USER MANUAL K 4.91 M Kärcher

CE-Erklärung Produkt: HochdruckreinigerTyp: 1.636-xxxEinschlägige EG-Richtlinien98/37/EG (bis 28.12.2009)2006/42/EG (ab 29.12.2009) 2004/108/EG2000/14/EGAngewandte harmonisierte NormenEN 55014–1: 2006EN 55014–2: 1997 + A1: 2001EN 60335–1EN 60335–2–79EN 61000–3–2: 2006EN 61000–3–3: 2008EN 62233: 2008Angewandtes Konformitätsbewertungsver-fahrenAnhang VSchallleistungspegel dB(A)K 3.91 MGemessen: 84 Garantiert: 85 K 4.91 MGemessen: 84 Garantiert: 86 CEO Head of Approbation 8 DeutschDeutsch 3 Dear Customer, Please read and comply with these original instructions prior to the initial operation of your appliance and store them for later use or subsequent owners. Danger Immediate danger that can cause severe injury or even death. 몇 Warning Possible hazardous situation that could lead to severe injury or even death. Caution Possible hazardous situation that could lead to mild injury to persons or damage to property. This high-pressure cleaner is designed for do- mestic use only: – to clean machines, vehicles, buildings, tools, facades, terraces, garden equipment etc. us- ing a high-pressure water jet (and detergents if required). – with accessories, replacement parts and de- tergents approved by KÄRCHER. Observe the instructions provided with these deter- gents. The packaging material can be recycled. Please do not place the packaging into the ordinary refuse for disposal, but arrange for the proper recycling. Old appliances contain valuable materials that can be recycled. Please arrange for the proper recycling of old appliances. Please dispose your old appliances using appro- priate collection systems. Notes about the ingredients (REACH) You will find current information about the ingre- dients at: http://www.karcher.de/de/unternehmen/ umweltschutz/REACH.htm The warranty terms published by the relevant sales company are applicable in each country. We will repair potential failures of your appliance within the warranty period free of charge, provid- ed that such failure is caused by faulty material or defects in manufacturing. In the event of a warranty claim please contact your dealer or the nearest authorized Customer Service centre. Please submit the proof of purchase. (See address on the reverse) Danger Never touch the mains plug and the socket with wet hands. The appliance must not be used if the power cord or important parts of the appliance, e.g. high-pressure hoses, trigger gun or safety devices are damaged. Check the power cord and mains plug for damage before every use. If the power cord is damaged, please arrange for it to be re- placed immediately by an authorised repair agent or a skilled electrician Check the high-pressure hose for damage before every use. Please arrange for the im- mediate replacement of a damaged high- pressure hose. The appliance may not be used in areas where a risk of explosion is present. If the appliance is used in hazardous areas (e.g. filling stations) the corresponding safety provisions must be observed. High-pressure jets can be dangerous if improperly used. The jet must not be directed at persons, animals, live electri- cal equipment or at the appliance itself. The high-pressure jet must not be directed at other persons or directed by the user at him/ herself to clean clothing or footwear. Never use the appliance to clean objects containing hazardous substances (e.g. as- bestos). Vehicle tyres or tyre valves are susceptible to damage from the high-pressure jet and may burst. The first indication of this is a dis- colouration of the tyre. Damaged vehicle tyres/tyre valves are highly dangerous. En- sure that a distance of at least 30 cm is ob- served when cleaning with the jet! Never draw in fluids containing solvents or undiluted acids and solvents! This includes petrol, paint thinner and heating oil. The spray mist thus generated is highly inflam- General information Hazard levels Proper Use Environmental protection Warranty Safety instructions English 94 Deutsch mable, explosive and poisonous. Do not use acetone, undiluted acids and solvents as they are damaging to the materials from which the appliance is made.

The mains plug and the coupling of an exten- sion cable must be watertight and must never lay in the water.

Unsuitable extension cables can be hazard- ous. Only use extension cables outdoors which have been approved for this purpose and la- belled with a sufficient cable cross-section: 1 - 10 m: 1.5 mm

Always fully unroll electrical cables from the ca- ble drum.

High-pressure hoses, fixtures and couplings are important for the safety of the appliance. Only use high-pressure hoses, fixtures and couplings recommended by the manufacturer.

This appliance is not intended for use by per- sons with reduced physical, sensory or mental capabilities. The appliance must not be operated by chil- dren or persons who have not been instructed accordingly. Children should be supervised to prevent them from playing with the appliance.

The operator must use the appliance correctly. When working with the appliance, he must con- sider the local conditions and pay due care and attention to other persons, in particular chil- dren, who are nearby.

Do not use the appliance when there are other persons around unless they are also wearing safety equipment.

Wear protective clothing and safety goggles to protect against splash back containing water or dirt. Caution

Do not operate the appliance at temperatures below 0 °C.

Observe a distance of at least 30 cm when us- ing the jet to clean painted surfaces to avoid damaging paintwork.

Never leave the appliance unattended when it is in operation.

Make sure that the power cable or extension cables are not damaged by running over, pinching, dragging or similar. Protect the power cable from heat, oil, and sharp edges.

All current-conducting parts in the working area must be protected against jet water.

The appliance may only be connected to an electrical supply which has been installed in ac- cordance with IEC 60364.

The appliance may only be connected to alter- nating current. The voltage must correspond with the type plate on the appliance.

For safety reasons, we recommend that you operate the appliance only via a earth-leakage circuit breaker (max. 30 mA).

Cleaning operations which produce oily waste water, e.g. engine washes, underbody washes, may only be carried out using washing stations equipped with an oil separator.

This appliance was designed to be used with detergents which are supplied or recommend- ed by the manufacturer. The use of other deter- gents or chemicals may compromise the safety of the appliance. Caution Safety devices protect the user and must not be modified or bypassed. The appliance switch prevents unintentional op- eration of the appliance. This lock locks the lever of the trigger gun and prevents the inadvertent start of the appliance. The overflow valve prevents the permissible working pressure from being exceeded. If the lever on the trigger gun is released the pressure switch turns off the pump, the high- pressure jet is stopped. If the lever is pulled the pump is turned on again. The high pressure hose is specially constructed with reinforced walls to handle water pressure up to 13 MPa (1900 psi) - it can be easily damaged and should be stored carefully. Do not kink. Do not drive vehicles over the hose. Do not expose the hose to sharp edges or corners. Misuse will lead to ballooning or premature fail- ure and will invalidate warranty. Safety Devices Power switch Lock trigger gun Overflow valve with pressure switch High pressure hose 10 EnglishDeutsch 5 The scope of delivery of your appliance is illus- trated on the packaging. Check the contents of the appliance for completeness when unpack- ing. In the event of missing accessories or any trans- port damage, please contact your dealer. These operating instructions describe the maxi- mum equipment. Depending on the model, there are differences in the scopes of delivery (see packaging). Illustrations on Page 2 1 Coupling element for water connection 2 High pressure connection 3 Appliance switch "0/OFF“/ „I/ON“ 4 Detergent Tank 5 Suction hose for detergent 6 Storage for trigger gun 7 Transport handle 8 Storage for high-pressure hose 9 Storage for accessories 10 Mains cable with mains plug 11 Water connection 12 Trigger gun 13 Lock trigger gun 14 High pressure hose 15 Spray lance with Dirtblaster 16 Spray lance with pressure regulation (Vario Power) 17 Washing brush Special accessories expand the possibilities of using your appliance. Please contact your KÄRCHER dealer for further information. Illustration Mount loose parts delivered with appliance prior to start-up. Illustration Î Push the high pressure hose into the trigger gun until it locks audibly. Note: Make sure the connection nipple is aligned correctly. Î Check the secure connection by pulling on the high-pressure hose. According to the applicable regula- tions, the appliance must never be used on the drinking water supply with- out a system separator. Use a suitable system separator manufactured by KÄRCHER; or, as an alternative, a system separator as per EN 12729 Type BA. Water flowing through a sys- tem separator is considered non-drinkable. Note: Impurities in the water can damage the high-pressure pump and accessories. For pro- tection, the use of the KÄRCHER water filter (op- tional accessory, order no. 4.730-059) is recommended. Observe regulations of water supplier. For connection values, see type plate/technical data. Î Use a fibre-reinforced water hose (not in- cluded) with a standard coupling. (Minimum diameter 1/2 inch (13 mm), minimum length

Î Screw the coupling element (supplied) to the water connection on the appliance. Î Push the water supply hose onto the cou- pling unit, then connect it to the water supply. This high-pressure cleaner is suited to work with the KÄRCHER suction hose with backflow valve (Optional accessory, order no. 4.440-238) to draw in surface water, e.g. from water butts or ponds (see specifications for max. suction height). Î Fill the KÄRCHER suction hose with back- flow valve with water, screw to water supply and hang into the water butt. Î Separate the high pressure hose from the high pressure connection of the appliance. Î Switch the appliance on (I/ON) for a max. of 2 minutes and wait until the water exits the high-pressure connection without bubbles. Î Turn off the appliance "0/OFF". Caution Dry runs lasting longer than two minutes lead to damages to the high pressure pump. If the appli- ance does not build up pressure within two min- utes, switch it off and proceed as instructed in the Chapter "Troubleshooting". Operation Scope of delivery Description of the Appliance Special accessories Before Startup Water supply Water supply from mains Drawing in water from open reservoirs Start up English 116 Deutsch Î Connect the high pressure hose to the high pressure connection of the appliance. Î Push the spray lance into the trigger gun and fasten it by turning it through 90°. Î Completely open the water tap. Î Insert the mains plug into the socket. Î Turn on the appliance “I/ON”. 몇 Danger The trigger gun is subjected to a recoil force when the water jet is discharged. Make sure that you have a firm footing and are also holding the trigger gun and spray lance firmly. Î Unlock the lever on the trigger gun. Î Pull on the lever of the trigger gun; the device will switch on. Note: Release the lever of the trigger gun; the device will switch off again. High pressure re- mains in the system. Carrying out the most common cleaning tasks. The work pressure can be stagelessly regulated between "Min" and "Max". Î Release the lever on the trigger gun. Î Turn the spray lance to the desired position. For particularly dirty items or areas. Not suitable for use with detergents. Suitable for use with detergents. Please use exclusively KÄRCHER detergents and care products to carry out the respective cleaning task, as these were specifically devel- opped for your appliance. The use of other deter- gents and care products may lead to premature wear and can invalidate your warranty claims. Please obtain information at your local dealer or request information directly from KÄRCHER. Î Fill the detergent solution in the detergent tank (observe dosage instructions on the packaging of the detergent). Î Use spray lance with pressure regulation (Vario Power). Î Turn the spray lance to "Mix" position. Note: This will mix the detergent with the wa- ter stream. Î Spray the detergent sparingly on the dry sur- face and allow it to react, but not to dry. Î Spray off loosened dirt with the high-pres- sure jet. Î Release the lever on the trigger gun. Î Lock the lever on the trigger gun. Î During longer breaks (more than 5 minutes), also turn the appliance off using the "0/OFF" switch. Î Insert the trigger gun in its holder. Caution Only separate the high-pressure hose from the trigger gun or the appliance while there is no pressure in the system.

After working with detergent, suspend deter- gent suction hose in a container filled with clear water, switch the appliance on for around 1 minute once the spray lance has been re- moved and rinse until water runs clear. Î Release the lever on the trigger gun. Î Turn off the appliance "0/OFF". Î Turn off tap. Î Detach the appliance from the water supply. Î Press the lever on the trigger gun to release any remaining pressure in the system. Î Lock the lever on the trigger gun. Î Pull out the mains plug. Î Insert the trigger gun in its holder. Î Stow away the mains cable, the high-pres- sure hose and accessory at the appliance. Danger Turn off the appliance and remove the mains plug prior to any care and maintenance work. The appliance is maintenance-free. Prior to longer periods of storage, e.g. in the win- ter: Î Completely drain all water from the appli- ance: Switch the appliance on with detached high-pressure hose and detached water sup- ply (max. 1 minute) and wait, until no more water exits at the high-pressure connection. Turn off the appliance. Operation Spray lance with pressure regulation Spray lance with Dirtblaster Washing brush Working with detergent Recommended cleaning method Interrupting operation Finish operation Maintenance and care Maintenance Storage 12 EnglishDeutsch 7 Î Remove filter from suction hose for deter- gent and clean under running water. Î Pull out the sieve in the water connection us- ing flat-nose pliers and clean under running water. Caution Protect the appliance and its accessories against frost. The appliance and its accessories can get de- stroyed through frost if there are any water resi- dues in them. To avoid damage to them: Î Store the appliance and the entire accesso- ries in a frost-safe room. Use only original KÄRCHER spare parts. You will find a list of spare parts at the end of these operating instructions. You can rectify minor faults yourself with the help of the following overview. If in doubt, please consult the authorized cus- tomer service. Danger Turn off the appliance and remove the mains plug prior to any care and maintenance work. Repair works may only be performed by the au- thorized customer service. Î Pull on the lever of the trigger gun; the device will switch on. Î Check whether the voltage indicated on the type plate corresponds to the voltage of the mains supply. Î Check the mains connection cable for dam- ages. Î Check setting at the spray lance. Î Appliance ventilation: Switch the appliance on with the high-pressure hose detached and operate (max. 2 minutes) until the water exits the high-pressure connection without bubbles. Switch off appliance and reconnect high-pressure hose. Î Check the water supply. Î Pull out the sieve in the water connection us- ing flat-nose pliers and clean under running water. Cause: Voltage reduction due to weak mains supply or when using an extension cable. Î When switching on, first pull the lever of the trigger gun and then switch the appliance switch to "I/ON". Î Clean high-pressure nozzle: Remove dirt and debris from the nozzle bore, using a needle and rinse through with water from the front. Î Check water flow quantity. Î Slight leakage from the appliance pump is normal. If the leakage increases contact the authorized customer service. Î Use spray lance with pressure regulation (Vario Power). Turn the spray lance to "Mix" position. Î Clean the detergent suction hose filter. Î Check the detergent suction hose for kinks. KÄRCHER UK Limited operate a helpline allow- ing customers to discuss any problems experi- enced with our products. The helpline operates during normal business hours and may be busy at peak periods.If you have difficulty getting through we would ask that you try to contact us again later in the day. The helpline number is 01295 752200, open from 8.30 am to 5.00 pm Monday to Friday. It helps us if you have the model number and data plate details to hand before making your call so that we can assist you with your query more effectively. Alternatively you may write to us at the ad- dress below: KÄRCHER UK Ltd Kärcher House Beaumont Road Banbury Oxon, OX16 1TB or E-mail us: info@karcher.co.uk Frost protection Spare parts Troubleshooting Appliance is not running Pressure does not build up in the appliance Appliance does not start, motor hums Strong pressure fluctuations Appliance is leaking No detergent infeed Helpline English 138 Deutsch Subject to technical modifications! We hereby declare that the machine described below complies with the relevant basic safety and health requirements of the EU Directives, both in its basic design and construction as well as in the version put into circulation by us. This declaration shall cease to be valid if the machine is modified without our prior approval. The undersigned act on behalf and under the power of attorney of the company management. Alfred Kärcher GmbH Co. KG Alfred-Kärcher-Str. 28 - 40 D - 71364 Winnenden Phone: +49 7195 14-0 Fax: +49 7195 14-2212 Technical specifications K 3.91 M K 4.91 M Water connection Max. feed temperature °C 40 Min. feed volume I/min 10 Max. feed pressure MPa 1,2 Max. Suction height m 0,5 Electrical connection Voltage *GB 1~50 Hz V240 Connected load kW 1,7 1,9 Mains fuse (slow-blow) *GB A13 Protective class I Protection class IP X5 Performance data Working pressure MPa 11 12 Max. permissible pressure MPa 12 13 Water flow rate I/min 6,3 6,7 Dimensions Length mm 336 Width mm 334 Height mm 837 Weight kg 12,5 Detergent flow rate I/min 0,3 Recoil force of trigger gun N 15 Hand-arm vibration (ISO 5349) m/s
