Technical Specifications	REMINGTON ProPower HC7170 Hair Clipper
Motor Type	ProPower Motor
Cutting Length	3 to 42 mm (adjustable)
Number of Combs	8 guide combs
Battery Life	60 minutes cordless
Charging Time	4 hours
Weight	0.5 kg
Usage	Wireless and wired use
Maintenance	Cleaning with the supplied brush
Safety	Use only on dry hair
Warranty	2 years

Frequently Asked Questions - ProPower HC7170 REMINGTON

How do I charge the REMINGTON ProPower HC7170 clipper?

To charge the clipper, plug the charger into a power outlet and connect it to the clipper. Make sure the charging indicator lights up to confirm the clipper is charging.

What is the clipper's battery life after a full charge?

The REMINGTON ProPower HC7170 clipper has approximately 60 minutes of battery life after a full charge.

How do I clean the clipper blades?

To clean the blades, remove the cutting guard and use the supplied brush to remove hair. You can also rinse the blades under running water, but make sure the clipper is unplugged before doing so.

What should I do if my clipper does not turn on?

First, check that the clipper is charged. If it still does not turn on, try plugging it directly into the power outlet. If the problem persists, you may need to contact customer service.

How do I adjust the cutting length of the clipper?

To adjust the cutting length, use the different guards supplied with the clipper. Attach the desired guard to the cutting head and ensure it is securely in place before starting to cut.

Is the clipper waterproof?

The REMINGTON ProPower HC7170 clipper is not fully waterproof but is water-resistant. Avoid fully submerging it in water.

How do I know when to change the blades?

If you notice the clipper pulling or snagging hair, or if cuts become uneven, it is probably time to change the blades.

Can I use the clipper on wet hair?

It is recommended to use the clipper on dry hair for best results. However, you can use it on slightly damp hair if necessary.

USER MANUAL ProPower HC7170 REMINGTON

Thank you for buying your new Remington® product. Please read these instructions carefully and keep them safe. Remove all packaging before use.

IMPORTANT SAFEGUARDS

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been supervised/instructed and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be done by children unless they are older than 8 and supervised. Keep the appliance and cable out of reach of children under 8 years.

The device is suitable for cleaning under an open water tap.
WARNING: Detach the shaver from the charging adapter before cleaning it in water.
- Do not use the product with a damaged cord. A replacement can be obtained via our International Service Centres.
- This product should only be used with the charging adaptor supplied.
- The adaptor contains a transformer. Do not cut off the adaptor to replace it with another plug, as this causes a hazardous situation.
- Use this appliance only for its intended use as described in this manual. Do not use attachments not recommended by Remington.
- Do not use this product if it is not working correctly, if it has been dropped or damaged, or dropped in water.
- This appliance should never be left unattended when plugged into a power outlet, except when charging.
- Keep the power plug and cord away from heated surfaces.
- Do not plug or unplug the appliance with wet hands.
- Do not twist or kink the cable, or wrap it round the appliance.
- This appliance is not intended for commercial or salon use.

GB

PARTS

1. On/Off/Turbo Switch
2. Blade set
3. 2 attachment guide combs 1-21mm and 24-44mm (not shown)

4. Blade release button

5. Digital display

6. Micro USB port
7. Adaptor (not shown)
8. Slide select adjustable comb switch

GETTING STARTED

CHARGING YOUR APPLIANCE

• Before using your hairclipper for the first time, charge for 4 hours.
• Ensure the product is switched off.
• Connect the charging adaptor to the product and then to the mains.
• If the product is not going to be used for an extended period of time (2 - 3 months), unplug it from the mains and store.
• Fully recharge your hairclipper when you would like to use it again.
• Allow 4 hours for a complete charge.

DIGITAL DISPLAY

• The device features a digital fuel gauge to show remaining charge and charging status:

During charging:
When the unit is plugged in, the corded indicator icon will show ( ) With the device turned off and connected to the charger, the display will light up in a rotating pattern during charging.
Once charged the display will show 90 and the corded indicator icon ( )
During corded use:
When the unit is plugged in, the corded indicator icon will show ( ) Normal operating speed:
When the unit is plugged in, the corded indicator icon will show ( ) Turbo mode:
During cordedless use:
The display will show the remaining run time in minutes. When the run time reaches 5 minutes it will flash.
When in turbo mode, the display will be the same as above with the turbo symbols (>>>)

• To preserve the life of your batteries, let them run out every 6 months then recharge for 4 hours.
• The clipper comes with a quick charge function, 10 minutes charging will give an emergency burst of run time.

CHARGING VIA STANDARD ELECTRICAL SOCKET

• Ensure the product is switched off.
• Connect the charging adaptor to the product and then to the mains.

USB

• Connect Micro USB to the appliance, and the USB connector to any standard USB port or charger
• Product will only charge through USB and will not run in corded mode.

CORDED USE

• Connect the charging adaptor to the product then to the mains.

CAUTION Extended mains only use will result in the reduction of the battery life.

CORDLESS USE

• When the product is switched on and fully charged it can be used in cordless mode for up to 90 minutes.

INSTRUCTIONS FOR USE

BEFORE STARTING THE CUT

• Inspect the clipper making sure that it is free from hair and dirt.
• Seat the person so that their head is approximately at your eye level.
• Before cutting, always comb the hair so it is tangle free and dry.

TO ATTACH A COMB

• Hold the comb with its teeth upward.
• To attach a comb, align the legs of the comb with the holes in the top of the clipper on each side of the blade and slide the legs into the trimmer until they click.
• To remove, firmly pull the comb straight up away from the clipper.

HAIR CLIPPER COMB SETTINGS

• The clipper comes with two adjustable combs, a short length adjustable comb (indicated by 1-21mm on the back of the comb) and a longer length adjustable comb. (indicated by 24-44mm on the back of the comb).

• Please see table below for different cutting lengths available on each comb.

Shorter Length Adjustable Comb Longer Length Adjustable Comb
1mm 24mm
3mm 26mm
6mm 29mm
9mm 32mm
12mm 35mm
15mm 38mm
18mm 41mm
21mm 44mm

• On the slide select switch there is a silver indicator which, when the short length adjustable comb is on the product, shows the corresponding length setting on the left of the slide select switch. On the other side of the slide select switch there is another silver indicator which shows the corresponding length setting when the longer length adjustable comb is on the product, on the right side of the slide select switch.
• To adjust the length settings, you must press the upper half of the slide select switch to release the locking mechanism, then apply force upwards on the slide select switch to increase the length setting. To decrease the length settings press the upper part of the slide select switch down and slide downwards.
• Use the clipper without any fixed combs for trimming hair close to the skin.
• This will trim hair to 1mm , holding the clipper so the blades are perpendicular to the skin will trim hair to 0.5mm .

INSTRUCTIONS FOR CUTTING HAIR

• To turn the product On or Off slide the switch. To locate the On/Off switch please refer to the key features section.
• For even cutting, allow the comb attachment/blade to cut its way through the hair. Do not force it through quickly. If you are cutting for the first time, start with the maximum comb attachment.

STEP 1 - NAPE OF THE NECK

• Set the comb to 3mm or 6mm.
• Hold the clipper with the blade teeth pointing upwards. Begin starting at the centre of the head at the base of the neck.
• Slowly lift the clipper, working upwards and outwards through the hair, trimming just a little at a time.

STEP2-BACKOF THE HEAD

• With the comb set at 12 mm or 18 mm ,cut the hair at the back of the head.

STEP 3 - SIDE OF THE HEAD

• With the comb set at 3mm or 6mm, trim sideburns. Then change to the longer 9mm guide comb and continue to cut the top of the head.

STEP 4 - TOP OF THE HEAD

• Use the longer length comb attachment and set it to 24mm or 27mm then cut hair on top of the head against the direction in which the hair normally grows.
• For longer hair on top, use the longer length comb attachment (24 - 44mm) to achieve the desired style.
  Always work from the back of the head.

• Use the clipper without an attachment comb for close trimming around the base and sides of the neck.
  To produce a clean straight line at the sideburns, reverse the hair clipper.
• Place the reversed clipper at right angles to the head, tips of the blades lightly touching the skin and then work downwards.

AUTO TURBO SYSTEM

• Push the power button and the appliance runs in Normal Mode. The Auto Turbo will automatically activate when the clipper senses it needs more power.
• To run in Turbo mode, hold down the power button for 2 seconds and the clipper will run in boost until it is turned off.

CARE FOR YOUR HAIRCLIPPER

• Your clipper is fitted with high quality blades.
  To ensure long lasting performance of your clipper, clean the blades and unit regularly.
• Always keep the attachment guide comb on the trimmer blade.

AFTER EACH USE

• Ensure the appliance is switched off and unplugged from the mains before cleaning.
• Brush the accumulated hair from the blades and body of the clipper. Do not submerge the clipper in water.
• To clean unit, wipe with a damp cloth and dry immediately.
• Place a few drops of cutter or sewing machine oil onto the blades. Wipe off excess oil.

WASHABLE BLADE CLEANING

This clipper is fully washable and therefore can be rinsed under a running tap. However, avoid getting the micro USB port wet.

• To remove the blades ensure the unit is off. Press the blade release button on the back of the clipper where it meets the blade and push away from the clipper.

ENGLISH

• To reattach once the blades are cleaned and dry, align the bottom of the blade with the bottom blade housing tab and slide the cartridge back into place until you hear a click.
• Do not run the entire unit under the tap, only the blade set is meant to be submerged water.
• Place a few drops of cutter or sewing machine oil onto the blades. Wipe off excess oil.

EVERY SIX MONTHS

• Remove the 2 screws retaining the fixed blade with a screwdriver.
• Remove the blade set.
• Brush out hairs from between the blades with a soft cleaning brush. Do not remove the lubricating grease from the blades. It is not necessary to remove the small moving blade from the unit.
• If the moving blade has been removed this can be re-fitted by slotting the moving blade holder over the pin in the centre of the interior product head.
• The groove on the moving blade just below the teeth should rest on the plastic pressure arm which rides inside the groove. The fixed blade should be assembled with the bevelled edge of the 2 screw holes facing outward and fixed with screws.
  Note that if the blades are not correctly aligned then cutting efficiency will be impaired.

CLEANING CAUTIONS

• Do not use harsh or corrosive cleaners on the units or their blades.
• Ensure the appliance is switched off and unplug from the main outlet before cleaning.

REMOVING THE RECHARGEABLE BATTERY

We strongly recommend that a professional removes the rechargeable battery. Parts of the shaver case, and tools have sharp edges and may cause injury if not handled correctly.

• The rechargeable battery must be removed from the appliance before it is scrapped.

• Disconnect the charging adapter before removing the battery.

• Ensure that the battery is fully discharged. To do this, operate the trimmer until it stops.

• Remove the comb attachment.
• Detach the blade cartridge.
• Pry the decorative panel off the top housing to expose the 6 screws located in the inner housing.
• Unscrew the 6 screws.
• Pry the inner housing apart from bottom housing to expose the internals and printed circuit board.
• Remove the battery and printed circuit board assembly from the battery chamber.
• Disconnect the battery from the circuit board.
• The battery must be disposed of at an appropriate official recycling/collection point.
• Do not attempt to operate the trimmer once you have opened it.

RECYCLING

To avoid environmental and health problems due to hazardous substances, appliances and rechargeable and non-rechargeable batteries marked with one of these symbols must not be disposed of with unsorted municipal waste. Always dispose of electrical and electronic products and, where applicable, rechargeable and non-rechargeable batteries, at an appropriate official recycling/ collection point.
