USER MANUAL DEHX6500BT PIONEER

To ensure proper use, please read through this

manual before using this product. It is especially

important that you read and observe WARN-

INGs and CAUTIONs in this manual. Please

keep the manual in a safe and accessible place for

4500BT IC: 775E-K054

This device complies with Part 15 of FCC Rules and Industry Canada licence-exempt

RSS standard(s). Operation is subject to the

following two conditions: (1) this device may

not cause interference, and (2) this device

must accept any interference, including inter-

ference that may cause undesired operation

This transmitter must not be co-located or op-

erated in conjunction with any other antenna

The antenna for Bluetooth cannot be removed

(or replaced) by user.

This equipment complies with FCC/IC radia-

tion exposure limits set forth for an uncon-

trolled environment and meets the FCC radio

frequency (RF) Exposure Guidelines in Sup-

plement C to OET65 and RSS-102 of the IC

radio frequency (RF) Exposure rules. This

equipment has very low levels of RF energy

that it deemed to comply without maximum

permissive exposure evaluation (MPE). But it

is desirable that it should be installed and op-

erated keeping the radiator at least 20 cm or

more away from person’s body (excluding ex-

tremities: hands, wrists, feet and ankles).

Alteration or modifications carried out with-

out appropriate authorization may invalidate

the user’s right to operate the equipment.

This equipment has been tested and found

to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reason-

able protection against harmful interference

in a residential installation. This equipment

generates, uses and can radiate radio fre-

quency energy and, if not installed and used

in accordance with the instructions, may

cause harmful interference to radio commu-

nications. However, there is no guarantee

that interference will not occur in a particu-

lar installation. If this equipment does cause

harmful interference to radio or television re-

ception, which can be determined by turning

the equipment off and on, the user is encour-

aged to try to correct the interference by one

or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equip-

- Connect the equipment into an outlet on a

circuit different from that to which the re-

ceiver is connected.

- Consult the dealer or an experienced radio/

TV technician for help.

The Safety of Your Ears is in

Get the most out of your equipment by playing it

at a safe level—a level that lets the sound come

through clearly without annoying blaring or dis-

tortion and, most importantly, without affecting

your sensitive hearing. Sound can be deceiving.

Over time, your hearing “comfort level” adapts to

higher volumes of sound, so what sounds “nor-

mal” can actually be loud and harmful to your

hearing. Guard against this by setting your

equipment at a safe level BEFORE your hearing

ESTABLISH A SAFE LEVEL:

! Set your volume control at a low setting.

! Slowly increase the sound until you can hear

it comfortably and clearly, without distortion.

! Once you have established a comfortable

sound level, set the dial and leave it there.

BE SURE TO OBSERVE THE FOLLOWING GUIDELINES:

! Do not turn up the volume so high that you

can’t hear what’s around you.

! Use caution or temporarily discontinue use

in potentially hazardous situations.

! Do not use headphones while operating a

motorized vehicle; the use of headphones

may create a traffic hazard and is illegal in

The tuner frequencies on this unit are allocated

for use in North America. Use in other areas

may result in poor reception.

WARNING Handling the cord on this product or cords asso-

ciated with accessories sold with the product

may expose you to chemicals listed on proposi-

tion 65 known to the State of California and

other governmental entities to cause cancer and

birth defect or other reproductive harm. Wash

hands after handling.

! Do not allow this unit to come into contact

with liquids. Electrical shock could result.

Also, damage to this unit, smoke, and over-

heating could result from contact with

! Always keep the volume low enough to hear

! Avoid exposure to moisture.

! If the battery is disconnected or discharged,

any preset memory will be erased.

Important (Serial number)

The serial number is located on the bottom of

this unit. For your own security and conven-

ience, be sure to record this number on the en-

closed warranty card.

2 Section Before you start

Function setting operations are completed even

if the menu is canceled before the operations

! In the following instructions, USB memories

and USB audio players are collectively re-

ferred to as “USB storage device”.

! In this manual, iPod and iPhone will be re-

ferred to as “iPod”.

After-sales service for

Please contact the dealer or distributor from

where you purchased this unit for after-sales

service (including warranty conditions) or any

other information. In case the necessary infor-

mation is not available, please contact the com-

panies listed below:

Please do not ship your unit to the companies at

the addresses listed below for repair without ad-

Pioneer Electronics (USA) Inc.

Long Beach, CA 90801-1760

CANADA Pioneer Electronics of Canada, Inc.

CUSTOMER SATISFACTION DEPARTMENT

Markham, Ontario L3R 2Z5, Canada

For warranty information please see the Limited

Warranty sheet included with this unit.

Should this unit fail to operate properly, please

contact your dealer or nearest authorized

PIONEER Service Station.

http://www.pioneerelectronics.com

http://www.pioneerelectronics.ca

! Learn about product updates (such as firm-

ware updates) for your product.

! Register your product to receive notices

about product updates and to safeguard pur-

chase details in our files in the event of loss

! Access owner’s manuals, spare parts infor-

mation, service information, and much

DEH-X6500BT and DEH-X65BT

! Use an optional Pioneer USB cable (CD-

U50E) to connect the USB storage device as

any device connected directly to the unit will

protrude out from the unit, which could be

! Do not use unauthorized products.

Remote controller buttons marked with the

same numbers as on the unit operate in the

same way as the corresponding unit button re-

gardless of button name.

f VOLUME Press to increase or decrease

g MUTE Press to mute. Press again to

Press to recall preset stations.

Press to select the next/pre-

Press to end a call, reject an in-

coming call, or reject a call

waiting while on another call.

3 Section Operating this unit

j DISP/SCRL Press to select different dis-

Press and hold to turn dimmer

Press to pause or resume play-

Press to start talking on the

phone while operating a

ENTER Press to display the disc title,

track title, folder, or file list de-

pending on the source.

Press to display the list de-

pending on the source.

While in the operating menu,

press to control functions.

DEH-X6500BT and DEH-X65BT

! Tuner: band and frequency

! CD player, USB storage de-

vice and iPod: elapsed play-

Appears when a lower tier of

folder or menu exists.

swering function is on.

Shows when 12H is selected

under 12H/24H and CLOCK is

selected under INFO DISPLAY.

The list function is being oper-

Sub information is displayed.

7 LOC Local seek tuning is on.

The sound retriever function is

The iPod source is selected

and the shuffle or shuffle all

The pandora source is selected

and the QuickMix is selected.

Track or folder repeat is on.

erated from your iPod.

Connected to a Bluetooth de-

The line is on hold.

When you turn the ignition switch to ON after in-

stallation, set up menu appears on the display.

You can set up the menu options below.

1 After installation of this unit, turn the

ignition switch to ON.

2 Turn M.C. to switch to YES.

# If you do not operate for 30 seconds, the set up

menu will not be displayed.

# If you prefer not to set up at this time, turn M.C.

to switch to NO. Press to select.

If you select NO, you cannot set up in the set up

3 Press M.C. to select.

4 Complete the procedure outlined below

To proceed to the next menu option, you need to

confirm your selection.

CLOCK SET (setting the clock)

1 Turn M.C. to adjust hour.

2 Press M.C. to select minute.

3 Turn M.C. to adjust minute.

4 Press M.C. to confirm the selection.

5 To finish your settings, turn M.C. to select

# If you prefer to change your setting again, turn

M.C. to switch to NO. Press to select.

6 Press M.C. to select.

! You can set up the menu options from the

system menu. For details about the settings,

refer to System menu on page 13.

! You can cancel set up menu by pressing

! Handle gently when removing or attaching

! Avoid subjecting the front panel to excessive

! Keep the front panel out of direct sunlight

and high temperatures.

! To avoid damaging the device or vehicle inte-

rior, remove any cables and devices attached

to the front panel before detaching it.

4 Section Operating this unit

<QRD3123-A/N>4Removing the front panel to protect your unit from

1 Press the detach button to release the front

2 Push the front panel upward (M) and then pull

3 Always keep the detached front panel in a pro-

tection device such as a protection case.

Re-attaching the front panel

1 Slide the front panel to the left.

Make sure to insert the tabs on the left side of

the head unit into the slots on the front panel.

2 Press the right side of the front panel until it is

If you cannot attach the front panel to the

head unit successfully, make sure that you are

placing the front panel onto the head unit cor-

rectly. Forcing the front panel into place may

result in damage to the front panel or head

1 Press SRC/OFF to turn the unit on.

Turning the unit off

1 Press and hold SRC/OFF until the unit turns

1 Press SRC/OFF to cycle between:

TUNER (tuner)—CD (CD player) —USB (USB)/

iPod (iPod)—PANDORA (Pandora)—AUX

(AUX)—BT AUDIO (Bluetooth audio)

Adjusting the volume

1 Turn M.C. to adjust the volume.

CAUTION For safety reasons, park your vehicle when re-

moving the front panel.

When this unit’s blue/white lead is connected to

the vehicle’s auto-antenna relay control termi-

nal, the vehicle’s antenna extends when this

unit’s source is turned on. To retract the anten-

na, turn the source off.

Use and care of the remote

Using the remote control

1 Point the remote control in the direction of the

front panel to operate.

When using for the first time, pull out the film

protruding from the tray.

Replacing the battery

1 Slide the tray out on the back of the remote

2 Insert the battery with the plus (+) and minus

(–) poles aligned properly.

! Keep the battery out of the reach of children.

Should the battery be swallowed, consult a

! Batteries (battery pack or batteries installed)

must not be exposed to excessive heat such

as sunshine, fire or the like.

! Use one CR2025 (3 V) lithium battery.

! Remove the battery if the remote control is

not used for a month or longer.

! There is a danger of explosion if the battery is

incorrectly replaced. Replace only with the

same or equivalent type.

! Do not handle the battery with metallic tools.

! Do not store the battery with metallic ob-

! If the battery leaks, wipe the remote control

completely clean and install a new battery.

! When disposing of used batteries, comply

with governmental regulations or environ-

mental public institutions’ rules that apply in

! “Perchlorate Material – special handling may

perchlorate. (Applicable to California,

! Do not store the remote control in high tem-

peratures or direct sunlight.

! The remote control may not function properly

! Do not let the remote control fall onto the

floor, where it may become jammed under

the brake or accelerator pedal.

Frequently used menu

Returning to the previous display

Returning to the previous list (the folder one level

Returning to the ordinary display from the list

until the desired band (FM1,

FM2,FM3 for FM or AM) is displayed.

Switching preset stations

! Select PCH (preset channel) under SEEK to

use this function. For details about the set-

tings, refer to SEEK (left/right key setting) on

Manual tuning (step by step)

! Select MAN (manual tuning) under SEEK to

use this function. For details about the set-

tings, refer to SEEK (left/right key setting) on

1 Press and hold c or d, and then release.

You can cancel seek tuning by briefly pressing

While pressing and holding c or d, you can

skip stations. Seek tuning starts as soon as

5 Section Operating this unit

<QRD3123-A/N>5Storing and recalling stations

Using preset tuning buttons

1 When you find a station that you want

to store in memory, press one of the preset

to 6/ ) and hold until

the preset number stops flashing.

2 Press one of the preset tuning buttons

to 6/ ) to select the desired station.

Switching the display

Selecting the desired text information

1 Press DISP to cycle between the following:

! BRDCST INFO (program service name/

song title/artist name)

! FREQUENCY (frequency)

! CLOCK (source name and clock)

! BRDCST INFO text information will change

! Depending on the band, text information can

! Text information items that can be changed

2 Turn M.C. to change the menu option

and press to select FUNCTION.

3 Turn M.C. to select the function.

Once selected, the following functions can be

BSM (best stations memory)

the six strongest stations in the order of their sig-

1 Press M.C. to turn BSM on.

To cancel, press M.C. again.

LOCAL (local seek tuning)

Local seek tuning lets you tune in to only those

radio stations with sufficiently strong signals for

1 Press M.C. to select the desired setting.

FM: OFF—LV1 —LV2—LV3—LV4

The highest level setting allows reception of

only the strongest stations, while lower levels

allow the reception of weaker stations.

SEEK (left/right key setting)

You can assign a function to the left and right keys

Select MAN (manual tuning) to tune up or down

manually or select PCH (preset channel) to switch

between preset channels.

1 Insert the disc into the disc loading slot with

Ejecting a CD/CD-R/CD-RW

Playing songs on a USB storage device

1 Open the USB port cover.

2 Plug in the USB storage device using a USB

Playback is performed automatically.

Stopping playback of files on a USB storage de-

1 You may disconnect the USB storage device at

The unit stops playback.

Fast forwarding or reversing

1 Press and hold c or d.

! When playing compressed audio, there is no

sound during fast forward or reverse.

Returning to root folder

1 Press and hold BAND/

Switching between compressed audio and CD-DA

Switching between playback memory devices

You can switch between playback memory devices

on USB storage devices with more than one Mass

Storage Device-compatible memory device.

! You can switch between up to 32 different

Disconnect USB storage devices from the unit

Only for DEH-X6500BT and DEH-X65BT You can use this function when USB is selected as

1 Press 3/MIX to turn MIXTRAX on or off.

! For more details about MIXTRAX, refer to

About MIXTRAX on page 15.

! For more details about MIXTRAX functions,

refer to MIXTRAX menu on page 15.

! When MIXTRAX is in use, the sound retriever

function is disabled.

Switching the display

Selecting the desired text information

1 Press DISP to cycle between the following:

! ELAPSED TIME (track number and play-

! CLOCK (source name and clock)

! SPEANA (spectrum analyzer)

! TRACK INFO (track title/track artist/disc

! ELAPSED TIME (track number and play-

! CLOCK (source name and clock)

! SPEANA (spectrum analyzer)

! TRACK INFO (track title/artist name/album

! FILE INFO (file name/folder name)

! ELAPSED TIME (track number and play-

! CLOCK (source name and clock)

! SPEANA (spectrum analyzer)

6 Section Operating this unit

! TRACK INFO and FILE INFO text information

will change automatically.

! Depending on the version of iTunes used to

write MP3 files to a disc or media file types,

incompatible text stored within an audio file

may be displayed incorrectly.

! Text information items that can be changed

depend on the media.

Selecting and playing files/

tracks from the name list

1 Press to switch to the file/track name

2 Use M.C. to select the desired file name

Selecting a file or folder

1 When a file or track is selected, press M.C.

Viewing a list of the files (or folders) in the se-

1 When a folder is selected, press M.C.

Playing a song in the selected folder

1 When a folder is selected, press and hold M.C.

Operations using special buttons

Selecting a repeat play range

to cycle between the following:

! ALL – Repeat all tracks

! ONE – Repeat the current track

! FLD – Repeat the current folder

! ALL – Repeat all files

! ONE – Repeat the current file

! FLD – Repeat the current folder

Playing tracks in random order

to turn random play on or off.

Tracks in a selected repeat range are played in

! To change songs during random play, press d

to switch to the next track. Pressing c restarts

playback of the current track from the begin-

1 Press 4/PAUSE to pause or resume.

Enhancing compressed audio and restoring rich

sound (sound retriever)

1 Press 3/S.Rtrv to cycle between:

1 is effective for low compression rates, and 2

is effective for high compression rates.

! Key operation is disabled when MIXTRAX is

and press to select FUNCTION.

Once selected, the function below can be ad-

! S.RTRV is not available when MIXTRAX is

S.RTRV (sound retriever)

Automatically enhances compressed audio and

restores rich sound.

1 Press M.C. to select the desired setting.

For details, refer to Enhancing compressed

audio and restoring rich sound (sound retriever)

Playing songs on an iPod

1 Open the USB port cover.

2 Connect an iPod to the USB cable using an

iPod Dock Connector.

Playback is performed automatically.

Selecting a song (chapter)

Fast forwarding or reversing

1 Press and hold c or d.

! The iPod cannot be turned on or off when the

control mode is set to CONTROL AUDIO.

! Disconnect headphones from the iPod be-

fore connecting it to this unit.

! The iPod will turn off about two minutes after

the ignition switch is set to OFF.

Operations using the MIXTRAX

Turning MIXTRAX on or off

Only for DEH-X6500BT and DEH-X65BT

1 Press 3/MIX to turn MIXTRAX on or off.

! For more details about MIXTRAX, refer to

About MIXTRAX on page 15.

! For more details about MIXTRAX functions,

refer to MIXTRAX menu on page 15.

Switching the display

Selecting the desired text information

1 Press DISP to cycle between the following:

CONTROL AUDIO/CONTROL iPod

! TRACK INFO (track title/artist name/album

! ELAPSED TIME (track number and play-

! CLOCK (source name and clock)

! SPEANA (spectrum analyzer)

! CONTROL APP (APP MODE is displayed)

! CLOCK (source name and clock)

! SPEANA (spectrum analyzer)

1 Press to switch to the top menu of list

7 Section Operating this unit

Changing the name of the song or category

Playlists—artists—albums—songs—podcasts

—genres—composers—audiobooks

1 When a song is selected, press M.C.

Viewing a list of songs in the selected category

1 When a category is selected, press M.C.

Playing a song in the selected category

1 When a category is selected, press and hold

Searching the list by alphabet

1 When a list for the selected category is dis-

to switch to alphabet search

! You also can switch to alphabet search

mode by turning M.C. twice.

2 Turn M.C. to select a letter.

3 Press M.C. to display the alphabetical list.

! You can play playlists created with the PC ap-

plication (MusicSphere). The application will

be available on our website.

! Playlists that you created with the PC appli-

cation (MusicSphere) are displayed in abbre-

Operations using special buttons

Selecting a repeat play range

to cycle between the following:

! ONE – Repeat the current song

! ALL – Repeat all songs in the selected list

! When the control mode is set to CONTROL

iPod/CONTROL APP, the repeat play range will

be same as what is set for the connected iPod.

Selecting a random play range (shuffle)

to cycle between the following:

! SNG – Play back songs in the selected list

! ALB – Play back songs from a randomly se-

lected album in order.

! OFF – Not play back in random order.

Playing all songs in random order (shuffle all)

to turn shuffle all on.

! To turn off shuffle all, select OFF in shuffle. For

details, refer to Selecting a random play range

(shuffle) on this page.

1 Press 4/PAUSE to pause or resume.

Enhancing compressed audio and restoring rich

sound (sound retriever)

1 Press 3/S.Rtrv to cycle between:

1 is effective for low compression rates, and 2

is effective for high compression rates.

Playing songs related to the

currently playing song

You can play songs from the following lists.

• Album list of the currently playing artist

• Song list of the currently playing album

• Album list of the currently playing genre

to switch to link play

2 Turn M.C. to change the mode; press to

! ARTIST – Plays an album of the artist cur-

rently being played.

! ALBUM – Plays a song from the album cur-

rently being played.

! GENRE – Plays an album from the genre cur-

rently being played.

The selected song/album will be played after the

currently playing song.

! The selected song/album may be canceled if

you operate functions other than link search

(e.g. fast forward and reverse).

! Depending on the song selected to play, the

end of the currently playing song and the be-

ginning of the selected song/album may be

Operating this unit’s iPod

function from your iPod

This unit's iPod function can be operated from a

If you switch to APP Mode, you can have the

sound from your iPod applications be output

from your car's speakers.

CONTROL iPod is not compatible with the fol-

! iPod nano 1st generation

CONTROL APP is compatible with the following

! iPod touch 4th generation

! iPod touch 3rd generation

! iPod touch 2nd generation

! iPod touch 1st generation

to switch the control

! CONTROL iPod – This unit’s iPod function

can be operated from the connected iPod.

! CONTROL APP – This unit’s iPod function

can be operated from the connected iPod.

The unit will play back the sound from your

! CONTROL AUDIO – This unit’s iPod function

can be operated from this unit.

! Switching the control mode to

CONTROL iPod/CONTROL APP pauses song

playback. Operate the iPod to resume play-

! The following operations are still accessible

from the unit even if the control mode is set

to CONTROL iPod/CONTROL APP.

— Fast forward/reverse

— Selecting a song (chapter)

! The volume can only be adjusted from this

2 Turn M.C. to change the menu option

and press to select FUNCTION.

3 Turn M.C. to select the function.

Once selected, the following functions can be

! AUDIO BOOK is not available when

CONTROL iPod/CONTROL APP is selected in

the control mode. For details, refer to Operat-

ing this unit’s iPod function from your iPod on

8 Section Operating this unit

1 Press M.C. to display the setting mode.

2 Turn M.C. to select your favorite setting.

! FASTER – Playback at a speed faster than

! NORMAL – Playback at normal speed

! SLOWER – Playback at a speed slower

S.RTRV (sound retriever)

Automatically enhances compressed audio and

restores rich sound.

1 Press M.C. to select the desired setting.

For details, refer to Enhancing compressed

audio and restoring rich sound (sound retriever)

on the previous page.

Requirements to access Pandora using the

Pioneer car audio/video products:

! iPhone compatibility

iPod touch 2G, iPod touch 3G or iPod touch 4G

(firmware version 3.0 or later).

Certain firmware versions for the iPhone may not

be compatible with the Pandora application. If

this appears to be the case, please update the

firmware to a version that is compatible with

! Latest version of the Pandora application, down-

loaded to your device (Search Apple iTunes App

Store for “Pandora”).

! Current Pandora account (Free account and paid

accounts available from Pandora; create a free

http://www.pandora.com/register or through the

Pandora application for the iPhone).

Note: If the Data Plan for your iPhone does not

provide for unlimited data usage, additional

charges from your carrier may apply for accessing

the Pandora service via 3G and/or EDGE net-

! Connection to the Internet via 3G, EDGE or Wi-Fi

! Optional Pioneer adapter cable connecting your

iPhone to the Pioneer car audio/video products.

! Access to the Pandora service will depend on the

availability of a cellular and/or Wi-Fi network for

purposes of allowing your device to connect to

! Ability of the Pioneer car audio/video products to

access the Pandora service is subject to change

without notice and could be affected by any of

the following: compatibility issues with future

firmware versions of iPhone; compatibility issues

with future firmware versions of the Pandora ap-

plication for the iPhone; changes to the Pandora

music service by Pandora; discontinuation of the

Pandora music service by Pandora.

! Certain functions of the Pandora service are not

available when accessing the service through the

Pioneer car audio/video products, including, but

not limited to, creating new stations, deleting sta-

tions, emailing current stations, buying tracks

from iTunes, viewing additional text information,

logging in to Pandora, and adjusting Cell Net-

Pandora internet radio is a music service not af-

filiated with Pioneer. More information is avail-

able at http://www.pandora.com.

You can play Pandora by connecting your

iPhone with the Pandora application installed.

1 Connect an iPhone to the USB cable using an

iPhone Dock Connector.

2 Start up the Pandora application installed on

to give a “Thumbs Up” for the track

Giving a Thumbs Down

to give a “Thumbs Down” for the

track currently playing and to skip to the next

Switching the display

Selecting the desired text information

1 Press DISP to cycle between the following:

! TRACK INFO (station name/track title/ar-

tist name/album title)

! CLOCK (source name and clock)

! Depending on the station, text information

Selecting and playing the

QuickMix/station list

The device name that appears on the screen

may not be the same as the device name of the

(list) to switch to the QuickMix/

2 Use M.C. to select the QuickMix or de-

Changing the sort order

! ABC – You can sort the items in the list alpha-

! DATE – You can sort the items in the list in

order of the dates on which the items were

Changing QuickMix or stations

1 When QuickMix or the station is selected,

1 Press 4/PAUSE to pause or resume.

Enhancing compressed audio and restoring rich

sound (sound retriever)

1 Press 3/S.Rtrv to cycle between:

1 is effective for low compression rates, and 2

is effective for high compression rates.

1 Press M.C. to display the main menu.

2 Turn M.C. to change the menu option

and press to select FUNCTION.

3 Turn M.C. to select the function.

Once selected, the following functions can be

9 Section Operating this unit

<QRD3123-A/N>9BOOKMARK (bookmark)

1 Press M.C. to store track information.

S.RTRV (sound retriever)

Automatically enhances compressed audio and

restores rich sound.

1 Press M.C. to select the desired setting.

For details, refer to Enhancing compressed

audio and restoring rich sound (sound retriever)

on the previous page.

! Since this unit is on standby to connect with

your cellular phone via Bluetooth wireless

technology, using it without the engine run-

ning can drain the battery power.

! Operations may vary depending on the kind

! Advanced operations that require attention

such as dialing numbers on the monitor,

using the phone book, etc., are prohibited

while driving. Park your vehicle in a safe

place when using these advanced opera-

! Be sure to park your vehicle in a safe place

and apply the parking brake when perform-

Setting up for hands-free phoning

Before you can use the hands-free phoning

function you must set up the unit for use with

your cellular phone.

Operate the Bluetooth telephone connection

menu. Refer to Connection menu operation on

1 Refer to Phone menu operation on the next

Answering an incoming call

1 When a call is received, press

Rejecting an incoming call

1 When a call is received, press and hold

Answering a call waiting

1 When a call is received, press

Switching between callers on hold

Canceling call waiting

Adjusting the other party’s listening volume

1 Press c or d while talking on the phone.

! When private mode is on, this function is not

Turning private mode on or off

while talking on the phone.

! If private mode is selected on the cellular

phone, hands-free phoning may not be avail-

! The estimated call time appears in the dis-

play (this may differ slightly from the actual

Storing and recalling phone numbers

1 If you find a phone number that you

want to store to memory, press and hold

down one of the preset tuning buttons (1/

to 6/ ) to store it to the relevant preset

The functions below can be used to store phone

numbers to the memory. For details, refer to

Phone menu operation on the next page.

! MISSED (missed call history)

! DIALED (dialed call history)

! RECEIVED (received call history)

! PHONE BOOK (phone book)

2 Press one of the preset tuning buttons

to 6/ ) to recall the desired phone

3 Press M.C. to make a call.

Switching the display

Selecting the desired text information

You can change the display during a call.

1 Press DISP to cycle between the following:

! Name of other party

! Number of other party

Using voice recognition

This feature can be used on an iPod equipped

with voice recognition that is connected by

Bluetooth with the source set to iPod or

% Press and hold M.C. to switch to voice

The commands available with this unit are listed

For details on voice recognition features, check

the manual for the iPod you are using.

Connection menu operation

! Be sure to park your vehicle in a safe place

and apply the parking brake when perform-

! Connected devices may not operate properly

if more than one Bluetooth device is con-

nected at a time (e.g. a phone and a separate

audio player are connected simultaneously).

to display the connec-

# You cannot operate this step during a call.

2 Turn M.C. to select the function.

Once selected, the following functions can be

10 Section Operating this unit

<QRD3123-A/N>10DEVICELIST (connecting or disconnecting a de-

vice from the device list)

! When no device is selected in the device list,

this function is not available.

1 Press M.C. to display the setting mode.

2 Turn M.C. to select the name of a device you

want to connect/disconnect.

! Press and hold M.C. to switch the

Bluetooth device address and device

3 Press M.C. to connect/disconnect the selected

If the connection is established, * is indicated

DEL DEVICE (deleting a device from the device

! When no device is selected in the device list,

this function is not available.

1 Press M.C. to display the setting mode.

2 Turn M.C. to select the name of a device you

! Press and hold M.C. to switch the

Bluetooth device address and device

3 Press M.C. to display DELETE YES.

4 Press M.C. to delete a device information from

! While this function is in use, do not turn off

ADD DEVICE (connecting a new device)

1 Press M.C. to start searching.

! To cancel, press M.C. while searching.

! If this unit fails to find any available cellular

phones, NOT FOUND is displayed.

2 Turn M.C. to select a device from the device

! If the desired device is not displayed, select

! Press and hold M.C. to switch the

Bluetooth device address and device

3 Press M.C. to connect the selected device.

! To complete the connection, check the de-

vice name (Pioneer BT Unit) and enter the

PIN code on your device.

! PIN code is set to 0000 as the default. You

can change this code.

! 6-digit number appears on the display of

this unit. Once the connection is estab-

lished, this number disappears.

! If you are unable to complete the connec-

tion using this unit, use the device to con-

! If three devices are already paired, DEVICE-

FULL is displayed and it is not possible to

perform this operation. In this case, delete

a paired device first.

A. CONN (connecting to a Bluetooth device auto-

1 Press M.C. to turn automatic connection on or

VISIBLE (setting the visibility of this unit)

To check the availability of this unit from other de-

vices, Bluetooth visibility of this unit can be turned

1 Press M.C. to turn the visibility of this unit on

PIN CODE (PIN code input)

To connect your device to this unit via Bluetooth

wireless technology, you need to enter a PIN code

on your device to verify the connection. The default

code is 0000, but you can change it with this func-

1 Press M.C. to display the setting mode.

2 Turn M.C. to select a number.

3 Press M.C. to move the cursor to the next posi-

4 After inputting PIN code, press and hold M.C.

to the PIN code input display, and you can

change the PIN code.

DEV. INFO (Bluetooth device address display)

1 Press M.C. to display the setting mode.

2 Turn M.C. to display the device information.

Device name—Bluetooth device address

Phone menu operation

Be sure to park your vehicle in a safe place and

apply the parking brake when performing this

to display the phone menu.

2 Turn M.C. to select the function.

Once selected, the following functions can be

MISSED (missed call history)

DIALED (dialed call history)

RECEIVED (received call history)

1 Press M.C. to display the phone number list.

2 Turn M.C. to select a name or phone number.

3 Press M.C. to make a call.

PHONE BOOK (phone book)

! The phone book in your cellular phone will be

transferred automatically when the phone is

connected to this unit.

! Depending on the cellular phone, the phone

book may not be transferred automatically. In

this case, operate your cellular phone to trans-

fer the phone book. The visibility of this unit

should be on. Refer to VISIBLE (setting the visi-

bility of this unit) on this page.

1 Press M.C. to display SEARCH (alphabetical

2 Turn M.C. to select the first letter of the name

you are looking for.

3 Press M.C. to display a registered name list.

4 Turn M.C. to select the name you are looking

5 Press M.C. to display the phone number list.

6 Turn M.C. to select a phone number you want

7 Press M.C. to make a call.

PRESET1-6 (preset phone numbers)

1 Press M.C. to display the setting mode.

2 Turn M.C. to select the desired preset number.

3 Press M.C. to make a call.

! You can also use the preset number but-

to 6/ to recall a preset phone

For more details about storing phone num-

bers, refer to Storing and recalling phone

numbers on the previous page.

PHONE FUNC (phone function)

You can set A. ANSR, R.TONE and PB INVT from

this menu. For details, refer to Function and opera-

Function and operation

1 Display PHONE FUNC.

Refer to PHONE FUNC (phone function) on this

11 Section Operating this unit

<QRD3123-A/N>112 Press M.C. to display the function menu.

3 Turn M.C. to select the function.

Once selected, the following functions can be

A. ANSR (automatic answering)

1 Press M.C. to turn automatic answering on or

R.TONE (ring tone select)

1 Press M.C. to turn the ring tone on or off.

PB INVT (phone book name view)

1 Press M.C. to invert the order of names in the

! Depending on the Bluetooth audio player

connected to this unit, the available opera-

tions will be limited to the following two lev-

— A2DP profile (Advanced Audio Distribution

Profile): You can only playback songs on your

You cannot use the A2DP connection when

iPod or PANDORA is selected as a source.

— AVRCP profile (Audio/Video Remote Control

Profile): You can perform playback, pause

playback, select songs, etc.

! Since there are a number of Bluetooth audio

players available on the market, available op-

erations will vary extensively. When operating

your player with this unit, refer to the instruc-

tion manual that came with your Bluetooth

audio player as well as this manual.

! As the signal from your cellular phone may

cause noise, avoid using it when you are lis-

tening to songs on your Bluetooth audio

! When a call is in progress on the cellular

phone connected to this unit via Bluetooth

wireless technology, the sound of the

Bluetooth audio player connected to this unit

! When the Bluetooth audio player is in use,

you cannot connect to a Bluetooth telephone

! Playback continues even if you switch from

your Bluetooth audio player to another

source while listening to a song.

! Depending on the type of Bluetooth audio

player you have connected to this unit, oper-

ation and information display may not be

available for some functions.

Setting up for Bluetooth audio

Before you can use the Bluetooth audio function

you must set up the unit for use with your

Bluetooth audio player. This entails establishing

a Bluetooth wireless connection between this

unit and your Bluetooth audio player, and pair-

ing your Bluetooth audio player with this unit.

Operate the Bluetooth telephone connection

menu. Refer to Connection menu operation on

Fast forwarding or reversing

Switching the display

Selecting the desired text information

1 Press DISP to cycle between the following:

! DEVICE INFO (device name)

! TRACK INFO (track title/artist name/album

! ELAPSED TIME (track number and play-

! CLOCK (source name and clock)

Selecting a repeat play range

to select a repeat play range from

! This function may not be available depend-

ing on the type of Bluetooth audio player

! The repeat play range varies depending on

the Bluetooth audio player in use.

Playing tracks in random order

to turn random play on or off.

! The random play range varies depending

on the Bluetooth audio player in use.

1 Press 4/PAUSE to pause or resume.

Enhancing compressed audio and restoring rich

sound (sound retriever)

1 Press 3/S.Rtrv to cycle between:

1 is effective for low compression rates, and 2

is effective for high compression rates.

1 Press M.C. to display the main menu.

2 Turn M.C. to change the menu option

and press to select FUNCTION.

3 Turn M.C. to select the function.

Once selected, the following functions can be

1 Press M.C. to start playback.

1 Press M.C. to stop the playback.

S.RTRV (sound retriever)

Automatically enhances compressed audio and

restores rich sound.

1 Press M.C. to select the desired setting.

For details, refer to Enhancing compressed

audio and restoring rich sound (sound retriever)

2 Turn M.C. to change the menu option

and press to select AUDIO.

3 Turn M.C. to select the audio function.

Once selected, the following audio functions

! FADER is not available when SUB.W/SUB.W

is selected in SP-P/O MODE. For details, refer

to SP-P/O MODE (rear output and preout set-

12 Section Operating this unit

<QRD3123-A/N>12! SUB.W, SUB.W CTRL and HPF SETTING are

not available when REAR/REAR is selected in

SP-P/O MODE. For details, refer to

SP-P/O MODE (rear output and preout set-

! SUB.W CTRL and HPF SETTING are not avail-

able when SUB.W is selected in OFF. For de-

tails, refer to SUB.W (subwoofer on/off

setting) on this page.

FADER (fader adjustment)

1 Press M.C. to display the setting mode.

2 Turn M.C. to adjust the front/rear speaker bal-

BALANCE (balance adjustment)

1 Press M.C. to display the setting mode.

2 Turn M.C. to adjust the left/right speaker bal-

EQ SETTING (equalizer recall)

1 Press M.C. to display the setting mode.

2 Turn M.C. to select the equalizer.

POWERFUL—NATURAL—VOCAL—CUS-

TOM1—CUSTOM2—FLAT—SUPER BASS The equalizer band and equalizer level can be

customized when CUSTOM1 or CUSTOM2 is

If selecting CUSTOM1 or CUSTOM2, complete

the procedures outlined below. If selecting

other options, press M.C. to return to the pre-

! CUSTOM1 can be set separately for each

source. However, USB, iPod and PAN-

DORA are all set to the same setting auto-

! CUSTOM2 is a shared setting used in com-

mon for all sources.

3 Press M.C. to display the setting mode.

4 Press M.C. to cycle between the following:

Equalizer band—Equalizer level

5 Turn M.C. to select the desired setting.

Equalizer band: 80HZ—250HZ—800HZ—

2.5KHZ—8KHZ Equalizer level: +6 to –6

Loudness compensates for deficiencies in the low-

frequency and high-frequency ranges at low vol-

1 Press M.C. to select the desired setting.

OFF (off)—LOW (low)—MID (mid)—HI (high)

SUB.W (subwoofer on/off setting)

This unit is equipped with a subwoofer output

which can be turned on or off.

1 Press M.C. to select the desired setting.

NOR (normal phase)—REV (reverse phase)—

SUB.W CTRL (subwoofer adjustment)

Only frequencies lower than those in the selected

range are outputted from the subwoofer.

1 Press M.C. to display the setting mode.

2 Press M.C. to cycle between the following:

Cut-off frequency—Output level—Slope level

Rates that can be adjusted will flash.

3 Turn M.C. to select the desired setting.

Cut-off frequency: 50HZ—63HZ—80HZ—

100HZ—125HZ—160HZ—200HZ Output level: –24 to +6

BASS BOOST (bass boost)

1 Press M.C. to display the setting mode.

2 Turn M.C. to select a desired level.

0 to +6 is displayed as the level is increased or

HPF SETTING (high pass filter adjustment)

When you do not want low sounds from the sub-

woofer output frequency range to play from the

front or rear speakers, turn on the HPF (high pass

filter). Only frequencies higher than those in the

selected range are output from the front or rear

1 Press M.C. to display the setting mode.

2 Press M.C. to cycle between the following:

Cut-off frequency—Slope level

3 Turn M.C. to select the desired setting.

Cut-off frequency: OFF—50HZ—63HZ—80HZ

—100HZ—125HZ—160HZ—200HZ Slope level: –6— –12

SLA (source level adjustment)

SLA (Source level adjustment) lets you adjust the

volume level of each source to prevent radical

changes in volume when switching between sour-

! Settings are based on the FM volume level,

which remains unchanged.

! The AM volume level can also be adjusted with

! When selecting FM as the source, you cannot

! USB, iPod and PANDORA are all set to the

same setting automatically.

1 Press M.C. to display the setting mode.

2 Turn M.C. to adjust the source volume.

Adjustment range: +4 to –4

3 Turn M.C. to select the system menu

Once selected, the following system menu func-

tions can be adjusted.

! INFO DISPLAY is not available for DEH-

CLOCK SET (setting the clock)

1 Press M.C. to display the setting mode.

2 Press M.C. to select the segment of the clock

display you wish to set.

3 Turn M.C. to adjust the clock.

13 Section Operating this unit

<QRD3123-A/N>131 Press M.C. to select the desired setting.

12H (12-hour clock)—24H (24-hour clock)

INFO DISPLAY (sub information)

2 Turn M.C. to select the desired setting.

or LEVEL METER when the source is set to

AUX (auxiliary input)

Activate this setting when using an auxiliary de-

vice connected to this unit.

1 Press M.C. to turn AUX on or off.

BT AUDIO (Bluetooth audio activation)

You need to activate the BT AUDIO source in order

to use a Bluetooth audio player.

1 Press M.C. to turn the BT AUDIO source on or

BT MEM CLEAR (clearing the Bluetooth device

data stored on this unit)

Bluetooth device data stored on this unit can be

cleared. To protect personal information, we rec-

ommend that you clear this data before transfer-

ring this unit to other persons. The following types

of data on this unit will be cleared in such cases.

! Preset phone numbers

1 Press M.C. to show the confirmation display.

YES is displayed. Clearing memory is now on

If you do not want to clear the Bluetooth device

data stored on this unit, turn M.C. to display

CANCEL and press it again to select.

2 Press M.C. to clear the memory.

CLEARED is displayed and the Bluetooth de-

vice data is cleared.

! While this function is in use, do not turn

BT VERSION (Bluetooth version display)

You can display the system versions of this unit

and of Bluetooth module.

1 Press M.C. to display the information.

Selecting the key color

Only for DEH-X6500BT and DEH-X65BT You can select desired colors for the keys of this

4 Turn M.C. to select the illumination color.

You can select any one of the options in the fol-

! Preset colors (ranging from WHITE to ROSE)

! SCAN (cycle through all colors)

! Sets of colors (WARM, AMBIENT, CALM)

! CUSTOM (customized illumination color)

! When SCAN is selected, the system auto-

matically cycles through the preset colors.

! When WARM is selected, the system auto-

matically cycles through the warm colors.

! When AMBIENT is selected, the system au-

tomatically cycles through the ambient col-

! When CALM is selected, the system auto-

matically cycles through the calm colors.

! When CUSTOM is selected, the customized

color saved is selected.

Selecting the display color

Only for DEH-X6500BT and DEH-X65BT You can select the desired colors for the display

4 Turn M.C. to select the illumination color.

You can select any one of the options in the fol-

! Preset colors (ranging from WHITE to ROSE)

! SCAN (cycle through all colors)

! Sets of colors (WARM, AMBIENT, CALM)

! CUSTOM (customized illumination color)

For details about colors on the list, refer to Se-

lecting the key color on this page.

Selecting key and display color

Only for DEH-X6500BT and DEH-X65BT You can select the desired colors for the keys

and display of this unit.

4 Turn M.C. to select the illumination color.

You can select any one of the options in the fol-

! Preset colors (ranging from WHITE to ROSE)

! SCAN (cycle through all colors)

! Once you select a color in this function, col-

ors on the keys and display of this unit auto-

matically switch to the color you selected.

! For details about colors on the list, refer to

Selecting the key color on this page.

Selecting the key colors

displayed when a call is

Only for DEH-X6500BT and DEH-X65BT You can select the desired key colors to display

when an incoming call is received.

1 Press M.C. to display the main menu.

14 Section Operating this unit

4 Turn M.C. to select the illumination color.

You can select any one of the options in the fol-

! FLASHING – The color selected from

! FLASH MODE1 to FLASH MODE6 – The sys-

key colors for this unit. Select the desired

! OFF – No change in key color made when in-

coming calls are received.

Switching the dimmer setting

You can adjust the brightness of illumination.

1 Press M.C. to display the main menu.

to select the desired setting.

! You can also change the dimmer setting by

pressing and holding

Only for DEH-X6500BT and DEH-X65BT You can create custom illumination colors for

both KEY COLOR and DISP COLOR.

1 Press M.C. to display the main menu.

3 Turn M.C. to display KEY COLOR or

DISP COLOR. Press to select.

4 Press M.C. and hold until the customizing

illumination color setting appears in the dis-

5 Press M.C. to select the primary color.

R (red)—G (green)—B (blue)

6 Turn M.C. to adjust the brightness level.

Adjustment range: 0 to 60

# You cannot select a level below 20 for all three of

R (red), G (green), and B (blue) at the same time.

# You can also perform the same operation on

You cannot create a custom illumination color

while SCAN, WARM, AMBIENT or CALM is se-

About MIXTRAX Only for DEH-X6500BT and DEH-X65BT MIXTRAX technology is used to insert a variety

of sound effects in between songs, allowing you

to experience your music as a nonstop mix com-

plete with visual and lighting effects.

! Depending on the file/song, sound effects

! MIXTRAX includes a MIXTRAX flashing color

mode that when switched on turns the flash-

ing colors on and off in time with the audio

track. If you find the feature distracting while

driving, please turn MIXTRAX off. Refer to Op-

erations using the MIXTRAX button on page 6.

Only for DEH-X6500BT and DEH-X65BT

Once selected, the following MIXTRAX functions

can be adjusted. The function is enabled when

SHORT PLAYBACK (short playback mode)

You can select the length of the playback time.

1 Press M.C. to display the setting mode.

2 Turn M.C. to select the desired setting.

1.0 MIN (1.0 minute)—1.5 MIN (1.5 minutes)—

2.0 MIN (2.0 minutes)—2.5 MIN (2.5 minutes)

—3.0 MIN (3.0 minutes)—OFF (off)

! Turn this option OFF if you want to play a selec-

tion all the way through from start to finish.

FLASH AREA (flash area)

You can select areas for flashing colors.

1 Press M.C. to display the setting mode.

2 Turn M.C. to select the desired setting.

KEY/DISPLAY (key and display)—KEY (key)—

! When OFF is selected, the color set under IL-

LUMI is used as the display color.

FLASH PATTERN (flash pattern)

You can select flashing color patterns.

1 Press M.C. to display the setting mode.

2 Turn M.C. to select the desired setting.

You can select any one of the options in the fol-

! SOUND LEVEL 1 to SOUND LEVEL 6 –

Flashing colors will flash on and off in syn-

chronization with the sound level in a

song. Select the desired mode.

! LOW PASS 1 to LOW PASS 6 – Flashing

colors will flash on and off in synchroniza-

tion with the bass level in a song. Select

! RANDOM 1 – The pattern for the flashing

colors is randomly selected from the sound

level mode and low pass mode.

! RANDOM 2 – The pattern for the flashing

colors is randomly selected from the sound

! RANDOM 3 – The pattern for the flashing

colors is randomly selected from the low

DISPLAY FX (display effect)

The MIXTRAX special effects display can be turned

1 Press M.C. to select the desired setting.

ON (MIXTRAX special effects display)—OFF

CUT IN FX (manual cut-in effect)

You can turn on or off the MIXTRAX sound effects

while manually changing tracks.

1 Press M.C. to select the desired setting.

1 Press and hold SRC/OFF until the unit

15 Section Operating this unit

<QRD3123-B/N>152 Press and hold M.C. until the main menu

appears in the display.

3 Turn M.C. to change the menu option

Once selected, the following initial menu func-

tions can be adjusted.

SP-P/O MODE (rear output and preout setting)

The rear speaker leads output and the RCA output

of this unit can be used to connect a full-range

speaker or subwoofer. Select a suitable option for

1 Press M.C. to display the setting mode.

2 Turn M.C. to select the desired setting.

You can select any one of the options in the fol-

! REAR/SUB.W – Select when there is a full-

range speaker connected to the rear speak-

er leads output and there is a subwoofer

connected to the RCA output.

! SUB.W/SUB.W – Select when there is a

subwoofer connected directly to the rear

speaker leads output without any auxiliary

amp and there is a subwoofer connected

! REAR/REAR – Select when there is a full-

range speaker connected to the rear speak-

er leads output and the RCA output.

If there is a full-range speaker connected to

the rear speaker leads output and the RCA

output is not used, you may select either

REAR/SUB.W or REAR/REAR.

S/W UPDATE (updating the software)

This function is used to update this unit with the

latest Bluetooth software. For about Bluetooth

software and updating, refer to our website.

! Never turn the unit off while the Bluetooth soft-

ware is being updated.

1 Press M.C. to display the data transfer mode.

Follow the on-screen instructions to finish up-

dating the Bluetooth software.

1 Press and hold SRC/OFF until the unit

2 Press and hold M.C. until the main menu

appears in the display.

3 Turn M.C. to change the menu option

and press to select SYSTEM.

4 Turn M.C. to select the system menu

Once selected, the following system menu func-

tions can be adjusted.

For details, refer to System menu on page 13.

1 Insert the stereo mini plug into the AUX

2 Press SRC/OFF to select AUX as the

AUX cannot be selected unless the auxiliary set-

ting is turned on. For more details, refer to AUX

(auxiliary input) on page 14.

Switching the display

Selecting the desired text information

1 Press DISP to cycle between the following:

! Source name and clock

If an unwanted display appears

Turn off the unwanted display using the proce-

4 Turn M.C. to switch to YES.

5 Press M.C. to select.

16 Section Operating this unit

! Use speakers over 50 W (output value) and

between 4 W to 8 W (impedance value). Do

not use 1 W to 3 W speakers for this unit.

! The black cable is ground. When installing

this unit or power amp (sold separately),

make sure to connect the ground wire first.

Ensure that the ground wire is properly con-

nected to metal parts of the car’s body. The

ground wire of the power amp and the one of

this unit or any other device must be con-

nected to the car separately with different

screws. If the screw for the ground wire loos-

ens or falls out, it could result in fire, genera-

tion of smoke or malfunction. Ground wireMetal parts of car’s bodyPOWER AMPOther devices(Another electronic device in the car) Important

! When installing this unit in a vehicle without

an ACC (accessory) position on the ignition

switch, failure to connect the red cable to the

terminal that detects operation of the ignition

key may result in battery drain.

O N S T A R T O F F ACC position No ACC position

! Use this unit with a 12-volt battery and nega-

tive grounding only. Failure to do so may re-

sult in a fire or malfunction.

! To prevent a short-circuit, overheating or mal-

function, be sure to follow the directions

— Disconnect the negative terminal of the bat-

tery before installation.

— Secure the wiring with cable clamps or adhe-

sive tape. Wrap adhesive tape around wiring

that comes into contact with metal parts to

— Place all cables away from moving parts,

such as the shift lever and seat rails.

— Place all cables away from hot places, such

as near the heater outlet.

— Do not connect the yellow cable to the battery

by passing it through the hole to the engine

— Cover any disconnected cable connectors

with insulating tape.

— Do not shorten any cables.

— Never cut the insulation of the power cable of

this unit in order to share the power with

other devices. The current capacity of the

— Use a fuse of the rating prescribed.

— Never wire the negative speaker cable directly

— Never band together negative cables of multi-

! When this unit is on, control signals are sent

through the blue/white cable. Connect this

cable to the system remote control of an ex-

ternal power amp or the vehicle’s auto-anten-

na relay control terminal (max. 300 mA

12 VDC). If the vehicle is equipped with a

glass antenna, connect it to the antenna

booster power supply terminal.

! Never connect the blue/white cable to the

power terminal of an external power amp.

Also, never connect it to the power terminal

of the auto antenna. Doing so may result in

battery drain or a malfunction.

8 Wired remote input

Hard-wired remote control adapter can be

connected (sold separately).

Perform these connections when not connect-

ing a rear speaker lead to a subwoofer.

LR F R Perform these connections when using a sub-

e Black (chassis ground)

Connect to a clean, paint-free metal location.

Connect to the constant 12 V supply termi-

Connect to terminal controlled by ignition

Connect to system control terminal of the

power amp or auto-antenna relay control ter-

minal (max. 300 mA 12 V DC).

<QRD3123-A/N>17j When using a subwoofer of 70 W (2 W), be

sure to connect the subwoofer to the violet

and violet/black leads of this unit. Do not

connect anything to the green and green/

! With a 2 speaker system, do not connect any-

thing to the speaker leads that are not con-

! Change the initial menu of this unit. Refer to

SP-P/O MODE (rear output and preout set-

The subwoofer output of this unit is monau-

Power amp (sold separately)

Perform these connections when using the op-

1 System remote control

Connect to Blue/white cable.

2 Power amp (sold separately)

3 Connect with RCA cables (sold separately)

7 Rear speaker or subwoofer

! Check all connections and systems before

! Do not use unauthorized parts as this may

! Consult your dealer if installation requires

drilling of holes or other modifications to the

! Do not install this unit where: — it may interfere with operation of the vehicle.— it may cause injury to a passenger as a resultof a sudden stop. ! The semiconductor laser will be damaged if

it overheats. Install this unit away from hot

places such as near the heater outlet.

! Optimum performance is obtained when the

unit is installed at an angle of less than 60°.

! When installing, to ensure proper heat dis-

persal when using this unit, make sure you

leave ample space behind the rear panel and

wrap any loose cables so they are not block-

DIN front/rear mount

This unit can be properly installed using either

front-mount or rear-mount installation.

Use commercially available parts when instal-

1 Insert the mounting sleeve into the dash-

For installation in shallow spaces, use the sup-

plied mounting sleeve. If there is enough space,

use the mounting sleeve that came with the ve-

2 Secure the mounting sleeve by using a

screwdriver to bend the metal tabs (90°) into

2 1 Dashboard2 Mounting sleeve# Make sure that the unit is installed securely inplace. An unstable installation may cause skippingor other malfunctions. DIN Rear-mount

1 Determine the appropriate position

where the holes on the bracket and the side

2 Tighten two screws on each side.

3 1 Screw2 Mounting bracket3 Dashboard or console! Use either truss (5 mm × 8 mm) or flush sur-face (5 mm × 9 mm) screws, depending onthe bracket screw holes. Removing the unit

1 Remove the trim ring. 1 Trim ring2 Notched tab! Releasing the front panel allows easier ac-cess to the trim ring.! When reattaching the trim ring, point theside with the notched tab down. 2 Insert the supplied extraction keys into

both sides of the unit until they click into

Removing and re-attaching the

You can remove the front panel to protect your

Press the detach button and push the front

panel upward and pull it toward you.

For details, refer to Removing the front panel to

protect your unit from theft and Re-attaching the

front panel on page 5.

Securing the front panel

The front panel can be secured with the sup-

Installing the microphone

CAUTION It is extremely dangerous to allow the micro-

phone lead to become wound around the steer-

ing column or shift lever. Be sure to install the

unit in such a way that it will not obstruct driv-

Install the microphone in a position and orienta-

tion that will enable it to pick up the voice of the

person operating the system.

When installing the microphone

1 Install the microphone on the micro-

With the sun visor up, install the microphone

clip. (Lowering the sun visor reduces the voice

2 1 Microphone clip2 ClampUse separately sold clamps to secure thelead where necessary inside the vehicle. When installing the microphone

on the steering column

1 Install the microphone on the micro-

1 1 Microphone2 Microphone base3 Microphone clip4 Fit the microphone lead into the groove.# Microphone can be installed without using mi-crophone clip. In this case, detach the microphonebase from the microphone clip. To detach the micro-phone base from the microphone clip, slide the mi-crophone base. 2 Install the microphone clip on the steer-

3 1 Double-sided tape2 Install the microphone clip on the rear side ofthe steering column.3 ClampUse separately sold clamps to secure thelead where necessary inside the vehicle. Adjusting the microphone angle

The microphone angle can be adjusted.

19 Section Installation

changed (NO TITLE, for ex-

When you contact your dealer or your nearest

Pioneer Service Center, be sure to note the error

AMP ERROR Unit fails to op-

The disc is dirty. Clean the disc.

ERROR-15 The inserted

ERROR-23 Unsupported

USB storage device/iPod

NO AUDIO There are no

SKIPPED The connected

Additional information

20 Appendix Additional information

<QRD3123-A/N>20Message Cause Action

PROTECT All the files in

N/A USB The USB device

CHECK USB The connected

ERROR-19 Communication

iPod failure. Disconnect the

iPod failure. Disconnect the

ERROR-10 The power failed

ERROR-19 Communication

TRY AGAIN Unable to save

CHECK APP This version of

Additional information

21 Appendix Additional information

Use only discs that feature either of the following

Use 12-cm discs. Do not use 8-cm discs or an

adapter for 8-cm discs.

Use only conventional, fully circular discs. Do not

Do not insert anything other than a CD into the

Do not use cracked, chipped, warped, or other-

wise damaged discs as they may damage the play-

Unfinalized CD-R/RW discs cannot be played

Do not touch the recorded surface of the discs.

Store discs in their cases when not in use.

Do not attach labels, write on or apply chemicals

to the surface of the discs.

To clean a CD, wipe the disc with a soft cloth out-

ward from the center.

Condensation may temporarily impair the player’s

performance. Let it rest for about one hour to ad-

just to a warmer temperature. Also, wipe any

damp discs off with a soft cloth.

Playback of discs may not be possible because of

disc characteristics, disc format, recorded applica-

tion, playback environment, storage conditions,

Road shocks may interrupt disc playback.

Read the precautions for discs before using them.

When using discs that can be printed on label sur-

faces, check the instructions and the warnings of

the discs. Depending on the discs, inserting and

ejecting may not be possible. Using such discs

may result in damage to this equipment.

Do not attach commercially available labels or

other materials to the discs.

! The discs may warp making the disc unplay-

! The labels may come off during playback and

prevent ejection of the discs, which may result

in damage to the equipment.

Address any questions you have about your USB

storage device to the manufacturer of the device.

Connections via USB hub are not supported.

Do not connect anything other than a USB stor-

Firmly secure the USB storage device when driv-

ing. Do not let the USB storage device fall onto the

floor, where it may become jammed under the

brake or accelerator pedal.

Depending on the USB storage device, the follow-

ing problems may occur.

! Operations may vary.

! The storage device may not be recognized.

! Files may not be played back properly.

! The device may generate noise in the radio.

Do not leave the iPod in places with high tempera-

To ensure proper operation, connect the dock con-

nector cable from the iPod directly to this unit.

Firmly secure the iPod when driving. Do not let the

iPod fall onto the floor, where it may become

jammed under the brake or accelerator pedal.

! When an iPod is connected, this unit changes

the EQ (equalizer) setting of the iPod to off in

order to optimize the acoustics. When you dis-

connect the iPod, the EQ returns to the original

! You cannot set Repeat to off on the iPod when

using this unit. Repeat is automatically

changed to All when the iPod is connected to

Incompatible text saved on the iPod will not be dis-

DualDiscs are two-sided discs that have a record-

able CD for audio on one side and a recordable

DVD for video on the other.

Since the CD side of DualDiscs is not physically

compatible with the general CD standard, it may

not be possible to play the CD side with this unit.

Frequent loading and ejecting of a DualDisc may

result in scratches on the disc. Serious scratches

can lead to playback problems on this unit. In

some cases, a DualDisc may become stuck in the

disc loading slot and will not eject. To prevent this,

we recommend you refrain from using DualDisc

Please refer to the information from the disc man-

ufacturer for more detailed information about

Bit rate: 48 kbps to 320 kbps (CBR), 48 kbps to

Sampling frequency: 32 kHz, 44.1 kHz, 48 kHz

Windows Media Audio Professional, Lossless,

Voice/DRM Stream/Stream with video: Not com-

Bit rate: 8 kbps to 320 kbps (CBR), VBR Sampling frequency: 8 kHz to 48 kHz (32 kHz,

44.1 kHz, 48 kHz for emphasis)

Additional information

22 Appendix Additional information

<QRD3123-A/N>22Compatible ID3 tag version: 1.0, 1.1, 2.2, 2.3, 2.4

(ID3 tag Version 2.x is given priority over Version

WAV File extension: .wav

Quantization bits: 8 and 16 (LPCM), 4 (MS ADPCM)

Sampling frequency: 16 kHz to 48 kHz (LPCM),

22.05 kHz and 44.1 kHz (MS ADPCM)

Supplemental information

Only the first 32 characters can be displayed as a

file name (including the file extension) or a folder

This unit may not operate correctly depending on

the application used to encode WMA files.

There may be a slight delay at the start of playback

of audio files embedded with image data or audio

files stored on a USB storage device that has nu-

merous folder hierarchies.

Playable folder hierarchy: up to eight tiers (A prac-

tical hierarchy is less than two tiers.)

Playable folders: up to 99

Playable files: up to 999

File system: ISO 9660 Level 1 and 2, Romeo, Joliet

Multi-session playback: Compatible

Packet write data transfer: Not compatible

Regardless of the length of blank sections be-

tween the songs from the original recording, com-

pressed audio discs play with a short pause

Playable folder hierarchy: up to eight tiers (A prac-

tical hierarchy is less than two tiers.)

Playable folders: up to 500

Playable files: up to 15 000

Playback of copyright-protected files: Not compati-

Partitioned USB storage device: Only the first par-

tition can be played.

There may be a slight delay when starting play-

back of audio files on a USB storage device with

numerous folder hierarchies.

! Pioneer cannot guarantee compatibility with

all USB mass storage devices and assumes

no responsibility for any loss of data on

media players, smart phones, or other devi-

ces while using this product.

! Do not leave discs or a USB storage device

in any place that is subject to high tempera-

This unit supports only the following iPod mod-

els. Supported iPod software versions are shown

below. Older versions may not be supported.

! iPod touch 4th generation (software version

! iPod touch 3rd generation (soft ware version

! iPod touch 2nd generation (software version

! iPod touch 1st generation (software version

! iPod classic 160GB (software version 2.0.4)

! iPod classic 120GB (software version 2.0.1)

! iPod classic (software version 1.1.2)

! iPod with video (software version 1.3.0)

! iPod nano 6th generation (software version

! iPod nano 5th generation (software version

! iPod nano 4th generation (software version

! iPod nano 3rd generation (software version

! iPod nano 2nd generation (software version

! iPod nano 1st generation (soft ware version

! iPhone (software version 3.1.2)

Depending on the generation or version of the

iPod, some functions may not be available.

Operations may vary depending on the software

When using an iPod, an iPod Dock Connector to

USB Cable is required.

A Pioneer CD-IU51 interface cable is also avail-

able. For details, consult your dealer.

About the file/format compatibility, refer to the

Audiobook, Podcast: Compatible

CAUTION Pioneer accepts no responsibility for data lost

on the iPod, even if that data is lost while this

Sequence of audio files

The user cannot assign folder numbers and

specify playback sequences with this unit.

Folder selection sequence or other operation

may differ depending on the encoding or writing

Playback sequence is the same as recorded se-

quence in the USB storage device.

To specify the playback sequence, the following

method is recommended.

1 Create a file name that includes numbers

that specify the playback sequence (e.g.,

001xxx.mp3 and 099yyy.mp3).

2 Put those files into a folder.

3 Save the folder containing files on the USB

However, depending on the system environment,

Additional information

23 Appendix Additional information

<QRD3123-A/N>23For USB portable audio players, the sequence is

different and depends on the player.

In order to use Bluetooth wireless technology,

devices must be able to interpret certain pro-

files. This unit is compatible with the following

! PBAP (Phone Book Access Profile)

! AVRCP (Audio/Video Remote Control Profile)

Copyright and trademark

word mark and logos are regis-

tered trademarks owned by Bluetooth SIG, Inc.

and any use of such marks by PIONEER CORPORATION is under license. Other trade-

marks and trade names are those of their re-

Apple and iTunes are trademarks of Apple Inc.,

registered in the U.S. and other countries.

Supply of this product only conveys a license for

private, non-commercial use and does not con-

vey a license nor imply any right to use this prod-

uct in any commercial (i.e. revenue-generating)

real time broadcasting (terrestrial, satellite,

cable and/or any other media), broadcasting/

streaming via internet, intranets and/or other

networks or in other electronic content distribu-

tion systems, such as pay-audio or audio-on-de-

mand applications. An independent license for

such use is required. For details, please visit

http://www.mp3licensing.com.

WMA Windows Media is either a registered trademark

or trademark of Microsoft Corporation in the

United States and/or other countries.

This product includes technology owned by

Microsoft Corporation and cannot be used or

distributed without a license from Microsoft

iPhone, iPod, iPod classic, iPod nano, and iPod

touch are trademarks of Apple Inc., registered in

the U.S. and other countries.

“Made for iPod” and “Made for iPhone” mean

that an electronic accessory has been designed

to connect specifically to iPod or iPhone, respec-

tively, and has been certified by the developer to

meet Apple performance standards. Apple is

not responsible for the operation of this device

or its compliance with safety and regulatory

standards. Please note that the use of this ac-

cessory with iPod or iPhone may affect wireless

Pandora is a registered trademark of Pandora

MIXTRAX MIXTRAX is a trademark of the PIONEER CORPORATION.

Power source 14.4 V DC (10.8 V to 15.1 V al-

Grounding system Negative type

Maximum current consumption

10.0 A Dimensions (W × H × D):

DIN Chassis 178mm × 50mm ×

(7 in. × 2 in. × 6-1/2 in.)

Nose 188mm × 58mm ×

(7-3/8 in.× 2-1/4 in.× 5/8 in.)

(DEH-X6500BT/DEH -X65BT)

Nose 188mm × 58mm ×

(7-3/8 in.× 2-1/4 in.× 5/8 in.)

D Chassis 178mm × 50mm ×

(7 in.× 2 in.× 6-1/2 in.)

Nose 170mm × 46mm ×

(6-3/4 in.× 1-3/4 in.× 5/8 in.)

(6-3/4 in. × 1-3/4 in. × 5/8 in.)

Weight 1 kg (2.2 lbs)

Maximum power output ... 50 W × 4

70 W × 1/2 W (for subwoofer)

Continuous power output

22W × 4 (50 Hz to 15000Hz,

5 % THD, 4 W load, both chan-

Load impedance 4 W (4 W to 8 W allowable)

2.0V Loudness contour +10 dB (100 Hz), +6.5 dB

Equalizer (5-Band Graphic Equalizer):

125 Hz/160 Hz/200 Hz

Slope –6 dB/oct, –12 dB/oct

Gain +6dB to –24 dB Phase Normal/Reverse

System Compact disc audio system

Usable discs Compact disc

Signal-to-noise ratio 94dB (1kHz) (IHF-A network)

Number of channels 2 (stereo)

MP3 decoding format MPEG-1 & 2 Audio Layer 3

WMA decoding format Ver. 7, 7.1, 8, 9, 10, 11, 12 (2ch

(Windows Media Player)

Maximum current supply

1 A USB Class MSC (Mass Storage Class)

File system FAT12, FAT16, FAT32

MP3 decoding format MPEG-1 & 2 Audio Layer 3

WMA decoding format Ver. 7, 7.1, 8, 9, 10, 11, 12 (2ch

(Windows Media Player)

Frequency range 87.9 MHz to 107.9 MHz

Frequency range 530 kHz to 1 710 kHz

Usable sensitivity 25µV (S/N: 20 dB)

Signal-to-noise ratio 62dB (IHF-A network)

Additional information

24 Appendix Additional information

<QRD3123-A/N>24Bluetooth

Version Bluetooth 3.0 certified

Output power +4dBm Maximum

CEA2006 Specifications

Power output 14 W RMS × 4 Channels (4 W

S/N ratio 91dBA (reference: 1 W into

Specifications and the design are subject to

modifications without notice.

Additional information

Pioneer Electronics (USA) Inc.

Markham, Ontario L3R 2Z5, Canada

http://www.pioneerelectronics.ca

service ou hors service.

S.RTRV (sound retriever)

service ou hors service.

S.RTRV (sound retriever)

S.RTRV (sound retriever)

S.RTRV (sound retriever)

BASS BOOST (accentuation des graves)

BT AUDIO (activation audio Bluetooth)

1.0 MIN (1,0 minute)—1.5 MIN (1,5 minutes)—

2.0 MIN (2,0 minutes)—2.5 MIN (2,5 minutes)

—3.0 MIN (3,0 minutes)—OFF (hors service)

! Tournez cette option OFF si vous souhaitez lire

ches)—OFF (hors service)

46 Section Installation

! PBAP (Phone Book Access Profile)

PIONEER CORPORATION.

Pente –6 dB/oct, –12 dB/oct

(Windows Media Player)

(Windows Media Player)

Pioneer Electronics (USA) Inc.

Pioneer Electronics of Canada, Inc.

CUSTOMER SATISFACTION DEPARTMENT

http://www.pioneerelectronics.ca

(Pandora)—AUX (AUX)—BT AUDIO (audio

aleatorio (shuffle all)

! PBAP (Phone Book Access Profile)

“Made for iPod” y “Made for iPhone” significan

D Bastidor 178mm × 50mm ×

(Windows Media Player)

(Windows Media Player)

340 Ferrier Street, Unit 2, Markham, Ontario L3R 2Z5, Canada

PIONEER ELECTRONICS AUSTRALIA PTY. LTD.

ã 2012 PIONEER CORPORATION. All rights reserved.
