RCD2000 - Detector Royal Sovereign - Free user manual and instructions

Product Type	Counterfeit Detector
Brand	Royal Sovereign
Model	RCD-2000
Dimensions (L x W x H)	268 x 140 x 139 mm
Power Supply Voltage	110 V / 60 Hz (US/CA) or 220-240 V / 50 Hz (EU)
Power Consumption	20 W
Ambient Temperature	0 to 40 °C
Ambient Humidity	40 to 90 %
Detection Methods	Ultraviolet, magnetic ink, watermark, microprinting
UV Bulbs	2 x 5 W UV bulbs
Microprinting Magnification	Magnifying lenses
Magnetic Indicator	Audible beep and red indicator light
Watermark Verification Window	Yes
Weight	Approximately 0.5 kg
Cleaning and Maintenance	Clean with alcohol and a dry cloth; unplug before cleaning
Safety	Do not expose eyes to UV; do not use outdoors; unplug before cleaning
Replacement Parts	Replaceable 5 W UV bulbs
Warranty	3 years (excluding bulbs and cosmetic parts)

Frequently Asked Questions - RCD2000 Royal Sovereign

How to use UV detection on the RCD2000?

Place the selector switch to the UV position ("O"). Turn on the device, then place the bill under the UV lamps. A genuine bill will not glow, while counterfeit bleached paper will reflect UV.

How to test magnetic ink on a bill?

Turn on the device: the magnetic head is activated automatically. Rub the suspected area of the bill against the magnetic head. If magnetic ink is present, the device beeps and the red indicator lights up.

How to verify a watermark with the RCD2000?

Place the selector switch to the watermark position ("I"). Insert the bill into the verification window. The watermark should be clearly visible.

How to use the magnifier for microprinting?

No power needed. Place the bill under the magnifying lenses and observe the microprinting. It should be sharp and legible.

What to do if the UV lamp does not turn on?

Check that the device is powered on and the switch is in UV position. If the lamp remains off, replace the UV bulbs with 5 W models.

How to clean the RCD2000 detector?

Unplug the device. Clean the UV bulbs with a dry cloth to remove dust. Use alcohol to clean other surfaces. Do not use liquid aerosol cleaners.

What safety precautions should be taken?

Avoid exposing your eyes to UV rays. Do not place the device near water. Unplug it before cleaning. Do not use if the cord is damaged.

How to obtain a return authorization number for a defective product?

Go to www.royalsovereign.com, Customer Support tab, and request a return authorization number. Returns without this number will not be accepted.

The device no longer works, what should I do?

Check the power supply and fuses. If the watermark window does not work, contact Royal Sovereign customer service. For other issues, refer to the troubleshooting guide.

What is the warranty of the RCD2000?

The RCD2000 has a three-year limited warranty for the original purchaser, excluding bulbs and cosmetic parts. Damage caused by misuse is not covered.

USER MANUAL RCD2000 Royal Sovereign

Two black rectangular electronic devices with a US dollar bill printed on the cover, placed vertically (no visible text or symbols on the device itself)

Please read and retain these instructions.

To register your product, please go to www.royalsovereign.com USA.

Click the customer Support Tab, then Registration Tab.

www.royalsovereign.com

Royal Sovereign International, Inc.

FOUR-WAY COUNTERFEIT DETECTOR

SAFETY INSTRUCTIONS

The safety recommendations outlined in this section should be read and understood before operating this machine. When using this machine follow these basic safety precautions to reduce risk of fire, electric shock or injury. Keep this information for future reference.

Warning

1. Do not expose your eyes directly to Ultraviolet light source (bulb) for extended periods of time.
2. Do not place the machine in an area where it may be exposed to water or other liquids.
3. Before cleaning the machine always unplug the machine from the wall. Do not use liquid or aerosol cleaners on the machine.
4. To reduce the risk of electrical shock, do not take apart the machine. When service or repair work is needed bring it to a qualified service repair technician.
5. Do not use the machine in areas with high temperature or high humidity. This may result in the machine not working properly.

Caution

1. When unplugging the power plug, grip the plug to pull it out. Pulling the cord may result in electric shock, fire, or damage to the machine.
2. Do not use the machine if the cord is damaged. This may result in electric shock, fire, or other hazards.
3. Do not place objects on the power cord and do not bend it excessively. This may result in electric shock, fire or other hazards.
4. When not using the machine for long periods of time, unplug the power cord from the outlet.

CONTENTS

Box Contents 5

Parts 5

Features 6

Operation 7

Troubleshooting 8

Maintenance 8

Specifications 8

Warranty 9

Contact Information 9

FEATURES

Ultraviolet Counterfeit Detection

Ultraviolet light can detect if paper currency and other official documents (including credit cards, driver's licenses, travelers checks, passports, and green cards) are authentic or counterfeit. The ultraviolet light allows you to see fluorescent strips, dots, or other markings used on authentic bills and documents. The special fibrous paper that currency is made from is not fluorescent, where as a counterfeit bill printed on bleached or white paper will reflect ultraviolet light, causing the bill to glow.

Magnetic Ink Counterfeit Detection

Magnetic detection is used to determine if there is magnetic ink present on a bill or document. This is found by rubbing the bill or document over the magnetic head on the machine. If there is magnetic ink present the unit will beep and the red magnetic indicator will light up. If the unit does not beep and the indicator does not light up, the bill or document may not be authentic.

Watermark Counterfeit Detection

The watermark verification window is used to verify that a watermark is present in a bill or document. If the watermark is missing or hard to see, the bill or document may not be authentic.

Micro-printing Counterfeit Detection

The micro-printing magnifier is used to clearly see the micro-printed words on a bill or document. If the micro-printing is missing, the bill or document may not be authentic.

Compact, Portable Design

This unit is lightweight and compact, easily moved from place to place.

OPERATION

NOTE: Before you begin to check your bill or document, make sure you know and understand the security features of that specific bill or document. This will ensure that you are using this machine properly.

1. Plug in the unit and turn the power on by flipping the power switch from "O" to "I" position (on the back of the unit).

To use Ultraviolet counterfeit detection:

1. Flip the Ultraviolet/Watermark selector switch from "I" to "O" (on the front of the unit).

2. Place the bill or document under the UV lamp. If the bill has fluorescent ink or fibers, the bill will glow.

NOTE: Avoid using the counterfeit detector under strong sunlight, as it will affect the ultraviolet light.

To use Magnetic ink counterfeit detection:

1. After turning the unit on, the magnetic head is automatically turned on.
2. Rub the area of the bill or document that is supposed to have magnetic ink on the magnetic head.
3. If magnetic ink is present the unit will beep and the red magnetic indicator will turn on.

To use Watermark counterfeit detection:

1. Flip the Ultraviolet/Watermark selector switch from "O" to "I" (on the front of the unit).
2. Place the bill or document onto the watermark verification window.
3. You should be able to clearly see any watermarks that should be on the bill or document.

To use Micro-printing counterfeit detection:

1. The unit does not need to be turned on for this function.
2. Hold the bill or document under the micro-printing magnifier lens.
3. You should be able to clearly see the micro-printed words and lines on the bill or document.

TROUBLESHOOTING

Symptom Solution
Switch is powered on but ultraviolet bulbs are not working. Replace with new 5W Ultraviolet bulbs.
Switch is powered on but the watermark verification window is not lit. Contact Royal Sovereign's Service Center.

MAINTENANCE

1. Use alcohol to clean the counterfeit detector regularly, and clean the dust on the ultraviolet tube with a dry towel to maintain ultraviolet light quality.
2. Be certain to switch power off when finishing detection to ensure long bulb life.
3. Disconnect power cord for cleaning or maintenance if the unit will not be used for a long time.

SPECIFICATIONS

Model RCD-2000
Ambient Temperature 32~104 °F / 0~40 °C
Ambient Humidity 40~90%
Power Voltage 110V/60Hz (US, CA) or 220~240V/50Hz (EU)
Power Consumption 20W
Unit Size 268 x 140 x 139 (mm)/ 10.6 x 5.5 x 5.5 (in)

LIMITED THREE YEAR WARRANTY

This warranty applies to repair or replacement of product found to be defective in material or workmanship for three years from the date of the original purchase. This warranty is extended only to the original purchaser.

This warranty does not apply to damage resulting from abuse, misuse, or improper maintenance of damage that is attributable to acts of nature. This warranty excludes both parts and labor for bulbs and cosmetic parts (cabinet). Royal Sovereign International, Inc. (and its affiliated companies) is not liable for incidental or consequential damages of any nature. This limitation would not apply if you live in those areas that do not permit the exclusion or limitation of incidental or consequential damages.

Defective products for warranty repair or replacement cannot be returned without a Return Authorization number. Please go to www.royalsovereign.com USA-Customer Support Tab to make a request for an Office Product Return Authorization.

Defective products must be returned to Royal Sovereign International Consumer Return Department, freight prepaid, with proof of purchase and Return Shipping and Handling payment (check or money order). Upon repair or replacement the product will be returned to the customer.

Return defective product to the following address with a detailed description of the problem. If possible, pack in original carton. Please prepay shipping charges.

For out of warranty service or frequently asked questions please go to www.royalsovereign.com USA- Customer Support Tab.

For sales of product, parts or accessories please visit us at www.royalfulfillmentcorp.com.

For service or sales please contact your local Royal Sovereign Office:

ROYAL SOVEREIGN INTERNATIONAL, INC.

2 Volvo Drive Rockleigh, NJ 07647 USA

TEL: [phone] FAX: [phone]

RS CANADA INC. RS Holland B.V.

1025 Westport Crescent, Mississauga On L5T 1E8 CANADA Industrieweg 6K, 4104AR, Culemborg, The Netherlands

TEL : [phone] TF #: [phone] Tel: [phone]

FAX : [phone] Fax: [phone]

www.royalsovereign.com
