Product type LED lighting
Brand BEGLEC
Model MYSTERY LED
Dimensions (L x W x H) 296 x 271 x 140 mm
Weight 3.8 kg
Power supply AC 230 V, 50 Hz
Power consumption 34 W
Fuse 250 V, 6.3 A, slow (20 mm glass)
Light sources 2 x 10 W RGB LED
Number of lenses 28
Sound control Built-in microphone
DMX connections XLR 3-pin (male/female)
DMX channels 1 or 3 channels
Operating modes Standalone, Master/Slave, DMX
Number of preprogrammed shows 8 (show 0 to show 8)
Optional remote control CA-8 (1/4" jack)
Display 4-digit display
IEC power chaining Up to 17 units
Minimum safety distance 0.5 m
Maximum ambient temperature 40 °C
External optics maintenance Every 30 days
Internal optics maintenance Every 90 days (by qualified personnel)
Protection class Class I (grounded)
Usage Indoor use only

Frequently Asked Questions - MYSTERY LED BEGLEC

How to connect multiple MYSTERY LED units in master/slave mode?
Connect up to 16 units in daisy chain using balanced microphone cables. Set the first unit to master mode, the others to slave mode (SL 1 for synchronized, SL 2 for opposite). Plug all into the mains.
What DMX control modes are available?
Two modes: 1 channel (selection of 11 music programs) or 3 channels (dimmer/strobe, color, speed/rotation). Set via the CHNd menu.
How to set the DMX start address?
Press MENU until Rddr is displayed, confirm with ENTER, then use UP/DOWN to select the address. Confirm with ENTER.
What to do if the unit does not react to sound?
Check that sound mode is activated: in menu 501n, set to on. Make sure the internal microphone is not obstructed. If in master/slave mode, the master must have black out disabled (BLID set to NO).
Can a remote control be used?
Yes, connect the optional CA-8 remote to the 1/4 inch jack on the master unit. It allows control of standby, strobe, shows, and speed.
What is the power consumption and fuse type?
Consumption: 34 W. Fuse: 250 V, 6.3 A, slow (20 mm glass). Always replace with an identical model.
How to clean the lenses?
Clean the external optics every 30 days with a soft cloth and glass cleaner. Internal optics should be cleaned every 90 days by a qualified technician.
What safety precautions for high installation?
Use a support capable of bearing 10 times the weight of the device and a safety cable capable of bearing 12 times the weight. The device must be at least 0.5 m from walls and out of reach of the public.
What to do if the display shows nothing?
Check the display setting: menu LED to turn the display on (on) or off (OFF). If the display turns off automatically, it will light up upon pressing any key.
How to reset the device?
Press MENU until SEP is displayed, then ENTER to reset the motors. To set the home position, hold ENTER for 5 seconds until OPAN appears, then adjust with UP/DOWN.
