USER MANUAL WGD90HEFC WHIRLPOOL

DÉPANNAGE ..........................................................................33 GARANTIE .............................................................................. 37 ASSISTANCE OU SERVICE ...........................Couverture arrière3 IMPORTANT: When discarding or storing your old clothes dryer, remove the door.4 Accessories Enhance your new washer and dryer with the following genuine Whirlpool accessories. For more information on options and ordering, call 1-800-901-2042, or visit us at: www.whirlpool.com/accessories. In Canada, call 1-800-807-6777 or visit us at www.whirlpoolparts.ca 15" Pedestal Color-matched pedestals raise the washer and dryer to a more comfortable working height. The large drawer provides convenient storage. Stack Kit If space is at a premium, the stack kit allows the dryer to be installed on top of the washer. Drying Rack The Drying Rack provides a stationary drying surface for items such as sweaters and tennis shoes. See the “Additional Features” section for more information.5 Check Your Vent System for Good Airow Good airow Along with heat, dryers require good airow to efciently dry laundry. Proper venting will reduce your drying times and improve your energy savings. See Installation Instructions. The venting system attached to the dryer plays a big role in good airow. Service calls caused by improper venting are not covered by the warranty and will be paid for by the customer, regardless of who installed the dryer. Maintain good airow by:

Cleaning your lint screen before each load.

Replace plastic or foil vent material with 4" (102 mm) diameter heavy, rigid vent material. Good Better

Use no more than four 90° elbows in a vent system; each bend and curve reduces airow.

Remove lint and debris from the exhaust hood.

Remove lint from the entire length of the vent system at least every 2 years. When cleaning is complete, be sure to follow the Installation Instructions supplied with your dryer for nal product check.

Clear away items from the front of the dryer. Use Automatic Cycles for better fabric care and energy savings Use the Automatic Cycles to provide the most energy savings and enhanced fabric care from the dryer. During Automatic Cycles, drying air temperature and moisture level are sensed in the load. This sensing occurs throughout the drying cycle and the dryer shuts off when the load reaches the selected dryness. Use the NORMAL dryness level to provide optimal energy savings. With Timed Dry, the dryer runs the amount of time set and sometimes results in shrinkage, wrinkling, and static due to over-drying. Use Timed Dry for the occasional damp load that needs a little more drying time or when using the drying rack. Tips for getting the best performance from your steam dryer (on some models)

Results may vary depending on fabric. 100% cotton garments with wrinkle-free nish may yield better results than those without. 100% cotton items may require additional touching up after cycles that use steam.

Use of fabric softener sheet is not recommended with cycles that use steam. It may cause temporary staining on clothes.

Cycles that use steam are not recommended for items that have been starched. Wash any starched or new garments prior to using a cycle that uses steam.

The Steam Refresh Cycle is best for smoothing out wrinkles and reducing odors from loads consisting of dry items of wrinkle-free cotton, cotton-polyester blend, common knits, and synthetics.6 Control panel and features Not all features and cycles are available on all models. NOTE: The control panel features a sensitive surface that responds to a light touch of your nger. To ensure your selections are registered, touch the control panel with your nger tip, not your ngernail. When selecting a setting or option, simply touch its name.

EC7 POWER Touch to turn the dryer on and off. Touch to stop/cancel a cycle at any time.

Turn the knob to select a cycle for your laundry load. Automatic Cycles are Heavy Duty, Normal, Bulky, Casual (on some models), Delicates, Towels (on some models), and Sanitize (on some models). Manual Cycles are Quick Dry and Timed Dry. The Steam Cycle (on some models) is Steam Refresh. See “Cycle Guide” for detailed descriptions of cycles. START/PAUSE Touch and hold until the LED comes on to start a cycle, or touch once while a cycle is in process to pause it.

LED DISPLAY AND SETTINGS

When you select a cycle, its settings will light up and the estimated time remaining (for Automatic Cycles) or actual time remaining (for Manual Cycles) will be displayed. On 2-digit displays, for times longer than 99 minutes, hours will be displayed followed by minutes. See “Cycle Guide” for available settings on each cycle. Not all settings are available with all cycles. Cycle Status Lights The indicators at the top of the display will let you know what stage of the drying cycle is in process. For more information on each stage, see “Cycle Status Indicators.” –/+ (Adjust Drying Time) Touch “+” or “–” with Manual Cycles to increase or decrease the length of a Timed Dry or Quick Dry cycle. Temp When using Manual Cycles or Steam Refresh, you may select a dry temperature based on the type of load you are drying. Use the warmest setting safe for the garments in the load. Follow garment label instructions. NOTE: Automatic Cycles use a preset temperature that is not adjustable. Dryness Level When using Automatic Cycles (except for the Sanitize cycle), you may select a Dryness Level based on the type of load you are drying. NOTE: Dryness Level is for use with Automatic Cycles only. Damp Dry Signal (on some models) Touch to select the Damp Dry Signal. When selected, a series of beeps will sound when the load is damp, but not completely dry. This will allow you to take clothes out of the load that do not need to dry completely. This option is available on Heavy Duty, Normal, Bulky, Casual, Delicates, and Towels cycles. The Damp Dry Signal is selected as a default for the Bulky cycle, as a reminder to manually reposition bulky loads midway through the cycle. Wrinkle Shield

Option If you will be unable to remove a load immediately, touch Wrinkle Shield to add up to 140 minutes of periodic tumbling to help reduce wrinkling. You may select the “With Steam” setting (on some models) to add a short steam cycle after 60 minutes to help smooth out wrinkles.

OPTIONS Use to select available options for your dryer. Not all cycles and options are available on all models. Static Reduce Touch to add the Static Reduce option to selected Automatic cycles (see the “Cycle Guide”). The dryer will automatically tumble, pause, and introduce a small amount of moisture into the load to help reduce static. This option adds approximately 8 minutes to the total cycle time. Steam Touch to activate the Steam option, which adds steam to the end of the Heavy Duty, Towels, Normal, or Bulky cycle to help smooth out wrinkles. The Steam option can be used with High or Medium heat settings. EcoBoost

option, which allows you to increase your energy savings by using a slightly lower heat level. The EcoBoost

option will increase drying times by approximately 40 minutes; the LED Display will reect this time. The EcoBoost

option is only available for Normal. For optimal energy turn on the EcoBoost

option. NOTE: Energy savings may vary across loads. Drum Light Touch to turn the LED drum light on or off. The light will also turn on when the door is open, and turn off automatically after about 5 minutes. Cycle Signal Use this to turn the signal indicating the end of a drying cycle on or off. NOTE: You may also turn off the tones that sound when a feature, setting, or option is touched. Touch and hold Cycle Signal for about one second to turn sounds on or off. Control Lock Use to lock the controls of the dryer and avoid an accidental change in cycle options or preferences during a drying cycle. Touch and hold CONTROL LOCK for 3 seconds to lock or unlock the controls of the dryer. During this time, the LED Display will count down 3-2-1. Once the controls are locked, the LED Display will display “Lc” or “Loc.” NOTE: The Control Lock function may be enabled when recovering from a power failure. To unlock the control, touch and hold CONTROL LOCK for at least 3 seconds.

Items to dry: Cycle: Drying Temperature: Dryness Level: Default Time: Available Options: Cycle Details: Work clothes, casual wear, mixed cottons, sheets, corduroys Normal Medium More Normal Less 78 Damp Dry Signal Wrinkle Shield

Static Reduce* EcoBoost

Steam* Uses Medium heat to dry large loads of mixed fabrics and items. Normal is the preferred energy cycle. Jackets, comforters, pillows Bulky Medium More Normal Less 55 Damp Dry Signal Wrinkle Shield

Static Reduce* Steam* Use for drying large, bulky items; do not overll dryer drum. Partway through the cycle, the signal will sound to indicate when it is time to rearrange items for optimal drying. Heavyweight items such as towels or heavy work clothes Heavy Duty High More Normal Less 45 Damp Dry Signal Wrinkle Shield

Static Reduce* Steam* Offers stepped drying starting with High heat followed by Medium heat for enhanced fabric care and energy savings. Large loads of cotton towels, heavyweight items Towels High More Normal Less 1:00

Static Reduce* Steam* This is a high heat cycle. Use for large loads of heavyweight fabrics such as cotton towels. Large loads of heavyweight items Sanitize High More 1:10

This is a long cycle with high heat, which has been proven to reduce household bacteria. This cycle is not recommended for all fabrics. Use for large loads of heavyweight fabrics. Undergarments, blouses, lingerie, performance wear Delicates Extra Low More Normal Less 28 Damp Dry Signal Wrinkle Shield

Static Reduce* Uses Extra Low heat to gently dry delicate items. Shirts, blouses, permanent press, synthetics, lightweight items Casual Low More Normal Less 35 Damp Dry Signal Wrinkle Shield

Static Reduce* Uses a stepped drying temperature from Medium to Low for improved moisture removal and enhanced fabric care. Cycle Guide – Automatic Cycles Settings and options shown in bold are default settings for that cycle. If settings are changed, the new settings will be remembered. If there is a power failure, settings will return to the default. Not all features and cycles are available on all models. Not all settings and options are available on each cycle. Load Size Recommendations For best results, follow the wet load size recommendations noted for each cycle. Small load: Fill the dryer drum with 3–4 items, not more than 1/4 full. Medium load: Fill the dryer drum up to about 1/2 full. Large load: Fill the dryer drum up to about 3/4 full. Do not pack tightly. Items need to tumble freely. Use Automatic Cycles for better fabric care and energy savings The dryer senses moisture in the load or air temperature and shuts off when the load reaches the selected dryness level. Use the NORMAL dryness level to provide optimal energy savings.

On some models, you may select the “With Steam” setting to add a short steam cycle after 60 minutes. This is available only with High and Medium Drying Temperature settings.

• On steam models only.9 Cycle Guide – Manual Cycles Settings and options shown in bold are default settings for that cycle. If settings are changed, the new settings will be remembered (except on Quick Dry). If there is a power failure, settings will return to the default. Not all features and cycles are available on all models. Not all settings and options are available on each cycle. Cycle Guide – Steam Cycle (steam models only) Settings and options shown in bold are default settings for that cycle. Not all settings and options are available on each cycle. Steam cycles are designed for use with dry loads to loosen wrinkles, reduce odors, and refresh fabrics. Load Size Recommendations For best results, follow the load size recommendations noted for each cycle. Small load: Fill the dryer drum with 3–4 items, not more than 1/4 full. Medium load: Fill the dryer drum up to about 1/2 full. Large load: Fill the dryer drum up to about 3/4 full. Do not pack tightly. Items need to tumble freely.

On some models, you may select the “With Steam” setting to add a short steam cycle after 60 minutes. This is available only with High and Medium Drying Temperature settings. Selecting the Drying Temperature A High heat setting may be used for drying heavyweight items such as towels and work clothes. A Low to Medium heat setting may be used for drying medium-weight items such as sheets, blouses, dresses, underwear, permanent press fabrics, and some knits. Use a no heat (air only) setting for foam, rubber, plastic, or heat-sensitive fabrics. Line dry bonded or laminated fabrics. NOTE: If you have questions about drying temperatures for various loads, refer to the care label directions.

You may select the “With Steam” setting to add a short steam cycle after 60 minutes. This is available only with High and Medium Drying Temperature settings.* On steam models only. Items to dry: Cycle: Drying Temperature: Default Time: Available Options: Cycle Details: Small loads and sportswearQuick Dry HighMedium Low Extra LowAir Only13 Wrinkle Shield For small loads of 3–4 items.Any loadNOTE: Select Air Only to dry foam, rubber, plastic, or heat-sensitive fabrics.Timed Dry HighMedium Low Extra LowAir Only40 Wrinkle Shield Use to dry items to a damp level for items that do not require an entire drying cycle. Select a drying temperature based on the type of fabrics in your load. If you are unsure of the temperature to select for a load, select the lower setting rather than the higher setting. Items to refresh: Cycle: Drying Temperature: Default Time: Available Options: Cycle Details: Shirts, blouses, and slacksSteam Refresh High Medium22 Wrinkle Shield Static Reduce*Use to reduce odors and light wrinkles. Do not add dryer sheets. Adjusting drying time on Timed Cycles When you select a Timed Cycle, the time appears in the display. Use + and – to increase or decrease the time in 1-minute increments. Touch and hold to change the time in 5-minute increments. The maximum dry time is 100 minutes.10

Touch POWER to turn on the dryer.

4. Select the desired cycle

Select the desired cycle for your load. See the “Cycle Guide” for more information about each cycle. Not all cycles are on all models. Using Your Dryer

1. Clean the lint screen

Clean the lint screen before each load. Pull the lint screen straight up. Roll lint off the screen with your ngers. Do not rinse or wash screen to remove lint. Wet lint is hard to remove. Push the lint screen rmly back into place. For additional cleaning information, see “Dryer Care.”

Open the door by pulling on the handle. Place laundry in the dryer. Add a dryer sheet to wet load, if desired. Close the door. IMPORTANT: Do not tightly pack the dryer. Items need to tumble freely. Tightly packing can lead to poor drying performance and may increase wrinkling and tangling.

WARNING: To reduce the risk of re, electric shock, or injury to

persons, read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance. Appearance may vary.Appearance may vary.11

7. Touch and hold START/PAUSE

to begin cycle Touch and hold START/PAUSE to begin the cycle.

8. Remove garments promptly

after cycle is nished Promptly remove garments after cycle has completed to reduce wrinkling.

5. Adjust cycle settings, if desired

You may adjust different settings, depending on whether you have selected an Automatic Cycle, Manual Cycle, or Steam Cycle (on some models). See the “Cycle Guide” for detailed information. NOTE: Not all options and settings are available with all cycles. Not all cycles are on all models. Automatic Cycles: You can select a different dryness level, depending on your load. Touch DRYNESS LEVEL to scroll to More, Normal, or Less. Selecting More, Normal, or Less automatically adjusts the dryness level at which the dryer will shut off. Once a dryness level is set, it cannot be changed without stopping the cycle. Automatic Cycles give the best drying in the shortest time. Drying time varies based on fabric type, load size, and dryness setting. Drying time is estimated and may change throughout the cycle. Drying time can not be changed on Automatic Cycles. NOTE: Automatic Cycles use a preset temperature that is not adjustable. Manual Cycles: When you select a Manual Cycle, the time appears in the display. Touch + and – to increase or decrease the time in 1 minute increments. Touch and hold to change the time in 5 minute increments. The temperature may be changed by pressing Temp until the desired dry temperature is lit. Once a cycle has started, the temperature can be changed after rst pausing the cycle. Cycle time is estimated and may change throughout the cycle. Cycle time can not be changed on Steam Cycles. Steam Cycles (on some models): Select Steam Refresh to reduce odors and light wrinkles in dry loads. Do not add dryer sheets. Changing the Automatic Cycle settings to increase or decrease drying time If all your loads on all Automatic Cycles are consistently less dry or more dry than you would like, you may change the default settings to increase or decrease the default dryness level. Your automatic drying settings can be adjusted to adapt to different installations, environmental conditions, or personal preference. This change is retained and will affect all of your Automatic Cycles, not just the current cycle/load. There are 5 drying settings (setting codes differ depending on model), which are displayed using the time display: 01/F1 Factory preset dryness level. 02/F2 Slightly drier clothes, 15% more drying time. 03/F3 Much drier clothes, 30% more drying time. 04/F4 Slightly wetter clothes, 15% less drying time. 05/F5 Much wetter clothes, 30% less drying time. To change the drying settings: NOTE: The settings cannot be changed while the dryer is running or paused. The dryer must be in standby mode (power is off) to adjust the default settings.

1. Before starting a cycle, touch and hold DRYNESS

LEVEL for 6 seconds.

setting. Appearance may vary.

6. Select any additional options

The display will show the settings for the selected cycle. To adjust a setting, touch its name – Static Reduce, Steam, EcoBoost, Drum Light, Cycle Signal, or Control Lock.. NOTE: Not all options and settings are available with all cycles. Appearance may vary. Appearance may vary.12 Additional Features

2. Align the two hooks on the front of the drying rack with

the holes in the dryer door opening and press down fully into holes. Rest the rear support on the dryer back ledge.

USING THE DRYING RACK

To purchase a drying rack for your dryer, order by calling 1-877-944-7566. You will need your model and serial number and the purchase date. Remove and discard any packing material before use. Use the Drying Rack for items that you do not want to tumble dry, such as sweaters and tennis shoes. When you use the drying rack, the drum continues to turn, but the rack remains stationary. The drying rack is intended for use with the Manual Dry/ Timed Dry cycles only. The drying rack cannot be used with Automatic cycles. To use the drying rack: IMPORTANT: Do not remove the lint screen.

3. Place wet items on top of the drying rack. Allow space

around items for air to circulate. The drying rack does not move, but the drum will rotate; be sure to leave adequate clearance between items and the inside of the dryer drum. Make sure items do not hang over the edges or between drying rack grille.

5. Select a Timed Dry/Air Only, or Low Temperature cycle.

Items containing foam, rubber, or plastic must be dried on a clothesline or by using the Air Only setting.

6. When the cycle is selected, the Estimated Time

Remaining display shows the default time. You can change the actual time in the cycle by increasing or decreasing the cycle time.

NOTE: Check the lint screen and remove any lint accumulated from items dried on the drying rack after the cycle is nished. Cycle Status Indicators The Cycle Status Indicators show the progress of a cycle. Not all indicators are available on all models. Check Vent This indicator will show the status of airow through the dryer and dryer vent system for the dryer’s life. During the sensing phase at the beginning of the cycle, the Check Vent light will come on if a blocked vent or low airow issue is detected. This light will stay on for the entire cycle. The light will be cleared when selecting a new cycle, touching POWER, or opening the door after the cycle has completed. This feature is available during Automatic and Steam cycles only. For more information on maintaining good airow, see “Check Your Vent System for Good Airow.” NOTE: If there are other error issues during a cycle, the Check Vent indicator will not light up. See “Troubleshooting” section. Wet The load is still wet and/or the cycle just started. Damp This indicator shows that the load is partially dried and items that you may wish to hang up or iron while still damp may be removed. Cool Down The dryer has nished drying with heat, and is now tumbling the load without heat to cool it down and reduce wrinkling. Done This will indicate that the selected cycle has ended and the load may be removed from the dryer. If Wrinkle Shield

option has been selected, the dryer may continue to tumble the load, even if the Done indicator is lit. Sensing The Sensing indicator will light during Automatic Cycles to indicate that the moisture sensor on the dryer is operating. This indicator will not light during Manual Cycles or options such as Wrinkle Shield. Static Reduce This indicator will light when the Static Reduce function is active. NOTE: Static Reduce is not available on all cycles. Steaming This indicator will light when the Steam function is active. NOTE: Steam is not available on all cycles. Wrinkle Shield

option has been selected and is running. The dryer will periodically tumble the load for up to 140 minutes after the cycle has ended. Appearance may vary.13 Dryer Care

CLEANING THE DRYER LOCATION

Keep dryer area clear and free from items that would block the airow for proper dryer operation. This includes clearing piles of laundry in front of the dryer.

1. Use a mild hand dish detergent mixed at a low

concentration with very warm water, and rub with a soft cloth.

2. Rinse well with a wet sponge or towel.

3. Tumble a load of clean clothes or towels to dry drum

Use a microber cloth and hot water in a spray bottle to clean the drum and a second microber towel to dry. NOTE: Garments that contain unstable dyes, such as denim blue jeans or brightly colored cotton items, may discolor the rear of the dryer interior. These stains are not harmful to your dryer and will not stain future loads of clothes. Dry unstable dye items inside out to avoid transfer of dye.

REMOVING ACCUMULATED LINT

From Inside the Dryer Cabinet Lint should be removed every 2 years, or more often, depending on dryer usage. Cleaning should be done by a qualied appliance servicer. From the Exhaust Vent Lint should be removed every 2 years, or more often, depending on dryer usage.

CLEANING THE LINT SCREEN

Every load cleaning The lint screen is located in the door opening of the dryer. A screen blocked by lint can increase drying time. To clean:

1. Pull the lint screen straight up. Roll lint off the screen

with your ngers. Do not rinse or wash screen to remove lint. Wet lint is hard to remove.

2. Push the lint screen rmly back into place.

Do not run the dryer with the lint screen loose, damaged, blocked, or missing. Doing so can cause overheating and damage to both the dryer and fabrics.

If lint falls off the screen into the dryer during removal, check the exhaust hood and remove the lint. See “Venting Requirements” in the Installation Instructions. As needed cleaning Laundry detergent and fabric softener residue can build up on the lint screen. This buildup can cause longer drying times for your clothes, or cause the dryer to stop before your load is completely dry. The screen is probably clogged if lint falls off while the screen is in the dryer. Clean the lint screen with a nylon brush every 6 months, or more frequently, if it becomes clogged due to a residue buildup. To wash:

1. Roll lint off the screen with your ngers.

2. Wet both sides of lint screen with hot water.

3. Wet a nylon brush with hot water and liquid detergent.

Scrub lint screen with the brush to remove residue buildup.

4. Rinse screen with hot water.

5. Thoroughly dry lint screen with a clean towel.

Water Inlet Hose Replace inlet hose and hose screen after 5 years of use to reduce the risk of hose failure. Periodically inspect and replace inlet hose if bulges, kinks, cuts, wear, or leaks are found. When replacing your inlet hose, record the date of replacement. To Winterize the Dryer

1. Unplug dryer or disconnect power.

2. Shut off water faucet.

3. Disconnect water inlet hose from faucet and drain.

To Use the Dryer Again

1. Flush water pipes. Reconnect water inlet hose to faucet.

Turn on water faucet.

2. Plug in dryer or reconnect power as described in the

Installation Instructions.

NON-USE, STORAGE, AND MOVING CARE

Install and store your dryer where it will not freeze. Because some water may stay in the hose, freezing can damage your dryer. If storing or moving your dryer during freezing weather, winterize it. Non-Use or Storage Care Operate your dryer only when you are at home. If you will be on vacation or not using your dryer for an extended period of time, you should:

1. Unplug dryer or disconnect power.

2. Clean lint screen. See “Cleaning the Lint Screen.”

3. Turn off the water supply to the dryer. This helps to

avoid unintended ooding (due to a water pressure surge) while you are away. Moving Care For power supply cord-connected dryers:

1. Unplug the power supply cord.

2. Gas models only: Close shut-off valve in gas supply line.

3. Gas models only: Disconnect gas supply line pipe and

remove ttings attached to dryer pipe.

4. Gas models only: Cap the open gas supply line.

5. Steam models only: Shut off water faucet.

6. Disconnect the water inlet hose from faucet, then drain

the hose. Transport hose separately.

7. Make sure leveling legs are secure in dryer base.

8. Use tape to secure dryer door.

For direct-wired dryers:

1. Disconnect power.

2. Disconnect wiring.

3. Steam models only: Shut off water faucet.

4. Steam models only: Disconnect the water inlet hose from

faucet; then drain the hose. Transport hose separately.

5. Make sure leveling legs are secure in dryer base.

6. Use tape to secure dryer door.

Reinstalling the Dryer Follow the Installation Instructions to locate, level, and connect the dryer.15 First try the solutions suggested here or visit our website at www.whirlpool.com/product_help – In Canada www.whirlpool.ca for assistance and to possibly avoid a service call. If you experience Possible Causes Solution Door not closed completely. Make sure the dryer door is closed completely. Touch and hold START/PAUSE 2–5 seconds. Household fuse is blown or circuit breaker has tripped. There may be 2 household fuses or circuit breakers for the dryer. Check that both fuses are intact and tight, or that both circuit breakers have not tripped. Replace the fuses or reset the circuit breaker. If the problem continues, call an electrician. Troubleshooting Dryer will not run Humming or whining noise with Steam cycle selected (on some models) Water pump or water inlet valve (depending on model) on dryer is running. Unusual Noise START/PAUSE not touched rmly or held long enough. Dryer Operation Incorrect power supply. Electric dryers require 240-volt power supply. Check with a qualied electrician. Wrong type of fuse. Use a time-delay fuse. The water pump or water inlet valve on the dryer is used during the Steam function. If the dryer has just been installed or unused for an extended period, the pump or valve may be louder and run longer. This is normal. NOTE: The valve may make this noise even with no water line connected. Thumping noise Dryer hasn’t been used in a while. This is due to temporary at spots on the drum rollers. The thumping sound will diminish after a few minutes. Rattling or vibrating noise A small object caught between the edges of dryer drum. Check the front and rear edges of the drum for small objects. Clean out pockets before laundering. Dryer isn’t properly leveled. The dryer may vibrate if not properly installed. See the Installation Instructions. All four dryer feet should be in rm contact with the oor. Clothing is balled up in dryer. When balled up, the load will bounce, causing the dryer to vibrate. Separate the load items and restart the dryer. Dryer Results Dryer will not heat Household fuse is blown or circuit breaker has tripped. The drum may be turning, but you may not have heat. Electric dryers use 2 household fuses or circuit breakers. Replace the fuses or reset the circuit breaker. If the problem continues, call an electrician. Clothes are not drying satisfactorily or drying times are too long Lint screen is clogged with lint. Clean lint screen before each load. Run the dryer for 5–10 minutes. Hold your hand under the outside exhaust hood to check air movement. If you do not feel air movement or air movement is minimal, clean exhaust system of lint or replace exhaust vent with heavy metal or exible metal vent. See the Installation Instructions. The exhaust vent or outside exhaust hood is clogged with lint, restricting air movement. Incorrect power supply. Electric dryers require 240-volt power supply. Check with a qualied electrician. Supply line valve not open. For gas dryers, make sure that the valve on the gas supply line is open. Clicking noise Gas valve operating. On gas dryers, you may hear the gas valve clicking as it opens and closes. This is normal. For optimal dry times, turn off the EcoBoost

option is on. Loud humming or increased noise during cycle Load is packed tightly or exhaust vent is blocked. Reduce load size to recommended load size in “Cycle Guide.” Run the dryer for 5–10 minutes. Hold your hand under the outside exhaust hood to check air movement. If you do not feel air movement or air movement is minimal, clean exhaust system of lint or replace exhaust vent with heavy metal or exible metal vent. See the Installation Instructions.16 Possible Causes Solution Dryer Results (cont.) The dryer is located in a room with temperature below 45ºF (7ºC). Proper operation of dryer cycles requires temperatures above 45ºF (7ºC). The dryer is located in a closet. Closet doors must have ventilation openings at the top and bottom of the door. The front of the dryer requires a minimum of 1" (25 mm) of airspace, and, for most installations, the rear of the dryer requires 5" (127 mm). See the Installation Instructions. Cycle time is too short Steam models only: Clothes are coming out of the Steam Refresh cycle with damp or wet spots. Under certain environmental or installation conditions, you may experience underdrying. The automatic cycle is ending early. Change the dryness level setting on Automatic Cycles. Increasing or decreasing the dryness level will change the amount of drying time in a cycle. If loads are consistently ending too early, see also “Changing the Automatic Cycle settings to increase or decrease drying time.” Lint on load Lint screen is clogged with lint. Stains on load Improper use of fabric softener. Add dryer fabric softener sheets at the beginning of the cycle. Fabric softener sheets added to a partially dried load can stain your garments. Do not use fabric softener sheets with steam cycles. Loads are wrinkled The load was not removed from dryer at the end of the cycle. Steam models only: Select Steam Refresh Cycle to tumble the load with water and heat. This cycle is best for smoothing out wrinkles and reducing odors from dry loads consisting of wrinkle-free cotton, cotton-polyester blends, common knits, and synthetics. NOTE: Refer to garment care label instructions. Dry-clean-only garments are not recommended. The dryer was tightly packed. Dry smaller loads that can tumble freely. Results may also vary depending on fabric type. Clothes are not drying satisfactorily or drying times are too long (cont.) Steam models only: For steam cycles, the water is not properly connected with the dryer. Steam models only: Make sure water is connected to the dryer. Check that water inlet hose is connected to both the faucet and dryer’s water inlet valve. Check that the water supply is turned on. The load is too large and heavy to dry quickly. Fabric softener sheets are blocking the grille. The air outlet grille is just inside the door, behind the lint screen. Check that it is not blocked by a fabric softener sheet. Use only one fabric softener sheet, and use it only once. Separate the load to tumble freely. The load may not be contacting the sensor strips on Automatic Cycles. Level the dryer. See the Installation Instructions. All four dryer feet should be in rm contact with the oor. Clean lint screen before each load. Stains on drum Loose dyes in clothes. Drum stains are caused by dyes in clothing (usually blue jeans). These will not transfer to other clothing. Troubleshooting First try the solutions suggested here or visit our website at www.whirlpool.com/product_help – In Canada www.whirlpool.ca for assistance and to possibly avoid a service call. If you experience The Air Only temperature setting has been selected. Select the correct temperature for the types of garments being dried. See “Cycle Guide.” The exhaust vent is not the correct length. Check that the exhaust vent is not too long or has too many turns. Long venting will increase drying times. See the Installation Instructions. The exhaust vent diameter is not the correct size. Use 4" (102 mm) diameter vent material. The dryer is not level. Clothes not contacting the moisture sensors during Automatic cycles. See “Level Dryer” in the Installation Instructions.17 Possible Causes Solution The drying cycle has been interrupted by a power failure. Touch and hold START to restart the dryer. NOTE: The Control Lock function may be enabled when recovering from a power failure. To unlock the control, touch and hold CONTROL LOCK for at least 3 seconds. There may be a problem with your home power supply, keeping the dryer’s heater from turning on. The dryer will continue to run when this diagnostic code is present. Touch any pad to clear the code from the display and return to the estimated time remaining. NOTE: This error will only show during the initial installation. Try the following: Check to see if a household fuse has blown or circuit breaker has tripped. Electric dryers use two household fuses or breakers. Replace the fuse or reset the circuit breaker. Conrm that the power cord is properly installed. Refer to the Installation Instructions for details. Select a Timed Dry heated cycle, and restart the dryer. If the message persists, consult a qualied electrician. “L2” Diagnostic Code (low or no line voltage condition) The lint screen or vent is clogged; the vent is crushed or kinked or has too many turns. The dryer will continue to run when this indicator is lit. Try the following:

• Check to see if the vent run from the dryer to the wall is crushed or kinked.

• Conrm that the vent run from the dryer to the wall is free of lint and debris.

• Conrm that the exterior vent exhaust hood is free of lint and debris.

• Conrm that your vent system falls within the recommended run length and number of elbows for the type of vent you are using. Refer to “Plan Vent System” in the Installaton Instructions for details.

• Select a Timed Dry heated cycle, and restart the dryer.

• If the indicator remains lit, have your entire home venting run cleaned. Check Vent indicator is lit “PF” (power failure) The dryer is in need of service. If a code beginning with an “F” appears in the display, alternating between F# and E#, the dryer control has detected a problem that requires service. Call for service. Dryer Displaying Code Message or Cycle Status Indicator Lights Up Dryer Results (cont.) Load removed before cooldown portion of cycle complete. Allow the dryer to complete the cooldown portion of the cycle before removing the load. Load too hot Using Timed Dry cycle with a high temperature setting. Select an Automatic Cycle with a lower heat setting to avoid overdrying the load. Odors Recent painting, staining, or varnishing in the area where your dryer is located. Ventilate the area. When the odors or fumes are gone from the area, rewash and dry the clothing. Steam models only: For steam cycles, the water is not properly connected with the dryer. Make sure water is connected to the dryer. Check that water inlet hose is connected to both the faucet and dryer’s water inlet valve. Check that the water supply is turned on. Odors are left in garments after wearing. Steam models only: To remove odors left in garments after wearing, select Steam Refresh. This cycle is best for reducing wrinkles and odors from dry loads consisting of wrinkle-free cotton, cotton-polyester blends, common knits, and synthetics. “F# E#” (F1 E1, F3 E1, etc.) variable service codes First try the solutions suggested here or visit our website at www.whirlpool.com/product_help – In Canada www.whirlpool.ca for assistance and to possibly avoid a service call. If you experience Troubleshooting The Control Lock is enabled. Touch and hold CONTROL LOCK for 3 seconds to unlock the controls of the dryer. During this time the LED Display will count down 3-2-1. When the Control Lock is disabled, the LED Display will clear. “Loc” or “Lc”18 WHIRLPOOL

Name, address, and telephone number

Model number and serial number

A clear, detailed description of the problem

Proof of purchase including dealer or retailer name and address

DISCLAIMER OF IMPLIED WARRANTIES

IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW. Some states and provinces do not allow limitations on the duration of implied warranties of merchantability or tness, so this limitation may not apply to you. This warranty gives you specic legal rights, and you also may have other rights that vary from state to state or province to province. LIMITATION OF REMEDIES; EXCLUSION OF INCIDENTAL AND CONSEQUENTIAL DAMAGES YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN. WHIRLPOOL SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states and provinces do not allow the exclusion or limitation of incidental or consequential damages, so these limitations and exclusions may not apply to you. This warranty gives you specic legal rights, and you also may have other rights that vary from state to state or province to province.

DISCLAIMER OF REPRESENTATIONS OUTSIDE OF WARRANTY

Whirlpool makes no representations about the quality, durability, or need for service or repair of this major appliance other than the representations contained in this Warranty. If you want a longer or more comprehensive warranty than the limited warranty that comes with this major appliance, you should ask Whirlpool or your retailer about buying an extended warranty. 11/14 IF YOU NEED SERVICE:

1. Before contacting us to arrange service, please determine whether your product requires repair.

Some questions can be addressed without service. Please take a few minutes to review the Troubleshooting or Problem Solver section of the Use and Care Guide, scan the QR code on the right to access additional resources, or visit https://www.whirlpool.com/product_help.

2. All warranty service is provided exclusively by our authorized Whirlpool Service Providers.

In the U.S. and Canada, direct all requests for warranty service to: Whirlpool Customer eXperience Center In the U.S.A. call 1-800-253-1301. In Canada call 1-800-807-6777. If outside the 50 United States and Canada, contact your authorized Whirlpool dealer to determine if another warranty applies. https://www.whirlpool.com/product_help

ONE YEAR LIMITED WARRANTY

1. Commercial, non-residential, multiple-family use, or use inconsistent with published user,

operator, or installation instructions.

2. In-home instruction on how to use your product.

3. Service to correct improper product maintenance or installation, installation not in

accordance with electrical or plumbing codes, or correction of household electrical or plumbing (i.e. house wiring, fuses, or water inlet hoses).

4. Consumable parts (i.e. light bulbs, batteries, air or water filters, preservation solutions,

Defects or damage caused by the use of non-genuine Whirlpool parts or accessories.

6. Conversion of your product from natural gas or L.P. gas or reversal of appliance doors.

7. Damage from accident, misuse, abuse, fire, floods, acts of God, or use with products not

approved by Whirlpool.

8. Repairs to parts or systems to correct product damage or defects caused by

unauthorized service, alteration, or modification of the appliance.

9. Cosmetic damage including scratches, dents, chips, and other damage to appliance

finishes unless such damage results from defects in materials and workmanship and is reported to Whirlpool within 30 days.

10. Discoloration, rust, or oxidation of surfaces resulting from caustic or corrosive

environments, including but not limited to, high salt concentrations, high moisture or humidity, or exposure to chemicals.

11. Pick-up or delivery. This product is intended for in-home repair.

12. Travel or transportation expenses for service in remote locations where an authorized

Whirlpool servicer is not available.

13. Removal or reinstallation of inaccessible appliances or built-in fixtures (i.e. trim,

decorative panels, flooring, cabinetry, islands, countertops, drywall, etc.) that interfere with servicing, removal, or replacement of the product.

14. Service or parts for appliances with original model/serial numbers removed, altered, or

not easily determined. The cost of repair or replacement under these excluded circumstances shall be borne by the customer. For one year from the date of purchase, when this major appliance is installed, operated, and maintained according to instructions attached to or furnished with the product, Whirlpool Corporation or Whirlpool Canada LP (hereafter “Whirlpool”) will pay for Factory Specified Replacement Parts and repair labor to correct defects in materials or workmanship that existed when this major appliance was purchased, or at its sole discretion replace the product. In the event of product replacement, your appliance will be warranted by the remaining term of the original unit’s warranty period.

SHALL BE PRODUCT REPAIR AS

Factory Specied Parts. These parts will t right and work right because they are made with the same precision used to build every new WHIRLPOOL

appliance. To locate FSP

© 2015 Whirlpool. All rights reserved. Used under license in Canada.
