Features	Details
Product type	Microwave oven
Capacity	30 liters
Microwave power	900 W
Grill function	Yes
Grill power	1000 W
Number of automatic programs	10
Dimensions (W x D x H)	51 x 40 x 30 cm
Weight	15 kg
Cavity material	Stainless steel
Safety system	Child lock
Energy consumption	Energy class A
Included accessories	Turntable, grill rack
Warranty	2 years

Frequently Asked Questions - KOTR30X BERTAZZONI

How do I reset the BERTAZZONI KOTR30X microwave oven?

To reset the microwave oven, unplug it for about 10 minutes, then plug it back in.

Why isn\u0027t my BERTAZZONI KOTR30X microwave oven heating?

Check if the door is properly closed. If it is closed, there might be a problem with the fuse or the magnetron.

How do I clean the inside of the BERTAZZONI KOTR30X microwave oven?

Use a mixture of water and vinegar in a bowl, heat it for 5 minutes, then wipe the inside with a soft cloth.

The BERTAZZONI KOTR30X microwave oven is making a strange noise. What should I do?

A strange noise may indicate a problem with the fan or motor. Turn off the appliance and contact customer service.

How do I set the cooking time on the BERTAZZONI KOTR30X microwave oven?

To set the cooking time, turn the dial or press the 27plus27 and 27minus27 buttons to adjust the time.

Can I use metal in the BERTAZZONI KOTR30X microwave oven?

No, it is not recommended to use metal objects, as this can cause sparks and damage the appliance.

How do I know if the BERTAZZONI KOTR30X microwave oven is in eco mode?

When the oven is in eco mode, a light indicator turns on on the control panel.

The BERTAZZONI KOTR30X microwave oven displays an error code. What should I do?

Refer to the user manual for the specific error code. You can also try resetting the appliance.

How do I change the bulb inside the BERTAZZONI KOTR30X microwave oven?

Unplug the appliance, remove the bulb cover, and replace the bulb with a similar one.

The turntable of my BERTAZZONI KOTR30X microwave oven isn\u0027t turning. What should I do?

Check if the turntable is properly positioned on the support. If the problem persists, there may be an issue with the turntable motor.

USER MANUAL KOTR30X BERTAZZONI

BERTAZZION ITALIA

MicrowaveOven

INSTRUCTIONMANUAL

Model:KOTR30X

Read these instructions carefully before using your microwave oven, and keep it carefully.

If you follow the instructions, your oven will provide you with many years of good service.

SAVE THESE INSTRUCTIONS CAREFULLY

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY

(a) Do not attempt to operate this oven with the door open since this can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven door closes properly and that there is no damage to the:

(1) DOOR (bent)

(2) HINGES AND LATCHES (broken or loosened)

(3) DOOR SEALS AND SEALING SURFACE

(d) The oven should not be adjusted or repaired by anyone except properly qualified service personnel.

Specifications

Model:	KOTR30X
Rated Voltage:	120V~ 60Hz
Rated Input Power(Microwave):	1550 W
Rated Output Power(Microwave):	1000 W
Oven Capacity:	1.6 Cu.ft.(44 L)
Turntable Diameter:	13.6 inch(345 mm)
External Dimensions:	29.8×15.0×16.4 inch
Net Weight:	Approx. 55.11 Lbs(25kg)

IMPORTANT SAFETY INSTRUCTIONS

WARNING

To reduce the risk of burns, electric shock, fire,injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic safety precautions, including the following:

1. Read all instructions before using the appliance.
2. Read and follow the specific: "PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY" found on page 2.
3. As with most cooking appliances, close supervision is necessary to reduce the risk of a fire in the oven cavity.
4. To reduce the risk of fire in the oven cavity:
   i). Do not overcook food. Carefully attend the appliance when paper, plastic, or other combustible materials are placed inside the oven to facilitate cooking. ii). Remove wire twist-ties and metal handles from paper or plastic containers/bags before placing them in the oven.
   iii). If materials inside the oven ignite, keep the oven door closed. Turn the oven off, and unplug the appliance. Disconnect the power cord, shut off power at the fuse or circuit breaker panel. iv). Do not use the oven cavity for storage purposes. Do not leave paper products, cooking utensils, or food in the cavity when not in use.
5. This oven must be grounded. Connect only to properly grounded outlet. See "GROUNDING INSTRUCTIONS" found on page 4.
6. Install or locate this oven only in accordance with the installation instructions provided.

7. Some products such as whole eggs and sealed containers-for example, closed glass jars-are able to explode and should not be heated in the oven.

8. Use this appliance only for its intended uses as described in this manual. Do not use corrosive chemicals or vapors in this appliance. This oven is specifically designed to heat or cook or dry food. It is not designed for industrial or laboratory use.

9. As with any appliance, close supervision is necessary when used by children.
10. Do not operate this oven if it has a damaged cord or plug, if it is not working properly or if it has been damaged or dropped.
11. This appliance should be serviced only by qualified service technicians. Contact the nearest authorized service facility for examination, repair or adjustment.
12. Do not cover or block any openings on the oven.
13. Do not store or use this appliance outdoors.
14. Do not use this oven near water, for example, near a kitchen sink, in a wet basement, near a swimming pool, or similar locations.
15. Do not immerse cord or plug in water.
16. Keep cord away from heated surfaces.
17. Do not let cord hang over edge of table or counter.

18. When cleaning surfaces of door and oven that comes together on closing the door, use only mild, nonabrasive soaps or detergents applied with a sponge or soft cloth.

19. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE CONTAINER IS DISTURBED OR A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID.

i) Do not overheat the liquid.
ii) Stir the liquid both before and halfway through heating it.
iii) Do not use straight-sided containers with narrow necks.
iv) After heating, allow the container to stand in the microwave oven for a short time before removing the container.
v) Use extreme care when inserting a spoon or other utensil into the container.

1. Do not mount over sink.

2. Do not store anything directly on top of the appliance surface when the appliance is in operation.

3. VENTILATION HOODS: "Including OTR

1) Clean Ventilation Hoods Frequently -Grease should not be allowed to accumulate onhood or filter.
2) When flaming foods under the hood, turn the fan on.
3) Use care when cleaning the vent-hood filter. Corrosive cleaning agents, such as lye-basedoven cleaners, may damage the filter
4) Suitable fo use above both gas and electric cooking equipment. r

SAVE THESE INSTRUCTIONS GROUNDING INSTRUCTIONS

DANGER

Electric Shock Hazard

Touching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance.

WARNING

Electric Shock Hazard Improper use of the grounding can result in electric shock. Do not plug into an outlet until appliance is properly installed and grounded.

Three-pronged (grounding) plug

This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.

Consult a qualified electrician or serviceman if the grounding instructions are not completely understood or if doubt exists as to whether the appliance is properly grounded. If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-pronged grounding plug, and a 3-slot receptacle that will accept the plug on the appliance.

The marked rating of the extension cord shall be equal to or greater than the electrical rating of the appliance.

1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord.
2. Longer cord sets or extension cords are available and may be used if cared is exercised in their use.
3. If a long cord sets or extension cord is used:

1) The marked electrical rating of the cord set or extension marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance.
2) The extension cord must be a grounding-type 3-wire cord; and
3) The longer cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally.

Radio Interference

1. Operation of the microwave oven may cause interference to your radio, TV or similar equipment.
2. When there is interference, it may be reduced or eliminated by taking the following measures:

1) Clean door and sealing surface of the oven
2) Reorient the receiving antenna of radio or television.
3) Relocate the microwave oven with respect to the receiver.
4) Move the microwave oven away from the receiver.
5) Plug the microwave oven into a different outlet so that microwave oven and receiver are on different branch circuits.

UTENSILS

CAUTION

Personal Injury Hazard

Tightly-closed utensils could explode. Closed containers should be opened and plastic pouches should be pierced before cooking.

See the instructions on "Materials you can use in microwave oven or to be avoided in microwave oven." There may be certain non-metallic utensils that are not safe to use for microwaving. If in doubt, you can test the utensil in question following the procedure below.

Utensil Test:

1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.

Materials you can use in microwave oven

Utensils Remarks

Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of meat or poultry to prevent overcooking. Arcing can occur if foil is too close to oven walls. The foil should be at least 1 inch (2.5cm) away from oven walls.
Browning dish	Follow manufacturer's instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the turntable to break.
Dinnerware	Microwave-safe only. Follow manufacturer's instructions. Do not use cracked or chipped dishes.
Glass jars	Always remove lid. Use only to heat food until just warm. Most glass jars are not heat resistant and may break.
Glassware	Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use cracked or chipped dishes.
Oven cooking bags	Follow manufacturer's instructions. Do not close with metal tie. Make slits to allow steam to escape.
Paper plates and cups	Use for short-term cooking/warming only. Do not leave oven unattended while cooking.
Paper towels	Use to cover food for reheating and absorbing fat. Use with supervision for a short-term cooking only.
Parchment paper	Use as a cover to prevent splattering or a wrap for steaming.
Plastic	Microwave-safe only. Follow the manufacturer's instructions. Should be labeled "Microwave Safe". Some plastic containers soften, as the food inside gets hot. "Boiling bags" and tightly closed plastic bags should be slit, pierced or vented as directed by package.
Plastic wrap	Microwave-safe only. Use to cover food during cooking to retain moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.

Materials to be avoided in microwave oven

Utensils Remarks

Aluminum tray	May cause arcing. Transfer food into microwave-safe dish.
Food carton with metal handle	May cause arcing. Transfer food into microwave-safe dish.
Metal or metal-trimmed utensils	Metal shields the food from microwave energy. Metal trim may cause arcing.
Metal twist ties	May cause arcing and could cause a fire in the oven.
Paper bags	May cause a fire in the oven.
Plastic foam	Plastic foam may melt or contaminate the liquid inside when exposed to high temperature.
Wood	Wood will dry out when used in the microwave oven and may split or crack.

OPERATING INSTRUCTIONS

1). Press "CLOCK", the unit enters the clock setting states. AM indicator will light. "0:00" flash to remind you to input the time.
2). Press "CLOCK" again to select AM or PM. The responding AM or PM indicator lights.
3). Press the number keys and enter the correct time. For example, time is 10:12 now, please press "1,0,1,2" in turn.
4). Press "CLOCK" key finish setting the clock.

Note:

a. This is a 12 hour clock from 1:00 to 12:59. If the time set is not appropriate, press "CLOCK" will be no used.
b. When current time change from 11:59 to 12:00, AM and PM will change automatically.

MICROWAVE COOKING

1) Press "TIME COOK" to select microwave cooking. "0:00" flash to remind you to input the cooking time.
2) Press the number keys to adjust the cooking time you need. For example, to cook the time for 10 minutes. Please press "1,0,0,0" in turn. The maximum cooking time is 99 minutes 99 seconds.
3) At the same time, you can choose the power by pressing "POWER".
4) Press the number keys to select the power level.
5) Press "START/PAUSE" to start cooking. Time counts down.

Note:

1) If the power level you choose is 100% power, steps "3" and "4" can be skipped and go directly to the step "5".
2) After cooking finishing, buzzer sounds five times.
3) During cooking process, press "Add 30 Sec." to add 30 seconds. The MAX.time is 99 minutes 99 seconds.

Ten power levels are available:

LEVEL	POWER DISPLAY
10	100%	PL10
9	90%	PL9
8	80%	PL8
7	70%	PL7
6	60%	PL6
5	50%	PL5
4	40%	PL4
3	30%	PL3
2	20%	PL2
1	10%	PL1

MULTI-STAGE COOKING

At most two stages can be input.

For example: to cook the food with 100% microwave power for 10 minutes and then cook with 80% microwave power for 15 minutes. Do as following:

1) Press "TIME COOK" to choose microwave cooking;
2) Press "1", "0", "0", "0" to input the cooking time;
3) Press "POWER" to select the microwave power;
4) Press "10" to choose 100% microwave power;
5) Press "TIME COOK" to choose microwave cooking;
6) Press "1", "5", "0", "0" to input cooking time;
7) Press "POWER" to select the microwave power;
8) Press "8" to choose 80% microwave power;
9) Press "START/PAUSE" to start cooking.

Note:

a. Microwave cooking can be set as two stages only. Defrost program and auto menu cannot be set here.

b. When the first stage finish, buzzer sounds once and the second stage begins cooking.

DEFROST COOKING

A. Defrost By Weight

1) Press "DEFROST AUTO/TIME" once to choose defrost by weight function. 0.0 will flash and "lb" indicator flash;
2) Press number keys from 0 to 9 to input the derfost weight. For example: the food weight is 1.2 Lbs, then "1", "2" will be input. The maximum cooking weight is 6.0 Lbs. If the weight input is more than 6.0 Lbs, the unit will turn back to waiting states.
3) Press "START/PAUSE" to start defrosting. "Ib" indicator will be off.

DEFROST BY TIME

1) Press "DEFROST AUTO/TIME" twice to choose defrost by time function.0:00 flash and defrost indicator will light;
2) Press number keys from 0 to 9 to input the derfost time. The maximum time can be input is 99 minutes and 99 seconds.
3) Press "START/PAUSE" to start defrosting.

Note: If half the defrost time passes, the buzzer will sound twice to remind you to turn the food over.

OPERATING INSTRUCTIONS

POPCORN

a) Press "POPCORN" repeatedly until the number you wish appears in the display.

"1" SET: approximate 1.75 ounces

"2" SET: approximate 3.0 ounces

"3" SET: approximate 3.5 ounces

For example, press "POPCORN" three times , "3.5" appears in the LED.

b) Press "START/PAUSE" to cook.

Beverage Menu

a) Press "BEVERAGE" repeatedly until the number you wish appears in the display.

"1" SET: approximate 8.8 ounces

"2" SET: approximate 17.6 ounces

"3" SET: approximate 26.4 ounces

For example, press "BEVERAGE" once, "1" appears in the LED.

b) Press "START/PAUSE" to cook.

BAKED POTATO MENU

1) Press "BAKED POTATO" repeatedly until the number you wish appears in the display.

"1"SET: for approximately 7.1 ounces

"2"SET: for approximately 14.2 ounces

"3"SET: for approximately 21.3 ounces

For example, press "BAKED POTATO" once, "1" appears in the LED.

2) Press "START/PAUSE" to cook.

REHEAT

1) Press "REHEAT" repeatedly until the number you wish appears in the display.

For example, press "REHEAT" onec, "8.0" ounces appears in the LED. press "REHEAT" twice, "16.0" ounces appears in the LED. press "REHEAT" 3 times, "24.0" ounces appears in the LED.

2) Press "START/PAUSE" to cook.

HOOD FUNCTION

1) When the exhaust fan is under off states, press "VENT FAN/HI/LOW/OFF" once to choose the fan with high speed;

2) Press "VENT FAN/HI/LOW/OFF" twice to choose the fan with low speed;

3) Press "VENT FAN/HI/LOW/OFF" three times to choose the fan to be off.

OVEN LAMP

1) Press "SURFACE LIGHT ON/OFF" once to turn on the lamp;
2) Press "SURFACE LIGHT ON/OFF" twice to turn off the lamp.

TIMER FUNCTION

1) Press "TIMER", timer indicator will light;
2) Press number keys to input the timer time you need. The maximum cooking time is 99 minutes and 99 seconds.
3) Press "TIMER", time counts down. When time counting down is over, buzzer sounds to indicate off.

Note:

During timer states, hood and oven lamp can be activated. Others function will be no used.

LOCK FUNCTION FOR CHILDREN

Lock: In waiting state, press "STOP/CLEAR" for 3 seconds, there will be two beeps denoting the entering into the children-lock state.

Lock quitting: In locked state, press "STOP/CLEAR" for 3 seconds, there will be two beepsdenoting that lock is released.

INQUIRING FUNCTION

1) Under microwave cooking states, press "POWER" to check the power level.
2) During cooking states, press "CLOCK" to check the clock.

SPEEDY COOKING

a) Press number keys from 1 to 6 to start cooking with full microwave power for 1-6 minutes.
b) In the waiting state, press "ADD 30 SEC." to start cooking 100% microwaver for 30 seconds.
c) During cooking, 30 seconds can be added each time the "ADD 30 SEC" is pressed. The maximum cooking time is 99 minutes and 99 seconds.

Maintenance

Troubleshooting

Check your problem by using the chart below and try the solutions for each problem. If the microwave oven still does not work properly, contact the nearest authorized service center.

TROUBLE	POSSIBLE CAUSE POSSIBLE REMEDY
Oven will not start	a. Electrical cord for oven is not plugged in.b. Door is open.c. Wrong operation is set.	a. Plug into the outlet.b. Close the door and try again.c. Check instructions.
Arcing or sparking	a. Materials to be avoided in microwave oven were used.b. The oven is operated when empty.c. Spilled food remains in the cavity.	a. Use microwave-safe cookware only.b. Do not operate with oven empty.c. Clean cavity with wet towel.
Unevenly cooked foods	a. Materials to be avoided in microwave oven were used.b. Food is not defrosted completely.c. Cooking time, power level is not suitable.d. Food is not turned or stirred.	a. Use microwave-safe cookware only.b. Completely defrost food.c. Use correct cooking time, power level.d. Turn or stir food.
Overcooked foods	Cooking time, power level is not suitable.	Use correct cooking time, power level.
Undercooked foods	a. Materials to be avoided in microwave oven were used.b. Food is not defrosted completely.c. Oven ventilation ports are restricted.d. Cooking time, power level is not suitable.	a. Use microwave-safe cookware only.b. Completely defrost food.c. Check to see that oven ventilation ports are not restricted.d. Use correct cooking time, power level.
Improper defrosting	a. Materials to be avoided in microwave oven were used.b. Cooking time, power level is not suitable.c. Food is not turned or stirred.	a. Use microwave-safe cookware only.b. Use correct cooking time, power level.c. Turn or stir food.

BERTAZZO ITALIA

Four micro-ondes

MANUEL D'UTILISATION

MODELE : KOTR30X
