Ironhero 3000 Sauna I Pump - Iron CECOTEC - Free user manual and instructions

Product type	Steam iron with pump
Brand	Cecotec
Model	Ironhero 3000 Sauna I Pump
Power	2000 W
Supply voltage	220-240 V ~ 50/60 Hz
Soleplate type	Ceramic
Water tank capacity	300 ml
Continuous steam output	Up to 35 g/min
Variable steam output	Yes
Anti-scale function	Self-cleaning system
Auto shut-off	Yes
Cord length	2 m
Weight	1.5 kg
Dimensions (L x W x H)	30 x 15 x 20 cm
Care and cleaning	Clean the soleplate with a damp cloth; use the self-cleaning function regularly
Spare parts and repairability	Water tank, replacement soleplate available from Cecotec
General information	Steam iron with pump for efficient and effortless ironing

Frequently Asked Questions - Ironhero 3000 Sauna I Pump CECOTEC

How to fill the water tank of the Cecotec Ironhero 3000 Sauna I Pump?

Unplug the appliance, open the tank cap located at the front of the iron, pour water up to the max mark (300 ml), then close the cap.

How to use the steam pump function?

Press the pump button located under the handle to release a burst of powerful steam. Ideal for stubborn wrinkles.

What to do if the iron does not heat up?

Check that the plug is connected and the thermostat is set to a sufficient temperature. If the problem persists, contact Cecotec after-sales service.

How to clean the ceramic soleplate?

Let the iron cool down, then clean the soleplate with a soft, damp cloth. Do not use abrasive products.

How to descale the Cecotec Ironhero 3000 iron?

Use the self-cleaning function: fill the water tank, heat the iron, unplug it, and press the self-cleaning button until dirty water flows out. Repeat if necessary.

Can tap water be used in the iron?

Yes, but to extend the life, it is recommended to use a mixture of tap water and demineralized water (50/50) in very hard water areas.

How to activate the auto shut-off?

The auto shut-off is activated by default. The iron turns off after about 8 minutes of inactivity in the vertical position or 30 seconds in the horizontal position.

What is the power of the Cecotec Ironhero 3000 Sauna I Pump iron?

The power is 2000 W, ensuring fast heat-up and constant steam.

How to store the iron after use?

Empty the water tank, let the iron cool down, wrap the cord around the base and store it upright on its heel.

Where to find spare parts for this model?

Spare parts (tank, soleplate, etc.) are available on the official Cecotec website or from authorized dealers.

USER MANUAL Ironhero 3000 Sauna I Pump CECOTEC

Plancha horizontal con bomba/ Steam iron with pump

Safety instructions 7

1. Parts and components 34

2. Before use 34

3. Operation 34

4. Cleaning and maintenance 37

5. Technical specifications 37

6. Disposal of old electrical and electronic appliances 37

7. Technical support and warranty 38

8. Copyright 38

SOMMAIRE

Read these instructions thoroughly before using the device. Keep this instruction manual for future reference or new users.

• This device is designed for domestic use only and is not intended for bars, restaurants, farmhouses, hotels, motels, and offices.
• This appliance can be used by children aged 8 years and above and persons with reduced physical, sensory, or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. Children must not play with the appliance. Cleaning and maintenance should not be carried out by children without supervision.

- Keep the iron and its cord out of reach of children under 8 years of age when the appliance is plugged into a mains socket or when it is cooling down.

- Do not leave the appliance unattended while it is hot, plugged into an outlet, or on the ironing board.

- Unplug the appliance from the mains before filling or emptying the water tank.

- The filling opening must not be open during use.

- Place and use the appliance on a flat, stable, dry, and heat-resistant surface. Make sure the surface is stable.

- Do not operate the appliance if it has been dropped, shows visible damage, or is leaking.

- This symbol means “caution, hot surface”. The accessible surfaces of the appliance may reach high temperatures during operation. Be careful not to burn yourself. Do not touch hot surfaces during operation or immediately after.

- Check the power cable regularly for visible damage. If the

power cord is damaged, it must be replaced by the official Cecotec Service Centre or similarly qualified personnel to avoid hazards.

• Make sure that the mains voltage matches the voltage stated on the rating label of the appliance and that the wall outlet is earthed.
• Do not twist, bend, pull, or damage the power cable. Protect it from sharp edges and heat sources. Do not allow the cable to touch hot surfaces. Do not let the cable hang over the edge of the working surface or worktop.
• Do not immerse the cable, plug, or any other part of the appliance in water or any other liquid or expose electrical connections to water. Make sure your hands are dry before handling the plug or switching on the appliance.
• Avoid contact with the steam emitted by the appliance. Steam temperature is very high and can cause burns and other damage.
• The appliance is not intended to be operated by means of an external timer or separate remote-control system.
• Switch off and unplug the appliance when not in use and before cleaning it. Pull from the plug, not the cable, to disconnect it from the outlet.
• Keeping the iron at maximum temperature for too long may cause discolouration, which will not affect the performance of the appliance.
• Do not try to repair the device by yourself. Contact the official Cecotec Technical Support Service for advice.
• Cecotec takes no responsibility for any damage caused by misuse of the machine. Any misuse or non-compliance with these instructions voids the warranty and Cecotec's liability.

INSTRUCTIONS DE SÉCURITÉ

1. Indicator light
2. Mode knob
3. Temperature setting
4. Steam button
5. Spray trigger
6. Cable protection end
7. Water tank
8. Soleplate
9. Water spraying
10. Tank cover

NOTE:

the graphics in this manual are schematic representations and may not exactly match the device.

2. BEFORE USE

• This appliance is packaged in a way as to protect it during transport. Take the device out of its box and remove all packaging materials. You can keep the original box and other packaging elements in a safe place. This will help you prevent damage to the device when transporting it in the future. In case the original packaging is disposed of, make sure all packaging materials are recycled accordingly.
• Make sure all parts and components are included and in good conditions. If there is any piece missing or in bad conditions, contact the official Cecotec Technical Support Service immediately.

Box content

• Iron
• Instruction manual

3. OPERATION

Temperature setting

Let the iron preheat before use. If you change the temperature, wait for the iron to adapt to the new setting before using it; especially if you select a lower temperature setting. The iron takes longer to cool down than to heat up, so it is advisable to start ironing from a lower temperature.

Before first use

WARNING: remove adhesive stickers and any other plastic or cardboard packaging from the soleplate. Be sure to remove all stickers by rubbing the soleplate with a cloth dampened with methyl alcohol. Rinse the water tank: fill and empty it to remove any possible manufacturing residues.

NOTE: when the iron is switched on for the first time, it may release steam for up to 10 minutes due to the heating of the manufacturing residues. This is normal and does not impair the operation of the iron.

Filling up the water tank

Before filling the iron's water tank, make sure that it is switched off. It is possible to fill the water tank before or during use. To do this, place the iron in an upright position and open the tank cover; slowly pour the water through the filling hole without exceeding the maximum capacity of the tank. Put the tank cover back on.

Using the iron

Connect the iron to a power supply and turn it on.

Adjustment for synthetic, silk, and wool garments

If you want to iron dry, it is not necessary to fill the tank. If you want to dry iron and there is water in the tank, empty it before use.

1. Plug in the iron and switch it on.
2. After switching on, the indicator light on the iron will light up steadily.
3. Turn the temperature knob from OFF to the desired position: Synth, Silk, or Wool.
4. Once preheating is complete, the indicator light will flash you can use the iron when the indicator light changes from flashing to steady.

Adjustment for cotton and linen

For more difficult fabrics (such as cotton or wool), use the steam function and always set the temperature to the maximum setting.

1. Fill up the water tank. Note: Before steam ironing, make sure that the tank is at least 1/4 full.
2. Plug in the iron and switch it on.
3. The indicator light will come on to indicate that the appliance has started up correctly.
4. Turn the temperature knob from OFF to the desired setting: Cotton or MAX/linen.
5. The indicator light will change from flashing to steady to indicate that the iron has reached the selected temperature setting and you can start using it. With the iron in horizontal position, press the steam button: the indicator will light up red and the iron will emit continuous steam.
6. To deactivate the continuous steam function, press the steam button again: the indicator light will go out.

ENGLISH

Do not apply steam during dry ironing of synthetic, silk, or woollen garments.

Steam burst

Turn the knob to the Cotton or MAX/linen position. When the indicator light changes from flashing to steady, press the steam button twice in succession: the corresponding indicator light will light up and the iron will emit a steam burst. To release another steam burst, wait 5 seconds for the indicator light to go out, then press the steam button again twice in succession. Warning:

1. Make sure the tank is at least 1/4 full.
2. Select the desired temperature setting and wait for the indicator light to change from flashing to steady.
3. During use, press the steam button twice to start the electromagnetic pump.

Spraying

This function can be used for both dry ironing and steam ironing to dampen ironing fabrics.

1. Make sure the tank is at least 1/4 full.
2. Press the spray trigger during ironing to spray water.

Self-cleaning

For good ironing results and to keep the iron in good working condition, clean the iron at least once every two weeks. If the water in your water system is very hard, clean the iron more frequently.

1. Fill the water tank to MAX and plug in the iron; turn the temperature selector to the MAX/ linen position and wait for the indicator light to change from flashing to steady.
2. Then, turn the temperature selector to the OFF position. With the soleplate downwards, hold the iron over a sink or container and press the steam button for 3 seconds to start the electromagnetic pump for 1 minute: water and steam will come out of the soleplate.
3. Press the steam button again if necessary. If the water tank is empty, fill it up. Shake the iron lightly to expel more water. When cleaning is finished, turn the temperature knob to MAX/linen position, wait for the indicator light to change from flashing to steady and iron an unused fabric so that the remaining water inside the soleplate is vaporised.
4. Drain the remaining water, allow the iron to cool down and store it. If the soleplate is dirty, clean it with a soft, damp cloth.

Note: you can press the steam button at any time to stop cleaning the iron.

Automatic shut-off function

• The automatic shut-off system automatically switches off the iron in case of inactivity.
• The iron will automatically switch off after 15 minutes of inactivity in vertical position or 30 seconds of inactivity in horizontal position without moving it, or if it is left tilted for 30 seconds.

Anti-limescale filter

The integrated anti-limescale cartridge removes minerals from the tap water to prevent limescale build-up on the soleplate and steam chamber, prolonging the use of the appliance.

4. CLEANING AND MAINTENANCE

After each use

Switch off the appliance and unplug from the power outlet.

Storage

Always store the iron in a vertical position. Do not store the iron horizontally or in the cardboard box.

Cleaning

Wipe the outside of the iron with a soft damp cloth and dry it. Warning: do not use harsh abrasives, chemical cleaners, or solvents to clean the outside of the iron.

Cleaning the soleplate

Dry the soleplate thoroughly with a dry cloth. Warning: do not use scouring pads, abrasives, or aggressive cleaning agents to clean the soleplate to avoid damaging it.

5. TECHNICAL SPECIFICATIONS

Product reference: 01878

Product: IronHero 3000 Sauna i-Pump

Rated voltage: 220-240 V

Frequency: 50-60 Hz

Power: 3000 W

Technical specifications may change without prior notification to improve product quality. Made in China | Designed in Spain

6. DISPOSAL OF OLD ELECTRICAL AND ELECTRONIC APPLIANCES

This symbol indicates that, according to the applicable regulations, the product and/or batteries must be disposed of separately from household waste. When this product reaches the end of its shelf life, you should dispose of the cells/batteries/accumulators and take them to a collection point designated by the local authorities.

ENGLISH

Consumers must contact their local authorities or retailer for information concerning the correct disposal of old appliances and/or their batteries.

Compliance with the above guidelines will help protecting the environment.

7. TECHNICAL SUPPORT AND WARRANTY

Cecotec shall be liable to the end user or consumer for any lack of conformity that exists at the time of delivery of the product under the terms, conditions, and deadlines established by the applicable regulations.

It is recommended that repairs be carried out by qualified personnel.

If at any moment you detect any problem with your product or have any doubt, do not hesitate to contact the official Cecotec Technical Support Service at [phone].

8. COPYRIGHT

The intellectual property rights over the texts in this manual belong to CECOTEC INNOVACIONES, S.L. All rights reserved. The contents of this publication may not, in whole or in part, be reproduced, stored in a retrieval system, transmitted, or distributed by any means (electronic, mechanical, photocopying, recording or similar) without the prior authorization of CECOTEC INNOVACIONES, S.L.
