USER MANUAL IAN 282828 AURIOL

Intended use This product is intended for the observation of distant objects, animals, trees etc. as magnified images. The product is suitable for protected use in the open air. Other types of use or product modifications are not regarded as intended and may lead to risks such as injuries and damages. The manufacturer is not liable for any damages caused by any use other than its intended purpose. The product is not intended for commercial use.

Description of parts

Central focusing wheel

Threaded tripod mount socket

Includes 1 Binoculars 10 x 50 1 Shoulder bag 1 Cord loop 1 Cleaning cloth 1 Operating instructions Safety instructions

LOSS OF LIFE OR ACCIDENT

TO INFANTS AND CHILDREN! Never leave children unsupervised with the packaging materials. Packaging materials pre- sent a suffocation hazard. Children often under- estimate danger. Always keep the product out of reach of children. This product is not a toy and must be kept out of the reach of children. Children are not aware of dangers which may arise when using the product. CAUTION! FIRE HAZARD! Never place the binoculars directly in the sun. Please make sure that your binoculars are kept in a dry and dust-free place. Otherwise the bino- culars could be damaged. Always keep the binoculars in the shoulder bag

provided. Otherwise the binoculars could be damaged. Do not subject your binoculars to temperatures greater than 60 ºC. Otherwise the binoculars could be damaged. Never look through the inbuilt lenses directly into the sun, as this could damage the retina of the eye. Do not use the binoculars in heavy rain. Other- wise the binoculars could be damaged.9 GB/IE

Focusing Close your right eye. Adjust the view by turning the central focusing wheel

so that the view for the left eye is sh arp and clear.

until the object is sharp and clear. Retain this position for later use. + Focus on a closer object — Focus on a more distant object 0 No adjustment

Adjustment for eye positions Hold your binoculars with both hands and move the binocular body

(see Fig. B) until the two circles are superimposed to form one full circle (see Fig. C).

Plastic eyecups (for spectacle wearers) Fold back the eyepiece cups

. This enlarges the field of vision and makes using the binoculars easier for spectacle wearers.

Adjusting the neck cord Thread the ends of the neck cord

Thread the ends of the neck cord

through the cord guides

hen thread the ends of the neck cord

as shown in Fig. E. Pull the neck cord

tight on both sides of the buckle

. This fixes the neck cord

Use with a tripod Note: The tripod and the tripod adapter are not included with the product. They can be pur- chased separately from your specialist dealer. Observe the operating instructions supplied with your tripod during its assembly and use. Take out the tripod cap

from the threaded tripod mount socket

by turning it anti-clock- wise. Screw the threaded connector of the tripod adapter clockwise into the threaded tripod mount socket

on the binoculars. Then con- nect the tripod to the attached tripod adapter. After use, separate the tripod from the tripod adapter. Then unscrew the threaded connector of the tripod adapter anticlockwise out of the threaded tripod mount socket

on the bin- oculars. Put the tripod cap

back on the threaded tripod mount socket

Cleaning and care Never take your binoculars apart for cleaning. Use the cleaning cloth

provided or a soft cloth without threads to clean the binoculars. Do not press hard when cleaning the delicate lens surface. If the lenses are still dirty, dampen the cloth with a little clear alcohol (methylated spirit). Always cover the eyecups

and lens by the eyecups cover

while the binoculars is not in use to avoid scratch on the lens. Put the binoculars in the shoulder bag

while not in use.10 GB/IE

Disposal The packaging is made entirely of recyclable mate- rials, which you may dispose of at local recycling facilities. Contact your local refuse disposal authority for more details of how to dispose of your worn-out product. Warranty The product has been manufactured to strict quality guidelines and meticulously examined before deliv- ery. In the event of product defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below. The warranty for this product is 5 years from the date of purchase. Should this product show any fault in materials or manufacture within 5 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you. The warranty period begins on the date of purchase. Please keep the original sales receipt in a safe loca- tion. This document is required as your proof of pur- chase. This warranty becomes void if the product has been damaged, or used or maintained improperly. The warranty applies to defects in material or manu- facture. This warranty does not cover product parts subject to normal wear, thus possibly considered con- sumables (e.g. batteries) or for damage to fragile parts, e.g. switches, rechargeable batteries or glass parts. Warranty claim procedure To ensure quick processing of your case, please observe the following instructions: Please have the till receipt and the item number (e.g. IAN 123456_7890) available as proof of purchase. You will find the item number on the type plate, an engraving on the front page of the instructions (bot- tom left), or as a sticker on the rear or bottom of the appliance. If functional or other defects occur, please contact the service department listed either by telephone or by e-mail. You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred. Service Service Great Britain Tel.: 0800 404 7657 E-Mail: owim@lidl.co.uk Service Ireland Tel.: 1890 930 034 (0,08 EUR / Min., (peak)) (0,06 EUR / Min., (off peak)) E-Mail: owim@lidl.ie11 FR/BE Jumelles 10 x 50 Introduction Nous vous félicitons pour l‘achat de votre nouveau produit. Vous avez opté pour un produit de grande qualité. Avant la première mise en service, vous devez vous familiariser avec toutes les fonctions du produit. Veuillez lire attentivement le mode d’emploi ci-des- sous et les consignes de sécurité. N’utilisez le produit que pour l’usage décrit et les domaines d’application cités. Conserver ces instructions dans un lieu sûr. Si vous donnez le produit à des tiers, remettez-leur éga- lement la totalité des documents.
