| Brand | Hoover |
| Model | HFREEZE 500 HBOU 172N |
| Product type | Chest freezer |
| Climate class | SN, N, ST, T (10°C to 43°C) |
| Refrigerant | R600a (isobutane) |
| Insulation | Cyclopentane |
| Power supply | 220-240 V ~ 50 Hz |
| Number of compartments | 7 (2 flip-up flaps + 5 drawers) |
| Super freeze function | Yes, activate 2-3 h before, automatic shut-off after 24 h |
| Temperature setting | -16°C, -18°C, -20°C, -22°C, -24°C in steps |
| Power failure memory | Yes, restores settings after a power cut |
| Defrosting | Manual, recommended when frost >3 mm |
| Cleaning | Baking soda and warm water solution |
| Safety | Door seal, ventilation, automatic shut-off in case of overheating |
| Available spare parts (thermostats, sensors, boards, light sources) | 7 years from the date the last model was placed on the market |
| Available spare parts (handles, hinges, trays, bins) | 7 years from the date the last model was placed on the market |
| Available spare parts (door seals) | 10 years from the date the last model was placed on the market |
| Warranty | 2 years (EU), varies by country |
| Technical support | Haier Europe website |
Frequently Asked Questions - HFREEZE 500 HBOU 172N HOOVER
How to set the freezer temperature?
Use the temperature setting button (A) on the control panel. Press multiple times to scroll through settings: -16°C, -18°C, -20°C, -22°C, -24°C and the Super freeze function. The display (B) shows the current setting.
How to activate the Super freeze function?
Press the temperature setting button until the snowflake (Super freeze) is selected. Activate it 2 to 3 hours before introducing large quantities of food. It turns off automatically after 24 hours.
What to do if the freezer does not work?
Check that the appliance is plugged in and the house fuses are intact. Make sure the freezer has not been turned off and the socket works by testing another appliance. If the problem persists, contact customer service.
How to defrost the freezer?
Turn off and unplug the appliance. Remove frozen food and place it in a cool place. Leave the door open to speed up defrosting. Collect the water at the bottom, dry thoroughly, then plug back in and set the desired temperature. Never use sharp objects or naked flames.
Why is the door difficult to open just after closing?
This is normal, due to a pressure difference. Wait a few minutes for the pressure to equalize and the door will open normally.
How to clean the interior of the freezer?
Unplug the appliance. Use a mild baking soda and warm water solution to clean the drawers and surfaces. Avoid abrasive cleaners. Rinse and dry thoroughly before plugging back in.
Is it possible to reverse the door opening direction?
Yes, you can reverse the door. Disassemble the top and bottom hinges, remove the door, then reposition the hinges on the opposite side. Ensure the seals are well sealed after the operation. Ask for help from another person.
What to do in case of a power cut?
Do not open the door. Frozen food remains intact for up to 20 hours. If the power outage lasts longer, check the food and consume it quickly or refreeze after cooking.
How to store food in the freezer?
Place food in small packages (<2.5 kg), dry and labeled. Use the drawers: raw meat at the bottom, frozen vegetables in the middle, ice cream at the top. Do not overload to ensure good air circulation.
What to do if excessive frost forms?
Check that the door closes properly and the seal is not damaged. If frost exceeds 3 mm, defrost the appliance. Excessive buildup may indicate a seal problem or frequent door use.
