SENSEO QUADRANTE HD7864/61 - Coffee machine

QUADRANTE HD7864/61 - Coffee machine SENSEO - Free user manual and instructions

Find the device manual for free QUADRANTE HD7864/61 SENSEO in PDF.

English EN ⬇ Download 💬 AI Question ❓ 10 questions ⚙️ Specs
📄

Document temporarily unavailable

The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.

Pick your language and provide your email: we'll send you a specifically translated version.
Product type SENSEO pod coffee machine
Brand Philips SENSEO
Model HD7864/61
Power supply 220-240 V, ~50-60 Hz, 1450 W (approximate)
Dimensions (W x D x H) Approximately 25 x 30 x 35 cm
Weight Approximately 3 kg
Water tank capacity 1.5 L (up to 8 cups)
Preparation capacity 1 or 2 cups simultaneously
Main functions 1-cup and 2-cup buttons, intensity selector (model HD7864), automatic shut-off after 30 min, integrated rinse
Pod type SENSEO pods (only)
Maintenance and cleaning Removable parts dishwasher-safe (pod holder, coffee receiver, drip unit, water tank). Descaling recommended every 3 months with a citric acid-based descaler (e.g. SENSEO HD7012/HD7011/HD7006). Rinse after 3 days of inactivity.
Safety Automatic shut-off, dry boil protection, max altitude 2200 m, min ambient temperature 10°C, do not immerse.
Spare parts and repairability Accessories available at www.shop.philips.com/service. Repairs by Philips Authorized Service Center.
Warranty International warranty (see included leaflet)

Frequently Asked Questions - QUADRANTE HD7864/61 SENSEO

Why is the on/off indicator light flashing slowly and continuously?
This indicates that the machine has not yet been rinsed with fresh water before first use. Follow the rinsing procedure described in the Before first use chapter.
Why is the indicator light flashing rapidly?
The water tank is not properly positioned, there is insufficient water (level below MIN), or the ambient temperature is below 10°C. Check these points.
What to do if the machine produces no coffee or very little?
Make sure you have performed the initial rinse with fresh water (see the Before first use chapter). If the problem persists, check that the pod holder sieve is not clogged and descale the machine.
How to clean the pod holder sieve?
Rinse the pod holder under the tap. If necessary, use a dish brush or a pin to unclog the sieve in the center.
How often should I descale the machine?
Philips recommends descaling every 3 months (4 to 6 times a year) with a citric acid-based product. Never use vinegar or mineral acids.
What to do if the machine lid will not open?
Turn off the machine and wait 24 hours. A vacuum has formed under the lid. Do not force it. After opening, clean the pod holder and check that it is not obstructed.
Why is the coffee not hot enough?
Use suitable cups (capacity 150 to 280 ml). Preheat the cups by rinsing them with hot water. Avoid large cups which cool the coffee faster.
How to adjust coffee strength?
On model HD7864, use the intensity selector located on the top of the machine. High position for strong coffee (60 ml), low position for normal coffee (100 ml).
Can I use regular ground coffee?
No, use only SENSEO pods. Ground coffee would clog the machine and void the warranty.
The machine leaks, what should I check?
Check that the water level does not exceed MAX, that the pod holder sieve is not clogged, that the pod is centered correctly, and that the sealing ring is not displaced. See the Troubleshooting section of the manual.
