| Product Type | Towball bicycle carrier |
| Brand | Buzz Rack |
| Model | Buzzquatro |
| Capacity | 4 bicycles |
| Maximum weight per bicycle | 15 kg (33 lb) |
| Hitch type | Towball ISO 50 mm |
| Fastening system | Straps and holding arms |
| Security | Integrated anti-theft locks |
| Signaling | License plate holder and rear lights (depending on model) |
| Recommended maximum speed | 120 km/h (75 mph) |
| Usage | For standard bicycles, not tandems, recumbent bicycles or with child seat |
| Material | Steel with anti-corrosion coating |
| Maintenance | Clean and lubricate screws and bolts regularly |
| Cleaning | Remove before going through automatic car wash |
| Storage | Do not leave outside permanently, avoid sea air |
| Warranty | Consult the retailer |
Frequently Asked Questions - Buzzquatro Buzz Rack
How to install the Buzzquatro bike rack on my vehicle?
Clean and degrease the towball before mounting. Position the rack on the ball and tighten the locking mechanism. Check that all tightening is correct. Consult the manual for detailed steps.
What is the maximum weight per bicycle?
The maximum weight per bicycle is 15 kg (33 lb). Never exceed this limit.
Can I open the trunk of my car with the bike rack installed?
No, it is not recommended to open the trunk when bicycles are installed. If necessary, first remove the bicycles and the rack.
What is the maximum allowed speed with the bike rack?
Never exceed 120 km/h (75 mph), even if the speed limit is higher.
Is the bike rack compatible with electric bicycles?
Yes, provided that the weight of each bicycle does not exceed 15 kg. Remove the battery if possible to lighten the bicycle.
How to maintain the bike rack?
Regularly inspect parts for wear or corrosion. Lubricate screws and bolts. Remove the rack in extreme weather or car wash.
Can I use this bike rack on a trailer or a motorhome?
No, the bike rack is designed to be mounted on a vehicle towball, not on a trailer, motorhome, or mobile home.
What to do if a part is damaged?
Do not use the product if parts are damaged. Contact your retailer for replacement parts.
Does the bike rack come with an anti-theft system?
Yes, the integrated locks have a theft deterrent function. Use them to secure the bicycles.
Which types of bicycles are not compatible?
Do not transport tandems, recumbent bicycles, bicycles with child seats, panniers, wheel covers or motor. Remove any removable accessories before transport.
User questions about Buzzquatro Buzz Rack
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Bike rack in PDF format for free! Find your manual Buzzquatro - Buzz Rack and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. Buzzquatro by Buzz Rack.
USER MANUAL Buzzquatro Buzz Rack
- Please read and observe the instructions carefully before you use the product, and keep them in a safe place for future use. Check the part list after opening the package. Make sure that all the parts are fully assembled according to the instruction before fitting it on your car.
- The user is responsible for assembly and installation of this product, and the manufacturer disclaims any liability due to improper fitting or use of the product.
- Failure to properly install this bike carier and/or the bikes may cause damage to the vehicle and/or the bikes, and may result in personal injury.
- Do not use this product for purposes other than those for which it is designed. Do not modify any components of the product. Remove the carrier if not in use.
- Do not use the carier to carry more bikes than recommended. The weight of each bike cannot exceed 15kg/ 33lbs.
- Fits 50mm ISO tow balls. Always check the weight limitation of your towing system and never overload it.
- Do not install the bike carrier on trailers, campers, or RVs.
- This bike rack is not intended for transporting tandem, or recumbent bicycles.
09.Do not transport bicycles with attached baby seats, panniers, wheel covers, full bike covers or motors.
SAFE AND PROPER USE
- Please make sure you clean the surface of the towball completely before installing the rack.
- Check if the distance from the exhaust pipe to the bicycle tires is safe for your bicycles or the straps of the carrier. The heat of the exhaust could damage the bike or bicycle racks.
- If your vehicle is equipped with an automatic tailgate opening system, disable this function when using the bike carrier, and open the tailgate manually.
- When loading the bicycles, remove all loose parts and accessories from bicycles (toolbars, baby carriers, pumps, etc.)
- Always position the biggest/heaviest bike first and closest to the car, and then position the smaller bike after that.
- The user is responsible for periodically verifying that all hardware, straps, knobs, hubs are securely tightened for safety purposes.
- You might have to use extra protections to protect the bikes and the tailgate from scratches.
- Do not open the gate with the bikes installed on the carrier.
- The locks used on this rack are theft deterrent.
ROAD SAFETY
- Check before departure that the light board of the carrier is properly functioning.
- The bicycle rack increases the vehicle's length, and the bicycles may increase its width and height. Be aware of this when passing through narrow or low clearance spaces and when reversing.
Any loads exceeding the indicated dimensions must nevertheless respect existing regulations and be properly strapped down. - The load of rack and bicycles will affect driving. Do not exceed the speed limit, and do not drive faster than 120km / h (75 mph).
- Drive slowly over speed bumps. Respect the speed limit, and adapt your speed to the condition of the road.
- Off-road driving is not recommended and could result in damage to your vehicle, hitch receiver, bike carrier, or your bikes.
- If you hit a bump or a hole in the road, stop your vehicle and inspect the bikes and the carrier. If you notice anything wrong, remove the bikes and do not use the bike carier.
- Make sure there is a safe distance between the bikes and the ground, especially when entering a driveway.
MAINTAINING YOUR BICYCLE RACK
- Periodically inspect the product for signs of wear, corrosion, and fatigue.
- Do not use the carrier with defective parts, contact the dealer to replace them before using it again.
- Remove the product before entering an automatic car wash.
- To keep your product in the best condition, it is recommended to remove the product from the car when not in use. Please be advised that this product is not designed to resist extreme weather
conditions, especially seacoast air. - Lubricate the bolts in order to avoid corrosion.
