HP300S2-F7 - Boiler HAIER - Free user manual and instructions

Product Type	Heat Pump Water Heater
Brand	Haier
Model	HP300S2-F7
Tank Capacity	300 liters
Installation Type	Floor standing
Energy Source	Air source heat pump with electric backup
Power Supply	230 V / 50 Hz
Heating Input	Heat pump: 2.0 kW; Backup heater: 2.4 kW
Coefficient of Performance (COP)	Up to 3.5
Energy Efficiency Class	A+
Max Water Temperature	75 °C
Dimensions (H x W x D)	1800 x 600 x 600 mm
Net Weight	95 kg
Refrigerant	R134a
Water Connection	3/4" BSP
Noise Level	45 dB(A) at 1 meter
Protection Rating	IPX4
Temperature Range	15 - 75 °C
Control Panel	Digital display with push buttons
Safety Features	Over-temperature protection, pressure relief valve, anti-corrosion anode
Maintenance	Clean air filter regularly; check anode every 2 years
Spare Parts Availability	Guaranteed for 10 years after purchase
Warranty	5 years on tank, 2 years on components

Frequently Asked Questions - HP300S2-F7 HAIER

How does the heat pump water heater work?

The Haier HP300S2-F7 uses a heat pump to extract heat from the surrounding air and transfer it to the water in the tank. This process is highly efficient, making it up to 3 times more energy-efficient than a conventional electric water heater. An electric backup element provides additional heating when needed.

What is the recommended temperature setting for the HP300S2-F7?

For daily use, a temperature of 55°C is recommended to balance comfort and energy savings. If you plan to be away for an extended period, set the unit to 15°C (frost protection mode) to save energy. Boost mode raises the temperature to 75°C for high demand.

How do I install the HP300S2-F7?

Installation should be performed by a qualified technician. The unit must be placed on a level, solid floor with at least 50 cm clearance around it for proper airflow. Connect the water inlet and outlet pipes, and the electrical supply must match the 230V/50Hz specification. Refer to the manual for detailed steps.

How often should I perform maintenance?

Regular maintenance keeps the heater running efficiently. Clean the air filter every 3 months. Check the sacrificial anode every 2 years and replace it if heavily corroded. Annually inspect the pressure relief valve by lifting the lever briefly to ensure it operates correctly.

What should I do if the water heater is not producing hot water?

First, check the power supply and circuit breaker. Ensure the air filter is clean, as a clogged filter can reduce heat pump performance. If the display shows an error code, consult the troubleshooting section in the manual. If the backup heater is on, allow time for the water to heat up. If problem persists, contact customer service.

Can the HP300S2-F7 operate in cold climates?

Yes, the HP300S2-F7 is designed to operate in temperatures as low as -10°C. In very cold conditions, the electric backup heater automatically activates to ensure hot water supply. However, efficiency decreases as ambient temperature drops.

How can I reduce energy consumption?

Set the thermostat to 55°C instead of higher temperatures. Use eco mode if available, which optimizes the heat pump operation. Program the timer to heat water only during off-peak hours. Regularly clean the air filter to maintain efficiency.

What does the anti-legionella function do?

The anti-legionella function periodically heats the water to 65°C or higher to kill any Legionella bacteria that could cause illness. This ensures the water remains hygienic and safe for use. The cycle typically runs automatically but can be triggered manually.

How do I replace the sacrificial anode?

The sacrificial anode protects the tank from corrosion. To replace it, turn off the power and water supply, then drain the tank. Locate the anode (usually on top of the unit), unscrew it, and install a new one. Check it every 2 years and replace if more than 50% corroded.

Is the HP300S2-F7 compatible with solar panels?

Yes, the HP300S2-F7 can be integrated with solar thermal systems through the solar inlet connection. This allows the heat pump to work alongside solar heating, maximizing renewable energy use and reducing electricity bills. Consult the installation guide for proper connection.

USER MANUAL HP300S2-F7 HAIER

Heat Pump Water Heaters Monoblock + Split System

Significantly more efficient than traditional electric water heaters.

Our Brand

Empowering smarter, happier, and healthier living, Haier leads with smart technologies across a range of home appliances. Discover Smart Home Comfort.

Award Winning

1 SMART AIR CONDITIONING BRAND IN THE WORLD"

Global Scale

OPERATING IN 100 COUNTRIES

Innovation + Quality

10 R&D CENTRES GLOBALLY

Service + Support

NATIONWIDE SUPPORT

Heating and cooling expertise

Haier is the worlds largest manufacturer of electric hot water systems. We have been making hot water products since 1986 and during that time have sold over 200 million systems around the globe. Haier has been manufacturing efficient electric heat pump systems since 2010 and have sold over 5 million units during this time.

Founded in China in 1984, Haier's customer-centric approach has fueled the development of smart home appliances that blend technological innovation with functionality, making it the world's leading brand of connected air conditioners in 2023 with an impressive market share of over 33% in volume sales."

In Australasia, Haier's strength is complemented by Fisher & Paykel, a trusted brand that is now part of the Haier Group. Together, they leverage Haier's global reach and Fisher & Paykel's local service network to provide industry-leading products and support to our customers in Australia and New Zealand.

* Data source: Euromonitor International Limited Consumer Apptences 2007.pdf, four shares, 2005 volume sales data. Major accessories and other categories: Home devices applications for cooking appliances and kitchenware and equipment applications. Volume sales other to other rental orders, retail merchants and accommodation channels. * Data source: Eurochannel International Ltd. Accounts in terms of retail sales volume in 2005 based on records completed by February 2004. Commercial card loan is defined as an controller with connecting sequencing to communicate with other appliances and other devices and/or instruments.

Haier

OFFICIAL HOME APPLIANCES PARTNER

From grassroots to Grand Slams, Haier is a major supporter of tennis around the world. As the official Home Appliance Partner of the Australian Open and the official Partner of Tennis Australia, Haier is excited to share their love for the game with you.

04

An energy-efficient way to heat your water

Heat Pump Water Heaters bring new innovation to hot water heating – using less energy than standard electric water heaters.

Split SystemMonoblock

Efficient design

Haier heat pump technology results in a 64% to 79% reduction in the amount of electricity used to heat the same volume of water, compared to a traditional electric resistance water heater. Heat is drawn in from the surrounding ambient air, with electricity only used for the compressor and the fan, rather than using it to heat the water directly through an electrical element.

Respect for the planet

Haier heat pump hot water systems have lower electricity use, and use low impact refrigerants. They also complement solar PV set-ups, prioritising solar energy to reduce electricity use. *

Connected home

We believe in integrating smart technology into the heart of every home. The SmartHQ™ app puts control in your hands, allowing you to adjust heating as your hot water needs change – and do it from anywhere.

Change between five user modes using SmartHQ™ on your smartphone: Auto mode, Eco mode with Solar PV mode, Electric mode, Vacation mode and Boost.

* Energy values of 60-19% reduction on the later heat pump water performance, when compared to a standard relative electric storage water heater in 7 years (Eco) AS-025473.
** Compared to each confidence and gas metals.

10

Respect for the Planet

Haier's Monoblock is a one piece water heater that uses heat pump technology and careful design to create an energy-efficient, high performance water heater. The Split System uses considered technologies and materials to help reduce our impact on the planet, including the ability to integrate with your solar PV system.

Reduced running costs

The heat pump technology results in a 69 to 79%* (Monoblock) and 64 to 68%** (Split System) reduction in electricity used to heat the same volume of water compared to an electric resistance heater. This is likely to lower your electricity bill and save you money every year.

Eco mode for lower electricity use

Eco mode optimises the benefits of solar PV and lower cost, time-of-use electricity when you have a separate solar PV system. With Solar PV mode, your heat pump water heater integrates with your solar PV system to maximise consumption of PV solar-generated energy, which can help to reduce your power bill.

Low GWP refrigerant

Our Monoblock Heat Pump Water Heaters use R290 which has a GWP of 3. Many heat pumps use R134A. R290 has a global warming potential that is 476 times lower than R134A. Split Heat Pump Water Heaters use R32 refrigerant, a next generation refrigerant that efficiently carries heat and has a significantly lower environmental impact than its predecessors. The GWP (Global Warming Potential) of R32 is 675, nearly half as much as R134A, which is used by many heat pump water heaters.

Solar PV ready

If you have a solar PV system, surplus solar energy it generates can be stored in the tank as hot water, reducing the use of grid-supplied energy. In Solar PV mode, the Heat Pump Water Heater receives a signal from the solar PV system, notifying it that generated energy is available to use. It uses the available solar PV energy to heat water at up to 75 degrees, storing it for later use.

* Energy ratings of 51-70% are based on Inner Mongolia 2021, 3.68 and 3.88, when compared to a standard river-to-ocean water heater in Zone 1 to 3 in AS/9524512006. ** Energy ratings of 51-70% are based on Inner Split System 2021 when compared to a standard relative electric storage water heater in Zone 1 to 3 in AS/9524512014.

Efficient Design

Haier Heat Pump Water Heaters have been designed to give you hot water reheating efficiency. The Split System has flexibility in installation location and the Monoblock has been designed to make installation as simple and familiar as possible.

Designed for efficiency

No more electric heating element to heat water – Instead this system uses efficient heat pump technology. This technology, which transfers heat from the air to the water in the tank instead of heating via electricity alone, results in a reduction in electricity of 69 to 79% (Monoblock) and 64 to 68%* (Split System) to heat the same volume of water compared to a traditional electric resistance water heater.

Fast reheating

Water reheats fast in the Split System with a heating capacity of 4.58kW, the largest in our heat pump water heater range, meaning that even if a large volume of water has been consumed, fresh water is rapidly heated to keep the hot water flowing.

Longevity

Using patented technology with a triple layer protection creates a long lasting, corrosion-resistant inner tank. The inner tank is tested to over 160,000 cycles to ensure durability over the expected lifetime.

Easy installation

Monoblock requires the same installation procedure as an electric storage water heater. If located in the same position, there's minimal need for additional valves or pipe layout changes, making it easy to swap from an electric resistance water heater. With the Split System heat pump split from the cylinder, you have the flexibility to place the heat pump unit outside away from noise sensitive areas and the cylinder outside or inside in a discrete area.

Heat boost

The Split System has a back up booster of 2.5kW and built in "one-time boost" further help with fast recovery when hot water use has been particularly high.

Quiet operation

With an operating noise level of 43-46dBA (Monoblock) and 52dBA (Split System) at a distance of one metre. Haier Heat Pump Water Heaters are quiet. The outdoor unit can be located away from noise sensitive areas of the home, helping with a good night's sleep even while your heat pump works hard.

*Energy earnings of 60-24% are based on Lower Pariback 2021, 3.25 and 1.001 when compared to a standard model for the water heater in Panama 3 to 5 in ASIN25C35.2008. **Energy trading of 14-18% are based on Lower Split System 2021 when compared to a standard model for electric storage water heater in Panama 3 to 5 in ASIN25C35.

Connected Home

We believe in integrating smart technology into the heart of every home. The SmartHQ™ app puts control in your hands, allowing you to adjust heating as your hot water needs change – and do it from anywhere.

Change between five user modes using SmartHQ™ on your smartphone: Auto mode, Eco mode with Solar PV mode, Electric mode, Vacation mode and Boost.

Specifications

Monoblock

Heat Pump Water Heater

Model HP200M1-U1 Model HP250M1-U1

Model HP330M1U1

Split System

Heat Pump Water Heater

Model HP300S2-F7

(Trisik reconsinatromotels TIP500G2-F) & DIP50.52-F

Model:HP200M1-U1 HP250M1-U1 HP330M1U1 HP300G2-F7

Tons
Total water capacity 195L 246L 390L 270L
Rated voltage/frequency 270-740V/10Hz 270-740V/10Hz 270-740V/10Hz 270-740V/10Hz
PTB setting 700Pa 700Pa (800Pa 700Pa)
Isgress protection IP24 IP24 IP24 IFX4
Hot & cold inlet connections	%* RF	%* RF	%* RF	%* RF
PTB connection	%* RF	%* RF	%* RF	%* RF
COP @ 20°C/15°C	4.49 4.48 4.48	4.48
Power input of electric element	1.3kW	1.5kW	2.3kW	2.6kW
Rated power input of heat pump	0.43kW	0.63kW	0.70kW	N/A
Rated power input of appliance	N/A	N/A	N/A	4.3kW
Average power input of heat pump	N/A	N/A	N/A	1.10kW
Par colitube and connection size - Laxlcline	N/A	N/A	N/A	N/A (0.3mmH/1% - 20kW)
Par colitube and connection size - Suction line	N/A	N/A	N/A	N/A (0.52mmH/1% - 180kW)
Maximum power input of heat pump	0.75kW	0.75kW	1.3kW	1.7kW
Maximum power input of appliance	2.75kW	2.75kW	3.0kW	N/A
Average heating capacity by heat pump	2.0kW	2.0kW	2.5kW	4.5kW
Deafert temperature setting	60°C	60°C	60°C	55°C
Heating range (with increment)	35°C~75°C	35°C~75°C	35°C~75°C	35°C~75°C
Heating range (heat pump only)	35°C~65°C	35°C~65°C	35°C~65°C	35°C~65°C
Refrigerant type/weight	R290V/0.34kg	R290V/0.34kg	R290V/0.47kg	R32V/0.53kg
Refrigerant pipe length	N/A	N/A	N/A	min. 3m~max. 3m
Noise	dB(A)	dB(B)	dB(A)	dB(B)
Ambient temperature range	-7~45°C	-7~43°C	-7~45°C	-7~45°C

Per centimeter 20°C/15°C Airbus, air pressure, 15°C to 55°C water (per galvan)
The COP was measured under test conditions that an amount of temperature of 20°C to 5°C. Dry Sub-Wet Bulk and heating of the water from 15°C to 65°C during water recovery operation.

THE DO BANGYUAN MANSUF BOAT 1 MTRCT THE KAMF DARTIF UNTG 2 NO PA T AVE COCONUTING STATION LEET 2.0 LST IN 8 DATA - INTERNO CONVORARY MEAT 8 INDUSTO

Performance

Model	Air temp (°C)	Cold water temp (°C)	Recovery time (hours)	Recovery rate (L/H)	Average heating capacity (kW)	Coefficient of Performance (COP)
	19	15	5.6	33	2.1	4.5
HP200M1-U1	988.7	24	1.6	3.5
	2810.2	15	1.2	2.9
	19	15	6.9	36	2.7	4.5
HP210M1-U1	9810.6	25	1.6	3.5
	2812.3	20	1.2	2.9
	19	15	5.82	57	2.8	4.0
HP310M1U1	989.5	34	2.5	3.9
	2813.3	26	1.5	2.2
	19	15	2.5	110	5.1	4.3
HP300S2-F2	784.15	67	3.6	3.6
	284.20	62	3.4	2.9

Performance results are measured at April 2014.
HP52051-47 performance testing completed with a 3m distance between the heat pump unit and the cylinder.

Warranty and Support

Warranty

With a warranty of up to 7 years on the cylinder, you have peace of mind.

		Cylinder Refrigeration Components		Other Components*
Domestic Use	Part in 7 years 5 years 5 years
	Labour 5 years 7 years 5 years
Commercial Use	Part in 1 year	1 year	1 year
	Labour 5 year	2 year	2 year

The power components refer to the entire power pump in which it is consensus, the component, operator value and operational process. It also refers to the microchannel value and person within the cylinder unit.

"Other components industrial electrical components such as cinked circuit boards, the user interface, electrical voltage instruments, sensors, along with all plumbing valves and disassembled devices.

Our goods come with the construction contracts included under Australian Consumer (ac). You are entitled to a pre-appointment or refund for a major financial compensation for any other necessarily favorable, or, or surplus. You are also entitled to have the goods applied and corrected these goods fully due to a acceptable deal by and the bill you does not amount to a major failure. Our Manufacturer is Warranty in addition to any tangible remediation that you may have and it is not intended to limit any right you may have an order of Australia. For consumers we are an alternative kind of interest to our payers.

Federal Small-Scale Technology Certificate (STCs)

In addition to the Federal STC rebates, state rebates are also available in some states to replace inefficient water heating technologies with efficient technologies such as hot water heat pumps.

AUSTRALIAN SMALL-SCALE TECHNOLOGY CERTIFICATES (STCs)

	STC Entitlements for 2025 STC Entitlements for 2026
Listed Code	Zone 1	Zone 2	Zone 3	Zone 4	Zone 1	Zone 1	Zone 2	Zone 3	Zone 4	Zone 5
HP200M1-U1 15 15 18 19 19 13 12 15 16 15
HPV30M1-U1 16 15 19 21 20 13 18 18 17 17
HP330M1U1 15 14 16 19 19 12 12 15 16 16
HP300S2-Fr13 13 16 18 18 13 13 16 18 18

Local Customer Care

With nation-wide Customer Care support and local warehousing of spare parts, if there is an issue with your water heater, we will help you get back up and running as quickly as possible.

18

.

ΛΟ Haier

OFFICIAL HOME APPLIANCES PARTNER

Make more time for tennis with Haier

Customer Care

Visit the website for more information

Australia: haierhome.com.au

Customer support and service booking

Australia: support.haier.com.au/s/book-a-service

LEARN MORE ABOUT OUR PRODUCT HERE

Haier
