PDES 4 B2 - Circular cutting tool PARKSIDE - Free user manual and instructions
Find the device manual for free PDES 4 B2 PARKSIDE in PDF.
| Product type | Circle cutter for plasma cutter |
| Brand | Parkside |
| Model | PDES 4 B2 |
| Dimensions (L x W x H) | 35.3 x 4.2 x 5.4 cm |
| Weight | Approx. 310 g |
| Adjustable cutting diameter | 15 to 60 cm |
| Intended use | With Parkside PPS 40 A1 and PPS 40 B2 plasma cutters |
| Attachment | By magnet or metal pin (for center punch) |
| Supplied accessories | 1 compass, 1 magnet, 1 metal pin, 1 fixing screw, 1 instruction manual |
| Material | Steel and bakelite (torch holder) |
| Cleaning | Soft, damp cloth, without aggressive products |
| Storage | Dry place, out of reach of children |
| Safety | Do not attach the magnet to the plasma cutter; follow the cutter's instructions |
| Repairability | Contact customer service via www.lidl-service.com (IAN 356278) |
Frequently Asked Questions - PDES 4 B2 PARKSIDE
User questions about PDES 4 B2 PARKSIDE
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Circular cutting tool in PDF format for free! Find your manual PDES 4 B2 - PARKSIDE and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. PDES 4 B2 by PARKSIDE.
USER MANUAL PDES 4 B2 PARKSIDE
Operation and Safety Notes Translation of the original instructions
FR BE
NL BE
COMPASPPKS35B2
GB/IEOperation and Safety Notes
Page 13
service.at@cmc-creative.de
service.ch@cmc-creative.de
Telefon: +49 (0) 6894/ 9989750
Table of pictograms used
Page. 14
Introduction
Page. 14
Intendeduse
Page. 15
Package contents
Page. 15
Parts description
Page. 16
Technical specifications
Page. 16
Safety instructions
Page. 17
Handling the circle cutter
Page. 17
Cleaning
Page. 18
Storage
Page. 18
Information about recycling and disposal
Page. 18
Service
Page. 19
| Table of pictograms used | |
| Read the instruction manual of this product attentively and with care before use. | |
| Disposition of packaging properly. Do not dispose of the appliance in household waste! | |
| Made from recycling material. | |
| Important note! | |
Circle cutter PPKS 35 B2
Introduction
Congratulations! You have purchased one of our high-quality products. The operating instructions form part of this product.
They contain important information on safety, usage and disposal. Please familiarise yourself with all operating and safety instructions before using the product. Use the product only as described and only for the specific applications as stated. Please retain the operating instructions properly and ensure that you hand over all documentation when passing the product onto someone else.
This product must be set up or used only by people who have been trained to do so.
Any use that differs to the intended use as stated above is prohibited and potentially dangerous. Damage or injury caused by misuse or disregarding the above warning is not covered by the warranty or any liability on the part of the manufacturer. The device is not intended for commercial use. Commercial use will void the guarantee.
KEEP OUT OF THE REACH OF CHILDREN!
- Intendeduse
The circle cutters PPKS 35 B2 is designed for use with the PPS 40 A1 and PPS 40 B2 plasma cutters from Parkside. You can use the circle cutter to make circular cuts, the diameter of these cuts can be continuously adjusted over a range of approx. 15cm to 60~cm . Centring can be carried out either using a magnet or metal pin (during preparation for each centre punch). Please refer to the operating instructions of the plasma cutter you are using for information about material thicknesses which can be cut.
Package contents
1 circle cutter PPKS 35 B2
1 set of operating instructions
- Parts description
PLEASE NOTE!
After unpacking the product, please check that all of the package contents are present and that the accessory is in perfect condition. Do not use the accessory if it is defective.
1 Circle cutter
2 Centring device
3 Magnetic holder
4 Metal pin
5 Torch holder with Bakelite inner ring
6 Spacer
7 Adjusting screws
- Technical specifications
Length: 35.3cm
Width: 4.2cm
Height: 5.4 cm
Weight: approx. 310 g
Cut diameter: approx. 15-60 cm
- Safety instructions
KEEP OUT OF THE REACH OF CHILDREN!
Never attach the magnets to the plasma cutter itself or its housing. Before using, please read the operating instructions for the circle cutter PPKS 35 B2 and the operating instructions for the plasma cutter you are using in full.
It is essential that you observe the safety instructions of your plasma cutter!
Check the circle cutter before fitting it to the plasma cutter. Damaged components must not be used.
- Handling the circle cutter
Attach the circle cutter 1 using the magnetic holder 3 or metal pin 4 (during preparation for each centre punch) on to the metal surface to be processed. The plasma torch can now be positioned in the torch holder with Bakelite inner ring, as in Figure B 5. Using the adjusting screws 7 of the spacer 6 you can now set the precise gap from the plasma torch to the workpiece (Fig. C), so that the plasma torch is lying flat. Using the
centring device 2 of the circle cutter 1 you can continuously adjust the radius. When setting a small radius make sure that when the plasma torch is being used, it will not be affected 2 by the centring device (Fig. E). Never attach the magnetic foot 3 to the plasma cutter itself or other electrical devices. Make sure that you do not touch the hot plasma torch by accident.
RISK OF BURNS!
- Cleaning
Clean the product with a soft moistened cloth. Do not use any aggressive or abrasive detergents.
Storage
Keep the device in a dry location and out of the reach of children.
Information about recycling and disposal
Please return this device, accessories and packaging to your local recycling depot.
Service
Note:
You can download this handbook and many more, as well as product videos and software at www.lidl-service.com.
With this QR code you can gain immediate access to the Lidl Service page (www.lidl-service.com) and you can open your Operating Instructions by entering the article number (IAN) 356278.
How to contact us:
GB,IE
Name: C. M. C. GmbH
Website: www.cmc-creative.de
E-mail: service.gb@cmc-creative.de
Phone: 0-808-189-0652
Registered office: Germany
IAN 356278_2004
Please note that the following address is not a service address. Please first contact the service point given above.
Address:
C. M. C. GmbH
Katharina-Loth-Str. 15
66386 St. Ingbert
GERMANY
Ordering spare parts:
Site web: www.cmc-creative.de
E-mail: service.fr@cmc-creative.de
Telephone:0033(0)387847234
Siège : Allemagne
