• Nummerierung gemäß Gerätebeschreibung Technische Daten Modell Multifunktions-Küchenmaschine Multi-FiXX 500 Typnummer M20.001 Abmessungen 170 x 400 x 235 mm Nettogewicht 3,14 kg Bruttogewicht ca. 3,9 kg Betriebsspannung 220-240V~ Netzfrequenz 50/60 Hz Leistungsaufnahme 500 W Schutzklasse II Schutzart IPX016 Multi-FiXX 500 DE BEEM - Elements of Lifestyle17 EN Multi-FiXX 500 BEEM - Elements of Lifestyle Dear Customer, before using the appliance, please read the instructions contained in this user manual on startup, safety, intended use as well as cleaning and care. Open the fold-out page at the beginning and end of the user manual in order to view the illustrations during reading. Keep this user manual in a safe place and pass it on to any future owners together with the appliance. General notes Copyright This document is copyrighted. Any dupli- cation or reprinting, in whole or in part, as well as reproduction of the illustrations even in modied form is only permitted with the written approval of the manufac- turer. Notes on environmental protection The packaging materials used can be recycled. When no longer re- quired, dispose of the packaging materials according to local environmental regula- tions. This product may not be disposed of in the domestic refuse within the Eu- ropean Union. Dispose of the appli- ance via communal collection points. Warranty/Guarantee In addition to the statutory warranty obliga- tion, BEEM also grants an extended man- ufacturer’s guarantee for some products. Provided this is granted, the correspond- ing details for each product can be found either on the product-specic packaging, advertising material or on the BEEM web- site. Please visit our website to obtain more information on comprehensive guarantee conditions, available accessories and spare parts as well as user manuals in various languages. General notes. . . . . . . . . . . . . . . . . . . . 17 Safety instructions . . . . . . . . . . . . . . . 19 Startup . . . . . . . . . . . . . . . . . . . . . . . . . 21 Appliance description .............22 Operation and use ................22 After using . . . . . . . . . . . . . . . . . . . . . . 26 Storage .........................27 Cleaning and care . . . . . . . . . . . . . . . . 27 Troubleshooting . . . . . . . . . . . . . . . . . 28 Spare parts and other accessories . . 29 Technical data . . . . . . . . . . . . . . . . . . . 29 Contents18 Multi-FiXX 500 EN BEEM - Elements of Lifestyle WARNING If not used for its intended purpose and/ or used in any other way, the appliance may be or become a source of danger. Use the only for its intended pur- ► pose. Observe the procedures described in ► this user manual. No claims of any kind will be accepted for damage resulting from use of the for other than its intended purpose. The risk must be borne solely by the user. Limitation of liability We assume no reliability for damage or follow-up damage in the case of: failure to observe the instructions in ■ the user manual, use for other than the intended pur- ■ pose, improper or unsuitable handling, ■ incorrectly performed repairs, ■ unauthorised modications, ■ use of non-approved parts or spare ■ parts, use of unsuitable supplementary or ac- ■ cessory parts. Declaration of Conformity BEEM hereby declares that this appliance complies with the fundamental require- ments and other relevant provisions of 2006/95/EC, 2009/125/EC and 2004/108/EC directives. Symbols used DANGER This indicates an imminent hazardous situation, which could lead to severe physical injury or death. Follow these instructions to avoid ► danger. WARNING This indicates a possible hazardous situation, which could lead to severe physical injury or death. Follow these instructions to avoid ► danger. CAUTION This indicates a potentially hazardous situation, which could lead to minor injuries or material damage. Follow these instructions to avoid ► danger. NOTE A note contains additional tips to ► facilitate the use of the appliance. Intended use This appliance is intended primarily for non-commercial use in closed rooms for mixing and chopping food and for extract the juice from citrus fruits (lemons, orang- es, grapefruit) in normal household quanti- ties. Any use other than previously stated is considered as improper use.19 EN Multi-FiXX 500 BEEM - Elements of Lifestyle Safety instructions Inspect the appliance for visible signs ■ of damage before use. Do not use a damaged appliance. This appliance is not intended for use ■ by persons (including children) with re- stricted physical, sensory or mental ca- pabilities or with insufcient experience and/or knowledge unless they are supervised by a person responsibly for their safety or have received instruc- tions on the use of the appliance from such a person. Children must be supervised to ensure ■ that they do not play with the appli- ance. Store the appliance and accessory ■ parts out of the reach of children. Do not leave the appliance unattended ■ during operation. Only allow repairs to the appliance ■ to be carried out by an authorised specialist or by the works customer service; this particularly applies to re- placing a damaged connecting cable. Unqualied repairs can lead to consid- erable danger for the user. They will also invalidate the warranty/guarantee. Repairs to the appliance during the ■ guarantee period may only be carried out by service centres authorised by the manufacturer, otherwise the war- ranty/guarantee will become invalid in the event of damage or subsequent damage. Defective parts may only be replaced ■ with original spare parts. Only original spare parts guarantee that the safety requirements are met. Only use spare parts from the manu- ■ facturer or spare parts that are spe- cically recommended by the manu- facturer. The warranty/guarantee will otherwise be invalidated. Do not use this appliance together with ■ an external timer or a separate remote control system. DANGER Danger from electric current! Do not use the appliance if the mains ► cable or mains plug is damaged. Never open the housing of the ap- ► pliance. Danger from electric current if live connections are touched and/ or the electrical and mechanical conguration is changed. Never immerse the appliance or the ► mains plug in water or other liquids. Pull the plug out of the mains socket, ► when changing the attachments, – if you are not using the appliance, – if a malfunction occurs during op- – eration, before you clean the appliance. – Danger of suffocation! Never play with packaging material. ► Risk of suffocation.20 Multi-FiXX 500 EN BEEM - Elements of Lifestyle WARNING Frozen food such as frozen fruit ► must be defrosted before they are chopped otherwise the container could be damaged. Do not operate the appliance without ► the corresponding lid. Danger from sharp blades! Remove the blade lid of the chopper ► knives carefully. Do not touch the blades. Always hold ► the chopping blade by the plastic shaft. Remove the blade before emptying ► the jug. Always push food in with the pusher. ► Never use your ngers. Danger from moving parts! Always disconnect the mains plug ► before assembling, disassembling, cleaning or storing the appliance. Never put your ngers or other ob- ► jects into the feed shaft. CAUTION Always switch off the appliance be- ► fore removing the upper parts. Only operate the appliance when the ► upper part is locked and the lid or pusher is in place. Do not pull the connecting cable ► to remove the plug from the mains socket. Remove the stones and seeds from ► fruit before blending. Never operate the appliance when ► the jug is empty. CAUTION Always use the stopper for insert- ► ing ingredients into the lling chute, never use any other objects. Do not use sharp objects or abra- ► sive cleaning agents to clean the surfaces. When using for prolonged periods ► of time, allow the appliance to cool down occasionally to avoid overheat- ing. The jugs are not suitable for ovens ► or microwave ovens. Never lift or move the appliance with ► the mains cable. Requirements for the place of use For safe and trouble-free operation of the appliance, the installation location must satisfy the following requirements: Place the appliance on a rm, dry, at, ■ waterproof and heat-resistant surface. Do not install the appliance in a hot, ■ wet or very humid environment. The mains socket must be easily ac- ■ cessible and allow fast disconnection in the event of an emergency. The surface nishes on furniture may ■ contain substances that can be detri- mental to the suction feet of the appli- ance. If necessary, place a mat under the suction feet of the appliance.21 EN Multi-FiXX 500 BEEM - Elements of Lifestyle Electrical connection For safe and trouble-free operation of the appliance, the following instructions must be observed for the electrical connection: Before connecting the appliance, ■ compare the connection data (voltage and frequency) on the rating plate with those of your mains power supply. This data must correspond in order to avoid damage to the appliance. If in doubt, ask your electrical appliance retailer. The mains socket must be protected ■ by at least a 10 A automatic circuit breaker. Ensure that the mains cable is undam- ■ aged and is not laid over hot surfaces or sharp edges. The mains cable must not pulled ■ tightly, bent or come into contact with hot surfaces. Route the cable to prevent risk of trip- ■ ping. The electrical safety of the appliance ■ is only assured when it is connected to a properly installed protective earth (PE) conductor system. Connection to a mains socket without PE conductor is forbidden. If in doubt, the electrical system must be checked by a qualied electrician. The manufacturer assumes no liability for injury or damage caused by a missing or interrupted protective earth conductor. Startup Unpacking Remove the appliance, all accessory parts including those in the accesso- ries compartment on the back of the appliance, and the user manual from the box. Remove all packaging materials and protective foils from the product and the accessories before using it for the rst time. NOTE Do not remove the rating plate or ► any warning signs on the appliance. If possible, keep the original packag- ► ing throughout the warranty period so that the appliance can be duly packed in case of a warranty claim. Transport damage will invalidate the warranty/guarantee. Check the delivery contents Check for visible signs of damage or missing items. Report incomplete or damaged con- tents to your supplier immediately. Before using for the rst time Clean the appliance and the acces- sories as described in the section Cleaning and care.22 Multi-FiXX 500 EN BEEM - Elements of Lifestyle Appliance description (See illustration on the left fold-out page) Motor unit1 Rotary switch2 Jug (750 ml)3 Spindle attachment4 Grating disc5 Cutting/rasping disc6 Chopper blade7 Jug lid8 Pusher9 Collecting bowl10 Drive attachment 11 Grater attachment12 Blender blade unit13 Sealing ring14 Blender jug (1200 ml)15 Blender lid16 Lid lock17 Accessories compartment 18 (back of the appliance)User manual (not illustrated)19 Rotary switch Level Function

Impulse operation. Run the appliance intermit- tently at maximum power for short intervals. 0 Appliance switched off.

Continuous operation: low speed level

Continuous operation: high speed level Safety switches The appliance is equipped with a safety switch and can only be operated if the cor- responding attachment has been correctly tted and locked onto the motor unit. WARNING Before using each time, check the ► function of the safety switch. Switch on the appliance with attached jug for this purpose. If the motor turns, the safety switch is defective and the appliance may not be used. Operation and use Switching the appliance on/off The appliance is turned on and off via the rotary switch (2). Set the rotary switch (2) to level 1 or 2 for continuous operation. For impulse operation, turn the rotary switch (2) to level P. The appliance runs at maximum speed as long as the rotary switched is pressed.23 EN Multi-FiXX 500 BEEM - Elements of Lifestyle Mixing (see images A1 - A6) Place the sealing ring (14) around the base of the chopping unit (13). Make sure that the sealing ring is lying at all the way round. Insert the blade unit (13) with the t- ted sealing ring (14) into the blender jug (15) from below. The noses of the base t into the recesses at the bot- tom of the blender jug. Turn the blade unit (13) with the lid lock (17) anticlockwise to tighten. Place the blender jug (15) onto the motor unit (1) with the handle to the right and turn the blender jug clock- wise until it audibly snaps in. NOTE Make sure that the blender jug (15) ► is seated properly, otherwise the ap- pliance cannot be operated (safety switch). Put liquid/fruit into the blender (15). NOTE Pour liquids into the blender rst and ► then the solids. Do not put solid parts (metal, wood, ► bones) into the blender jug. Cut through larger parts so that the ► blade unit (13) can seize them. Pay attention to the maximum lling ► quantity in the blender jug (15). Place the lid of the blender (16) onto the blender jug (15) and lock it by turning it clockwise. Place the lid lock (17) onto the lid of the blender (16) and lock it by turning it clockwise until it snaps in. NOTE Pay attention to proper seating of the ► lid (16) and the lid lock (17) to pre- vent squirting out of the appliance. Insert the plug into the mains socket and move the rotary switch (2) to im- pulse or continuous operation. CAUTION Observe the maximum operating ► time of 2 minutes. Allow the appliance to cool down for ► 1 minute. Relling: Switch off the appliance. Remove the lid lock(17) and ll the blender (15). Close the lid (16) again with the lid lock (17). NOTE Pay attention to the maximum lling ► quantity in the blender jug (15).24 Multi-FiXX 500 EN BEEM - Elements of Lifestyle Chopping (see images B1 - B5) Place the jug (3) onto the motor unit (1) with the handle to the right and turn the blender jug clockwise until it audibly snaps in. Put the chopping blades (7) onto the spindle attachment (4) and press the chopping blade downwards to that the spindle attachment snaps in. WARNING Danger from sharp blades! Do not touch the blades. Always hold ► the chopping blade by the plastic shaft. Put the spindle attachment (4) with t- ted chopping blade (7) onto the drive spindle of the jug (3). Put the food to be chopped into the jug (3). NOTE Pay attention to the maximum lling ► quantity in the blender jug (3). Only ll liquid up to the "Max. Liquid" marking. Put the jug lid (8) onto the jug (3) and lock it by turning it clockwise. Insert the pusher (9) into the lling shaft of the jug lid (8). NOTE Make sure that the jug (3) and ► the jug lid (8) are seated properly, otherwise the appliance cannot be operated (safety switch). Make sure that the pusher (9) is ► inserted into the jug lid (8) during operation to prevent squirting out of the appliance. Insert the plug into the mains socket and move the rotary switch (2) to im- pulse or continuous operation. CAUTION Observe the maximum operating ► time of 2 minutes. Allow the appliance to cool down for ► 1 minute. Relling: Switch off the appliance. Remove the jug lid (8) and ll the jug (3). Put the jug lid (8) onto the jug (3) again and lock it by turning it clock- wise. NOTE Pay attention to the maximum lling ► quantity in the blender jug (3). Before emptying the jug, remove the ► spindle attachment (4) with the chop- ping blade (7).25 EN Multi-FiXX 500 BEEM - Elements of Lifestyle Cutting/rasping (see image C1) Place the jug (3) onto the motor unit (1) with the handle to the right and turn the blender jug clockwise until it audibly snaps in. If the chopping blade (7) is tted, re- move it from the spindle attachment (4) by pressing in the latches. WARNING Danger from sharp blades! Do not touch the blades. Always hold ► the chopping blade by the plastic shaft. Put the spindle attachment (4) with- out chopping blade (7) onto the drive spindle of the jug (3). Remove the grating disc (5) or the cutting/rasping disc (6) from the ac- cessories compartment (18) on the back of the appliance. Put the grating disc (5) or the cutting/ rasping disc (6) onto the spindle at- tachment (4), in the case of the latter, with the rasper or blade edge pointing upwards. Put the jug lid (8) onto the jug (3) and lock it by turning it clockwise. NOTE Make sure that the jug (3) and ► the jug lid (8) are seated properly, otherwise the appliance cannot be operated (safety switch). Fill the food to be rasped or cut into the lling shaft of the jug lid (8). Insert the plug into the mains socket and move the rotary switch (2) to im- pulse or continuous operation. Push the food downwards with the pusher (9) until the lling shaft is empty. CAUTION Observe the maximum operating ► time of 2 minutes. Allow the appliance to cool down for ► 1 minute. Relling: Switch off the appliance. Take out the pusher (9) and ll the shaft of the jug lid (8) with more food. NOTE Pay attention to the maximum lling ► quantity in the blender jug (3). Before emptying the jug, remove the ► grating disc (5) or the cutting/rasp- ing disc (6) and the spindle attach- ment (4).26 Multi-FiXX 500 EN BEEM - Elements of Lifestyle Insert the plug into the mains socket and move the rotary switch (1) to im- pulse or continuous operation level 1. To extract juice, push the halved fruit onto the grater attachment (12). CAUTION Observe the maximum operating ► time of 2 minutes. Allow the appliance to cool down for ► 1 minute. NOTE Pay attention to the maximum lling ► quantity in the blender jug (3). In the case of larger quantities, ► empty the collecting bowl periodically to prevent overowing. After using Switch off the appliance and pull the plug out of the mains socket. Rinse the jug and the accessories used with water. Clean the appliance and the accesso- ries used as described in the section Cleaning and care. Juice extraction Place the jug (3) onto the motor unit (1) with the handle to the right and turn the blender jug clockwise until it audibly snaps in. If the chopping blade (7) is tted, re- move it from the spindle attachment (4) by pressing in the latches. WARNING Danger from sharp blades! Do not touch the blades. Always hold ► the chopping blade by the plastic shaft. If the grating disc (5) or the cutting/ rasping disc (6) is tted, remove it from the spindle attachment (4). Put the spindle attachment (4) onto the drive spindle of the jug (3). Insert the drive attachment (11) into the collecting bowl (10) and lock it by turning it clockwise. Put the collecting bowl (10) onto the jug (3) and lock it by turning it clock- wise. NOTE Make sure that the jug (3) and the ► collecting bowl (10) are seated prop- erly, otherwise the appliance cannot be operated (safety switch). Place the grater attachment (12) onto the drive attachment (11).27 EN Multi-FiXX 500 BEEM - Elements of Lifestyle Storage If you do not intend to use the appliance for a longer period of time, clean it as de- scribed in the section Cleaning and care. Store the appliance and all accessory parts at a dry, clean and frost-free loca- tion, which is protected against direct sunlight. Accessories compartment (see images D1 - D2) Store the grating disc (5) and the cutting/ rasping disc (6) in the accessories com- partment (18) on the back of the appli- ance. Cable compartment (see images E1 - E2) If the connecting cable is too long, it can be stowed in the cable compartment on the back of the appliance. Stowing the cable: Press the cable not needed into the inside of the appliance through the round open- ing of the cable outlet. Fixing the cable: Pull the cable into the narrow recess of the cable outlet to x the cable. Cleaning and care Before beginning work, pay attention to the safety instructions in the section on safety! Cleaning the appliance Wipe the motor unit (1) with a slightly damp cloth. All other parts can be cleaned in a warm washing-up liquid solution or in the dish washer. Dry all parts of the appliance thor- oughly after cleaning. NOTE Dried and caked food residues can ► be removed more easily if you allow them to soak in warm washing-up liquid solution for 10 minutes before cleaning. Immediately after processing very ► salty ingredients, rinse the chopping blades. After processing strongly coloured ► ingredients, the plastic parts of the appliance can become discoloured. Rub these parts with cooking oil before cleaning them.28 Multi-FiXX 500 EN BEEM - Elements of Lifestyle Troubleshooting The following table helps in localising and remedying minor faults: Fault Possible cause Remedy The appliance does not work after turning the rotary switch. Plug not inserted into socket. Insert plug. Automatic circuit breaker in electrical distribution board tripped. Switch on the automatic circuit breaker again. The internal safety switch has switched off the appliance as a result of overheating. Allow the appliance to cool down. The jug and/or the kid is not tted properly. Fit and lock the jug and lid properly. The automatic circuit breaker in the electrical distribution board trips. Too many appliances connect- ed to the same power circuit. Reduce the number of appliances on the power circuit. Appliance is defective. Contact customer service. Motor runs extremely slowly or stops. Jug overlled. Remove some of the ingredients. Pressure too strong. Exert less pressure. NOTE If you cannot resolve the problem with the steps described above, please contact ►29 EN Multi-FiXX 500 BEEM - Elements of Lifestyle Spare parts and other accessories Item* Article No. Designation
