d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool.Power tools are dangerous in the hands of untrained users.e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use.Many accidentsare caused by poorly maintained power tools.f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.g) Use the power tool, accessories and tool bits etc., in accordance with theseinstructions, taking into account the working conditions and the work to beperformed.Use of the power tool for operations different from those intended couldresult in a hazardous situation.5) Battery tool use and carea) Recharge only with the charger specified by the manufacturer. A charger that issuitable for one type of battery pack may create a risk of fire when used with anotherbattery pack. b) Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.c) When battery pack is not in use, keep it away from other metal objects likepaper clips, coins, keys, nails, screws, or other small metal objects that canmake a connection from one terminal to another. Shorting the battery terminalstogether may cause burns or a fire.d) Under abusive conditions, liquid may be ejected from the battery, avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritationor burns.6) Servicea) Have your power tool serviced by a qualified repair person using only identicalreplacement parts.This will ensure that the safety of the power tool is maintained.SAFETY INSTRUCTIONS FOR ALL OPERATIONSSafety Warnings Common for Grinding, Sanding, Wire Brushing, Polishing orAbrasive, Cutting-Off Operationsa) This power tool is intended to function as a grinder, sander, wire brush, polisher or cut-off tool. Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.b) Do not use accessories which are not specifically designed and recommended by the tool manufacturer. Just because the accessory can be attached to your power tool, it does not assure safe operation.c) The rated speed of the accessory must be at least equal to the maximumspeed marked on the power tool. Accessories running faster than their ratedspeed can break and fly apart.d) The outside diameter and the thickness of your accessory must be within the capacity rating of your power tool. Incorrectly sized accessories cannot be adequately guarded or controlled.e) The arbour size of wheels, flanges, backing pads or any other accessorymust properly fit the spindle of the power tool. Accessories with arbour holesthat do not match the mounting hardware of the power tool will run out of balance,vibrate excessively and may cause loss of control. f) Do not use a damaged accessory. Before each use inspect the accessorysuch as abrasive wheel for chips and cracks, backing pad for cracks, tear orexcess wear, wire brush for loose or cracked wires. If power tool or accessory is dropped, inspect for damage or install an undamaged accessory. After inspecting and installing an accessory, position yourself andbystanders away from the plane of the rotating accessory and run the powertool at maximum no-load speed for one minute. Damaged accessories will normally break apart during this test time.g) Wear personal protective equipment. Depending on application, use faceshield, safety goggles or safety glasses. As appropriate, wear dust mask,hearing protectors, gloves and work shop apron capable of stopping smallabrasive or workpiece fragments. The eye protection must be capable of stopping flying debris generated by various operations. The dust mask or respiratormust be capable of filtrating particles generated by your operation. Prolonged exposure to high intensity noise may cause hearing loss.h) Keep bystanders a safe distance away from work area. Anyone entering the work area must wear personal protective equipment. Fragments of workpiece or of a broken accessory may fly away and cause injury beyond immediate area ofoperation.i) Hold power tool by insulated gripping surfaces only, when performing anoperation where the cutting accessory may contact hidden wiring or its own cord. Cutting accessory contacting a “live” wire may make exposed metal parts of the power tool “live” and shock the operator. j) Position the cord clear of the spinning accessory. If you lose control, the cordmay be cut or snagged and your hand or arm may be pulled into the spinningaccessory.k) Never lay the power tool down until the accessory has come to a complete stop. The spinning accessory may grab the surface and pull the power tool out of your control.l) Do not run the power tool while carrying it at your side. Accidental contact withthe spinning accessory could snag your clothing, pulling the accessory into yourbody.m)Regularly clean the power tool’s air vents. The motor’s fan will draw the dustinside the housing and excessive accumulation of powdered metal may cause electrical hazards. n) Do not operate the power tool near flammable materials. Sparks could ignite these materials. o) Do not use accessories that require liquid coolants. Using water or other liquid coolants may result in electrocution or shock. p) Do not use Type 11 (flaring cup) wheels on this tool. Using inappropriate accessories can result in injury. q) Always use side handle. Tighten the handle securely. The side handle should always be used to maintain control of the tool at all times.Causes and Operator Prevention of KickbackKickback is a sudden reaction to a pinched or snagged rotating wheel, backing pad,brush or any other accessory. Pinching or snagging causes rapid stalling of therotating accessory which in turn causes the uncontrolled power tool to be forced inthe direction opposite of the accessory’s rotation at the point of the binding. For example, if an abrasive wheel is snagged or pinched by the workpiece, theedge of the wheel that is entering into the pinch point can dig into the surface of thematerial causing the wheel to climb out or kick out. The wheel may either jumptoward or away from the operator, depending on direction of the wheel’s movementat the point of pinching. Abrasive wheels may also break under these conditions.Kickback is the result of tool misuse and/or incorrect operating procedures or conditions and can be avoided by taking proper precautions as given below:a) Maintain a firm grip on the power tool and position your body and arm toallow you to resist kickback forces. Always use auxiliary handle, if provided,for maximum control over kickback or torque reaction during start up. Theoperator can control torque reaction or kickback forces, if proper precautions aretaken. b) Never place your hand near the rotating accessory. Accessory may kickback over your hand.c) Do not position your body in the area where power tool will move if kickback occurs. Kickback will propel the tool in direction opposite to the wheel’s movement at the point of snagging.d) Use special care when working corners, sharp edges etc. Avoid bouncing andsnagging the accessory. Corners, sharp edges or bouncing have a tendency tosnag the rotating accessory and cause loss of control or kickback. e) Do not attach a saw chain woodcarving blade or toothed saw blade. Such blades create frequent kickback and loss of control. General Power Tool Safety Warnings WARNING! Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.The term “power tool” in the warnings refers to your mains-operated (corded)power tool or battery-operated (cordless) power tool.1) Work area safetya) Keep work area clean and well lit.Cluttered or dark areas invite accidents.b) Do not operate power tools in explosive atmospheres, such as in the presenceof flammable liquids, gases or dust. Power tools create sparks which may ignite thedust or fumes.c) Keep children and bystanders away while operating a power tool. Distractions cancause you to lose control.2) Electrical safetya) Power tool plugs must match the outlet. Never modify the plug in any way. Donot use any adapter plugs with earthed (grounded) power tools. Unmodified plugsand matching outlets will reduce risk of electric shock.b) Avoid body contact with earthed or grounded surfaces such as pipes, radiators,ranges and refrigerators. There is an increased risk of electric shock if your body isearthed or grounded.c) Do not expose power tools to rain or wet conditions.Water entering a power toolwill increase the risk of electric shock.d) Do not abuse the cord. Never use the cord for carrying, pulling or unpluggingthe power tool. Keep cord away from heat, oil, sharp edges or moving parts.Damaged or entangled cords increase the risk of electric shock. e) When operating a power tool outdoors, use an extension cord suitable for outdoor use.Use of a cord suitable for outdoor use reduces the risk of electric shock. f) If operating a power tool in a damp location is unavoidable, use a residual currentdevice (RD) protected supply. Use of an RCD reduces the risk of electric shock.3) Personal safetya) Stay alert, watch what you are doing and use common sense when operating apower tool. Do not use a power tool while you are tired or under the influence ofdrugs, alcohol or medication. A moment of inattention while operating power toolsmay result in serious personal injury.b) Use personal protective equipment. Always wear eye protection.Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protectionused for appropriate conditions will reduce personal injuries.c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool.Carrying power tools with your finger on the switch or energising power tools that havethe switch on invites accidents.d) Remove any adjusting key or wrench before turning the power tool on. A wrenchor a key left attached to a rotating part of the power tool may result in personal injury.e) Do not overreach. Keep proper footing and balance at all times. This enables bet-ter control of the power tool in unexpected situations.f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothingand gloves away from moving parts.Loose clothes, jewellery or long hair can becaught in moving parts.g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.Use of dust collectioncan reduce dust-related hazards.4) Power tool use and carea) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.b) Do not use the power tool if the switch does not turn it on and off. Any power toolthat cannot be controlled with the switch is dangerous and must be repaired.c) Disconnect the plug from the power source and/or the battery pack from thepower tool before making any adjustments, changing accessories, or storingpower tools. Such preventive safety measures reduce the risk of starting the powertool accidentally.INFORMATION YOU SHOULD KNOW• Wait until grinding wheel reaches full speed before applying work.• Hold grinder at proper angle, as shown in Figure 10 and 11.VEA EL ESPAÑOL EN LA CONTRAPORTADA.SAVE THIS MANUAL FOR FUTURE REFERENCE.INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y PÓLIZA DE GARANTÍA.ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO. CAT. NO. FS8500AG FORM NO. 496437-00 Rev. 1 JAN. ‘08Copyright © 2008 Black & Decker Printed in China

HANK HANK YOU YOU FOR FOR CHOOSING CHOOSING

.Safety Warnings Specific for Grinding and Abrasive Cutting-Off OperationsOperationsa) Use only wheel types that are recommended for your power tool and the specific guard designed for the selected wheel. Wheels for which the power tool was not designed cannot be adequately guarded and are unsafe.b) The guard must be securely attached to the power tool and positioned formaximum safety, so the least amount of wheel is exposed towards the operator. The guard helps to protect operator from broken wheel fragments andaccidental contact with wheel. c) Wheels must be used only for recommended applications. For example: donot grind with the side of cut-off wheel. Abrasive cut-off wheels are intended forperipheral grinding, side forces applied to these wheels may cause them to shatter.d) Always use undamaged wheel flanges that are of correct size and shape for your selected wheel. Proper wheel flanges support the wheel thus reducing the possibility of wheel breakage. Flanges for cut-off wheels may be different fromgrinding wheel flanges. e) Do not use worn down wheels from larger power tools. Wheel intended for larger power tool is not suitable for the higher speed of a smaller tool and may burst.Additional Safety Warnings Specific for Abrasive Cutting-Off Operationa) Do not “jam” the cut-off wheel or apply excessive pressure. Do not attempt to make an excessive depth of cut. Overstressing the wheel increases the loading and susceptibility to twisting or binding of the wheel in the cut and the possibility ofkickback or wheel breakage. b) Do not position your body in line with and behind the rotating wheel. When the wheel, at the point of operation, is moving away from your body, the possiblekickback may propel the spinning wheel and the power tool directly at you.c) When wheel is binding or when interrupting a cut for any reason, switch offthe power tool and hold the power tool motionless until the wheel comes to acomplete stop. Never attempt to remove the cut-off wheel from the cut whilethe wheel is in motion otherwise kickback may occur. Investigate and take corrective action to eliminate the cause of wheel binding.d) Do not restart the cutting operation in the workpiece. Let the wheel reach full speed and carefully reenter the cut. The wheel may bind, walk up or kickback if the power tool is restarted in the workpiece.e) Support panels or any oversized workpiece to minimize the risk of wheel pinching and kickback. Large workpieces tend to sag under their own weight. Supports must be placed under the workpiece near the line of cut and near theedge of the workpiece on both sides of the wheel.f) Use extra caution when making a “pocket cut” into existing walls or otherblind areas. The protruding wheel may cut gas or water pipes, electrical wiring orobjects that can cause kickback.Safety Warnings Specific for Sanding Operationsa) Do not use excessively oversized sanding disc paper. Follow manufacturersrecommendations, when selecting sanding paper. Larger sanding paper extending beyond the sanding pad presents a laceration hazard and may causesnagging, tearing of the disc or kickback.Safety Warnings Specific for Polishing Operationsa) Do not allow any loose portion of the polishing bonnet or its attachment strings to spin freely. Tuck away or trim any loose attachment strings. Loose and spinning attachment strings can entangle your fingers or snag on the workpiece.Safety Warnings Specific for Wire Brushing Operationsa) Be aware that wire bristles are thrown by the brush even during ordinaryoperation. Do not overstress the wires by applying excessive load to the brush. The wire bristles can easily penetrate light clothing and/or skin. b) If the use of a guard is recommended for wire brushing, do not allow any interference of the wire wheel or brush with the guard. Wire wheel or brush may expand in diameter due to work and centrifugal forces. Additional Safety Information

• Do not use Type 1 flat cut-off abrasive or diamond wheels without proper guard. (Guard not included with unit.)

WARNING: ALWAYS use safety glasses. Everyday eyeglasses are NOT safety glasses.

Also use face or dust mask if cutting operation is dusty. ALWAYS WEAR CERTIFIEDSAFETY EQUIPMENT:• ANSI Z87.1 eye protection (CAN/CSA Z94.3),• ANSI S12.6 (S3.19) hearing protection,• NIOSH/OSHA/MSHA respiratory protection.WARNING: Some dust created by power sanding, sawing, grinding, drilling, andother construction activities contains chemicals known to the State of California tocause cancer, birth defects or other reproductive harm. Some examples of thesechemicals are:• lead from lead-based paints,• crystalline silica from bricks and cement and other masonry products, and • arsenic and chromium from chemically-treated lumber.Your risk from these exposures varies, depending on how often you do this type of work.To reduce your exposure to these chemicals: work in a well ventilated area, and work withapproved safety equipment, such as those dust masks that are specially designed to filterout microscopic particles.• Avoid prolonged contact with dust from power sanding, sawing, grinding, drilling,and other construction activities. Wear protective clothing and wash exposedareas with soap and water. Allowing dust to get into your mouth, eyes, or lay on the skinmay promote absorption of harmful chemicals.WARNING: Use of this tool can generate and/or disburse dust, which may cause seriousand permanent respiratory or other injury. Always use NIOSH/OSHA approved respiratoryprotection appropriate for the dust exposure. Direct particles away from face and body.WARNING: Always wear proper personal hearing protection that conforms to ANSIS12.6 (S3.19) during use. Under some conditions and duration of use, noise from thisproduct may contribute to hearing loss.WARNING: Always use eye protection. All users and bystanders must wear eyeprotection that conforms to ANSI Z87.1.WARNING: When not in use, place grinder on a stable surface where it will notmove inadvertantly, roll or cause a tripping or falling hazard. The grinder may standupright on the battery pack but may be easily knocked over. Serious personal injury mayresult.CAUTION: To reduce the risk of personal injury, use extra care when working into acorner or edge because a sudden, sharp movement of the tool may be experienced whenthe wheel or other accessory contacts a secondary surface or a surface edge. The label on your tool may include the following symbols.V ..........................volts A..........................amperesHz ........................hertz W ........................wattsmin ........................minutes ......................alternating current......................direct current o ........................no load speed..........................Class II Construction........................earthing terminal ........................safety alert symbol SPM ....................strokes per .../min ....................revolutions or minutereciprocations per minute Extension Cord When using an extension cord, be sure to use one heavy enough to carry the current yourproduct will draw. An undersized cord will cause a drop in line voltage resulting in loss ofpower and overheating. The table below shows the correct size to use depending on cordlength and nameplate ampere rating. If in doubt, use the next heavier gage. The smallerthe gage number, the heavier the cord. Motor Your tool is powered by a Black & Decker specified motor. Be sure your power supplyagrees with the nameplate marking. A marking of 120 volts, 50/60 Hz or 120 volts, AC onlymeans that the tool is designed to operate on normal 120 volt house current. Voltagedecrease of more that 10% will cause loss of power and overheating. All Black & Deckertools are factory tested. If this tool does not run, check the power supply. ASSEMBLY

WARNING: To prevent accidental operation, turn off and unplug tool before

performing the following operations. Failure to do this could result in serious personal injury. Attaching the Wheel Guard - Fig. 2

WARNING: NEVER GRIND OR BRUSH WITHOUT GUARD IN PLACE.

• Place the tool on a table, with the spindle (9) facing up.• Place the spring washer (8) over the spindle and locate it on the shoulder (10).• Place the guard (4) onto the tool as shown.• Place the flange (7) over the spindle with the protruding pips towards the guard. Makesure that the holes in the flange align with the screw holes.• Secure the flange with the screws (6). Make sure that the screws are fully tight and thatthe guard can be rotated. Removing the Wheel Guard (For Sanding Only) - Fig. 3 CAUTION: To prevent loss of control, do not set tool down until accessory hascompletely stopped turning.This tool is fitted with a guard. For sanding only, you can remove the guard as follows:• Remove the outer flange, disc and inner flange if they have been attached.• Use a screwdriver to remove the screws (6).• Remove the flange (7), guard (4) and spring washer (8). Store these parts carefully.1. On/off switchInterrupteur Marche/ArrêtConmutador de encendido y apagado2. Lock-on buttonBouton de verrouillage en position de marcheBotón de bloqueo en encendido3. Side handle Poignée latéraleMango lateral4. Spindle lockBouton de verrouillage de la brocheSeguro del eje5. GuardDispositif de protection Protector

8Adjusting the Guard The guard can be rotated 90°.

• Rotate the guard as required. Fitting the Side Handle

• A three position auxiliary handle (4) is furnished with your grinder and can be screwed into either side of the grinder housing as well as into the top.

WARNING: This handle SHOULD BE USED AT ALL TIMES to maintain complete

control of the tool. Always make sure the handle is tight. Fitting and Removing Depressed Center Wheels - Fig. 4 - 6 CAUTION: Never use any depressed-center wheels without the proper guard. Fitting - Figure 4,5

• Fit the guard as described above.

• Place the inner flange (11) onto the spindle (7) as shown (fig. 4). Make sure that the flange is correctly located on the flat sides of the spindle.

• Place the disc (12) onto the spindle (7) as shown (fig. 4). If the disc has a raised center (13), make sure that the raised center faces the inner flange.

• Make sure that the disc locates correctly on the inner flange.

• Place the outer flange (14) onto the spindle. When fitting a grinding disc, the raised center on the outer flange must face towards the disc (A in fig. 5). When fitting a cutting disc, the raised center on the outer flange must face away from the disc (B in fig. 5).

• Keep the spindle lock (5) depressed and tighten the outer flange using the two-pin spanner (15) (fig. 6).

• When using a depressed-center wheel, hold the tool so that an angle of approximately 30° exists between the wheel and the work.

• When using ready-mount or hubbed wheels, flanges are not required.

WARNING: Check rated speed on depressed-center wheel. Never use a wheel with

rated speed lower than the speed on the nameplate of the tool. EDGE GRINDING Edge grinding may be done with Type 27 depressed center wheels specifically designed for this purpose. These wheels are available locally. They must not be subject to side pressure. CAUTION: Wheels used for edge grinding may break if they bend or twist while being used for cut-off work or deep grinding. To reduce the risk of serious injury, limit the use of these wheels to shallow cutting and notching (less than 1/2 in. in depth). The open side of the guard must be positioned away from the operator. Removing - Figure 6

• Keep the spindle lock (5) depressed and loosen the outer flange (14) using the two-pin spanner (15) (fig. 6).

• Remove the outer flange (14) and the disc (12). Fitting Wire Cup Brushes & Stringer Bead/Cable Twist Brushes Wire brushes screw directly on the spindle of the machine without the use of flanges. When using wire brushes, thread firmly on spindle by hand. Fitting Abrasive Discs Use an abrasive disc with a backing pad for sanding with your angle grinder.

• Place the flange, (backing pad and abrasive disc sold separately) and outer flange on the spindle as shown in Figure 7. Figure 7A shows how to attach an abrasive disc with a rubber backing pad.

• Tighten the abrasive disc as shown in Figure 8 by depressing the spindle lock button and turning the abrasive disc by hand. OPERATION

WARNING: Let the tool work at its own pace. Do not overload.

Switching On and Off

• To switch the tool on, press the on/off switch (1).

• For continuous operation, press the lock-on button (2) and release the on/off switch.

• To switch the tool off, release the on/off switch. To switch the tool off in continuous operation, press the on/off switch once more and release it.

WARNING: Do not switch the tool off while under load.

Overload Overloading will cause damage to the motor of your angle grinder. This can happen if your angle grinder is subjected to heavy use for prolonged periods of time. Do not in any circumstances, attempt to exert too much pressure on your angle grinder to speed up your work. The abrasive discs operate more efficiently when light pressure is exerted, thus avoiding a drop in the speed of your angle grinder. SANDING Precautions to Take When Sanding Paint

• Sanding of lead based paint is NOT RECOMMENDED due to the difficulty of controlling the contaminated dust. The greatest danger of lead poisoning is to children and pregnant women.

• Since it is difficult to identify whether or not a paint contains lead without a chemical analysis, we recommend the following precautions when sanding any paint: Personal Safety

• No children or pregnant women should enter the work area where the paint sanding is being done until all cleanup is completed.

• A dustmask or respirator should be worn by all persons entering the work area. The filter should be replaced daily or whenever the wearer has difficulty breathing. NOTE: Only those dustmasks suitable for working with lead paint dust and fumes should be used. Ordinary painting masks do not offer this protection. See your local hardware dealer for the NIOSH approved proper mask. Environmental Safety

• Paint should be removed in such a manner as to minimize the amount of dust generated.

• Areas where paint removal is occurring should be sealed with plastic sheeting of 4 mils thickness.

• Sanding should be done in a manner to reduce tracking of paint dust outside the work area. GENERAL INFORMATION Helpful Hints

• Hold your angle grinder with one hand on the body and the other hand firmly around the side handle as shown in Figure 9.

• Always position the guard so that as much of the exposed disc as possible is pointing away from you.

• Be prepared for a stream of sparks when the disc touches the metal.

• Maintain an angle between the disc and work surface (Fig. 10) of approximately 30° when grinding and 10°-15° when sanding ( Fig. 11) for best tool control, material removal, and minimal loading. CAUTION: Use extra care when grinding into a corner as a sudden, sharp movement of the grinder may be experienced when the wheel contacts a secondary surface.

WARNING: Always wear eye protection while operating this power tool.

Maintenance Cleaning Blowing dust and grit out of the motor housing using compressed air is a necessary maintenance procedure. CAUTION: Dust and grit from metal grinding often accumulate on interior surfaces and could create an electrical shock hazard if not cleaned out. Use only mild soap and a damp cloth to clean the tool. Never let any liquid get inside the tool; never immerse any part of the tool into a liquid. IMPORTANT: To assure product SAFETY and RELIABILITY, repairs, maintenance and adjustment should be performed by authorized service centers or other qualified service personnel, always using identical replacement parts. Lubrication Black & Decker tools are properly lubricated at the factory and are ready for use. Tools should be lubricated regularly every year depending on usage. (Tools used on heavy duty jobs and tools exposed to heat may require more frequent lubrication.) This lubrication should be attempted only by trained power tool repairperson's such as those at Black & Decker service centers or in other qualified service personnel. Accessories Recommended accessories for use with your tool are available from your local dealer or authorized service center. If you need assistance regarding accessories, please call: 1-800-54-HOW-TO (544-6986).

WARNING: The use of any accessory not recommended for use with this tool could be

hazardous. Service Information Black & Decker offers a full network of company-owned and authorized service locations throughout North America. All Black & Decker Service Centers are staffed with trained personnel to provide customers with efficient and reliable power tool service. Whether you need technical advice, repair, or genuine factory replacement parts, contact the Black & Decker location nearest you. To find your local service location, refer to the yellow page directory under "Tools—Electric" or call: 1-800-54-HOW TO. Full Two-Year Home Use Warranty Black & Decker (U.S.) Inc. warrants this product for two years against any defects in material or workmanship. The defective product will be replaced or repaired at no charge in either of two ways. The first, which will result in exchanges only, is to return the product to the retailer from whom it was purchased (provided that the store is a participating retailer). Returns should be made within the time period of the retailer’s policy for exchanges (usually 30 to 90 days after the sale). Proof of purchase may be required. Please check with the retailer for their specific return policy regarding returns that are beyond the time set for exchanges. The second option is to take or send the product (prepaid) to a Black & Decker owned or authorized Service Center for repair or replacement at our option. Proof of purchase may be required. Black & Decker owned and authorized Service Centers are listed under "Tools-Electric" in the yellow pages of the phone directory. This warranty does not apply to accessories. This warranty gives you specific legal rights and you may have other rights which vary from province to province. Should you have any questions, contact the manager of your nearest Black & Decker Service Center. This product is not intended for commercial use. FREE WARNING LABEL REPLACEMENT: If your warning labels become illegible or are missing, call 1-800-544-6986 for a free replacement. Special Warranty Note to Contractors: FIRESTORM

branded products are offered as high end consumer home use tools and carry a HOME USE WARRANTY. These tools are designed, manufactured and tested to meet or exceed the needs of the do-it-yourselfer in the execution of projects and repairs in and around the home. With proper use they will provide the home owner with step up power and performance well beyond their two year warranty. However, if you use tools for a living and use FIRESTORM

branded products or any of Black & Decker’s other Consumer Home Use tools ON THE JOBSITE you should know that they CANNOT BE COVERED UNDER OUR WARRANTY. See ‘Tools- Electric’ – Yellow Pages – for Service & Sales Imported by Black & Decker (U.S.) Inc., 701 E. Joppa Rd. Towson, MD 21286 U.S.A. 1-800-544-6986 www.FireStormTools.com TROUBLESHOOTING Problem Possible Cause Possible Solution

• Unit will not start. • Cord not plugged in. • Plug tool into a working outlet.

• Circuit fuse is blown. • Replace circuit fuse. (If the product repeatedly causes the circuit fuse to blow, discontinue use immediately and have it serviced at a Black & Decker service center or authorized servicer.)

• Circuit breaker is tripped. • Reset circuit breaker. (If the product repeatedly causes the circuit breaker to trip, discontinue use immediately and have it serviced at a Black & Decker service center or authorized servicer.)

Catalog No. FS8500AG
