Product type	Drip coffee maker
Brand	Hamilton Beach
Model	40913
Capacity	12 cups (1.8 L)
Power supply	120 V, 60 Hz, 900 W
Dimensions (W x D x H)	30 x 25 x 35 cm
Weight	2.5 kg
Carafe type	Glass carafe with markings
Filter	Permanent reusable filter
Delay timer	Yes, up to 24 hours
Auto shut-off	Yes, after 2 hours
Pause and serve function	Yes, allows serving before cycle ends
Anti-drip system	Yes
Water reservoir	Removable with level indicator
Indicator light	Indicates power on and programming
Maintenance and descaling	Descaling recommended every 3 months with white vinegar or descaler
Safety	Auto shut-off, non-slip base
Spare parts available	Carafe, filter basket, water reservoir, permanent filter
Repairability	Repairability index 7.5/10

Frequently Asked Questions - 40913 HAMILTON BEACH

How to program the Hamilton Beach 40913 coffee maker?

Press the Program button, then set the desired time using the Hour and Minute arrows. Confirm by pressing Program again. The machine will start automatically at the programmed time.

What is the maximum capacity of the machine?

The machine can brew up to 12 cups (1.8 liters) of coffee.

How to clean the permanent filter?

Rinse the permanent filter with warm water after each use. For a thorough cleaning, wash it in the dishwasher (top rack) or by hand with mild soap.

What to do if the machine does not turn on?

Check that the machine is plugged in and the outlet is working. Ensure the water reservoir is properly placed. If the problem persists, contact customer service.

How to descale the coffee maker?

Use a mixture of white vinegar and water (1:3) or a compatible descaler. Pour the solution into the reservoir, run a full cycle without coffee, then rinse by running two cycles of clear water.

Can I use ground coffee or pods?

This machine is designed for ground coffee only. Use the provided filter basket with your choice of ground coffee. Pods are not compatible.

Is the carafe dishwasher safe?

Yes, the glass carafe and lid can be washed in the dishwasher (top rack). The permanent filter as well.

How to adjust the auto shut-off?

The auto shut-off is preset to 2 hours after the cycle ends. It is not adjustable. The machine will turn off automatically to save energy.

Where to find spare parts for this model?

Spare parts (carafe, filter basket, reservoir) are available on the Hamilton Beach website or from authorized retailers. Use model number 40913 to identify parts.

What is the warranty of the machine?

The Hamilton Beach 40913 coffee maker is warranted for 1 year against manufacturing defects. Keep your receipt for any claims.

USER MANUAL 40913 HAMILTON BEACH

Visit www.hamiltonbeach.com for our complete line of products and Use and Care Guide, as well as

delicious recipes, tips, and

to register your product on

Please call us – our friendly

associates are ready to help.

USA: 1.800.851.8900

Questions?

Hamilton Beach blender with clear glass casing and black handle (no visible text or symbols)

Hamilton

Beach.

Iced Coffee Maker

When using this appliance, basic safety precautions should always be followed to reduce the risk of injury to persons, including the following:

1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs. Care must be taken, as burns can occur from touching hot parts or from spilled, hot liquid.
3. To protect against electric shock, do not place cord, plug, iced coffee maker, or water reservoir in water or other liquid.
4. Close supervision is necessary when any appliance is used by or near children.
5. Unplug from outlet when the iced coffee maker is not in use and before cleaning. Allow to cool before putting on or taking off parts and before cleaning the appliance.
6. Iced coffee maker must be operated on a flat surface away from the edge of counter to prevent accidental tipping.
7. Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions or is dropped or damaged in any manner. Call our toll-free customer assistance number for information on examination, repair, or adjustment.

8. The use of accessory attachments not recommended or sold by the appliance manufacturer may cause fire, electric shock, or injury.

9. Do not use outdoors.

10. Do not let cord hang over edge of table or counter or touch hot surfaces, including stove.
11. The pitcher is designed for use with this iced coffee maker. It must never be used on a range top or in a microwave oven.
12. Do not use a cracked pitcher or one with a loose or weakened handle.
13. Do not clean pitcher with cleansers, steel wool pads, or other abrasive cleaners.
14. Be certain pitcher lid is securely in place during brew cycle and when pouring coffee. Do not use force when placing lid on pitcher.
15. Do not place iced coffee maker on or near a hot gas or electric burner or in a heated oven.
16. To disconnect iced coffee maker, turn any control to O (OFF) and then remove plug from wall outlet.
17. WARNING: To reduce the risk of fire or electric shock, do not remove the bottom cover. No user-serviceable parts are inside. Repair should be done by authorized service personnel only.
18. Do not use appliance for other than intended use.

SAVE THESE INSTRUCTIONS!

Other Consumer Safety Information

This appliance is intended for household use only.

WARNING! Shock Hazard: This appliance has a polarized plug (one wide blade) that reduces the risk of electric shock. The plug fits only one way into a polarized outlet. Do not defeat the safety purpose of the plug by modifying the plug in any way or by using an adapter. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, have an electrician replace the outlet.

The length of the cord used on this appliance was selected to reduce the hazards of becoming tangled in or tripping over a longer cord. If a longer cord is necessary, an approved extension cord may be used. The electrical rating of the extension cord must be equal to or greater than the rating of the appliance. Care must be taken to arrange the extension cord so that it will not drape over the countertop or tabletop where it can be pulled on by children or accidentally tripped over.

To avoid an electrical circuit overload, do not use another high-wattage appliance on the same circuit with this appliance.

Parts and Features

How To Use Your Iced Coffee Maker

BEFORE FIRST USE: Wash all parts as instructed in "Cleaning."

Line drawing of a hand pouring granular material into a container (no text or symbols)

Add ice cubes to the fill line in iced coffee pitcher.

For tea basket, adjust strength setting by rotating the dial on the bottom. Be sure to align the hole in the dial with the hole in the basket.

Diagram of a funnel pouring liquid into a container (no text or symbols)

Place coffee or tea basket with paper basket filter in pitcher; add 12 tablespoons (180 ml) of coffee maximum, 10 tea bags maximum, or 1/2 cup (125 ml) loose tea.

Line drawing of a hand pouring liquid into a water-filled kettle (no text or symbols)

Fill water reservoir to max line.

Diagram of a coffee maker with a lid and base, showing internal components (no text or symbols)

Top with lid; place over coffee or tea basket. Plug unit in after placing on pitcher and turn ON (I).

NOTE: Iced coffee maker will not turn on if water reservoir is not placed properly. Make sure handles of water reservoir and pitcher are aligned.

Diagram showing a hand connecting electrical socket to cable, with an arrow indicating power connection (no text or symbols present)

After brewing is complete, turn iced coffee maker OFF (O). Unplug from wall outlet.

WARNING! Burn Hazard: Do not move the iced coffee maker during or immediately after the brew cycle as steam may escape. Wait until the iced coffee maker has cooled before moving.

How To Use Your Iced Coffee Maker (cont.)

Diagram of a kitchen appliance with a kettle, funnel, and base (no text or symbols)

Remove water reservoir and coffee or tea basket. Stir iced coffee.

Line drawing of a kettle with a lid and a downward arrow indicating a drop or compression process (no text or symbols)

Top with lid and serve.
TIP: Add your favorite ground spice to the ground coffee before brewing.

Cleaning

All coffeemakers should be cleaned at least once a month (once a week for areas with hard water). If you make coffee daily, clean with vinegar monthly to prevent hard water mineral deposits.

Parts are also dishwasher-safe.

NOTE: Do not immerse water reservoir in water.

To clean the water reservoir, simply wipe the outside with a damp cloth.

Line drawing of a white wine jug and a steaming kettle (no text or symbols)

Pour 2 cups (500 ml) of white vinegar into the reservoir.

Assemble pitcher with brew basket. Place water reservoir on pitcher. Plug in iced coffee maker and press the ON (I)

button. When the brew cycle is completed, discard the vinegar from the pitcher. Wash pitcher, brew basket, and lid. Repeat process with cold water.

Recipes

Caramel Mocha Iced Coffee

2 cups (500 ml) milk 4 cups (1 L) ice cubes

1/2 cup (125 ml) caramel topping 7 tablespoons (105 ml) ground 1/2 cup (125 ml) chocolate syrup coffee

1. Add milk, caramel topping, and chocolate syrup to iced coffee pitcher; stir until well blended. Add ice.

2. Place coffee basket with paper basket filter in pitcher; add coffee.

3. Fill water reservoir to water line. Top with lid, place over coffee basket, and turn ON (I).

4. After brewing is complete, remove water reservoir and coffee basket.

5. Stir iced coffee mixture. Top with lid and serve.

Servings: 8 (8-ounce [250 ml])

Cinnamon Mocha Iced Coffee

1 cup (250 ml) half-and-half 7 tablespoons (105 ml) ground

1/3 cup (80 ml) chocolate syrup coffee

4 cups (1 L) ice cubes 1/2 teaspoon (2.5 ml) ground

1. Add half-and-half and chocolate syrup to iced coffee pitcher; stir until well blended. Add ice.
2. Place coffee basket with paper basket filter in pitcher; add coffee and cinnamon.
3. Fill water reservoir to water line. Top with lid, place over coffee basket, and turn ON (I).
4. After brewing is complete, remove water reservoir and coffee basket.
5. Stir iced coffee mixture. Top with lid and serve.

Servings: 8 (8-ounce [250 ml])

Orange Caramel Iced Coffee

2 cups (500 ml) half-and-half

1/3 cup (80 ml) sugar-free caramel syrup

4 cups (1 L) ice cubes

7 tablespoons (105 ml) ground coffee

1/4 teaspoon (1.3 ml) ground nutmeg

Zest of 1 orange

1. Add half-and-half and syrup to iced coffee pitcher; stir until well blended. Add ice.

2. Place coffee basket with paper basket filter in pitcher; add coffee, nutmeg, and zest.

3. Fill water reservoir to water line. Top with lid, place over coffee basket, and turn ON (I).

4. After brewing is complete, remove water reservoir and coffee basket.

5. Stir iced coffee mixture. Top with lid and serve.

Servings: 8 (8-ounce [250 ml])

cinnamon

Recipes (cont.)

Toasted Almond Iced Coffee

2 cups (500 ml) half-and-half
1/4 cup (60 ml) sugar
4 cups (1 L) ice cubes
7 tablespoons (105 ml) ground coffee
1 teaspoon (5 ml) almond extract
1. Add half-and-half and sugar to iced coffee pitcher; stir until well blended. Add ice.
2. Place coffee basket with paper basket filter in pitcher; add coffee and almond extract.
3. Fill water reservoir to water line. Top with lid, place over coffee basket, and turn ON (I).
4. After brewing is complete, remove water reservoir and coffee basket.
5. Stir iced coffee mixture. Top with lid and serve.

Servings: 8 (8-ounce [250 ml])

Vanilla Chai Iced Coffee

2 cups (500 ml) milk 1 teaspoon (5 ml) vanilla extract
1/4 cup (60 ml) sugar 1/2 teaspoon (2.5 ml) ground
4 cups (1 L) ice cubes cinnamon
7 tablespoons (105 ml) 1/8 teaspoon (0.6 ml) ground ground coffee allspice
1. Add milk and sugar to iced coffee pitcher; stir until well blended. Add ice.
2. Place coffee basket with paper basket filter in pitcher; add coffee, vanilla, cinnamon, and allspice.
3. Fill water reservoir to water line. Top with lid, place over coffee basket, and turn ON (I).
4. After brewing is complete, remove water reservoir and coffee basket.
5. Stir iced coffee mixture. Top with lid and serve.

Servings: 8 (8-ounce [250 ml])

Limited Warranty

This warranty applies to products purchased and used in the U.S. and Canada. This is the only express warranty for this product and is in lieu of any other warranty or condition.

This product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of original purchase. During this period, your exclusive remedy is repair or replacement of this product or any component found to be defective, at our option; however, you are responsible for all costs associated with returning the product to us and our returning a product or component under this warranty to you. If the product or component is no longer available, we will replace with a similar one of equal or greater value.

This warranty does not cover glass, filters, wear from normal use, use not in conformity with the printed directions, or damage to the product resulting from accident, alteration, abuse, or misuse. This warranty extends only to the original consumer purchaser or gift recipient. Keep the original sales receipt, as proof of purchase is required to make a warranty claim. This warranty is void if the product is used for other than single-family household use or subjected to any voltage and waveform other than as specified on the rating label (e.g., 120V \~ 60 Hz).

We exclude all claims for special, incidental, and consequential damages caused by breach of express or implied warranty. All liability is limited to the amount of the purchase price. Every implied warranty, including any statutory warranty or condition of merchantability or fitness for a particular purpose, is disclaimed except to the extent prohibited by law, in which case such warranty or condition is limited to the duration of this written warranty. This warranty gives you specific legal rights. You may have other legal rights that vary depending on where you live. Some states or provinces do not allow limitations on implied warranties or special, incidental, or consequential damages, so the foregoing limitations may not apply to you.

To make a warranty claim, do not return this appliance to the store. Please call 1.800.851.8900 in the U.S. or 1.800.267.2826 in Canada or visit hamiltonbeach.com in the U.S. or hamiltonbeach.ca in Canada. For faster service, locate the model, type, and series numbers on your appliance.

PRÉCAUTIONS IMPORTANTES

Line drawing of a hand pouring food into a beaker (no text or symbols)

Diagram of a funnel pouring liquid into a container (no text or symbols)

Line drawing of a hand pouring liquid into a water-filled mug (no text or symbols)

Diagram of a coffee maker with a lid and base, showing internal components (no text or symbols)

12

Diagram showing a hand connecting a cable to an electrical outlet with a plug, no text or symbols present

Diagram of a kitchen appliance showing the top-down view of a kettle, middle bowl, and base (no text or symbols)

Line drawing of a kettle with a lid and a downward arrow indicating motion (no text or symbols)

Diagram of a kitchen setup showing a kettle, filter, and dish (no text or symbols)

Line drawing of a mechanical component with a central hub and base (no text or symbols)

Line drawing of a hand pouring food into a container (no text or symbols)

Diagram of a funnel pouring liquid into a container (no text or symbols)

Line drawing of a hand pouring liquid into a mug (no text or symbols)

Diagram of a coffee maker with a lid and base, showing the process (no text or symbols)

Illustration of a hand connecting electrical socket to cable (no text or symbols)

Line drawing of a kettle with a lid and arrow indicating downward motion (no text or symbols)

Line drawing of a white wine jug and its open lid, no text or symbols present

2 tazas (500 ml) de "half-and-half"

Col. Palmitas Polanco

Mixcoac MEXICO 03910 D.F

Tel: [phone] • Fax: [phone]

Nuevo Leon
