Product type Chest freezer
Brand VALBERG
Model CF 198 F W742C
Climate class SN, N, ST, T (10°C to 43°C)
Temperature adjustment 5 levels (MIN to MAX) + SUPER mode
Super freeze mode Yes, activation by SET button, max duration 52 h
Defrosting Manual, via drain channel and drain plug
Power supply 220-240 V ~ 50 Hz
Earthing Mandatory
Warranty 2 years
Required space Sides 10 cm, rear 10 cm, top 70 cm
Interior cleaning Warm water and mild soap
Condenser cleaning Annually, with brush or vacuum cleaner
Safety Unplug before maintenance, do not use steam cleaner
Provided accessories 1 basket
Wheels Yes (4 wheels)
Lid handle Yes
Drain channel Yes
Drain plug Yes
LED indicators Yes, for display

Frequently Asked Questions - CF 198 F W742C - CF 198 F W742C VALBERG

How to adjust the temperature of my VALBERG CF 198 F W742C freezer?
Press the SET button to enter adjustment mode. The indicator bar increases by one level with each press, from MIN to MAX (coldest). The setting is saved automatically after 5 seconds.
How to activate super freeze mode?
From the MAX level, press SET several times until the SUPER indicator lights up. The compressor switches to super freeze mode. It deactivates automatically after 52 hours or manually.
How to defrost my freezer?
Unplug the appliance, remove the inner drain plug and place a tray under the outer drain channel. Pull the drainage knob and turn it 180° to drain the water. Once defrosting is complete, push the knob back, replace the plug, and wipe the interior dry.
What to do if the appliance does not work?
Check that the plug is connected and that the fuse has not blown. If the socket is defective, contact an electrician. Consult the troubleshooting table in the manual.
How to clean the interior of the freezer?
Unplug the appliance, remove the food, and clean with a cloth and warm water mixed with a little mild soap. Rinse with fresh water and dry completely before restarting.
Why is there ice on the door seal?
This indicates that the seal is not airtight. To repair it, gently heat the separated sections with a hair dryer (cool setting) and reshape the seal with your hand.
What noises are normal?
Operating sounds from the compressor and gas circulation are normal. If the appliance touches the wall or objects, move it slightly. If a tube at the back touches something, carefully bend it.
What clearance to leave around the appliance?
Maintain a free space of at least 10 cm on the sides and rear, and 70 cm above for optimal air circulation.
What is the climate class of this appliance?
The appliance is multi-class: SN (10-32°C), N (16-32°C), ST (16-38°C), T (16-43°C). Use it in the range corresponding to your environment.
What to do in case of prolonged power outage?
If the power is cut longer than the rise time indicated on the label, thawed food must be consumed quickly or cooked and refrozen. Avoid opening the door unnecessarily.
