Product type	Filtering pitcher / water purifier
Brand	Cecotec
Model	H2onature 2400 Active
Capacity	Approximately 2.4 L
Filtration technology	Activated carbon filter
Improvements	Reduces impurities and chlorine, and improves the taste, odor, and clarity of water
Filter change indicator	Yes, electronic with screen
Indicator power source	CR1620 button cell battery, 3 V included
Battery included	Yes, CR1620
Lid	Removable, with a tab for easy opening
Material	Food-grade plastic
Maintenance	Hand wash only, do not wash in dishwasher
Safety	Use from age 8 under supervision; immunocompromised individuals should boil water if necessary
Spare parts	Replacement filters (3 filters included)
Box contents	1 pitcher, 1 reservoir, 1 lid, 3 filters, 1 indicator (with battery), instruction manual
Warranty	2 years
Reference	04080 / 04081

Frequently Asked Questions - H2onature 2400 Active CECOTEC

How do I install the filter in the H2onature 2400 Active pitcher?

Remove the filter from its packaging, rinse it under cold water for 10 seconds in an upright position, then firmly press it into the reservoir tube until it is securely in place. Then replace the lid.

How do I reset the filter change indicator?

Press and hold the indicator button for 5 seconds until the screen flashes "00". Release, then briefly press to display the number of remaining days. The indicator is then reset.

When should I replace the filter?

The filter should be replaced when the indicator reaches the scheduled replacement date, usually after about 30 days or after filtering a certain volume of water. Follow the on-screen instructions.

Can I use hot or warm water?

No, fill the pitcher only with cold or room-temperature water. Hot water could damage the filter and reduce its effectiveness.

Can the pitcher be placed in the dishwasher?

No, the pitcher and its accessories are not dishwasher-safe. Clean them by hand with a soft cloth and soap.

Is the water drinkable immediately after the first refills?

After installing the filter, you must complete 3 full fill-and-filter cycles. Once these 3 cycles are done, the filtered water is ready to drink.

What should I do if the filter has not been in contact with water for 2 days?

Let the filter soak in water for 10 minutes, then reinstall it. This helps rehydrate the filter and maintain its performance.

Is the pitcher suitable for babies or sensitive individuals?

People with weakened immune systems (babies, the elderly) should follow medical recommendations regarding water. If their doctor advises boiling the water, this should be done before or after filtration.

How do I clean the pitcher and reservoir?

Use a soft cloth or sponge with soapy water. Rinse thoroughly with clean water and let dry. Do not use abrasive products.

Why is the indicator flashing?

The indicator flashing may indicate that the filter needs to be replaced or that the battery is low. If the screen flashes "00", reset the indicator or replace the filter.

USER MANUAL H2onature 2400 Active CECOTEC

Safety instructions 6

1. Parts and components 21
2. Before use 21
3. Product assembly 21
4. Operation 22
5. Cleaning and maintenance 22
6. Technical specifications 23
7. Disposal of old electrical appliances 23
8. Technical support service and warranty 23

SOMMAIRE

Read these instructions thoroughly before using the appliance. Keep this instruction manual for future reference or new users. All safety instructions should be closely followed when using the appliance.

This product is designed only for household use.

This product is intended to be filled with tap water only. Do not use water of unknown quality.

People with weak immune systems, such as babies or elders, must boil the water before or after the filtration if they have been recommended to do this before drinking it.

We recommend using only the filter included with the product or similar ones, as the use of other kind of filter may change the result.

Fill the product only with cold or room-temperature water. Avoid filling it with warm or hot water.

Do not use abrasive cleaning agents to clean the jar.

This product is not dishwasher safe.

If the jar or the tank are broken or cracked, you must replace the whole product. In case only the filter is damaged, replace only the filter.

The appliance is not intended to be used by children under the age of 8. It can be used by children over the age of 8, as long as they are given continuous supervision.

This product can be used by children and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge, as long as they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.

Supervise children, they shall not play with the appliance. Close supervision is necessary when the appliance is being used by or near children.

INSTRUCTIONS DE SÉCURITÉ

Take the product out of the box.

Remove all packaging materials. Keep the original box.

Make sure all the components are included and in good conditions, otherwise, contact immediately the official Technical Support Service of Cecotec.

3. PRODUCT ASSEMBLY

Remove the lid by pressing the tabs on both sides and pulling up.

Remove the filter (inside the packaging) from the jar and set aside.

Clean the jar, tank and lid with a soft cloth or a sponge and a mild liquid soap. Rinse it and a let it dry.

Warning: The scrubber side of a sponge may scratch the surface of the jar, so we recommend using only the soft side.

Place the tank back to the jar as shown in the image. The longest part of the tank must face the front of the jar.

Fig. 2

Installation of the filter

Remove the filter from its package. Wash it upright with cold or room-temperature water for 10 minutes. Rinse the filter under running water for 10 seconds.

Press it down firmly into the tank's tube to ensure a tight sealing.

Fig. 3

Assemble the lid.

Fig. 4

4. OPERATION

This product filters the impurities of tap water while improving its smell, taste and clarity. It also provides a more economical and environmental-friendly alternative to buying bottled water.

Filling the jar

Use cold or room-temperature water to fill the jar.

Press down the tab next to the filter's lifespan indicator to open the filling opening in the lid.

Fill the tank with water and allow all the water to filter through. Pour the water out and repeat. Repeat this process three times. After the third, water will be ready to drink.

Make sure all the water has passed through the filter before pouring it.

Fig. 5

Setting the filter's lifespan indicator

Press the filter's lifespan indicator button for 5 seconds until the display shows "00" blinking.

Press it again and the filter's lifespan will be displayed (in days).

Fig. 6

For achieving better results, make sure the bottom of the filter is always in contact with water so it will not dry out. If the filter has not been in contact with water for two days in a row, soak it for 10 minutes and then re-install it.

Store the jar in the refrigerator or in a cool location. If the water has been inside the jar for several days, pour it out and refill the jar with fresh water.

5. CLEANING AND MAINTENANCE

Use a soft, damp cloth to clean the product's surface.

Do not use abrasive scouring pads, powders or cleaners.

Replacing the filter

When the date on the filter's lifespan indicator is reached, replace the filter. Disassemble it using its tab. Repeat the steps above to install a new filter

6. TECHNICAL SPECIFICATIONS

Product reference: 04080 / 04081

Product: H20Nature 2400 Active/H20Nature 2400 Active Pro

Battery model: CR1620

Voltage: 3V

7. DISPOSAL OF OLD ELECTRICAL APPLIANCES

The European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), specifies that old household electrical appliances must not be disposed of with the normal unsorted municipal waste. Old appliances must be collected separately, in order to optimize the recovery and recycling of the materials they contain and reduce the impact on human health and the environment.

The crossed out “wheeled bin” symbol on the product reminds you of your obligation to dispose of the appliance correctly. If the product has a built-in battery or uses batteries, they should be removed from the appliance and disposed of appropriately.

Consumers must contact their local authorities or retailer for information concerning the correct disposal of old appliances and/or their batteries.

8. TECHNICAL SUPPORT SERVICE AND WARRANTY

This product is under warranty for 2 years from the date of purchase, as long as the proof of purchase is submitted, the product is in perfect physical condition, and it has been given proper use, as explained in this instruction manual.

The warranty will not cover the following situations:

The product has been used for purposes other than those intended for it, misused, beaten, exposed to moisture, immersed in liquid or corrosive substances, as well as any other fault attributable to the customer.

The product has been disassembled, modified, or repaired by persons, not authorised by the official Technical Support Service of Cecotec.

Faults deriving from the normal wear and tear of its parts, due to use.

The warranty service covers every manufacturing defects of your appliance for 2 years, based on current legislation, except consumable parts. In the event of misuse, the warranty will not apply.

If at any moment you detect any problem with your product or have any doubt, do not hesitate to contact Cecotec Technical Support Service at [phone].

1. PIÈCES ET COMPOSANTS

Img. 1

Fig./Img./Abb./Afb./ Rys. 3

Fig./Img./Abb./Afb./Rys. 4

Fig./Img./Abb./Afb./Rys. 5

Fig./Img./Abb./Afb./ Rys. 2

Fig./Img./Abb./Afb./ Rys. 6
