• Do not use benzene, thinner, or alcohol to clean the appliance. - This may result in discoloration, deformation, damage, electric shock, or re.

• Take care not to hurt yourself when cleaning the appliance (externally or internally). - You may hurt yourself on the sharp edges of the appliance.

• Do not clean the appliance with a steam cleaner. - This may result in corrosion.

• Keep the inside of the oven clean. Food particles or spattered oils stuck to the oven walls or oor can cause paint damage and reduce the efciency of the oven.22 English Important safety instructions Important safety instructions

SAVE THESE INSTRUCTIONS

• Remove and immediately recycle or dispose of used batteries according to local regulations and keep away from children. Do NOT dispose of batteries in household trash or incinerate.

• Even used batteries may cause severe injury or death.

• Call a local poison control center for treatment information.

• Compatible battery is ML414H.

• Nominal battery voltage is 3 V.

• Non-rechargeable batteries are not to be recharged.

• Do NOT force discharge, recharge, disassemble, heat above (−20 ºC to +60 ºC) or incinerate. Doing so may result in injury due to venting, leakage or explosion resulting in chemical burns.

• This product contains non-replaceable batteries. WARNING

INGESTION HAZARD: This product contains a button cell or coin battery.

DEATH or serious injury can occur if ingested.

• A swallowed button cell or coin battery can cause Internal Chemical Burns in as little as 2 hours

KEEP new and used batteries OUT OF REACH of CHILDREN

Seek immediate medical attention if a battery is suspected to be swallowed or inserted inside any part of the body. Important safety instructionsEnglish 23 Introducing your new range What’s included with your range Wire racks (2) * Air Fry tray (1) * Temperature probe (1) * NOTE If you need an extra accessory marked with a *, you can buy it from the Samsung Contact Center (1-800-726-7864). Introducing your new range Overview

• Do not use the Induction cooktop surface as a cutting board.

• Do not place or store items that can melt or catch re on the Induction cooktop, even when it is not being used.

• Turn the induction cooktop on only after placing the cookware on it.

• Do not store heavy items above the cooktop surface. They could fall and get damaged it. CAUTION DURING COOKING

• Metallic objects such as knives, forks, spoons, and lids should not be placed on the induction cooktop surface since they can get hot.

• After use, switch off the induction element using its control. Do not rely on the pan detector.

• Use this appliance for normal cooking and frying in the home only. It is not designed for commercial or industrial use.

• Never use the induction cooktop range to heat the room.

• Take care when plugging electrical appliances into a power outlet near the cooktop. Power cords must not come into contact with the cooktop.

• Overheated fat and oil can catch re quickly. Never leave surface units unattended when preparing foods in fat or oil, for example, when cooking french fries.

• Turn the cooking zones off after use.

• Never place combustible items on the induction cooktop. It may cause a re.

• Do not use the induction cooktop to heat aluminium foil, products wrapped in aluminium foil, or frozen foods packaged in aluminium cookware.

• There is the risk of burns from the appliance if used carelessly.

• Do not let cables from electrical appliances touch hot cookware or the hot surface of the induction range cooktop. Before you begin Clean the oven thoroughly before using it for the rst time. Then, remove the accessories, set the oven to bake, and then run the oven at 400 °F for 1 hour. There will be a distinctive odor. This is normal. Ensure your kitchen is well ventilated during this conditioning period. Energy saving tips

• During cooking, the oven door should remain closed except when you turn food over.

• Do not open the door frequently during cooking to maintain the oven temperature and to save energy.

• If cooking time is more than 30 minutes, you can switch the oven off 5-10 minutes before the end of the cooking time to save energy. The residual heat will complete the cooking process.

• To save energy and reduce the time needed for reheating the oven, plan oven use to avoid turning the oven off between cooking one item and the next.

• Whenever possible, cook more than one item at a time.English 25 Surface cooking

• Do not use the induction range to dry clothes.

• Never store ammable materials such as aerosols and detergents in the drawer or cupboards under the induction cooktop.

• Users with Pacemakers or Active Heart Implants must keep their upper body at least 1 ft. (30 cm) from the induction cooking zones when they are turned on. If in doubt, you should consult the manufacturer of your device or your doctor. CAUTION AFTER COOKING

• Do not touch the Induction elements until they have cooled down.

• The surface can stay hot for some time after cooking is complete. If you touch the surface before it has had time to cool down sufciently, you can burn yourself.

• Immediately clean spills on the cooking area to prevent a tough cleaning chore later.

• After you have activated elements on the cooktop, the internal fan may come on for cooling purposes.

• The fan activation time may differ depending on the temperature of the internal sensor. (10 minutes or 20 minutes)

• If you have cabinet storage directly above the cooking surface, make sure that the items in the cabinet are infrequently used and can be safely stored in an area subjected to heat. Temperatures may be unsafe for items such as volatile liquids, cleaners, or aerosol sprays. NOTE When you operate the knob, beep sounds once. Location of the induction cooktop elements and controls The induction control knobs operate the induction surface elements on the cooktop as shown below.

• The Cooktop display has a residual heat indicator for each element. It shows which elements are still hot. You should avoid touching an element when this indicator is displayed.

• Even if the Induction cooktop is switched off, the Hot

Hot indicator will stay lit while an element is still hot. The Hot indicator is hotter than Hot .26 English Surface cooking Surface cooking How to set the appliance for cooktop cooking CAUTION

• The cooktop elements may be hot even when off and burns can occur. Do not touch the cooktop elements until they have cooled down sufciently.

• Never leave cooking food unattended when you set the heating element to 6 or higher. Boilovers cause smoke. Greasy spillovers may catch on re.

• Be sure you turn OFF the heating element when you nish cooking.

1. Tap to turn on the display.

Induction Oven Oven 350°F Convection Bake 325°F Oven Induction Bake Convection Bake

2. Tap the cooktop control area.

3. Tap the induction element you want to

use. Induction 0 3 6 9BoostInductionBoost

4. Drag or tap to the setting you want.

5. To use the Power boost setting, tap Boost

level. Induction 0 3 6 9BoostInductionBoost

6. To use the Simmer setting, tap , and

then tap Simmer. Induction 0 3 6 9BoostSimmerMulti stagesInductionSimmerMulti stagesBoostEnglish 27 Surface cooking Induction Off Simmering... Simmer Induction Simmering... Off Simmer Sync control You can use Sync control to operate and control the two elements on the left side simultaneously, as a single cooking zone, and then use the zone for large cookware. (Examples : oval cookware, large spagetthi pots, etc.) Induction 0 3 6 9BoostInductionBoost

1. Sync control key will appear when you

set the left burner.

to use Sync control, and then tap Sync to conrm. The two left elements are synced and will now work together. Induction

Boost Cancel Sync Sync the front burner with the rear burner? Cancel Sync the front burner with the rear burner? Sync Induction 0 3 6 9BoostInductionBoost

3. To disable Sync control, tap the .

The two left elements are desynced and set to level you currently set. Multi stages Induction 0 3 6 9BoostMulti stagesSimmerInductionSimmerMulti stagesBoost

1. Tap , and then tap Multi stages.

Multi stagesYou can set the heat level for each stage. Start Stage 1Heat level

Time 0:00 Stage 2Heat level

Time 0:00 Stage 3Multi stagesYou can set the heat level for each stage.Stage 1TimeTime Heat levelHeat level Start Stage 2 Stage 3

2. You can set the heat level and cooking

time for each stage. You can set the stage to 3 stages and the total cooking time to within 1 hour 30 minutes. Multi stagesYou can set the heat level for each stage. Start Stage 1Heat level

Time 2:00 Stage 2Heat level

Time 1:00 Stage 3Multi stagesYou can set the heat level for each stage.Stage 1TimeTime Heat levelHeat level Start Stage 2 Stage 3

Stage 1 started Induction Stage 1 started28 English Surface cooking Surface cooking Before using the cooktop Use quality cookware in good condition The cookware used with the cooktop surface should have at bottoms that make good contact with the entire surface of the Cooking Zone. Check for atness by rotating a ruler across the bottom of the cookware. Be sure to follow all the recommendations for using cookware. Also remember to

• Use cookware made with the correct material for induction cooking. See Cookware for induction cooking zones on page 29.

• Use quality cookware with heavier bottoms for better heat distribution allowing for more even cooking results.

• The pan size should match the amount of food being prepared.

• Do not let pans boil dry. This may cause permanent damage in the form of breakage, fusion, or marring that can affect the ceramic cooktop. (This type of damage is not covered by your warranty.)

• Do not use dirty pans with grease buildup. Always use pans that are easy to clean after cooking. CAUTION

• The Cooking Zones may appear to be cool while turned ON and after they have been turned OFF. The glass surface may be HOT from residual heat transferred from the cookware and burns may occur.

• DO NOT TOUCH HOT COOKWARE or PANS directly with your hands. Always use oven mitts or pot holders to protect your hands from burns.

• DO NOT SLIDE cookware across the cooktop surface. Doing so may permanently damage the appearance of the ceramic cooktop. CORRECT INCORRECT Flat pan bottom & straight sides. Curved or warped pan bottoms or sides. Pan size meets or exceeds the recommended minimum size for the Cooking Zone. See Using the correct size cookware on page 29. Pan does not meet the minimum size required for the Cooking Zone used. See Using the correct size cookware on page 29. Pan rests completely on the Cooktop surface. Pan bottom rests on cooktop trim or does not rest completely on the cooktop surface. Pan is properly balanced. Heavy handle tilts pan. NOTE ANY one of the incorrect conditions listed above may be detected by the sensors located below the ceramic cooktop surface. If the cookware does not meet one or more of these conditions, one or more of the Cooking Zones will not heat, and settings will ash in the affected Cooking Zone display. Correct the problems before attempting to activate the cooktop.English 29 Surface cooking Using the correct size cookware

• The Induction Cooking Zones require that you use pots and pans of a minimum size or larger at each location. The inner ring of each Cooking Zone is your guide to the correct minimum pan size. The pan bottom must fully cover the inner ring for proper cooking to occur.

• The thicker outer ring at each Cooking Zone is helpful to determine the maximum pan size. After centering the cookware on the cooktop, make sure the cookware does not extend more than 1/2" beyond the thicker line on the Cooking Zone. The pan must fully contact the glass surface without the bottom of the pan touching the metal cooktop trim. NOTE

• If cookware is unsuitable, too small, or no cookware has been placed on the cooking zone, 'The cookware isn't compatible or there's no cookware in place.' message will be showed. After 30 seconds, the corresponding cooking zone will turn off. Pot and pan sizes Induction cooking zones adapt automatically to the size of the bottom of the cookware up to a certain limit. However the magnetic part of the bottom of the cookware must have a minimum diameter depending upon the size of the cooking zone. Cooking zones Minimum diameter of the bottom of the cookware 1 5.2 inches (130 mm) 2 4.5 inches (110 mm) 3 7.25 inches (180 mm) Cookware for induction cooking zones The Induction element can only be turned on when cookware with a magnetic base is placed on one of the cooking zones. You can use the cookware identied as suitable below. Cookware material Cookware material Suitable Steel, Enamelled steel Yes Cast iron Yes Stainless steel If appropriately labelled by the manufacturer Aluminium, Copper, Brass No Glass, Ceramic, Porcelain No NOTE

• Cookware appropriate for induction cooking is labelled as suitable by the manufacturer.

• Certain cookware can make noise when being used on induction cooking zones. These noises are not a fault in the appliance and do not affect operation in any way.30 English Surface cooking Surface cooking Better pans produce better results

• You can recognize good pots and pans by their bases. The base should be as thick and at as possible.

• When buying new pots or pans, pay particular attention to the diameter of the base. Manufacturers often give only the diameter of the upper rim.

• Do not use pans which have damaged bases with rough edges. You can scratch the ceramic cooktop permanently if you slide a pot or pan with a damaged base across the surface.

• When cold, pan bases are normally bowed slightly inwards (concave). They should never be bowed outwards (convex).

• If you want to use a special type of pot or pan, for example, a pressure cooker, a simmering pan, or a wok, please follow the manufacturer’s instructions. Energy saving tips You can save valuable energy by observing the following points:

• Always position pots and pans before switching on the cooking zone.

• Dirty cooking zones and pan bases increase power consumption.

• When possible, position lids rmly on pots and pans so that the lids cover them completely.

• Switch the cooking zones off before the end of the cooking time and use the residual heat to keep food warm. Right! Wrong! Wrong! Operating noises You may hear the following operational noises:

• Cracking noises : You may hear a cracking noise when you are using cookware made of two or more materials.

• Whistling : A whistling noise occurs when both back burners are in use. This is caused by vibrations. Whistling can vary depending on the weight or material of the cookware or the type of food you are cooking. (Noise can be reduced by using thicker cookware.)

• Humming : You may hear a low humming when you set an element to a high power setting. This sound is generated by energy transmission, and it will disappear when cooktop is turned off.

• Clicking : Electric switches are operating.

• Hissing, Buzzing : You may hear a fan noise during cooktop/oven operation. You may continue to hear it even after the cooktop/oven is turned off. This is normal. The fan runs to cool down the temperature inside. It will automatically shut off itself after a short period of time. These noises are normal and do not indicate any defects. Using suitable induction cookware Suitability test Cookware is suitable for induction cooking if a magnet sticks to the bottom of the cookware and the cookware is labelled as suitable by the cookware manufacturer.English 31 Surface cooking Temperature detection If for any reason the temperatures on any of the cooking zones exceeds the safety level, then the cooking zone will automatically reduce the heat to a lower power level. When you have nished using the cooktop, the cooling fan will continue to run until the cooktop’s electronics have cooled down. The cooling fan switches itself on and off depending upon the temperature of the electronics. NOTE If the induction cooktop overheats because of abnormal operation, C1 will be displayed and the induction cooktop will turn off. Power management The cooking zones, which consist of paired cooking elements, are restricted to drawing a certain maximum amount of power. If you cause a cooking zone to exceed its maximum allowed power by switching on the Power Boost function, the Power Management function automatically reduces the power setting of the two elements in the cooking zone and reduces the power draw. Suggested settings for cooking specic foods The gures in the table below are guidelines. The power settings required for various cooking methods depend on a number of variables, including the quality of the cookware being used, the type, and amount of food being cooked. Setting Cooking method Examples for use

Intensive Frying Boiling Rapid boiling Deep fat frying of frozen foods

Frying Stewing Boiling Pancakes, steak, cutlets, grilled meat Clear soup

Frying Stewing Boiling Cooking pasta Frying eggs Thick soup, sauces, and gravies Slow boiling rice and milk dishes

Poaching Defrosting Cooking potatoes Cooking soft vegetables 1 (Simmer) Melting, Warming Defrosting frozen vegetables Melting chocolate and butter, dissolving gelatin, simmer, keep warm. NOTE

• The power settings indicated in the table above are provided only as guidelines for your reference.

• You will need to adjust the power settings according to specic cookware and foods.32 English Operating the oven Operating the oven The control panel

01 Power: Press to turn On/Off the range. 02 Smart Control: Set Smart Control function On/Off. 03 Door Open: Use to open the oven door. 04 Display: Swipe to navigate through the menus and tap to select a desired settings. 05 Start: Press to start oven operation. 06 Light : Tap to turn oven light On/Off Protecting the cooktop Cleaning

• Clean the cooktop before using it for the rst time.

• Clean your cooktop daily or after each use. This will keep your cooktop looking good and can prevent damage.

• If a spillover occurs while you are cooking, immediately clean the spill from the cooking area while it is hot to prevent a tough cleaning chore later. Using extreme care, wipe the spill with a clean, dry towel.

• Do not allow spills to remain on the cooking area or the cooktop trim for a long period of time.

• Do not use abrasive cleansing powders or scouring pads, which will scratch the cooktop.

• Do not use chlorine bleach, ammonia, or other cleansers not specically recommended for use on a glass-ceramic surface. Preventing marks and scratches

• Do not use glass cookware. It may scratch the cooktop.

• Do not place a trivet or wok ring between the cooktop and the pan. These items can mark or scratch the cooktop.

• Make sure the cooktop and the pan bottom are clean.

• Do not slide metal pans across the cooktop. Preventing stains

• Do not use a soiled dish cloth or sponge to clean the cooktop surface. A lm will remain, which may cause stains on the cooking surface after the area is heated.

• Continuously cooking on a soiled surface can result in a permanent stain. Preventing other damage

• Do not allow plastic, sugar, or foods with high sugar content to melt onto the hot cooktop. Should this happen, clean immediately.

• Do not let a pan boil dry as this will damage the cooktop and the pan.

• Do not use the cooktop as a work surface or cutting board.

• Do not cook food directly on the cooktop. Always use the proper cookware. Surface cookingEnglish 33 Operating the oven Display Induction Oven Oven 350°F Convection Bake 325°F View all

Oven Induction Bake Convection Bake View all

01 Home : Tap to show the Home screen. 02 Settings : Use to display the setting screen. 03 Indicator area : When the feature is activated as Smart control, Mic, Lock, Timer and etc., Icon will appear on indicator area. 04 Control area : Swipe to navigate through the features (Induction, Oven, SmartThings, Device care) and tap to select a desired menu.

• Induction : Use to cooktop cooking. When you tap this area, induction burner and level can be set u want.

• Oven : Use to oven cooking. You can see the all oven mode by scrolling this area. When you tap the oven mode, temperature and cooking time can be set u want.

• SmartThings : Use to connect to the SmartThings app and control your devices remotely.

• Recipes : Use to see recipe guide.

• Product care : Tap to check the oven cleanings required. 05 App menu : Swipe to use app. App will appear on the screen. Tap to use SmartThings, Timer, Bixby, Weather, Internet, Ring and settings app. Display mode Sleep mode The control panel enters Sleep mode if the oven is not used for a while. In Sleep mode, the control panel is inactive until it is reactivated by the user. Turn on the display To activate the control panel, tap the . User preferences are available in this mode including the timer, oven light, and/or control lock.34 English Operating the oven Operating the oven Auto Open door Auto Open door can be opened by simply tapping Door Open button. You will be prompted one more time to conrm whether you want to open the door when the oven is running or within 10 minutes after cooking is complete.

2. The door slowly opens.

3. When closing the door, close it by hand.

• You can get hurt when the door opens and closes. Make sure you keep your distance from it. NOTE

• The range can get hot while in use, so for safety reasons, children or people who are not good at handling should not use it alone.

• If a pet touches the operator, the product may operate unintentionally, so be careful not to allow the pet to access the product.

• To open the door in an emergency or when the power is off, use the side pocket located at the upper right side of the door. Timer The timer serves as an extra timer that will beep when the set time has elapsed. It does not start or stop cooking functions. You can use the timer with any of the other oven functions. How to set the timer Induction Oven Oven 350°FConvection Bake 325°F

1. Swipe the app menu and tap Timer.

3. Set the timer name you want.

Swipe the screen or tap the numbers on numeric pad to set the time. (You can set the timer for any amount of time from 1 sec to 99 hr 59 min 59 sec). Timer Bake 00:59:59 Bake 00:59:59 Bake 00:59:59 Bake Bake Bake Timer

When the set time has elapsed, the oven will beep and the display will show the timer has nished.

• You can pause, cancel, or delete the timer at any time by touching the screen.English 35 Operating the oven Oven cooking STEP 1 Put all ingredients in a heat-safe container. STEP 2 Select a cooking mode, and then start preheating. STEP 3 Place the container on a rack. STEP 4 Close the door and start cooking. NOTE The cooling fan automatically runs for a certain amount of time after cooking is complete. Setting the mode Scrolling the screen Induction Oven Oven 350°FConvectionBake325°F Oven Induction Bake Convection Bake Scrolling the screen to select mode you want. Summarized mode Oven Bake 350°F Temp Cook Time View all Delay Stvart Oven Bake Cook Time Delay start View all Temp

1. Tap View all to display the summarized

2. Tap mode you want.36 EnglishOperating the oven

Operating the oven Induction Oven Oven 350°FConvectionBake325°F Oven Induction Bake Convection Bake

1. Tap oven mode you want.

Oven Bake 350°F Temp Cook TimeView allDelay Stvart Oven Bake Cook Time Delay start View all Temp

2. Tap Cook Time. The display will change to the cooking time screen.Delay Start

Oven BakeCancel OK Ends after Current time 10:42 PM Ready at 11:12 PM MinsHrs

Oven Current time 10:42 PM Ready at 11:12 PM Cancel

Mins Hrs Mins Ends after3. Swipe the screen or tap the numbers on numeric pad to set the time. (You can set the cooking time for any amount of time from 1 min to 9 hr 59 min).• You can set from 10 min to 99 hrs for Air Sous Vide mode.Delay StartOvenBake 350°F Temp 0:30 Cook TimeView allOven Bake Oven Off Oven Off Keep warm Keep Temp View all Temp Cook Time After Cooking 4. You can set after cooking options as Keep Warm, Keep Temp, and Oven Off after you set the Cook Time. (Default is Oven Off.) NOTE You can cancel a Cook Time at any time by setting the Cook Time to 0 minutes. Setting the temperature Oven Bake 350°F Temp Cook Time View all Delay Start Oven Bake Cook Time Delay start View all Temp

Bake Cook Time View all Temp Oven

2. Swipe the screen and tap the temperature you want. (You can swipe left or right).

Setting the Cooking options (Cook Time, Delay Start) CAUTIONFoods that can easily spoil, such as milk, eggs, sh, poultry, and meat, should be chilled in a refrigerator before they are placed in the oven. Even when chilled, they should not stand for more than 1 hour before cooking begins and should be removed promptly when cooking is completed.Cook TimeTimed cooking sets the oven to cook foods at a set temperature for a set length of time. The oven automatically turns off when it nishes. Mode : Bake / Convection Bake / Convection Roast / Convection Vegetable / Air Fry / Air Sous Vide / DehydrateEnglish 37 Operating the oven Basic baking and broiling instructions Induction Oven Oven 350°FConvectionBake325°F Oven Induction Bake Convection Bake

1. Tap oven mode you want.

Oven Bake 350°F Temp Cook TimeView allDelay Stvart Oven Bake Cook Time Delay start View all Temp

2. Set the temperature you want.

(See the Setting the temperature section on this page.)

• Broil mode can be set only High or Low.

• Bread Proof and Keep Warm temperature is xed and cannot be changed. Oven Bake 350°F Temp Cook TimeView allDelay Stvart Oven Bake Cook Time Delay start View all Temp

3. If you want to use the Cook Time, or

Delay Start function, set each fuction now. See the Setting the Cooking options section starting on page 34. Oven Bake 350°F Temp Cook TimeView allDelay Stvart Oven Bake Cook Time Delay start View all Temp

4. Tap Start to begin cooking.

Delay Start The Delay Start function lets you use the kitchen timer to automatically start and stop another cooking program. You can set Delay Start so that it delays the automatic start of a cooking operation you select by up to 12 hours. Mode : Bake / Convection Bake / Convection Roast / Convection Vegetable / Air Fry / Air Sous Vide / Dehydrate / Self clean Induction Oven Oven 350°F Convection Bake 325°F Oven Induction Bake Convection Bake

1. Place the container with the food on a

rack, and then close the door.

2. Tap oven mode you want.

• The display will change to the delay start screen.

• The current time is displayed as the rst entry. Delay Start Oven Bake Cancel OK Starts at Current time 15:14 End time 17:14

Oven Current time 15:14 End time 17:14Cancel OKStarts at

4. Swipe the screen or tap the numbers on

numeric pad to set the time you want the oven to start. And then tap OK. Oven Bake Start at 17:14 350°F Temp Cook Time Stop

5. The Delay Start screen closes. The start

time, and, if you set it, the Cook Time, is displayed on the screen.38 English Operating the oven Operating the oven CAUTION

• Do not cover an oven rack with aluminum foil. This will hamper heat circulation, resulting in poor baking.

• Do not place aluminum foil on the oven bottom. The aluminum can melt and damage the oven.

• Arrange the oven racks only when the oven is cool.

• When placing an oven rack in the top-most rack position (position 7), make sure the rack is situated stably on the embossed stop. Inserting and removing an oven rack To insert an oven rack

1. Place the rear end of the rack on a rack

2. Slide the rack into the rack guide while

holding the front end of the rack. To remove an oven rack

1. Pull out the rack until it stops.

2. Pull up the front end of the rack and

remove it from the rack guide. Oven Bake Preheating...175°F 350°FTemp Cook Time Stop

Oven Bake Temp Cook Time Preheating... Stop

5. Tap Stop when cooking is done or if you

want to cancel cooking. Using the oven racks Your oven range comes with 2 racks and 7 rack positions. The rack positions are delineated by rack guides which support the racks. Each rack guide has a stop that prevents the rack from loosening during the oven's operation. Each rack has stoppers that need to be placed correctly on the rack guides. The stoppers prevent the racks from accidently coming out of the oven completely when you pull the racks out.

Type of food Rack position Broiling hamburgers 7 Broiling meats or small cuts of poultry, sh

Bundt cakes, Pound cakes, Frozen pies, Casseroles 3 or 4 Angel food cakes, Small roats, Fresh and Frozen pizza

Turkey, Large roasts, Hams

This table is for reference only.English 39 Operating the oven Before using the racks The oven has two racks. Each rack has stops that need to be placed correctly on the supports. These stops will keep the rack from coming out completely.

1. Pull the rack straight out until it stops.

2. Lift up the front of the rack, and then pull it out.

1. Place the end of the rack on the support.

2. Tilt the front end up and push the rack in.

• Do not cover a rack with aluminum foil or place aluminum foil on the oven bottom. This will hamper heat circulation, resulting in poor baking, and may damage the oven bottom.

• Arrange the oven racks only when the oven is cool. Rack and Pan placement

Single Oven Rack Centering the baking pans in the oven as much as possible will produce better results. If baking with more than one pan, place the pans so each has at least 1" to 1 ½" of air space around it. When baking on a single oven rack, place the oven rack in position 3 or 4. See the gure on the left.

For cakes, place the oven racks in positions 3 and 5. For cookies, place the racks in positions 3 and 5. Using Multiple Oven Racks Type of Baking Rack Positions Cookies 3 and 5 Cakes 3 and 540 English Operating the oven Operating the oven

2. Insert the temperature probe plug into

the socket on the top side wall of the oven.

3. Select the cooking operation (Convection

Bake, Convection Roast, or Bake) and the temperature.

4. Set the internal temperature between

6. Tap START. When the food reaches the set internal temperature, the oven

automatically shuts off, and then beeps. NOTE Temperature probe operation will shut off either :

• When cooking time is over.

• When the temperature reaches the temperature you set. Temperature probe The temperature probe lets you cook roasts and poultry to the exact internal temperature you want, taking the guess work out of determining whether a piece of meat is done or not. You can use the temperature probe with the oven set to Bake, Convection Bake, or Convection Roast. When you use the temperature probe, the internal temperature is shown on the display when it reaches 100 °F.

1. Push the temperature probe into the

meat so that the tip of the probe reaches the center of the meat.

• When you insert the temperature probe, make sure it does not contact bone, fat, or gristle.

• For bone-in meats, insert the probe into the center of the lowest and thickest portion of the piece.

• For whole poultry (turkey, large chickens, etc.), insert the probe into the thickest part of the inner thigh, parallel to the leg.

• If you remove the temperature probe while cooking is in process, the oven shuts off in 60 seconds.

• The temperature probe may not function properly if inserted into frozen food. (The temperature probe icon doesn’t appear.)English 41 Operating the oven Cooking mode

• Make sure to close the door before you start cooking.

• If you leave the door open for about 2 minutes while the oven is in convection baking/roasting, baking, or broiling modes, the oven heating element shuts off. To restart the heating element, close the door. CAUTION Always use this cooking mode with the oven door closed. Use care when opening the door. Let hot air or steam escape before you remove food from or put food into the oven. Download Cooking Mode Temperature range (°F) Default temperature (°F) Temp. Probe Set Cook Time Delay Start Bake 175 - 550 350 O O O Broil Hi - Lo Hi X X X Convection Bake

Convection Vegetable

• To protect the temperature probe, be careful not to insert the probe so that it comes out of the meat. Make sure that the probe is inserted around the center of the meat.

• Do not store the probe in the oven.

• Do not leave the probe inside the oven during the Self-Cleaning or Broiling cycle. This will cause permanent damage to the probe.

• To avoid damage to the probe, defrost food in advance.

• Do not use tongs when inserting or removing the probe. Tongs can damage the probe.

• Use the temperature probe only for the applicable cooking operations. NOTE If you have covered the meat with aluminum foil and you let it stand covered for 10 minutes after cooking is complete, the internal temperature increases by

5 - 10 °F degrees.42 English

Operating the oven Operating the oven Mode Instruction Convection Vegetable

• Convection Vegetable provides excellent cooking conditions for vegetables such as potatoes, tomatoes, onions, carrots, bell peppers, broccoli and It creates optimal texture and taste for vegetable by increasing moisture content when compared to general convection.

• The uniform air circulation provided by Pure Convection allows you to use more oven capacity at once.

• For best results, use this mode in single oven mode and place the cooking tray in position 3.

• Preheating is not necessary for this mode.

• See the Convection Vegetable recommendation guide section starting on page 44. Air Fry

• Air Fry uses hot air for crispier and healthier frozen or fresh foods without or less oil than normal convection mode.

• For best results, use this mode in single oven mode and place the Air Fry tray in position 3.

• Preheating is not necessary for this mode.

• The temperature can be set between 350°F - 500°F.

• In this mode, the oven keeps constant low temperatures, cooking food that can keep its original fragrance and nutrients while offering enriched avor and soft texture.

• It is not necessary to preheat the oven when using Air Sous Vide mode.

• Place the sealed vacuum bags of food on the rack 3 of the oven.

• The temperature can be set between 100°F - 205°F.

• Use it to cook meat, sh, seafood, poultry or vegetables.

• Use fresh and quality ingredients only. Trim them in a clean condition and store under refrigeration.

• Use heat-resistant vacuum bags for moving and storing ingredients.

• Use Air Sous Vide recommendation guide. To nd the recommended cooking time and temperature for the food.

• See the Air Sous Vide section starting on page 47. Mode Instruction Bake

• Bake is used to cook cakes, cookies, and casseroles. Always preheat the oven rst.

• Baking temperatures and times will vary depending on the ingredients and the size and shape of the baking pan used.

• Dark or nonstick coatings may cook faster with more browning. NOTE For performance reasons, the convection fan may turn on or off during baking. Convection Bake

• Ideal for foods being cooked using multiple racks.

• Good for large quantities of food.

• Provides the best performance for cookies, biscuits, brownies, cupcakes, cream puffs, sweet rolls, angel food cake, and bread.

• Cookies bake best when cooked on at cookie sheets.

• The oven automatically adjusts the temperature for convection baking. Convection Roast

• Good for larger, tender cuts of meat, uncovered.

• For best performance, place a broiler pan and grid under the meat or poultry. The pan catches grease spills and the grid prevents grease spatters.

• Heated air circulates over, under, and around the food. Meat and poultry are browned on all sides as if they were cooked on a rotisserie. Broil

• Broiling uses the oven broil burner at the top of oven to cook and brown food.

• Meat or sh must be put on a broiling grid in a broiling pan.

• Preheating for 4 minutes before broiling is recommended.English 43 Operating the oven Broiling guide NOTE For reference only.

• Preheating for 4 minutes before broiling is recommended.

• The size, weight, thickness, starting temperature, and your doneness preference will affect broiling times.

• This guide is based on meats at refrigerator temperature. Food Doneness Size Thickness Broil setting Rack position Cooking time 1st side 2nd side Hamburgers Medium 9 patties 1" Hi 7 3:20 - 3:40 2:20 - 2:40 Beef steak Medium - 1" Hi 5 7:00 - 8:00 6:00 - 7:00 Medium - ¾" Hi 5 6:00 - 7:00 5:00 - 6:00 Chicken pieces Well done

• This oven is designed for closed door broiling. While broiling, keep the door closed. Only open the door to put food in, turn food over, or take food out.

• Use the Broil Rack for the best results.

• Use the Broil Lo for poultry or thick cuts of meat to prevent overbroiling.

• Use caution when you open the oven door to turn over the food. The air escaping from the oven will be very hot.

• If you leave the oven door open for more than 2 minutes when the oven is on, all heating elements will shut off automatically.

• When you have nished cooking, the cooling fan will continue to run until the oven has cooled down. Mode Instruction Keep Warm

• The keep warm mode will keep cooked food warm for serving up to 3 hours after cooking has nished.

• You can use the keep warm mode without any other cooking operations or you can set it to activate after a timed or delay timed cooking operation.

• You should not use this mode to reheat cold food. Bread Proof

• Proof provides an optimal temperature for thebread proong process, and therefore does not require a temperature adjustment.

• Place the dough on rack position 2. Proof needs to cover with cloth or with plastic wrap.

• For the best results, always start the Proof option with a cool oven. Dehydrate

• Dehydrate dries food or removes moisture from food via heat circulation. Place the food on rack position 3 or 4.

• After drying the food, keep it in a cool and dry place.

• For fruit, adding lemon or pineapple juice or sprinkling sugar on the fruit helps the fruit retain sweetness.

• See the table below for Dehydrate settings.44 English Operating the oven Operating the oven NOTE

• When cooking vegetables, place baking paper on a baking sheet or tray to catch any drippings.

• It is recommended to use some oil such as olive oil or avocado oil and some salt or pepper.

• It is recommended to serve with fresh herbs such as basil leaves, rosemary leaves, and grated cheeses as your taste after cooking.

• Serve cooked vegetables with your favorite main dish.

• It is recommended to take cooked vegetables every day for your health.

• Vegetables not listed in the table are recommended to be cooked at the default temperature at rst, and then cooked at a higher or lower temperature.

• For performance reasons, the convection fan may be turned on or off during the operation automatically.

• For more information, the Samsung website offers special menus and recipes to enjoy cooked vegetables on the guide table, you can download detailedrecipes for each feature from the our website. (www.samsung.com/us/support). Convection Vegetable recommendation guide

• Preheating is not necessary.

• For best results, use this mode on a single oven rack and place the dish on the rack position 3.

• This table is for reference onlyEnglish 45 Operating the oven NOTE

• Preheating is not necessary.

• Place the Air Fry tray on position 3.

• It is recommended to use avocado oil.

• Place a baking sheet or tray on the rack below the Air Fry tray to catch any drippings. This will help to reduce splatter and smoke. Air Fry This feature uses hot air for crispier and healthier frozen or fresh foods without, or less oil, than normal convection modes. For best results, use this mode on a single oven rack and place the Air Fry tray on the position 3. The temperature can be set between 350 °F and 500 °F. Preheating is not necessary for this mode. Follow recipe or package directions for set temperature, time, or quantity. Tray or Baking sheetTray or Baking sheet Air Fry trayAir Fry tray Air Fry tray recommended placement NOTE

• Place a baking sheet or tray on the rack below the Air Fry tray for getting any drippings. This will help to reduce splatter and smoke for high fat foods, such as chicken wings.

• Air Fry is designed for baking on a single oven rack. Place food on rack position 3 for best results. (Rack position number counts from the bottom.)

• Before using a baking ware, check the maximum allowable temperature of baking sheet.

• Place under a few sheets of paper like parchment paper to absorb the fat for reducing splatter and smoke during the Air Fry.

• For cooking fresh or homemade foods, spread the oil over a larger area more evenly, crisping up the food more effectively.

• Wet or thicken coating will not crisp or set to use with the Air Fry. CAUTION

• Foods that are high in fat will smoke when using the Air Fry model, such as chicken wings, bacon, sausage and turkey legs.

• Before you start Air Fry, turn on an exhaust hood at a high level fan setting.

• Open a window in your kitchen if it is possible to make sure the kitchen is well- ventilated.

• Once the oven has cooled, wipe down the interior of the oven before and after Air Fry cooking.

• Regularly, clean the grease lters of exhaust hood for preventing smoke during cooking.

• Avoid opening the oven door, or else it is difcult to maintain the oven temperature, prevent heat loss, and save energy.46 English Operating the oven Operating the oven Item Amount (oz) Temperature (°F) Time (min) Tips Frozen Frozen Chicken Nuggets

Poultry Fresh Drumsticks

35 - 45 425 - 450 30 - 35

Brush with 3 tbsp of oil. Add salt and pepper to taste. Air frying foods that are high in fat can create smoke. Fresh Chicken Wings

Frozen French Fries, Seasoned

Homemade French Fries

Peel potatoes and cut into sticks with a thickness of ⅓ inch. Soak in cold water for 30 min. Brush with 3tbsp of oil. Add salt and pepper to taste. Homemade Potato Wedges

Cut them into wedges. Brush with 3 tbsp of oil. Add salt and pepper to taste.English 47 Operating the oven Air Sous Vide Air sous vide mode uses low-temperature hot air to implement Sous Vide method without steam or the water tank. In this mode, the oven keeps constant low temperatures, cooking food that can keep its original fragrance and nutrients while offering enriched avor and soft texture. NOTE

• It is not necessary to preheat the oven when using Air Sous Vide mode.

• Place the vacuum sealed bags of food on the rack 4 of the oven.

• Use it to cook meat, sh, seafood, poultry or vegetables.

• Use fresh and quality ingredients only. Trim them in clean conditions and store in the refrigerator.

• Use heat-resistant vacuum bags for moving and storing ingredients.

• Never reuse the heat-resistant vacuum bags.

• The cooking time depends on the thickness of food. Addition of salt or sugar may shorten the cooking time.

• Use Air Sous Vide recommendation guide to nd the recommended cooking time and temperature for the food.

• Only use temperatures below 140 °F (60 °C) to cook foods that can safely be consumed raw. Tips

• To keep the original taste, we recommend you use less herbs and spices than in ordinary recipes.

• Meat and sh offer better avors when seared and served.

• Sous vide dishes are best served immedietly after cooking. Item Amount (oz) Temperature (°F) Time (min) Tips Chicken Breasts, Breaded

30 - 35 400 - 425 25 - 30

Dip chicken breasts into the our mixture. Whisk the egg and milk. Dip our coated breasts into the egg mixture. Place them into breaded crumbs and toss until items are coated with crumbs. Add salt and pepper to taste. Brush with 3 tbsp of oil. Vegetables Asparagus, Breaded

Dip sliced vegetables into the our mixture. Whisk the egg and milk. Dip our coated vegetables into the egg mixture. Place them into breaded crumbs and toss until items are coated with crumbs. Add salt and pepper to taste. Brush with 3 tbsp of oil. Egg Plants, Breaded

Vegetable Mix, Breaded

• Place the rack in rack position 3 or 4.

• If turn off the 12hr energy saving feature, this modes will operate until canceled. (12hr energy saving's default setting : on) CAUTION You should not use this feature to reheat cold food.

• If not served immediately after cooked, put the food in ice water and cool down completely. Then, store them under 40 °F (5 °C) to keep the fragrance and texture of food.

• Chicken, especially, is recommended to eat immediately after cooked. Air Sous Vide recommendation guide Food Doneness Temperature (°F) Time (hrs.) Beef Steak, 1.5" thick Rare 130 2.5 - 4 Medium 140 2.5 - 4 Well done 155 3 - 5 Roast Medium 150 6 - 12 Well done 155 6 - 12 Pork Chop, boneless Tender 150 3 - 5 Firm 160 3 - 5 Roast Medium 150 4 - 6 Well done 160 5 - 7 Pulled pork Well done 160 15 - 48 Poultry Chicken, breast Tender 145 3 - 4 Firm 160 3.5 - 4.5 Duck, breast Tender 145 3 - 4 FishEnglish 49 Operating the oven Camera In Oven (applicable models only) Camera in Oven Camera WARNING Clean the transparent inner side of door after the product cools down.

• You may get a burn due to the heat. CAUTION Do not wipe too hard when cleaning transparent inner side of door that have the camera functions.

• It could be damaged as it is made of glass. The built-in camera enables you to monitor the cooking process using the SmartThings app. Check the Camera Vision settings in Options - Settings. It is only available if the product is connected to Wi-Fi through Easy Connection.

• Live Streaming: Monitors the cooking status in the oven with the SmartThings app. However, the camera does not operate during certain modes, such as the Cleaning and lower setting in twin cooking mode. The light is turned on while the camera is in operation. (The camera will turn off if you turn off the Light.) The screen will display the camera indicator when the camera is running.

• To monitor the cooking process with the camera, place food between racks 1 and 4. Bread Proof The Bread Proof function automatically provides the optimum temperature for the bread proof process and, therefore does not have a temperature adjustment. If you press Bread Proof when the oven temperature is above 95 °F, Hot will appear in the display. Because these functions produce the best results when started while the oven is cool, we recommend that you wait until the oven has cooled down and Hot disappears from the display. NOTE

• There is no preheating before bread proof.

• Place the rack in rack position 3. Dehydrate Dehydrate dries food or removes moisture from food via heat circulation. After drying the food, keep it in a cool and dry place. For fruit, adding lemon (or pineapple) juice or sprinkling sugar on the fruit helps the fruit retain sweetness. NOTE

• There is no preheating before dehydrating.

• Place the rack in rack position 3 or 4.50 English Operating the oven Operating the oven Smart control How to connect the oven

1. Download and open the SmartThings app on your smart device.

2. Follow the app's on-screen instructions to connect your range.

3. Once the process is complete, the connected

icon located on your range displays and the app will conrm you are connected.

4. If the connection icon does not turn on, follow the instruction on the app to

• For optimal camera recognition, clean the transparent inner side of door and light on the back inside oven on the regular basis.

• Clean the inside of the oven after it completely cools down.

• Do not wipe too hard when cleaning the transparent inner side of door. It may cause scratches or other damage.

• While the Live Streaming feature is on, the food image from the camera may be steamed or fogged up depending on the food.

• While the Live Streaming feature is on, the food image may break off or pause due to a weak Wi-Fi signal depending on the product's distance to the router.

• Depending on the router/network condition, the food image may break or pause. A connection over 5 GHz Wi-Fi helps you enjoy the product without affecting the experience.

• Objects between the product and the router may affect the Live Streaming image quality. Please check if the internet upload speed is consistently over 30 Mbps at the product location.

• If the streaming image quality is low on your mobile device, please check if the download speed is at least 30 Mbps.

• The screen may be blurred by the internal lights when there is no food inside or depending on the food placement.

• If the camera is hard to see, wipe foreign matter on inner side of door surface.

• Please note that forcefully pressing the door switch while the door is open may cause the camera to malfunction.English 51 Operating the oven Voice control To use the Range’s Voice Control function, you need Bixby / Amazon Alexa App / Google Assistant App on your mobile device. Bixby

• Bixby is the name of Samsung's articial intelligence solution that makes it possible to control the product by voice.

• To use the voice recognition function, you need to connect the SmartThings app and the product on your smartphone.

• For models that do not directly recognize voice input for the product after connecting to the app, some functions can still be controlled through Bixby on Samsung smartphones.

• SmartThings App Menu → Voice assistant → Bixby, you can refer to the Bixby utterance of device. Amazon Alexa & Google Assistant Samsung smart home appliances are supported by SmartThings skill in Alexa and Action in Google Assistant. Installation Guide Here’s how to link SmartThings account into Amazon Alexa or Google Assistant. SmartThings App and Alexa App(or Google Assistant App) Should be installed on your phone.

1. Setup the supported devices to SmartThings.

2. After device setup, tap + button on the screen.

3. Tap ‘Voice assistant’ and link your Samsung account to Amazon Alexa.

(or Google Assistant)

4. Check the devices are visible on Amazon Alexa app. Then account linking is

complete. (Check the devices are visible and set the location(home&room) of devices in Google home app. Then account linking is complete.) NOTE On/Off spec of smart control is same as guided in SmartThings app. To control the oven remotely

. appears in the display. The oven can now be controlled remotely with a connected device.

2. Select the oven icon on the SmartThings app to open the Oven Control app.

When the app is connected to the oven, you can perform the following functions through the application: Oven remote control using the SmartThings app Oven/Cooktop Monitoring

• Check the status of the oven.

• Monitor the On/Off status of each cooktop burner. Oven Remote Control • Set or adjust oven settings remotely. My Cooking

• Turn the oven off remotely.

• Once cooking starts, change the set cooking time and temperature remotely. Error Check • Automatically recognize errors. Temp. Probe

• Monitor the current temperature and reset the probe setting.

is not shown in the display, you are still able to monitor the oven and cooktop status and turn the oven off. NOTE See the SmartThings app manual for detailed information. NOTE

• Important: Self Clean mode cannot be started remotely.

• This appliance is congurable to allow remote operation at any time. Do not store any ammable materials or temperature sensitive items inside, on top or near surface units of the appliance.

• When Smart Control is deactivated, you can still monitor the oven's status and turn the oven off.52 English Operating the oven Operating the oven Settings In Settings, you can change the default settings to your preference or diagnose problems with the network connection. Please refer to the following table for detailed descriptions. Induction Oven Oven 350°F Convection Bake 325°F View all OvenInduction Bake Convection Bake View all Setting Description Common Samsung Account Sign in to get started. Connections Use to set Wi-Fi, Easy-connection and Bluetooth connections. Lock Prevent children from accidentally starting or setting the devices. When Lock feature is on, control panel and door will be locked. Ambient Edge Lighting Ambient light lets you know the status of your oven. Sounds Use to set Sound mode, Sound style and Volume. Setting Description Common Home device notications Receive notications about registered devices in the SmartThings app. Display Use to set Brightness and Font size on screen. Display and style Use to set Cover screen and Screen saver. Bixby Use to set Voice wake-up and Sound feedback. Microphone You can set On/Off for microphone feature. Language You can change language you want. The default is English. Date and time Use to set date and time. You can use the date and time provided by your network when you set the automatic. Temp unit Use to set temp unit. (℉ or ℃) Accessibility Use to set Talkback and Visibility enhancements. Software update You can download and install new software when software update is available. Support Get remote support for all your needs related to your appliance. Reset Use to reset network and device. Device info Use to check device information included product name, model name and serial number. Induction Compatibility of the pot check Check if the cookware is suitable for your induction.English 53 Operating the oven Setting Description Oven My modes You can edit (add or remove) the cooking modes and create a custom list. To display the mode you want on the oven screen, try editing the list. Certain modes will not disappear. You can download a new mode through the SmartThings App, and you can add it to My Mode List. My pattern Shows your frequently modes and temperatures in order of most used. 12 hours Energy Saving Oven will turn itself off after 12 hours of baking or 3 hours of broiling. Oven will not turn off when feature is deactivated. Adjust temp Adjust temp with the range of -35 ℉ to +35

Sabbath See The Sabbath feature section on page 53. Demo mode This option is for use by retail establishments for display purposes only. (The heating element does not operate.)

1. Tap Settings > Common > Date and time

2. Tap Set time and set time to 12:34.

3. Tap Power and Smart control at the same time for 5 seconds.

4. The demo mode is on and indicator appearson screen.

Special features The Sabbath feature

(For use on the Jewish Sabbath and Holidays) Use this option only for baking on the Jewish Sabbath and Holidays. For more information, visit the website at http://www.star-k.org With the Sabbath feature

• The oven temperature can be set higher or lower after you have set this option.

• The display doesn’t change and makes no beep sounds when you change the temperature.

• Once the oven is properly set for baking with the Sabbath feature active, the oven will remain continuously on until the Sabbath feature is cancelled. This will override the factory preset 12 hour energy saving feature.

• If the oven light is needed during the Sabbath, press the pad before activating the Sabbath feature. Once the oven light is turned on and the Sabbath feature is active, the oven light will remain on until the Sabbath feature is turned off.

• If you want the oven light off, be sure to turn it off before activating the Sabbath feature.

• Do not use the surface cooktop when the Sabbath feature is on.

• In Sabbath mode, the Auto open door button will be disabled. To open the door, grasp it by the sides and pull.54 English Operating the oven Operating the oven To enable the Sabbath feature Oven BakePreheating...175°F 350°FTemp Cook Time Stop

Oven Bake Temp Cook Time Preheating... Stop

1. Start a Bake Mode, and then tap .

Settings Common Induction Oven Shows your frequently modes and temperatures in order of most used The 12-hour energy feature will turn the oven off. 12 hours Energy Saving 0°F Adjust Temp For baking on the Jewish Sabbath and holidays. Sabbath Common The 12-hour energy feature will turn the oven off. For baking on the Jewish Sabbath and holidays. Shows your frequently modes and temperatures in order of most used Induction Oven 12 hours Energy Saving Sabbath Adjust Temp

2. Tap Oven, and then tap Sabbath to use

the Sabbath feature. StartSabbath To start Sabbath mode,

1) Turn off your induction cooktop.

2) Remove Temp Probe.

3) Check active timer and cancel it.

4) Begin Bake mode. Sabbath function is only available in bake mode.

5) Be sure the oven light is on or off. Can’t change it during Sabbath mode.

To start Sabbath mode,

1) Turn off your induction cooktop.

2) Remove Temp Probe.

3) Check active timer and cancel it.

4) Begin Bake mode. Sabbath function is only available in bake mode.

5) Be sure the oven light is on or off. Can’t change it during Sabbath mode.

In Sabbath mode, the Auto door open button will be disabled. To open the door, grasp it by the sides and pull. Start Sabbath

You can change the temperature by 5 °F. To turn off Sabbath mode, tap and hold Stop for 3 seconds. Sabbath Temperature Stop To turn off Sabbath mode, tap and hold Stop for 3 seconds. Sabbath Temperature

4. To turn Sabbath mode off, tap and hold

Stop for 3 seconds. NOTE

• You can change the oven temperature, but the display will not change or beep. After changing the temperature, it takes 15 seconds before the oven recognizes the change.

• You can set the cooking time before activating the Sabbath feature.

• After a power failure, the oven will not resume operation automatically. "Sabbath" will appear in the control panel, but the oven will not go back on. Food can be safely removed from the oven, but you should not turn off the Sabbath feature and turn the oven back on until after the Sabbath/Holidays.

• In Sabbath mode, the Ambient Edge Lighting function will turn off. The settings will return to their previous specications when you exit Sabbath mode.

• After the Sabbath observance, turn off the Sabbath feature. CAUTION

• Do not attempt to activate any other functions except for Bake while the Sabbath feature is on.

• Do not open the oven door or change the oven temperature for about 30 minutes after you have started the Sabbath feature. Let the oven reach the set temperature. The oven fan operates only when the oven temperature increases.English 55 Maintaining your appliance Before a self-cleaning cycle Fig. 1Fig. 1 Fig. 2Fig. 2 Don’t hand Don’t hand clean the clean the oven door oven door gasket.gasket. You may You may hand clean hand clean the door.the door.

• We recommend venting your kitchen with an open window or using a ventilation fan or hood during the self- cleaning cycle.

• Remove the wire rack, broil pan, broil pan insert, all cookware, and any aluminum foil from the oven.

• Wipe up debris from the oven bottom. (Fig. 1)

• Residue on the front frame of the range and outside the gasket on the door will need to be cleaned by hand. Clean these areas with hot water, soap-lled steel- wool pads, or cleansers, such as Soft Scrub. Rinse well with clean water and dry.

• Do not clean the gasket. The berglass material of the oven door gasket cannot withstand abrasion. It is essential for the gasket to remain intact. If you notice it becoming worn or frayed, have it replaced. (Fig. 2)

• Make sure the oven light bulb cover is in place and the oven light is off. NOTE Remove oven racks and accessories before starting the self-clean mode. Maintaining your appliance Self-cleaning This self-cleaning oven uses high temperatures (well above cooking temperatures) to burn off leftover grease and residue completely or reduce them to a nely powdered ash that you can wipe away with a damp cloth. CAUTION

• During the self-cleaning cycle, the outside surface of the range will become very hot to the touch. Do not leave small children unattended near the appliance.

• Some birds are extremely sensitive to the fumes given off during the self- cleaning cycle of any range. Move birds to another well-ventilated room.

• Do not line the oven walls, racks, bottom, or any other part of the range with aluminum foil. Doing so will result in poor heat distribution, poor baking results, and cause permanent damage to the oven interior. Aluminum foil will melt and adhere to the interior surface of the oven.

• Do not force the oven door open. This can damage the automatic door locking system. Use care when opening the oven door after the self-cleaning cycle is complete. Stand to the side of the oven when opening the door to allow hot air or steam to escape. The oven may still be VERY HOT.

• Wear the glove during cleaning.

• Opening a window or turning on a ventilation fan or hood is recommended during and after self-cleaning.56 English Maintaining your appliance Maintaining your appliance How to run a self-cleaning cycle Oven Self Clean 3 hrs Clean TimeView allDelay Start How To Clean Oven Self Cleam 3 hrs Clean Time Delay start How To Clean View all

2. Tap Clean Time, and then tap clean

time you want. You can choose 2 hours, 3 hours, or 5 hours. (The default is 3 hours). Oven Self Clean 3 hrs Clean TimeView allDelay Start How To Clean Oven Self Cleam 3 hrs Clean Time Delay start How To Clean View all

3. Tap How To Clean.

If you want to use the Delay Start feature, See the Setting the cooking options on page 36. Delay Start Oven Self Clean Cancel Then, press Start to begin. Pressing the Power Button while cooking to cancel. Self Clean Start Stop Self Clean Cancel Then, press Start to begin. Pressing the Power Button while cooking to cancel. Start Stop

4. Information for self cleaning will show

on display. Start will appear on side of the screen when you swipe the screen. Tap Start to begin self cleaning. Delay Start Oven Self Clean Cancel Then, press Start to begin. Pressing the Power Button while cooking to cancel. Self Clean Start Stop Self Clean Cancel Then, press Start to begin. Pressing the Power Button while cooking to cancel. Start Stop

5. If you need to stop or interrupt a self

cleaning cycle, tap Power. NOTE

• You will not be able to start a self-cleaning cycle if the oven lock feature is activated or if the oven’s temperature is too hot.

• The oven door locks automatically. The display will show the cleaning time remaining. It is not be possible to open the oven doors until the temperature drops to a safe/cool temperature. After a self-cleaning cycle

• You may notice some white ash in the oven. Wipe it up with a damp cloth after the oven cools. (If white spots remain, remove them with a soap-lled steel wool pad and rinse thoroughly with a vinegar and water mixture.)

• If the oven is not clean after one cycle, repeat the cycle.

• You cannot set the oven for cooking until the oven is cool enough for the door to unlock.English 57 Maintaining your appliance Stop20minsCleaning...Cleaning...mins leftOvenSteam CleanEnd at 5:24 PM Stop

Steam Cleam 20 mins left End at 5:24 PM Cleaning... 20mins Cleaning... Oven

5. If you need to stop or interrupt a steam

cleaning cycle, tap Stop.

6. Clean the oven’s interior.

There will be a signicant amount of water remaining on the bottom of the oven after a steam-cleaning cycle. Remove the residual water with a sponge or soft dry cloth. NOTE When steam-cleaning, use exactly 10 oz. of water since this produces the best results. NOTE If you set Steam Clean when the oven temperature is above 100˚F, Hot will appear in the display. Because this function produces the best results when started while the oven is cool, we recommend that you wait until the oven has cooled down and Hot disappears from the display. CAUTION Wear the glove during cleaning. Steam-cleaning How to set the oven for steam-cleaning For light cleaning, the steam-cleaning function saves time and energy. For heavier- duty cleaning, use the self-cleaning function.

1. Remove all accessories from the oven.

2. Pour approximately 1 ¾ cups of water

onto the bottom of the empty oven and then close the oven door. Use normal water only, not distilled water. Oven Steam Clean 20mins Clean TimeView allHow To Clean Oven Steam Cleam 20mins Clean Time How To Clean View all

4. Information for steam cleaning will

show on display. Start will appear on the screen when you swipe the screen. Tap Start to begin steam cleaning.58 English Maintaining your appliance Maintaining your appliance Care and cleaning of the oven WARNING

• Be sure all controls are OFF and all surfaces are COOL before cleaning any part of the range.

• If your range is moved for cleaning, servicing, or any reason, be sure the Anti-Tip device is re-engaged properly when the range is replaced. If you fail to re-engage the Anti-Tip device, the range could tip and cause serious injury. Control panel First, lock the control panel and the door to prevent accidental operations and/or product tipping. WARNING

• Make sure the control panel turns off and all surfaces of the range are cool before cleaning. Otherwise, you can get burned.

• If the range has been moved away from the wall, make sure the Anti-Tip device is reinstalled properly when the range has been put into place again. Otherwise, the range may tip over, causing physical injuries.

• Do not use steel-wool or abrasive cleansers of any kind. These can scratch or damage the surface. Vent VentVent

• The cooling vents are located at the back of the oven range.

• This area could become hot during oven use.

• It is normal for steam to come out of the vent.

• The vent is important for proper air circulation. Never block this vent. After a steam-cleaning cycle

• Take care when opening the door before a steam-cleaning procedure has ended. The water on the bottom is hot.

• Open the oven door and remove the remaining water with a sponge. Do not leave the residual water in the oven for any length of time. Wipe the oven clean and dry with a soft cloth. Do not forget to wipe under the oven door seal.

• Use a detergent-soaked sponge, a soft brush, or a nylon scrubber to wipe the oven interior. Remove stubborn residue with a nylon scourer. You can remove lime deposits with a cloth soaked in vinegar.

• If the oven remains dirty, you can repeat the procedure once the oven has cooled.

• For heavy residue, such as grease left over from roasting, we recommend that you rub detergent into the residue before activating the steam-cleaning function.

• After cleaning, leave the oven door ajar at a 15° angle to allow the interior enamel surface to dry thoroughly.English 59 Maintaining your appliance Air Fry tray To keep the Air Fry tray clean, remove them from the cavity, and soak them in Lukewarm soapy water. Then, scour soil off of the Air Fry tray using a plastic scouring pad. NOTE The Air Fry tray is dishwasher-safe. CAUTION Do not leave the Air Fry tray in the oven during the self-cleaning cycle. The extreme heat generated in this cycle can permanently peel off the air fry coating, their color will turn slightly blue and nish will be dull. Oven door Don’t hand Don’t hand clean the clean the oven door oven door gasket.gasket. You may You may hand clean hand clean the door.the door.

• Use soap and water to thoroughly clean the top, sides, and front of the oven door. Rinse well. You may use a glass cleaner on the outside glass of the oven door. DO NOT immerse the door in water. DO NOT spray or allow water or the glass cleaner to enter the door vents. DO NOT use oven cleaners, cleaning powders, or any harsh abrasive cleaning materials on the outside of the oven door.

• DO NOT clean the oven door gasket. The oven door gasket is made of a woven material which is essential for a good seal. Care should be taken not to rub, damage, or remove this gasket. Cleaning painted parts and decorative trim

• For general cleaning, use a cloth with hot, soapy water.

• For more difcult residue and built-up grease, apply a liquid detergent directly onto the area and leave for 30 to 60 minutes. Wipe with a damp cloth and dry. Do not use abrasive cleaners on any of these surfaces. They can scratch. Cleaning stainless steel surfaces

1. Shake the bottle of Stainless Steel Appliance Cleaner or Polish well.

2. Place a small amount of Stainless Steel Appliance Cleaner or Polish on a damp

cloth or damp paper towel.

3. Clean a small area, rubbing with the grain of the stainless steel if applicable.

4. Dry and buff with a clean, dry paper towel or soft cloth.

5. Repeat as necessary.

• Do not use a steel-wool pad. It will scratch the surface.

• If a mineral oil-based stainless steel appliance cleaner has been used before to clean the appliance, wash the surface with dishwashing liquid and water prior to using the Stainless Steel Appliance Cleaner or Polish. Oven racks

• If the racks are left in the oven during a self-cleaning cycle, their color will turn slightly blue and the nish will be dull. After the self-cleaning cycle is complete and the oven has cooled, rub the sides of the racks with wax paper or a cloth containing a small amount of oil. This will help the racks glide more easily on their tracks.

• Gliding racks may be cleaned by hand with an abrasive cleaner or steel wool. During cleaning, be careful not to allow water or cleaner to enter the slides on the sides of rack. NOTE

• Do not clean in a dishwasher.

• If the rack becomes hard to remove or replace, lightly wipe the oven rack guides with cooking oil. Do not wipe cooking oil on the slides.

• If the rack becomes difcult to slide, the rack may need to be lubricated using a graphite lubricant.60 English Maintaining your appliance Maintaining your appliance Removing burned-on residue

1. Allow the cooktop to cool.

2. Spread a few drops of ceramic cooktop

cleaner on the entire burned residue area.

3. Using a cleaning pad for ceramic

cooktops, rub the residue area, applying pressure as needed.

4. If any residue remains, repeat the steps

listed above as needed.

5. For additional protection, after all residue

has been removed, polish the entire surface by applying ceramic cooktop cleaner with a paper towel. Removing heavy, burned-on residue

1. Allow the cooktop to cool.

2. Use a single-edge razor-blade scraper

at approximately a 45° angle against the glass surface and scrape the soil. It will be necessary to apply pressure to remove the residue.

3. After scraping with the razor scraper,

spread a few drops of ceramic cooktop cleaner on the entire burned residue area. Use a cleaning pad to remove any remaining residue. (Do not scrape the seal.)

4. For additional protection, after all residue

has been removed, polish the entire surface by applying ceramic cooktop cleaner with a paper towel. Drawer Handle Remove dust with soft brush or soft cloth covered with water. CAUTION

• Do not use alkaline detergents, sulfuric acid, hydrochloric acid, organic solvents, or disinfectants. - Surface can be damaged. Care and cleaning of the glass cooktop Normal daily use cleaning Use only a ceramic cooktop cleaner. Other creams may not be as effective. By following these steps, you can maintain and protect the surface of your glass cooktop.

1. Before using the cooktop for the rst time, clean it with a ceramic cooktop

cleaner. This helps protect the top and makes cleanup easier.

2. Daily use of a ceramic cooktop cleaner will help keep the cooktop looking new.

3. Shake the cleaning cream well. Apply a few drops of cleaner directly to the

4. Use a paper towel or a cleaning pad for ceramic cooktops to clean the entire

5. Use a dry cloth or paper towel to remove all cleaning residue. No need to rinse.

WARNING DAMAGE to your glass surface may occur if you use scrub pads other than those recommended.English 61 Maintaining your appliance Cleaning sugary spills and melted plastic

1. Turn off all surface units. Remove hot pans.

2. Wearing an oven mitt, use a single-edge razor-blade scraper to move the spill

to a cool area of the cooktop. Remove the spill with paper towels.

3. Any remaining spillover should be left until the surface of the cooktop has

4. Don’t use the surface units again until all of the residue has been completely

removed. NOTE If pitting or indentations in the glass surface have already occurred, the cooktop glass will have to be replaced. In this case, service will be necessary. Removing and reinstalling the oven door How to remove the door CAUTION

• The door is very heavy. Be careful when removing and lifting the door. Do not lift the door by the handle.

• Turn the power OFF before removing the door. Hinge lockHinge lock Locked positionLocked position Unlocked positionUnlocked position

1. Open the door completely.

2. Pull the hinge locks down toward the door frame to the unlocked position.

Removing metal marks and scratches

1. Be careful not to slide pots and pans across your cooktop. It will leave marks on

the cooktop surface. You can remove these marks by applying ceramic cooktop cleaner with a cleaning pad for ceramic cooktops.

2. If pots with a thin overlay of aluminum or copper are allowed to boil dry, the

overlay may leave black discoloration on the cooktop. You should remove this discoloration immediately or it may become permanent. WARNING Carefully check the bottoms of pans for roughness that may scratch the cooktop. Cleaning the cooktop seal To clean the seal around the edges of the glass, lay a wet cloth on it for a few minutes, then wipe clean with a nonabrasive cleaner. Potential for permanent damage to the glass surface

• Sugary spillovers (such as jellies, fudge, candy, syrups) or melted plastics can cause pitting of the surface of your cooktop. This is not covered under the warranty. You should clean the spill while it is still hot. Take special care when removing hot substances. Refer to the section below.

• When using a scraper, be sure it is new and the razor blade is still sharp. Do not use a dull or nicked blade.62 English Maintaining your appliance Maintaining your appliance How to re-install the door Hinge armHinge arm Bottom Bottom edge of edge of slotslot IndentationIndentation

1. Firmly grasp both sides of the door at the top.

2. With the door at the same angle as the removal position, slide the indentation

of the hinge arm into the bottom edge of the hinge slot. The notch in the hinge arm must be fully inserted into the bottom of the slot. Hinge lockHinge lock Locked positionLocked positionUnlocked positionUnlocked position

3. Open the door fully. If the door will not open fully, the indentation is not

inserted correctly in the bottom edge of the slot.

4. Push the hinge locks up against the front frame of the oven cavity to the locked

5. Close the oven door.

about 5°about 5° Fig. 1

3. Firmly grasp both sides of the door at

4. Close the door to the door removal

position, which is approximately 5 degrees from vertical (Fig. 1). Fig. 2

5. Lift door up and out until the hinge arm

is clear of the slot (Fig. 2).English 63 Maintaining your appliance Changing the oven light The oven light is a standard 40-watt appliance bulb. It will come on when the oven door is open. When the oven door is closed, press the pad to turn it on or off. It will not work during a self-cleaning cycle. RemoveRemove Glass bulb coverGlass bulb cover BulbBulb ReplaceReplace

1. Make sure the oven and the bulb are

2. Unplug the range or disconnect the

3. Turn the glass bulb cover in the back of

the oven counterclockwise to remove.

4. Turn the bulb counterclockwise to

remove it from its socket.

5. Insert a new 40-watt appliance bulb, and

then turn it clockwise to tighten. Replace the bulb cover by turning clockwise.

6. Plug in the range or reconnect the power.

CAUTION Before changing your oven light bulb, disconnect the electrical power to the range at the main fuse or circuit breaker panel. Make sure the oven and the bulb are cool. Removing and reinstalling the storage drawer

1. Slide open the drawer until it stops.

2. Locate the roller guide clips on either

side. Using both hands, pull down the left clip while lifting the right clip, and then remove the drawer.

3. Clean the drawer in warm, soapy water

using a cloth or soft brush. Then, rinse and dry it thoroughly.

4. Put the drawer in the roller guides on

either side, and then snap the clips into place.64 English Troubleshooting Troubleshooting Control display Problem Possible cause Solution The display goes blank. A fuse in your home may be blown or the circuit breaker tripped. Replace the fuse or reset the circuit breaker. The display ashes. There was a power failure. Reset the clock. Cooktop Problem Possible cause Solution The surface units will not maintain a rolling boil or will not cook fast enough. You may be using inappropriate cookware. Use pans that are at and match the diameter of the surface unit selected. In some areas, the power (voltage) may be low. Cover the pan with a lid until the desired heat is obtained. The surface units will not turn on. A fuse in your home may be blown or a circuit breaker may have tripped. Replace the fuse or reset the circuit breaker. The cooktop controls are set improperly. Check if the correct control is set for the surface unit you are using. Areas of discoloration on the cooktop. Food spillover was not cleaned. Refer to the section on the care and cleaning of the glass cooktop on page 60. The surface is hot and the model features a light- colored cooktop. This is normal. The surface may appear discolored when it is hot. This is temporary and will disappear as the glass cools. Troubleshooting Troubleshooting Samsung works hard to ensure that you don’t have problems with your new electric range. If you run into unexpected trouble, look rst for a solution in the tables below. If you’re still having trouble after trying the suggested solution, call Samsung at 1-800-SAMSUNG (1-800-726-7864). Installation Problem Possible cause Solution The range is not level. The appliance has been installed improperly.

• Place the oven rack in the center of the oven. Place a level on the oven rack. Adjust the leveling legs at the base of the range until the oven rack is level.

• Insure the oor is level and strong and stable enough to adequately support the range. The oor is sagging or sloping. Contact a carpenter to correct the situation. The kitchen cabinets are not properly aligned and make the range appear to be not level. Insure the cabinets are square and provide sufcient room for installation. The appliance must be accessed for servicing and cannot be moved easily. The kitchen cabinets are not square and too close to the appliance. Contact a builder or installer to make the appliance accessible. Carpet is interfering with movement of the range. Provide sufcient space so the range can be lifted over the carpet.English 65 Troubleshooting Problem Possible cause Solution Brown streaks or specks. Boilovers have been cooked onto the surface.

• Wait until the surface cools down. Then, use a single-edge razor-blade scraper at approximately a 45° angle against the glass surface to remove the soil.

• See the section on the Care and cleaning of the glass cooktop on page 60. Areas of discoloration with metallic sheen. Mineral deposits from water and food have been left on the surface of the cooktop.

• Remove using a ceramic- glass cooktop cleaning cream.

• Use cookware with clean, dry bottoms. Clean the cooktop with a ceramic cleaning agent regularly every week. "Cracking" or "popping" sound. This is the sound of the metal heating and cooling during both the cooking and self-cleaning functions. This is normal operation, and not a system failure. Use the range as usual. Problem Possible cause Solution The surface unit frequently cycles on and off. The element will cycle on and off to maintain the power setting. This is normal operation, and not a system failure. Use the range as usual. The surface unit stops glowing when changed to a lower setting. This is normal. The unit is still on and hot. Scratches or abrasions on the cooktop surface. The cooktop is being cleaned improperly. Scratches are not removable. Tiny scratches will become less visible in time as a result of cleaning. Use ceramic glass top cleaning cream. Do not use chemical or corrosive agents. These agents may damage the surface of the product. Cookware with rough bottoms was used on the cooktop or there were coarse particles (e.g., salt or sand) present between the cookware and the surface of the cooktop. To avoid scratches, follow the recommended cleaning procedures. Make sure cookware bottoms are clean before use, and use cookware with smooth bottoms. Cookware has been slid across the cooktop surface.66 English Troubleshooting Troubleshooting Oven Problem Possible cause Solution The oven will not turn on. The range is not completely plugged into the electrical outlet. Make sure the electrical plug is inserted into a live, properly grounded outlet. A fuse in your home may be blown or a circuit breaker may have tripped. Replace the fuse or reset the circuit breaker. The oven controls have been set improperly. See the chapter on operating the oven starting on page 32. The oven is too hot. Allow the oven to cool. Incomplete service wiring. Call for service. Power outage. Check to see if the house lights will turn on. If necessary, call your local electric company for service. The oven light will not turn on. The light bulb is loose or defective. Tighten or replace the bulb. The switch operating the light is broken. Call for service. The appliance will not turn on. The appliance is not completely plugged into the electrical outlet or a fuse in your home may be blown or a circuit breaker may have tripped. Make sure the power cord is plugged into a live, properly grounded outlet. Check the fuse and circuit breakers. Incomplete service wiring. Call for service. Power outage. Check to see if the house lights will turn on. If necessary, call your local electric company for service. Problem Possible cause Solution The oven smokes excessively during broiling. The oven controls have not been set properly. Refer to the section on broiling guide on page 43. The meat has been placed too close to the element. Reposition the rack to provide proper clearance between the meat and the element. Preheat the broil element for searing. The meat has not been properly prepared. Remove the excess fat from the meat. Cut away fatty edges that may curl, leaving the lean intact. Grease has built up on oven surfaces. Regular cleaning is necessary when broiling frequently. Food does not bake or roast properly. The oven controls have not been set correctly. See the chapter on operating the oven starting on page 32. The oven rack has been positioned incorrectly or is not level. See the section on using the oven racks on page 50. Incorrect cookware or cookware of improper size is being used. The oven sensor needs to be adjusted. See the section on Settings on page 52.English 67 Troubleshooting Problem Possible cause Solution The oven door will not open after a self- cleaning cycle. The oven is too hot. Allow the oven to cool. The oven is not clean after a self-cleaning cycle. The oven controls were not set correctly. See the section on self- cleaning on page 55. The oven was heavily soiled. Wipe up heavy spillovers before starting the self- cleaning cycle. Heavily soiled ovens may need to be self- cleaned again or for a longer period of time. Steam is coming out of the vent. When using the convection feature, it is normal to see steam coming out of the oven vent. This is normal operation and not a system failure. Use the range as usual. As the number of racks or amount of food being cooked increases, the amount of visible steam will increase. A burning or oily odor is coming from the vent. This is normal in a new oven and will disappear in time.

• To speed the process, set a self-cleaning cycle for a minimum of 3 hours.

• See the section on self- cleaning on page 55. Strong odor. An odor coming from the insulation around the inside of the oven is normal for the rst few times the oven is used. Operate the oven empty on the bake setting at 400 °F for 1 hour. Problem Possible cause Solution Food does not broil properly. The serving size may not be appropriate. Refer to the broiling guide for serving sizes on page 43, and then try again. The rack has not been properly positioned. See the broiling guide for serving sizes on page 43. The cookware is not suited for broiling. Use suitable cookware. In some areas, the power (voltage) may be low.

• Preheat the broil element for 10 minutes.

• See the broiling guide for serving sizes on page 43. The oven temperature is too hot or too cold. The oven sensor needs to be adjusted. See the section on Settings on page 52. The oven will not self-clean. The oven temperature is too high to start a self-clean operation. Allow the range to cool and then reset the controls. The oven controls have been set incorrectly. See the section on self- cleaning on page 55. A self-cleaning cycle cannot be started if the oven lock feature has been activated or if a cooktop element is on. Deactivate the oven lock. Make sure all surface elements are turned off. Excessive smoking during a self-cleaning cycle. There is excessive soiling in the oven. Tap Power Off. Open the windows to rid the room of smoke. Wait until the self- cleaning cycle is cancelled. Wipe up the excessive soil and then start the self- cleaning cycle again.68 English Troubleshooting Troubleshooting Problem Possible cause Solution Fan noise. A convection fan may automatically turn on and off. This is not a system failure but normal operation. Oven fan is making a noise, or won't turn off. The cooling fan is not visible, but you will hear it running whenever the electronics get hot and turn off when the electronics are cool. This is normal operation to cool the oven, cooling fan automatically shuts down when the oven cools. Oven racks are difcult to slide. The shiny, silver-colored racks were cleaned in a self- cleaning cycle. Apply a small amount of vegetable oil to a paper towel, and then wipe the edges of the oven racks with the paper towel. Drawer Problem Possible cause Solution The drawer does not slide smoothly or drags. The drawer is out of alignment. Fully extend the drawer and push it all the way in. See page 63. The drawer is overloaded or the load is unbalanced. Reduce weight. Redistribute drawer contents. Excessive condensation in the drawer. There is liquid present in the drawer. Remove the liquid. Uncovered foods. Cover food with a lid. Information codes Oven Displayed code Possible cause Solution C-d0 There is a short in the control panel. Tap Power Off, and then restart the oven. If the problem persists, disconnect all power to the range for at least 30 seconds and then reconnect the power. If this does not solve the problem, call for service. C-d1 The door lock is misaligned. C-F0 This code occurs if communication between the Main and Sub PBA is interrupted. C-F2 This code occurs if communication between the Main and Touch is interrupted. C-20 The oven sensor is open when the oven is operating. There is a short in the Oven sensor. C-21 This code occurs if the internal temperature rises abnormally high.English 69 Troubleshooting Cooktop Displayed code Possible cause Solution

This code occurs if communication between the Main and Inverter PBA is interrupted. Power Off, and then Power On to the setting you want again. If the problem persists, disconnect all power to the range for at least 30 seconds and then reconnect the power. If this does not solve the problem, call for service.

The top sensor is open when the burner is operating. Call for service The top sensor is short when the burner is operating.

The IGBT sensor is open when the burner is operating. The IGBT sensor is short when the burner is operating.

This code occurs if the DC fan motor is open or locked. Displayed code Possible cause Solution C-22 The sub PCB sensor is open when the oven is operating. Press Off, and then restart the oven. If the problem persists, disconnect all power to the range for at least 30 seconds and then reconnect the power. If this does not solve the problem, call for service. There is a short in the sub PCB sensor. C-23 The temperature probe sensor is short when the oven is operating. C-30 The main PCB sensor is open when the oven is operating. There is a short in the main PCB sensor. C-31 This code occurs if the PCB temperature rises abnormally high. Call for service Bad line This error message appears if the power cord is installed improperly. If the power connection is plugged in improperly, that code appears on the display. Reconnect the power connection properly, and the message disappears. C-A2 This code occurs if the sub PCB temperature rises abnormanlly high. Press Off. Check the oven vent and cooling vent. If the vent is closed, never block the vent by anything. After cooling the oven, restart the oven. If this does not solve the problem, call for service.70 English Warranty (U.S.A) Warranty (U.S.A) PLEASE DO NOT DISCARD. THIS PAGE REPLACES THE WARRANTY PAGE IN THE USE & CARE GUIDE

SAMSUNG ELECTRIC RANGE

LIMITED WARRANTY TO ORIGINAL PURCHASER WITH PROOF OF PURCHASE This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS AMERICA, INC. (SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in materials or workmanship for the limited warranty period, starting on the date of delivery to the original consumer purchaser, of: One (1) Year Parts and Labor This limited warranty is valid only on products purchased and used in the United States that have been installed, operated, and maintained according to the instructions attached to or furnished with the product. To receive warranty service, the purchaser must contact SAMSUNG at the address or phone number provided below for problem determination and service procedures. Warranty service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale and/or proof of delivery must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG’s authorized service center to receive warranty service. SAMSUNG will provide in-home service within the contiguous United States during the warranty period at no charge, subject to availability of SAMSUNG authorized servicers within the customer’s geographic area. If in-home service is not available, SAMSUNG may elect, at its option, to provide transportation of the product to and from an authorized service center. If the product is located in an area where service by a SAMSUNG authorized servicer is not available, you may be responsible for a trip charge or required to bring the product to a SAMSUNG authorized service center for service. To receive in-home service, product must be unobstructed and accessible to the service agent. Displayed code Possible cause Solution

This code appears if the internal temperature of a burner rises abnormally high. Power Off, and then Power On to the setting you want again. If the problem persists, disconnect all power to the range for at least 30 seconds and then reconnect the power. If this does not solve the problem, call for service.

UP The voltage is too high or low. Check the power connection and make sure to turn the appliance on after regulating the voltage.

The touch-enabled IC communicates abnormally. Restart the appliance using the POWER key. If the problem continues, disconnect power for more than 30 seconds. Then, restart the appliance. If the problem still continues, contact a local Samsung service center.

Communications between main and EEP-ROM failed. TroubleshootingEnglish 71 Warranty (U.S.A)

EXCLUSION OF IMPLIED WARRANTIES

IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW. Some states do not allow limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you. This warranty gives you specic rights, and you may also have other rights, which vary from state to state.

LIMITATION OF REMEDIES

YOUR SOLE AND EXCLUSIVE REMEDY IS PRODUCT REPAIR, PRODUCT REPLACEMENT, OR REFUND OF THE PURCHASE PRICE AT SAMSUNG’S OPTION, AS PROVIDED IN THIS LIMITED WARRANTY. SAMSUNG SHALL NOT BE LIABLE FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO TIME WAY FROM WORK, HOTELS AND/OR RESTAURANT MEALS, REMODELING EXPENSES, LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some states do not allow exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specic rights, and you may also have other rights, which vary from state to state. SAMSUNG does not warrant uninterrupted or error-free operation of the product. No warranty or guarantee given by any other person, rm, or corporation with respect to this product shall be binding on SAMSUNG. To obtain warranty service, please contact SAMSUNG at: Samsung Electronics America, Inc. 85 Challenger Road Ridgeeld Park, NJ 07660 1-800-SAMSUNG (726-7864) and www.samsung.com/us/support During the applicable warranty period, a product will be repaired, replaced, or the purchase price refunded, at the sole option of SAMSUNG. SAMSUNG may use new or reconditioned parts in repairing a product, or replace the product with a new or reconditioned product. Replacement parts and products are warranted for the remaining portion of the original product’s warranty or ninety (90) days, whichever is longer. All replaced parts and products are the property of SAMSUNG and you must return them to SAMSUNG. This limited warranty covers manufacturing defects in materials or workmanship encountered in normal household, noncommercial use of this product and shall not cover the following: damage that occurs in shipment, delivery, installation, and uses for which this product was not intended; damage caused by unauthorized modication or alteration of the product; product where the original factory serial numbers have been removed, defaced, changed in any way, or cannot be readily determined; cosmetic damage including scratches, dents, chips, and other damage to the product’s nishes; damage caused by abuse, misuse, pest infestations, accident, re, oods, or other acts of nature or God; damage caused by use of equipment, utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied or authorized by SAMSUNG; damage caused by incorrect electrical line current, voltage, uctuations and surges; damage caused by failure to operate and maintain the product according to instructions; in-home instruction on how to use your product; and service to correct installation not in accordance with electrical or plumbing codes or correction of household electrical or plumbing (i.e., house wiring, fuses, or water inlet hoses). In addition, damage to the glass cooktop caused by (i) use of cleaners other than the recommended cleaners and pads or (ii) hardened spills of sugary materials or melted plastic that are not cleaned according to the directions in the use and care guide are not covered by this limited warranty. The cost of repair or replacement under these excluded circumstances shall be the customer’s responsibility. Visits by an authorized servicer to explain product functions, maintenance or installation are not covered by this limited warranty.Please contact SAMSUNG at the number below for assistance with any of these issues.72 English Warranty (CANADA) SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specied above. All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG. Replacement parts and products assume the remaining original warranty, or ninety (90) days, whichever is longer. This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, noncommercial use of this product and shall not apply to the following: damage which occurs in shipment; delivery and installation; applications and uses for which this product was not intended; altered product or serial numbers; cosmetic damage or exterior nish; accidents, abuse, neglect, re, water, lightning or other acts of nature; use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied or authorized by SAMSUNG which damage this product or result in service problems; incorrect electrical line voltage, uctuations and surges; customer adjustments and failure to follow operating instructions, maintenance and environmental instructions that are covered and prescribed in the instruction book; product removal and reinstallation; problems caused by pest infestations, and overheating or overcooking by user. This limited warranty shall not cover cases of incorrect electric current, voltage or supply, light bulbs, house fuses, house wiring, cost of a service call for instructions, or xing installation errors. Furthermore, damage to the glass cooktop caused by the use of cleaners other than the recommended cleaners and pads, damage to the glass cook top caused by hardened spills of sugary materials or melted plastic that are not cleaned according to the directions in the use and care guide are not covered. SAMSUNG does not warrant uninterrupted or error-free operation of the product. Warranty (CANADA) PLEASE DO NOT DISCARD. THIS PAGE REPLACES THE WARRANTY PAGE IN THE USE & CARE GUIDE

This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS CANADA, INC. (SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in materials and workmanship for a limited warranty period of: One (1) Year Parts and Labor, One (1) Year Parts Warranty For Glass Cooktop This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in the CANADA. To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures. Warranty service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG’s authorized service center. Samsung will provide in-home service during the warranty period at no charge subject to availability within the contiguous CANADA. In home service is not available in all areas. To receive in home service product must be unobstructed and accessible to the service agent. If service is not available Samsung may elect to provide transportation of the product to and from an authorized service center.English 73 Appendix EXCEPT AS SET FORTH HEREIN THERE ARE NO WARRANTIES ON THIS PRODUCT EITHER EXPRESS OR IMPLIED AND SAMSUNG DISCLAIMS ALL WARRANTIES INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY, INFRINGEMENT OR FITNESS FOR A PARTICULAR PURPOSE. NO WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT, IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY. Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specic legal rights, and you may also have other rights which vary from state to state. To obtain warranty service, please contact SAMSUNG at: Samsung Electronics Canada Inc. 2050 Derry Road West, Mississauga, Ontario L5N 0B9 Canada 1-800-SAMSUNG (726-7864) and www.samsung.com/ca/support (English) www.samsung.com/ca_fr/support (French) Appendix Open Source Announcement The software included in this product contains open source software. You may obtain the complete corresponding source code for a period of three years after the last shipment of this product by contacting our support team via http://opensource. samsung.com (Please use the “Inquiry” menu.) It is also possible to obtain the complete corresponding source code in a physical medium such as a CD-ROM; a minimal charge will be required. The following URL http://opensource.samsung.com/opensource/COMMON_TZ7_0/ seq/0 leads to the open source license information as related to this product. This offer is valid to anyone in receipt of this information.Please be advised that the Samsung warranty does NOT cover service calls to explain product operation, correct improper installation, or perform normal cleaning or maintenance. QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT U.S.A Consumer Electronics 1-800-SAMSUNG (726-7864) www.samsung.com/us/support CANADA 1-800-SAMSUNG (726-7864) www.samsung.com/ca/support (English) www.samsung.com/ca_fr/support (French)

Scan the QR code* or visit www. samsung.com/spsn to view our helpful How-to Videos and Live Shows

1) Turn off your induction cooktop.

2) Remove Temp Probe.

3) Check active timer and cancel it.

4) Begin Bake mode. Sabbath function is only available in bake mode.

5) Be sure the oven light is on or off. Can’t change it during Sabbath mode.

(Multi-étapes). Multi stagesYou can set the heat level for each stage. Start Stage 1Heat level

1) Turn off your induction cooktop.

2) Remove Temp Probe.

3) Check active timer and cancel it.

4) Begin Bake mode. Sabbath function is only available in bake mode.

5) Be sure the oven light is on or off. Can’t change it during Sabbath mode.
