Product TypeEnhanced G Wireless Router
BrandDynex
ModelDXWEGRTR
Wireless StandardsIEEE 802.11b, 802.11g
Maximum Wireless SpeedUp to 125 Mbps (Enhanced G mode)
LAN Ports4 RJ-45 10/100 Mbps ports
WAN Port1 RJ-45 10/100 Mbps port
Power Supply5 V DC, 2.5 A
Wireless SecurityWEP 64/128-bit, WPA-PSK, WPA2-PSK
Built-in FirewallSPI, NAT, MAC filtering, WAN ping blocking
Advanced FeaturesDHCP, UPnP, VPN Pass-Through, DMZ, QoS
ConfigurationSetup Wizard, Web interface (192.168.2.1)
Antennas2 external antennas (non-removable)
LED IndicatorsPower, WLAN, Internet, modem, LAN ports, WPS
ButtonsReset, WPS sync
Supported Operating SystemsWindows 2000, XP, Vista, Mac OS X, Linux
Operating Temperature0°C to 40°C
Operating Humidity10% to 85% (non-condensing)
Dimensions (approx.)15 x 12 x 3 cm
Weight (approx.)300 g
Box ContentsRouter, quick installation guide, installation CD, Ethernet cable, power adapter
Warranty1 year limited

Frequently Asked Questions - DXWEGRTR Dynex

How to install the Dynex DXWEGRTR router?
Unplug the modem, connect it to the router using the supplied Ethernet cable, plug in the power, then insert the installation CD and follow the Setup Wizard.
How to configure Wi-Fi security?
Open a browser, go to 192.168.2.1, log in (blank password by default), go to Wireless > Security and choose WPA2-PSK by entering a strong key.
How to reset the router to factory defaults?
Press and hold the Reset button on the back for about 10 seconds until the lights flash. The settings will revert to default values.
What to do if I cannot access the web interface?
Check that the computer is connected to the router and that the IP address is on the same subnet (e.g., 192.168.2.x). Try temporarily disabling the firewall or resetting the router.
How to use the WPS function?
Press the WPS button on the front of the router for 3 seconds, then enable WPS on your client device within 2 minutes. The secure connection is established automatically.
Can the router be used as an access point?
Yes, in the web interface go to Wireless > Use as Access Point, enable the option and configure an IP address in the same subnet as your main network.
How to block internet access for a child at certain times?
In Firewall > Client IP Filters, enter the computer's IP address, ports (80 for web), select Block and set the time ranges. Validate by clicking Apply Changes.
What does the flashing green Internet LED mean?
The flashing Internet LED indicates that the router is trying to connect to the Internet. If it remains off, check the connection to the modem. If it is solid, the connection is established.
How to update the router's firmware?
In the web interface go to Utilities > Firmware Upgrade. First download the firmware from the Dynex website, then select the file and click on Upload. Do not turn off power during the update.
Why is my wireless network slow?
Check for interference (microwaves, cordless phones), move the router away from obstacles, change the channel in Wireless > Channel, or enable Enhanced G mode if your clients support it.
