BBEK1092 - Food Processor BRABANTIA - Free user manual and instructions

Features	Details
Product type	Food processor
Power	1500 W
Bowl capacity	4.5 liters
Bowl material	Stainless steel
Included accessories	Whisk, dough hook, beater
Adjustable speed	6 speeds
Pulse function	Yes
Dimensions	40 x 25 x 30 cm
Weight	5.5 kg
Usage	Preparation of doughs, creams, sauces, and other mixtures
Maintenance	Bowl and accessories dishwasher safe
Safety	Lid locking system, non-slip feet
Warranty	2 years

Frequently Asked Questions - BBEK1092 BRABANTIA

How do I assemble the BRABANTIA BBEK1092 food processor?

To assemble the processor, start by placing the bowl on the base, then attach the lid by turning it until it clicks into place. Make sure the accessories are properly in place before use.

How do I clean the BRABANTIA BBEK1092 food processor?

Unplug the processor and remove the accessories. Wash the bowl and accessories with warm soapy water or place them in the dishwasher. Wipe the base with a damp cloth.

What should I do if the food processor does not start?

Check that the processor is properly plugged in and that the outlet is working. Ensure the bowl and lid are correctly positioned, as the processor will not start if these parts are not securely attached.

The BRABANTIA BBEK1092 food processor is very noisy, is this normal?

A certain level of noise is normal when using powerful motors. However, if the noise is excessive or unusual, check that the accessories are correctly installed and that no foreign objects are blocking the motor.

How do I resolve an overheating issue?

If the processor overheats, turn it off immediately and unplug it. Let it cool down for at least 30 minutes before using it again. Avoid using the processor for extended periods without breaks.

Where can I find spare parts for the BRABANTIA BBEK1092?

Spare parts can be ordered directly from the manufacturer via their official website or from authorized dealers. Be sure to provide the exact model when ordering.

Can the food processor be used to prepare hot foods?

The processor is designed for cold and room temperature preparations. Do not use it for hot or high-temperature liquid foods, as this could damage the appliance.

How do I register the product warranty?

To register the warranty, visit the BRABANTIA website and fill out the product registration form with your information and the serial number of your food processor.

USER MANUAL BBEK1092 BRABANTIA

1. Please read the information and safety advice contained in these operating instructions carefully and thoroughly before you use the Stand Mixer for the first time.
2. The Stand Mixer should only be used for its intended purpose.
3. Before use, place the Stand Mixer on a horizontal and flat surface.
4. Place this appliance as close as possible to the power source so that you can disconnect the plug quickly and easily.
5. This appliance should not be set up in close proximity to a naked flame, inflammable materials (curtains, textiles, etc.), a radiator, an oven or any other heat source.
6. To avoid an electric shock do not use this appliance in the vicinity of water. Do not immerse the mains lead in water or other liquid.
7. Do not kink or clamp the mains lead. To avoid an accident do not allow the mains lead to hang over the edge of a table or a counter.
8. Switch off the appliance before changing accessories or approaching parts which move in use.
9. Make sure that the voltage shown on the rating plate corresponds to the voltage of the mains supply. The rating plate can be found on the bottom of the motor block. The Stand Mixer may only be connected to an AC power supply (220~240V). The motor must always be switched off before the Stand Mixer is connected to the mains supply. Turn the power switch (5) to the off position.
10. The Stand Mixer must be operated with the type of power specified on the rating plate. If you are unsure about the details of the available power supply, ask your dealer or the local power supply company.
11. Unplug the appliance when not in use or before cleaning.
12. Do not use outdoors. This appliance is suitable for indoor use only.
13. Do not use the Stand Mixer when the head unit is lifted up.
14. During use, do not touch moving parts with your fingers.
15. Never operate the Stand Mixer when it is empty. Never leave the appliance unsupervised when switched on.
16. Repairs should only be carried out by an authorised service centre.
17. Do not attempt to repair the Stand Mixer yourself, as opening or removing covers will expose you to live components and other hazardous conditions.
18. If the supply cord is damaged, it must be replaced by the manufacturer, an authorised service centre or a similarly qualified person in order to avoid a

hazard.

1. This is not a toy! Keep this appliance out of the reach of children. This appliance should be used and stored out of the reach of children.
2. Careful supervision is required when the appliance is used by or in the vicinity of children.
3. This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capacities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
4. Please note that when passing this appliance on to a third party, the operating instructions must be included.
5. No liability is accepted for damage due to improper use or the failure to observe the operating instructions or the safety notices.
6. IMPORTANT: Do not operate the mixer for more than 8 minutes (continuously) at a time.*
7. Meat grinder and blender not operational on this model. Do not operate with either the grinder or blender cover open.

KNOW YOUR TABLE BLENDER

1: Mixer blade
2: Large cover
3: Upper housing cover
4: Release button
5: Power switch
6: Lower housing cover
7:Feet

8: Mixing bowl
9: Egg whisk
10: Dough hook
11: Splash cover
12: Meat grinder cover
13: Blender cover
* Non functional

Before first use

1. All parts of the Stand Mixer must be thoroughly cleaned before being used for the first time. (See cleaning instructions).
2. Unwind the required length of cable from the cable tidy located on the base of the device and connect the device to the mains supply.

USAGE

1. Assemble and prepare all the ingredients. Open the upper housing cover (3) using the release button (4).

Fig. 2/ Fig. 3

1. Place the mixing bowl (8) on the device plate and turn the mixing bowl unit in an anti-clockwise direction until it is fixed. Fig. 4/ Fig. 5

2. Fix the dough hook (10) or the eggs whisk (9) or the mixer blade (1) onto the blade connector and rotate the blade connector clockwise until it engages firmly. Fig. 5/ Fig. 6

1. Turn the release button and at the same time press the upper housing cover (3) downwards. Fig. 7
2. Insert the power plug into the power socket. Switch the power switch to P for pulse usage and turn the switch to positions 1-8 for longer/ faster usage.
3. Turn the power switch (5) to the OFF position when finished.
4. Lift the upper housing cover (3) up by turning the release button (4) clockwise.
5. Remove the mixing bowl (8) from the device plate.

OPERATING INSTRUCTIONS

1. Turn the release knob clockwise and lift up the upper housing cover (3).
2. Put the mixing bowl (8) onto the bowl plate and turn the mixing bowl in an anti-clockwise direction. Put the ingredients to be mixed into the mixing bowl.
3. Insert the dough blade (10) or the egg whisk (9) or the mixer blade (1) into the blade connector then twist in a clockwise direction.
4. Press the upper housing cover (3) down by turning the release knob (4) in a clockwise direction.

APPLICATIONS

To mix or knead dough

1. Use the dough hook (10).
2. Put flour and water in a ratio of 5 to 3 into the mixing bowl.

NOTE: Do not put more than a maximum of 1000g of dry flour into the bowl.

1. To make dough, mix on speed 1 for 1 minute and then on speed 2 for 4 minutes.
2. The total amount of mixture inside the bowl must not exceed the amount indicated on the side of the bowl.
3. Do not mix more than a maximum of 2kg at a time.

Whipping egg whites or cream

1. Use the egg whisk (9) on speed 6-8 without stopping for about 5 minutes until the eggs are very fluffy.
2. Use the egg whisk to beat 250ml fresh cream on speed 6-8 without stopping for about 5 minutes until the cream is stiff.
3. When filling the mixing bowl with fresh milk, cream or other ingredients, please ensure that the indicated maximum is not exceeded.
4. A minimum of 3 and a maximum of 20 eggs may be whisked at one time.

Mixing shakes, cocktails or other liquids

1. Use the mixer blade (1) to mix liquids.
2. Mix the ingredients according to the recipe on speed 1 to 8 for about 5 minutes.
3. Do not exceed the maximum quantity indicated on the mixing bowl.
4. Maximum operating time is 5 minutes.

Cleaning

1. Before cleaning, please ensure that the power switch (5) is turned to the off position and that the plug has been disconnected from the socket.
2. Allow the Stand Mixer to cool down before you start to clean it.
3. Clean the exterior of the the Stand Mixer with a moist cloth and mild detergent.
4. When cleaning the interior and exterior and protective dust cover do not use abrasive detergents or alcohol.
5. Do not submerge the Stand Mixer in water when cleaning it.
6. The dough hook (10), egg whisk (9) and mixer blade (1) are not dishwasher safe. The accessories should only be cleaned in warm water and washing-up liquid.
7. The mixing bowl is dishwasher safe. The bowl can also be cleaned in warm water and washing-up liquid. Do not use abrasive detergents.

STANDARD ACCESSORIES

Stand mixer	1pc
Mixing bowl	1pc
Dough hook	1pc
Mixer blade	1pc
Egg whisk	1pc
Splash guard	1pc
User manual	1pc

SPECIFICATIONS

Rated voltage/ Frequency: 220-240V~50/60Hz

Rated power: 1000W

Mixing bowl capacity: Max 5.2 litres

Suggested maximum operating time: 8 minutes (continuous)

• If the unit works continuously for 10 minutes it will automatically cut out.

A reset will be required to start the machine again.

WARRANTY EXCLUSIONS

THE WARRANTY WILL ONLY BE VALID IF THE PRODUCT IS RETURNED WITH A PROOF OF PURCHASE TILL SLIP AND ORIGINAL PACKAGING.

The warranty will not be valid if:

1. The product has not been installed, operated or maintained in accordance with the manufacturer's operating instructions provided with the product.
2. The product has been used for any purpose other than its intended function.

3. The damage or malfunction of the product is caused by any of the following:

4. Incorrect voltage

5. Accidents (including liquid or moisture damage)
6. Misuse or abuse of the product
7. Faulty or improper installation
8. Mains supply problems, including power spikes or lightning damage
9. Infestation by insects
10. Tampering or modification of the product by persons other than authorised service personnel
11. Exposure to abnormally corrosive materials
12. Insertion of foreign objects into the unit
13. Usage with accessories not pre-approved by Brabantia

Please refer to and heed all warnings and precautions in the instruction manual.

Due to continuous product development, specifications may be subject to change without prior notification.

ENVIRONMENT FRIENDLY DISPOSAL

This marking indicates that this product should not be disposed of with other household waste. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable re-use of material resources. To dispose of your appliance correctly, please contact or take it to your local refuse/ recycling centre. Alternatively, contact your local council for information on your local re-use centre.

NL

BELANGRIJKE VEILIGHEIDSMAATREGELEN

Eiwit of room kloppen

STANDAARD ACCESSORIES

EXCLUSIONS DE GARANTIE

LA GARANTIE N'EST VALIDE QUE SI LE PRODUIT EST RETOURNÉ AVEC UNE PREUVE D'ACHAT, LE BON DE LIVRAISON ET L'EMBALLAGE ORIGINAL.

DIE GARANTIE IST NUR GÜLTIG, WENN DAS PRODUKT MIT EINEM

Should you experience any technical difficulty in setting up or using your new product, please feel free to contact our dedicated customer service help desk.

For Customer from Netherlands and Belgium please contact Elmarc B.V.

Elmarc B.V.

Wishing you many years of pure pleasure with your new Brabantia appliance.
