SRX120 (2016) - Snowmobile YAMAHA - Free user manual and instructions

Product type	Snowmobile
Brand	YAMAHA
Model	SRX120 (2016)
Overall length	181.6 cm
Overall width	87.6 cm
Overall height	78.7 cm
Dry weight	75.0 kg
Curb weight	Approx 76.8 kg
Engine type	4-stroke, forced air cooling
Displacement	123 cm³
Bore x stroke	56 x 50 mm
Compression ratio	8.3:1
Recommended fuel	Regular unleaded, minimum octane rating RON 95
Fuel tank capacity (actual)	1.7 L
Recommended engine oil	Synthetic 0W-40
Engine oil capacity	600 ml
Spark plug	NGK BPR4ES
Electrode gap	0.7-0.8 mm
Starting system	Manual recoil starter
Brake type	Band brake
Track width	25.4 cm
Track length (on ground)	43 cm
Track tension	6.4-9.5 mm
Headlight	12V/55W
Intended use	Children 6 years and older, with adult supervision, off-road, on snow
Number of seats	1 (driver only)

Frequently Asked Questions - SRX120 (2016) YAMAHA

What type of fuel to use for the SRX120?

Use regular unleaded gasoline with a minimum octane rating of RON 95. Oxygenated fuels containing up to 10% ethanol are acceptable. Do not use fuel containing methanol.

What engine oil is recommended and what is the capacity?

The recommended engine oil is synthetic SAE 0W-40. The engine oil capacity is 600 ml (20.3 oz).

How often should the engine oil be changed?

After the break-in period (10 hours), the oil should be changed every 100 hours of use (6 months) and before extended storage.

How to start the snowmobile when the engine is cold?

Pull the choke fully. Pull the recoil starter handle slowly until resistance is felt, then pull sharply. Once started, push the choke halfway, then fully after 2-3 minutes of warming.

What is the minimum recommended age to use the SRX120?

The snowmobile is designed for children at least 6 years old, under mandatory adult supervision.

How to check the track tension?

Measure the distance between the underside of the wear strip and the inner surface of the track. The correct tension is 6.4 to 9.5 mm (1/4 to 3/8 in).

What is the spark plug type and required gap?

The spark plug is a NGK BPR4ES with an electrode gap of 0.7 to 0.8 mm.

How to adjust the brake lever travel?

The distance between the brake lever and the stop should be 6 to 13 mm (1/4 to 1/2 in). To adjust, loosen the rear lock nut of the brake cable, then tighten the front lock nut to change the tension.

What is the stock maximum speed?

The stock maximum speed is 12.8 km/h (8 mph). Never increase beyond this speed.

How to store the snowmobile for a long period?

Drain the fuel, clean the snowmobile, change the oil, lubricate the chain and suspensions, remove the spark plug and pour 10 ml of oil into the well, then store in a dry place, preferably raised and under a non-plastic cover.

USER MANUAL SRX120 (2016) YAMAHA

Original instructions

Notice originale

Engineering Div., RV Business Unit

Business Development Operations

© 2015 Yamaha Motor Co., Ltd.

Yumaba and oonrssd and onceras the sae us of all sowneobies. Always follow these rules to ens your continued enjoyment of the sport. Recere preor training and operat e within your Capitale. See opetior's manuall for complarly anmtry instrutons.

RÉGEMENTS DE SECURITE EN MOTONEIGE

Yamaba aodosts eontourage fllllisation sacturiteo fouloe motoaigae. Respectaclouqués rcllements qusyou pommertnnt de pratiquere scopt en plassia

Don't drink and risk

Ne buvex pas longue neveu condusies.
Kor aldir om quir alkoholfoahid.

Joes at: Ata kalkalka!
Kiri akti under eikrimin ay alcohol

Sop for tyen is spartr vann.
