TWINTALKER 1302 - Talkie Walkie TOPCOM - Free user manual and instructions
Find the device manual for free TWINTALKER 1302 TOPCOM in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | PMR446 Walkie-talkie |
| Brand | Topcom |
| Model | TWINTALKER 1302 |
| Number of Channels | 8 PMR446 channels |
| Maximum Range | Up to 8 km in open field |
| Output Power | 0.5 W (500 mW) |
| Power Supply | 3 AAA batteries (not included) or NiMH rechargeable battery |
| Battery Life | Approximately 20 hours in normal use |
| Frequency | 446.00625 – 446.09375 MHz |
| Call Channel | Channel 8 (built-in CTCSS/DCS) |
| Privacy Code | 38 CTCSS codes and 83 DCS codes |
| VOX Function | Yes, hands-free |
| Display Function | Backlit LCD display |
| Dimensions | Approximately 160 x 55 x 30 mm |
| Weight | Approximately 120 g (without batteries) |
| Material | Durable ABS plastic |
| Maintenance and Cleaning | Wipe with a soft, slightly damp cloth. Do not use abrasive products. |
| Safety | Use only recommended batteries and chargers. Do not expose to extreme temperatures. |
| Spare Parts and Repairability | Batteries and belt clips are available as options. For any repairs, contact Topcom after-sales service. |
| General Information | Compliant with European regulations. License-free use. |
Frequently Asked Questions - TWINTALKER 1302 TOPCOM
What is the maximum range of the TWINTALKER 1302?
The maximum range is about 8 km in open field. In urban or wooded areas, the range may be reduced to 1-3 km.
How many batteries are needed and what type?
The device operates with 3 AAA batteries (not included). You can also use a NiMH rechargeable battery (sold separately).
How to change the privacy code?
Press the MENU key, use the arrows to select the CTCSS or DCS code setting, then choose the desired code with the + and - keys. Confirm with MENU.
Is the TWINTALKER 1302 compatible with other brands of walkie-talkies?
Yes, it is compatible with all PMR446 walkie-talkies using the same frequencies and CTCSS/DCS codes.
How to activate the hands-free function (VOX)?
Press the VOX key until the VOX icon appears on the screen. Then set the VOX sensitivity level (1 to 3) via the menu.
What is the battery life?
With new alkaline batteries, the battery life is approximately 20 hours in normal use (5% transmit, 5% receive, 90% standby).
How to lock the keypad to prevent accidental operation?
Press and hold the LOCK key (lock icon) for 3 seconds until the lock icon appears. To unlock, repeat the operation.
Can I use the walkie-talkie abroad?
Yes, in countries where the PMR446 band is authorized (European Union, Switzerland, Norway, etc.). Check local regulations before use.
How to adjust the volume and sensitivity?
Use the rotary knob on top of the device for volume. For squelch sensitivity, access the menu and adjust the level (0-9, 0 being most sensitive).
What to do if the screen does not light up?
Check that the batteries are correctly inserted and in good condition. If the problem persists, remove the batteries, wait 30 seconds, and reinsert them. Contact customer service if necessary.
