USER MANUAL Star 3 TAURUS

QUALSEVOL ALTRE LÍQUID. -Netegeu l’aparell amb un drap humit impregnat amb unes gotes de detergent i després eixugueu-lo. -Per netejar l’aparell, no utilitzeu dissolvents ni productes amb un factor pH àcid o bàsic, com el lleixiu, ni productes abrasius. -No submergiu l’aparell en aigua ni en cap altre líquid, ni el poseu sota l’aixeta. -Si l’aparell no es manté en bon estat de neteja, la superfície pot degradar- se i afectar de forma inexorable la durada de la vida de l’aparell i conduir a una situació perillosa. -Les següents peces són aptes per anetejar-les al rentavaixelles: o Cistella o Tapa o Cubeta o Cos Anomalies i reparació - En cas d’avaria, porteu l’aparell a un servei d’assistència tècnica autoritzat. No intenteu desmuntar-lo o reparar-lo perquè podria ser perillós. - Si la connexió a la xarxa està malmesa, cal substituir-la i actuar com en cas d’avaria. Ecologia i reciclabilitat del producte - Els materials que componen l’envàs d’aquest electrodomèstic estan integrats en un sistema de recollida, classificació i reciclatge. Si us en voleu desfer, utilitzeu els contenidors públics adequats per a cada tipus de material. - Aquest producte està exempt de concentracions de substàncies que es puguin considerar perjudicials per al medi ambient. Aquest aparell compleix la Directiva 2006/95/EC de Baixa Tensió i la Directiva 2004/108/EC de Compatibilitat Electromagnètica. - Aquest símbol significa que si us voleu desfer del producte, un cop exhaurida la vida de l’aparell, l’heu de dipositar, a través dels mitjans adequats, a mans d’un gestor de residus autoritzat per a la recollida selectiva de Residus d’Aparells Elèctrics i Electrònics (RAEE). English Deep fryer STAR 3 FUTURA 2 Dear customer, Many thanks for choosing to purchase a TAURUS brand product. Thanks to its technology, design and operation and the fact that it exceeds the strictest quality standards, a fully satisfactory use and long product life can be assured. Description A Lid B Lid handle C Temperature control thermostat D Pilot light E Automatic safety cut-off F Guide slots G Control unit H Heating element I Frying basket J Basket bracket K Basket handle L Tank M Level indicator N Body O Reset button P Power cable housing Q Power cable R Control unit base Safety advice and warnings -Read these instructions carefully before switching on the appliance and keep them for future reference. Failure to follow and observe these instructions could lead to an accident. -Clean all the parts of the product that will be in contact with food, as indicated in the cleaning section, before use.Personal safety: -Do not touch metal parts or the body when it is operating, as it may cause serious burns. Use and care: -Never connect the appliance without having first of all filled the oil bowl. -Do not use the appliance if the on/off switch does not work. -Do not move the appliance whilst in operation or if the oil is still hot. Once cooled, transport the appliance using the handles. (Fig. 6) -Respect the MAX and MIN levels. (Fig.3) -Disconnect the appliance from the mains when not in use and before undertaking any cleaning task. -This appliance is for household use only, not professional or industrial use. -This appliance is not a toy. Children should be supervised to ensure that they do not play with the appliance. -This appliance is intended for adult use. Ensure that this product is not used by the disabled, children or people unused to its handling. -This appliance should be stored out of reach of children and/or the disabled. -Never leave the appliance unattended when in use and keep out of the reach of children, as this is an electrical appliance that heats oil to high temperatures and may cause serious burns. -If fat is used instead of oil, melt first in a separate recipient (Fig.4) -If fat has hardened in the pan, make a few holes in the solid fat in order to allow the water, which has been retained in the fat to be released as steam when heated at the minimum thermostat temperature (Fig.5) Working environment: -Place the appliance on a horizontal, flat, stable surface, suitable for withstanding high temperatures and away from other heat sources and contact with water. -Keep the appliance away from flammable material such as textiles, cardboard or paper, etc. -Do not use the appliance in association with a programmer, timer or other device that automatically switches it on, as there is a risk of fire if the appliance is covered or incorrectly situated Electrical safety: -Do not use the appliance if the cable or plug is damaged. -Ensure that the voltage indicated on the rating label matches the mains voltage before plugging in the appliance. -Connect the appliance to a base with an earth socket withstanding a minimum of 10 amperes. -The appliance’s plug must fit into the mains socket properly. Do not alter the plug. Do not use plug adaptors. -Do not use or store the appliance outdoors. -Do not use the appliance if it has fallen on the floor, if there are visible signs of damage or if it has a leak. -Do not force the power cord. Never use the power cord to lift up, carry or unplug the appliance. -Do not allow the power cord to hang or to come into contact with the hot surfaces of the appliance. -Check the state of the power cord. Damaged or tangled cables increase the risk of electric shock. -Do not touch the plug with wet hands.-If, for some reason, the oil were to catch fire, disconnect the appliance from the mains and smother the fire using the lid, a cover or a large kitchen cloth. NEVER WITH WATER. -Turn the thermostat control to the minimum (MIN) setting. This does not mean that the iron is switched off permanently. -Any misuse or failure to follow the instructions for use renders the guarantee and the manufacturer’s liability null and void. Instructions for use Before use: -Make sure that all the product’s packaging has been removed. -Before using the product for the first time, clean the parts that will come into contact with food in the manner described in the cleaning section. Oil filling: -Open the cover -Ensure that the electrical equipment is appropriately positioned. -Pour oil up to the mark indicating the MAXIMUM level on the bowl (Fig.3). -The appliance must not be used with less oil than that indicated by the MINIMAL mark. Use: -Remove the lid. This fryer is not designed to fry with the lid on. -Take out the basket and attach the handle (Fig. 7) -Before using the appliance for the first time, wash the basket and the oil container with soap and water, rinsing well to eliminate any soap residue and then drying. -Take the length of cable required out of the housing. -Connect the appliance to the mains. -Select the desired frying temperature using the thermostat control. The indicator light will turn red, indicating that the oil is being heated (close the lid to save energy). -Prepare the food to be fried and place it in the basket, making sure that it does not rise above 3/4 of its capacity. Allow the food to drain before placing it in the basket. -Frozen food must be allowed for thaw beforehand. The placing of frozen food or food with high water content in the basket may cause the oil to suddenly spit after a few seconds. -Wait until the pilot light has gone out which will indicate that the appliance has reached an adequate temperature. -Slowly place the basket in the bowl to avoid overflowing and splashing. Fry with the lid open or closed, as required. -When the food has been fried sufficiently, lift the basket and position it in the support in order to allow the excess oil to drain from the food -Empty the basket. -Change the oil approximately every 15 or 20 frying operations, or every 5 – 6 months if not used frequently. -In order to minimize the generation of acrilamida during the frying process, avoid to reach dark brown colours on the fried food, remove any burnt leftovers from the oil container, food rich in scratch (such as potatoes or corns) should not be fried at temperatures higher to 170ºC Once you have finished using the appliance: -Select the minimum position (MIN)using the thermostat control. -Unplug the appliance from the mains. -Put the cable back in the cable housing. -The cable housing means you can remove and have available the required length of cable for working with the appliance, preventing accident risk situations. -Place the frying basket inside the container. The basket handle can be left attached or can be turned toward the inside of the basket by pressing sidewise on the rods and rotating (Fig.

-Close the lid. Practical recommendations: -Fry a few pieces of bread to remove the smell of used oil. -For food with a high water content, it is better and quicker to fry in two lots with less food than in just one. This will reduce the risk of splashes and spillage. -The “two-stage frying method” can be used for an even and crispy coating. This system consists of first frying the food until it is reasonably well done and then frying again using very hot oil to brown the food. -Olive oil with a minimum acidity level is recommendable for frying. -Do not mix different oils. -Wash potatoes before frying to stop them from sticking Safety thermal protector: -In the event of overheating, the thermal safety mechanism will be activated and the appliance will stop operating. When this occurs the appliance should be disconnected from the mains and left to cool. Then press the rearming button, situated at the back of the electrical circuit, with the tip of a pen or similar in order to reactivate the appliance (Fig. 2). Cleaning -Disconnect the appliance from the mains and allow it to cool before undertaking any cleaning task. -Disassemble the appliance in accordance with the following steps:

• Remove the basket and take out the electrical equipment

• Carefully pour the used oil from the bowl into a container (not the sink), according to the regulations in force for the treatment and disposal of waste. -Pour soapy water into the tank to degrease it. -Except for the power unit and the mains connection, all the parts can be cleaned with detergent and water or in washing up liquid. Rinse thoroughly to remove all traces of detergent. -Clean the electrical equipment and the mains connection with a damp cloth and dry. DO NOT IMMERSE IN WATER OR ANY OTHER LIQUID. -Clean the equipment with a damp cloth with a few drops of washing-up liquid and then dry. -Do not use solvents, or products with an acid or base pH such as bleach, or abrasive products, for cleaning the appliance. -If the appliance is not in good condition of cleanliness, its surface may degrade and inexorably affect the duration of the appliance’s useful life and could become unsafe to use. -The following pieces may be washed in a dishwasher:

2006/95/EC 2004/108/EC
