USER MANUAL TRUS460 Truvox

USER MANUAL EN

EC DECLARATION OF CONFORMITY

EN (English)

Machine Type: Commercial sweeper

Model: TRUS460...,

This machine is in conformity with the following EU directives:

• Machinery Directive:

2006/42/EC

Applied harmonised standards:

BS/EN ISO 12100:2010, BS/EN60335-1

Truvox International Limited, Unit C (East), Hamilton Business Park, Manaton Way

Botley Road, Hedge End, Southampton, SO30 2JR, UK

Malcolm Eneas, Operations Director

13/03/2025

EC DECLARATION OF CONFORMITY

EN (English)

Machine Type: Commercial sweeper

Model: TRUS460...,

This machine is in conformity with the following EU directives:

• Machinery Directive:

2006/42/EC

Applied harmonised standards:

BS/EN ISO 12100:2010, BS/EN60335-1

Truvox International SARL, 38 rue de Berri, 75008 Paris, France

Malcolm Eneas, Operations Director

13/03/2025

Malcolm Eneas, Operations Director

13/03/2025

DECLARATION DE CONFORMITE CE

FR (Français)

Type de machine: Balayeuse

Modèle: TRUS460...,

Malcolm Eneas, Operations Director

13/03/2025

Malcolm Eneas, Operations Director

13/03/2025

IMPORTANT - BEFORE USE READ THESE INSTRUCTIONS AND RETAIN FOR FUTURE REFERENCE

INTRODUCTION

The following instructions contain important information about the machine and safety advice for the operator. Equipment must be operated, serviced, and maintained in accordance with the manufacturer's instructions. If in doubt, contact the supplier of your machine.

Read all instructions before using the machine

PRODUCT INFORMATION

This sweeper is designed exclusively for operation on solid, level and dry surfaces. The machine is intended for commercial use, for example in hotels, schools, hospitals, factories, shops, offices, rental businesses and other than normal housekeeping purposes.

TECHNICAL SPECIFICATIONS

Model		TruSweep 460
Product Code		TRUS460
Capacity	litres	40
Brush diameter	cm	23
Brush speed	cpm	273 (at 4 km/h)
Working width	cm	65
Productivity rate	m2/h	2600 (at 4 km/h)
Dimensions (L x W x H)	cm	100 x 79 x 102
Dimensions (L x W x H) (without handle or side brush)	cm	80 x 73 x 40
Weight	kg	26
Warranty		1 year subject to conditions

• Above dimensions are approx. Since the company's policy is to continuously improve the product, there could be changes without prior notice.
• Handle vibration does not exceed 2.5 m / s² when operating on a smooth hard surface.

WASTE ELECTRICAL & ELECTRONIC EQUIPMENT (WEEE)

Do not dispose of this device with unsorted waste. Improper disposal may be harmful to the environment and human health. Please refer to your local waste authority for information on return and collection systems in your area.

IMPORTANT SAFETY ADVICE

The safety information described in this manual provides basic precautions and supplements standards in force in the country where the machine is used.

This symbol warns the operator of hazards and unsafe practices which could result in severe personal injury or death.

WARNING – to reduce the risk of injury, electric shock or fire.

1. This machine must only be used for the manufacturer's approved application as described in this manual.
2. Only genuine accessories and spare parts provided with the machine or those approved by the manufacturer should be used. The use of other accessories may impair the safety of the machine. All repairs must be performed by a qualified service agent.
3. DO NOT modify the machine from its original design.
4. Operators must be fully trained in the use of the machine in accordance with these instructions, able to perform regular user maintenance and the correct selection of accessories.
5. Operators should be physically capable to manoeuvre, transport and operate the machines.
6. Operators should be able to recognise unusual operation of the machine and report any problems.
7. This machine is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the machine by a person responsible for their safety.
8. Keep children and unauthorised persons away from the machine when in use. DO NOT use as a toy.
9. DO NOT use if it has been damaged, left outdoors or dropped in water.
10. DO NOT use where hazardous dust is present.
11. DO NOT use in an explosive atmosphere.
12. DO NOT pick up or use near flammable or combustible fluids, hazardous dusts or vapours.
13. CAUTION - If it is suspected that there is hazardous dust or flammable/corrosive material, stop cleaning the area immediately and consult your superior.
14. DO NOT use to clean up any burning or lighted materials such as cigarettes, matches, ashes or other combustible objects.
15. Only use the machine on firm level surfaces. DO NOT use on a gradient or slope of more than 2%.

16. DO NOT use on rough uneven surfaces e.g. industrial or coarse concrete surfaces.

17. Take care when using a machine near the top of stairs to avoid overbalancing.

18. DO NOT cover the machine when in use.
19. Keep hair, loose clothing, hands, feet and all other parts of the body away from openings and moving parts.
20. DO NOT operate the machine if it malfunctions or is damaged in any way. Contact an authorised service agent for repair or adjustments.
21. DO NOT sweep over wet surfaces.
22. If any parts are damaged they shall only be replaced by an approved part by the manufacturer, its service agent or a similar qualified person in order to avoid a hazard.

TRANSPORTING THE MACHINE

• Take extreme care when moving the machine up or down steps or stairs.
• Incorrect lifting techniques may result in personal injury. We advise that the manual handling regulations are followed.
• DO NOT expose the machine to rain or moisture.
- When transporting the machine ensure that all components, tanks and removable parts are securely fastened.
- Ensure the machine is empty prior to lifting or transporting.
• DO NOT attempt to lift the machine without assistance.

STORAGE

• Store the machine in a dry indoor area only.

MAINTENANCE

WARNING - Before undertaking maintenance operations or adjustments switch off machine and unplug from the electricity supply.

IMPORTANT – All other servicing and repairs should only be performed by a Truvox engineer or Authorised Service Agent.

IMPORTANT – Should the machine fail to operate please refer to the fault diagnosis section in the back of this instruction manual. If the problem / remedy is not listed, please contact Truvox Customer Service Department for rapid attention.

The machine requires minimum maintenance apart from the following checks by the operator prior to use:

• Body of the machine - Clean with a damp cloth.
• Empty the dirt collector, thoroughly clean the machine and remove any debris entangled in the main brush shaft.
- Check the brushes and seals.
• Grease the track wheels once a month.
- Check the V-belt tension once a month and retighten if necessary.

AFTER SALES SERVICE

Truvox machines are high quality machines that have been tested for safety by authorised technicians. It is always apparent that after longer working periods, electrical and mechanical components will show signs of wear and tear or ageing. To maintain operational safety and reliability the following service interval has been defined: Every year or after 250 hours. Under extreme or specialised conditions and/or insufficient maintenance, shorter maintenance intervals are necessary.

Use only original Truvox spare parts. Use of other spare parts will invalidate all warranty and liability claims. Should you require after sales service please contact the supplier from whom you purchased the machine, who will arrange service. Repairs and servicing of Truvox products should only be performed by trained staff. Improper repairs can cause considerable danger to the user.

GUARANTEE

Your product is guaranteed for one year from the date of original purchase, or hire purchase, against defects in materials or workmanship during manufacture. Within the guarantee period we undertake at our discretion, to repair or replace free of charge to the purchaser, any part found to be defective, subject to the following conditions:

CONDITIONS

1. Claims made under the terms of the guarantee must be supported by the original invoice/bill of sale issued at the time of sale, or the machine Serial No.
2. For claims under this guarantee contact the supplier from whom you purchased the product who will arrange the appropriate action. Do not initially return the product as this could result in transit damage.
3. Neither Truvox nor its distributor shall be liable for any incidental or consequential loss.
4. This guarantee is governed by the laws of England.
5. This guarantee does not cover any of the following:

• Periodic maintenance, and repair or replacement of parts due to normal wear and tear.
• Damage caused by accident, misuse or neglect, or the fitting of other than genuine Truvox parts.
- Defects in other than genuine Truvox parts, or repairs, modifications or adjustments performed by other than a Truvox service engineer or authorised service agent.
• Costs and risks of transport relating directly or indirectly to the guarantee of this product.
- Consumable items such as power cords, brushes, drive discs, filters, belts, vacuum skirts and other similar items.

This guarantee does not affect your statutory rights, or your rights against the supplier arising from their sales or purchase contract. Truvox International Limited policy is one of continual product development and we reserve the right to alter specifications without prior notice.

RECOMMENDED SPARES & ACCESSORIES

Description	Part No.
Main brush	90-0690-0000
Side Brush	90-0689-0000

FAULT DIAGNOSIS

The following simple checks may be performed by the operator. If the machine is still not working, please contact your local Service Agent:

Trouble	Remedy
Machine hard to push/pull	Clean the machineDecrease main brush pressure settingGrease main wheels
Sweeping unsatisfactory	Check pick up tray and empty if requiredIncrease main/side brush pressureClean main/side brushCheck main brush for loose bristles
Traces of dirt left behind the machine	Check pick up tray and empty if requiredCheck side/rear rubber sealings
Side brush not rotating	Check V-belt for transmission

PLEASE REFER TO THE BACK OF THE MANUAL FOR PICTORIAL INSTRUCTIONS

PRODUKTINFORMATIONEN

INFORMATIONS SUR LE PRODUIT

2

3

4

5

6

7

8

⑨

10

11

1

2

3

1

2

3
