Shiatsu MC 812 - Massage device MEDISANA - Free user manual and instructions

USER MANUAL Shiatsu MC 812 MEDISANA

1 Safety Information 2 Useful Information 3 Operating 4 Miscellaneous 5 Warranty

Massage seat cover Cable remote control On / Off button Button / LED for "Full Back" massage (A + B) Button / LED for "Upper Back" massage (A) Button / LED for "Lower Back" massage (B) Button / LED for Vibration massage Button / LED for Infrared heat

Manufacturer IMPORTANT INFORMATION! RETAIN FOR FUTURE USE! Read the instruction manual carefully before using this device, especially the safety instructions, and keep the instruction manual for future use. Should you give this device to another person, it is vital that you also pass on these instructions for use.

1 Safety InformationŸBefore connecting the device to your power supply, please ensure that the supply voltage stated on the rating plate is compatible with your mains supply. ŸOnly insert the power supply unit into a socket when the appliance is switched off. ŸOnly use the power supply unit supplied for the massager. ŸKeep the power supply unit, cable and appliance well away from heat, hot surfaces, moisture and liquids. ŸDo not touch the power supply unit when you are standing in water and always take hold of the plug with dry hands. ŸDo not take hold of a device if it falls into water. Pull out the power plug and the power supply unit from the socket immediately. ŸConnect the device only in that way, so that the power plug is freely accessible. ŸAlways switch off the appliance after use with the buttons on the control unit and unplug the power supply unit. ŸTo disconnect the unit from the power supply, always pull the plug out of the socket. Do not pull on the cable! Ÿ Do not carry, pull or rotate the device by its power cord. ŸIf the power supply cable is damaged, it may only be replaced by MEDISANA, an authorised dealer or by qualified personnel. ŸEnsure that the cable will not cause tripping. The cable must not be kinked, trapped or twisted. about the power supply

1 Safety Information 11ŸThis appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. ŸChildren must be supervised to ensure that they do not play with the device. ŸDo not use this unit to supplement or replace medical treatment. Chronic complaints and symptoms may be made worse. ŸDo not use the device, or only after consulting your doctor, if:

- you are pregnant, - you have a cardiac pacemaker, artificial joints or electronic implants, - you suffer from one or more of the following illnesses and complaints: Circulation disorders, varicose veins, open wounds, bruises, broken skin, inflammation of the veins. ŸIf you experience any pain or discomfort during the massage, stop immediately and consult your doctor. ŸTake care when using the heating function. The appliance has hot surfaces. Do not use the appliance on small children, vulnerable individuals or people who are not sensitive to heat. ŸBefore using the device, consult your doctor regarding any unexplained pain, if you are undergoing medical treatment or using medical equipment. ŸDo not use this product after a meal. specific groups of people

1 Safety Informationbefore using the unit ŸCheck the power supply unit, cable and device carefully for damage before each use. Do not attempt to use a defective unit. ŸDo not use the appliance if it, or the power cord show signs of damage, if it is not in perfect working order, or if it has been dropped or become damp. In order to prevent hazards, always send the unit in to the service centre. operating the unit The device is not to be used for commercial use or medical purposes. If you have health concerns, consult your doctor before using the device. Only use the massage seat cover indoors. Do not use the device in damp rooms (e.g. when bathing or showering). ŸThe device must only be used for its intended purpose as described in the instruction manual. ŸUsing the unit for any other purpose invalidates the warranty. ŸOnly use this device in the correct position as described in this manual. ŸDo not use the appliance while you are asleep or when you are lying in bed. ŸDo not use the appliance before going to sleep. The massage has a stimulating effect. ŸNever use the appliance while driving a vehicle or operating a machine. ŸThe maximum operating time for one session is 15 minutes. Prolonged use reduces the service life of the appliance.

1 Safety Information 13ŸVery long periods of use can lead to overheating. Always allow the appliance to cool down before using it again. ŸNever put the unit down next to an electric stove or other sources of heat. ŸNever leave the unit unattended if it is connected to the power supply. ŸDo not allow the massage seat cover to come into contact with pointed or sharp objects. ŸNever use the device under covers, such as blankets or pillows. There is danger of fire, electric shock or injuries. ŸDo not use an external time switch or a separate remote control system to operate the appliance. maintenance and cleaning ŸThe unit is maintenance free. If a fault does occur, just check whether the mains power adapter is properly connected. ŸYou may only clean the device yourself. If the device malfunctions please do not repair it yourself as this leads to the automatic expiry of all guarantee rights. Ask your specialist dealer and have repairs carried out by the service. ŸCleaning and user maintenance shall not be made by children without supervision. ŸDo not immerse the device in water or other fluids. ŸIf, nonetheless, liquid should penetrate the device, unplug the mains cable immediately.

1 Safety InformationThank you for your confidence in us and congratulations! You have acquired a MEDISANA quality product with this Shiatsu mas-sage seat cover MC 812. We recommend that you carefully read the following information on use and care of the product so that you experience its benefits and enjoy using your MEDISANA Shiatsu massage seat cover MC 812 for many years.Thank youvery muchThe packaging can be reused or recycled. Please dispose properly of anypackaging material no longer required. If you notice any transport damage during unpacking, please contact yourdealer without delay.

WARNING Please ensure that the polythene packing is kept away fromthe reach of children! Risk of suffocation!Please check first of all that the device is complete and is not damaged in any way. In case of doubt, do not use it and contact your dealer or your service centre. The following parts are included: Itemssupplied and packaging1 MEDISANA Shiatsu Massage seat cover MC 8121 Control unit1 Instruction manual

Shiatsu is a form of finger pressure massage and one of the most im- portant massaging techniques along with manual lymphatic drainage and reflexology. This form of physical therapy was developed in Japan but stems from traditional Chinese massage. Gentle stroking and bene-ficial pressure application techniques are used to awaken life forces and encourage them to flow through the body. The object of the massage is not just to ease tension, but also to opti-mise the flow of life force and harmonise body and soul. What is Shiatsumassage?In the MEDISANA Shiatsu massage seat cover MC 812 you have a modern device for genuine Shiatsu style back massages.The MEDISANA Shiatsu massage seat cover MC 812 has four rotating massage heads for Shiatsu massage of the three zones “Upper Back”, “Lower Back” and “Full Back”. The device is equipped with an additional vibration function and an infrared heat function. The unique combination ofintensive shiatsu and vibration massage with radiated heat makes the massage seat cover an effective and relaxing treatment. Their settings can be comfortably adjusted by means of the easy-to-handle control unit. How does the MEDISANAShiatsu MassageSeat Coverwork ? CAUTION Make sure that the maximum operating time of 15 minutes is not exceeded.

2 Useful Information 15The use of the Shiatsu massage seat cover will improve your wellbeing after a stressful day. The massage effect is particularly useful for treating tense muscles and tired tissue. The unit provides pleasant relaxation for overcoming everyday stress. The massaging can improve your well- being, and is also useful in the sport and fitness areas.

• This massage seat cover can be fixed on an office chair or any suitable seating with a backrest (e.g. chair, sofa or similar).

• Insert plug into the mains socket. Ensure that the power supply is easily accessible.

• Take a seat on the Shiatsu massage seat cover and familiarise your- self with the functions.

Operation Operating the unit

The MC 812 shiatsu massage seat cover can be switched on by pressing the On / Off button . After pressing the button, the LED above the On / Off button will flash and the massage heads will be automatically moved to home position. During this process, no function key works. After the homing function, the LED will stop flashing and the device is ready to use. During the homing function, do not press any function key until the LED above the On / Off button lights up constantly to indicate the device is ready to use.

ŸWhen the “Upper Back” massage button ("A") is pressed, the LED next to the button illuminates and the Shiatsu massage heads move from the home position up to the upper back area, massaging the back in a circular motion whilst doing so. If you press the button during the massage again, this function is switched off. ŸIf you press the “Lower Back” massage button ("B") , the LED next to the button illuminates and the Shiatsu massage heads move from the home position to the lower back area, massaging the lower back in a circular motion whilst doing so. If you press the button during the massage again, this function is switched off. ŸIf you press the “A+B” massage button the function procedure is similar to pressing buttons and , except that it is for the entire back. ŸYou can enhance the shiatsu massage at any time with a vibration massage by pressing the vibration massage button . ŸThe heat function can be activated at any time with the shiatsu mas- sage, just press the button for infrared heat to activate the function; the respective LED lights up. Press the button again to deactivate the heat function. ŸAfter each use, switch the device off using the On/Off button and remove the plug from the mains socket.

3 Operating Use the buttons on the cable remote control to operate the massage seat cover:4.1 Cleaning andmaintenanceBefore cleaning the appliance, make sure that the appliance is switched off and the power supply unit is disconnected. Allow the unit to cool down.Clean the device with a slightly damp sponge only. Never use brushes,aggressive cleaning agents, petrol, thinners or alcohol. Rub the seat dry with a clean dry cloth. Never immerse the appliance in water to clean it and ensure water cannotget into the appliance. Wait until the device is completely dry before using it again. i Undo any kinks in the cable. i Take care when rolling up the mains lead to avoid damaging it. iYou should ideally store the device in its original packaging and keep it in a clean, dry place.

Name and model Voltage supplyPower consumption Automatic switch-offOperating conditionsStorage conditionsWeightArticle No.EAN Code Technicalspecifications:

This product must not be disposed of together with domestic waste. All users are obliged to hand in all electrical or electronic devices, regard-less of whether or not they contain toxic substances, at a municipal or commercial collection point so that they can be disposed of in an en-vironmentally acceptable manner. Consult your municipal authority or your dealer for information about disposal. Disposal NOTES

• After approx. 15 minutes, the unit will switch off automatically for your safety.• When selecting the heat vibration together with the back massage, there will be a slight decrease of vibration strength. This adjust- ment is perfectly normal and should not be interpreted as a defect.In accordance with our policy of continual product improvement,we reserve the right to make technical and optical changeswithout notice.

3 Operating / 4 Miscellaneous

4 Miscellaneous The current version of this instruction manual can be found under www.medisana.comMEDISANA AG Jagenbergstraße 19 41468 NEUSS Germany eMail:[e-mail] Internet: www.medisana.com The service centre address is shown on the attached leaflet. Please contact your dealer or the service centre in case of a claim under the warranty. If you have to return the unit, please enclose a copy of your receipt and state what the defect is. The following warranty terms apply:

1. The warranty period for MEDISANA products is 3 years from date

of purchase. In case of a warranty claim, the date of purchase has to be proven by means of the sales receipt or invoice.

2. Defects in material or workmanship will be removed free of charge

within the warranty period.

3. Repairs under warranty do not extend the warranty period either for

the unit or for the replacement parts.

4. The following is excluded under the warranty:

a. All damage which has arisen due to improper treatment, e.g. non- observance of the user instructions. b. All damage which is due to repairs or tampering by the customer or unauthorised third parties. c. Damage which has arisen during transport from the manufacturer to the consumer or during transport to the service centre. d. Accessories which are subject to normal wear and tear.

5. Liability for direct or indirect consequential losses caused by the unit

are excluded even if the damage to the unit is accepted as a warranty claim. Warranty and repair terms
