26050Y - Waffle Maker PROCTOR SILEX - Free user manual and instructions

Product type	Waffle maker
Brand	Proctor Silex
Model	26050Y
Dimensions (L x W x H)	25 x 20 x 10 cm
Weight	2 kg
Power supply	220-240 V ~ 50 Hz
Power	900 W
Capacity	2 waffles
Coating	Non-stick
Indicator light	Yes, power indicator
Handle	Thermally insulated
Power cord	Detachable, length 0.8 m
Maintenance	Clean the plates with a damp cloth after cooling
Safety	Do not immerse in water, unplug after use
Spare parts	Not provided, appliance not user-serviceable
Warranty	1 year
Use	Household use only

Frequently Asked Questions - 26050Y PROCTOR SILEX

How to use the Proctor Silex 26050Y waffle maker?

Plug in the appliance, wait for the light to turn on, pour the waffle batter, close the lid, and let it cook until the light turns off or according to your preference.

What type of batter to use?

Use classic waffle batter or a ready-made mix. Avoid overly liquid batters to prevent overflow.

How to clean the waffle maker?

Let it cool completely, then wipe the plates with a damp cloth. Do not use abrasive sponges or harsh chemicals.

Are the plates removable?

No, the plates are not removable on this model. Clean them directly on the appliance.

What to do if the waffle maker doesn't heat up?

Check that the appliance is properly plugged in and that the outlet works. If the problem persists, contact customer service.

Can I use non-stick spray?

It is not necessary as the plates are already non-stick. If you wish to use it, spray lightly before each use.

How long does it take to cook a waffle?

About 3 to 5 minutes depending on power and desired texture. The light turns off when the optimal temperature is reached.

Does the waffle maker have an adjustable thermostat?

No, this model does not have temperature adjustment. It heats at a fixed optimal temperature for waffles.

Can I store the cord inside the appliance?

Yes, the cord can be wrapped under the base for compact storage.

Where to find the complete manual?

You can download the free PDF manual from notice-facile.com by searching for model 26050Y.

USER MANUAL 26050Y PROCTOR SILEX

Line drawing of a two-well-woven electric stove with grid panels (no text or symbols)

Waffle Baker

USA:1-800-851-8900

Gaufrier

Canada:1-800-267-2826

9

IMPORTANTSAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed including the following:

1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against risk of electrical sh12 do not immerse cord, plug or cooking unit in water or other liquid. 13.
4. Close supervision is necessary when any appliance is used by or near children. 14.
5. Unplug from outlet when not in use before cleaning. Allow to cool before putting on or taking off parts and before cleaning.
6. Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions or has been dropped or damaged in any manner. Call our toll-free customer service number for information on examination, repair or electrical or mechanical adjustment.
7. The use of accessory attachments not recommended by Hamilton Beach/Proctor-Silex may cause hazards or injuries.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or touch hot surfaces,

including the stove.

1. Do not place on or near a hot gas electric burner, or in a heated oven.
2. Extreme caution must be used when les moving an appliance containing hot oil or other hot liquids.
   12ck To disconnect, remove plug from wall outlet.
3. Do not use appliance for other than any intended use.
4. Do not use appliance unattended.
   45d When using this appliance, provide 4 to 6 inches air space above, behind ore and on both sides for air circulation. not use on surfaces where heat may cause a problem.
5. Make sure that neither the cord nor yourself touch any hot part of the appliance due to danger of burning.
6. Place the appliance only on a dry ar level surface.
7. Never remove the waffle with any kin of cutting device or other metallic kitchen utensil.
8. Always allow the appliance to cool down completely before putting it away and never wind the cord around the appliance while it is still hot.

SAVETHESEINSTRUCTIONS!

Consumer Safety Information

This appliance is intended for househoMour waffle baker will be equipped with use only. one of the following types of plugs:

No user serviceable parts inside. Refer servicing to qualified service personnel.

If the appliance has a grounded-type 3-cord, and an extension cord is used, it also be a grounded-type 3-wire cord.

To avoid an electrical circuit overload, d not operate another high wattage appliar on the same circuit with the waffle bak

Polarized plug:

This type of plug has one blade wider than the other. The plug will fit into an electrical outlet only one way. This is a must safety feature intended to help reduce the risk of electrical shock. If you are unable

Onset the plug into the outlet, try reversing the plug. If the plug should still fail to fix contact a qualified electrician to replace t

obsolete outlet. Do not attempt to defeat the safety purpose of the polarized plug modifying the plug in any way.

Grounded-type 3-wire cord (3-prong plug):

This type of plug will only fit into an electrical outlet made for a 3-prong plug. This is a safety feature intended to help reduce the risk of electrical shock. If the plug should fail to fit contact a qualified electrician to replace the obsolete outlet. Do not attempt to defeat the safety purpose of the grounding pin by modifying the plug in any way.

The length of the cord used on this appliance was selected to reduce the hazards of becoming tangled in, or tripping over a longer cord. If a longer cord is necessary an approved extension cord may be used. The electrical rating of the extension cord must be equal to or greater than the rating of the waffle baker. Care must be taken to arrange the extension cord so that it will not drape over the countertop or tabletop where it can be pulled on by children or accidentally tripped over.

Illustration of a mitten with polka-dot texture and textured band (no text or symbols)

⚠ WARNING Always use a hot mitt to protect hand when opening a hot waffle baker. Escaping steam can burn.

BEFORE FIRST USE: Wipe the bottom and top cooking grids with a soapy damp cloth. Rinse cloth then wipe grids again. Wipe or brush cooking grids with vegetable oil. This is only recommended before first use.

How to Use

1. Plug cord into electrical outlet. The red POWER On light will logbow.
2. Preheat with cover closed until the green PREHEATT light toconesoon.
3. Raise cover and pour about 14 cup batter onto the center of each cooking grid. Lower the cover.

The 2-grid waffle baker will use a total of 12 cup batter.

Line drawing of a hand pouring liquid into a waffle oven (no text or symbols)

total of 12 cup batter.

The 4-grid waffle baker will use a total of 1 cup batter. NOTE: The 4-grid waffle-baker will make more consistent waffles if the batter is

spread out with a plastic spatula.

1. Waffles are done in about 5 minutes, depending on recipe, or when steaming stops. Remove waffle with plastic or wooden utensil. Never use metal. This will damage the nonstick coating.
2. Unplug unit when through cooking. Let cool.

POWER On and PREHEAT Lights

The red POWER On Light comes on when the waffle baker is first plugged in. This light will stay on until the unit is unplugged.

The green PREHEAT Light comes on when the waffle baker has reached the perfect temperature. For best results, wait until the green PREHEAT Light comes on before adding the waffle batter. This light will cycle on and off during baking.

Waffle Baker Tips

• Most waffle recipes can be poured directly onto the nonstick waffle grids. Use a cooking spray for dessert waffles or any recipe with a lot of sugar. If your waffles start to stick, the grids may need to be scrubbed with a nylon brush to remove any cooked-on food particles.
• Waffles can be made ahead of time and kept warm in a 200°F oven. Or let them cool and pack in an airtight

container; store in refrigerator or freezer. They can be reheated in a microwave oven, a toaster oven, or regular oven.

- Most waffles are done in about 5 minutes. Some of the recipes which are made from scratch may take a little longer. Check for doneness at about 5 minutes. If the cover of the waffle baker doesn't lift up easily, then let it cook a minute more before checking again. When the steaming stops is also an indicator that the waffle is done.

How to Clean

1. Unplug from outlet and let cool.
2. Wipe cooking grids and outside of unit with a damp, soapy cloth. Rinse cloth and wipe grids again.

3. Do not use steel wool, scouring pads or abrasive cleansers on any part of the unit. Never use sharp or pointed objects for cleaning purposes.

4. Always allow the appliance to

Line drawing of a cabinet with a hanging bag inside (no text or symbols)

cool down completely before storing. The unit can be stored upright to save space.

DO NOT IMMERSE IN WATER OR OTHER LIQUID.

Basic Waffles

2 cups flour

2 tablespoons sugar

1 tablespoon baking powder

1 teaspoon salt

1^3/4 cups milk

13 cup vegetable oil

2 eggs

Combine flour, sugar, baking powder, and salt. Stir together milk, oil, and eggs. Gradually add milk mixture to the dry ingredients. Stir until just blended. Pour batter onto waffle baker. Makes 4½ cups batter.

Basic Blueberry Waffles: After pouring batter onto waffle grids, sprinkle fresh blueberries over batter then close lid. Do not stir berries into batter unless you want blue-gray waffles.

Best Buttermilk Waffles

2 cups flour

14 cup brown sugar, packed

1 teaspoon baking soda

1½ teaspoons baking powder

12 teaspoon salt

3 eggs, separated

2 cups buttermilk

12 cup butter, melted

1 teaspoon vanilla

In a large bowl, mix together flour, sugar, baking soda, baking powder, and salt. Set aside. In a medium bowl, beat the egg whites until stiff, but not dry. In another bowl, whisk together egg yolks, buttermilk, butter, and vanilla. Pour into dry ingredients and stir briefly until just combined. Fold whites into batter. Pour batter onto waffle baker.

Makes 3½ cups batter.

Cinnamon-Raisin Waffles

1 cup flour

2 tablespoons packed brown sugar

2 teaspoons baking powder

14 teaspoon salt

1½ teaspoons cinnamon

1 egg

1 / 2 cup milk

2 tablespoons oil

1 / 3 cup raisins

In a small bowl, whisk together the flour, sugar, baking powder, salt, and cinnamon. In a large bowl, whisk together the egg, milk, and oil. Add the flour mixture to the milk mixture. Stir until the batter is just combined. Stir in the raisins. Pour batter onto the waffle baker. Makes 2 cups batter.

Crispy Ginger Ale Waffles

2 cups baking mix (for example, Bisquick)

2 tablespoons oil

1¼ cups ginger ale

Whisk together baking mix, oil, and ginger ale. Let sit five minutes. Pour batter onto waffle baker.Makes 3 cups batter.

Weekend Waffles

1 cup flour 2 eggs, separated

3 teaspoons baking powder 1 cup milk

14 teaspoon salt 4 tablespoons oil

1 tablespoon sugar 1 teaspoon vanilla

In a large bowl, whisk together flour, baking powder, salt, and sugar. Set aside. Beat egg whites until stiff. Add milk and egg yolks to flour mixture. Stir until smooth. Add oil and vanilla to batter and mix well. Fold egg whites into the batter. Pour batter onto waffle baker.Makes 3 ^1/2 cups batter.

Whole Grain Waffles

12 cup flour 114 cups milk

½ cup whole wheat flour 1 tablespoon oil

½ cup quick-cooking rolled oats 1 egg

2 teaspoons baking powder

In a large bowl, mix together the flour, whole wheat flour, rolled oats, and baking powder. Set aside. In a small bowl whisk together the milk, oil, and egg. Pour the egg mixture into the dry ingredients and stir until just combined. Pour batter onto waffle baker. Makes 3 cups batter.

Cornbread Waffles

34 cup cornmeal 12 teaspoon salt

12 cup flour 2 eggs, separated

12 cup whole wheat flour 1 14 cups milk

1 teaspoon baking powder 14 cup yogurt
2 tablespoons sugar 2 tablespoons oil

In a large bowl, mix together the cornmeal, flour, whole wheat flour, baking powder, sugar, and salt. Set aside. In a small bowl, beat egg whites until stiff, but not dry. In a medium bowl mix together egg yolks, milk, yogurt, and oil. Pour the yogurt mixture into the dry ingredients and stir until just combined. Fold egg whites into batter. Pour batter onto waffle baker Makes 4 cups batter.

Quick & Easy Chili n' Cornbread

1 pound lean ground beef 16 ounce can kidney beans

1.5 ounce envelope chili seasoning mix 12 cup water
8 ounce can tomato sauce Cornbread Waffles

In a skillet, brown ground beef. Add chili seasoning, tomato sauce, kidney beans, and water. Stir to mix then simmer 15 minutes. Serve over Cornbread Waffles.

Makes 4 servings.

Open-Face Hot Turkey Sandwiches

8 to 12 slices cooked turkey (enough for 4 servings)
3 to 4 cups mashed potatoes, hot (homemade or instant)
15 ounce can turkey gravy, heated Basic Waffles

Place waffles on serving plates. Top with turkey slices, mashed potatoes and gravy. Serve immediately. Makes 4 servings.

Banana Sour Cream Waffles

1 cup flour

12 teaspoon baking powder

14 teaspoon baking soda

14 teaspoon salt

1 egg, separated

1 cup sour cream

14 cup milk

14 cup butter, melted

1 ripe banana, mashed

In a large bowl, whisk together flour, baking powder, baking soda, and salt. Set aside. In a small bowl, beat the egg white with a whisk until light peaks form. Add egg yolk, sour cream, milk, butter, and banana to the flour mixture and mix well. Fold in the whipped egg white. Pour batter onto the waffle baker Makes 3 cups batter.

Chocolate Dessert Waffles

14 cup vegetable shortening

12 cup sugar

1 egg

12 teaspoon vanilla

23 cup flour

3 tablespoons unsweetened baking cocoa

1 teaspoon baking powder Pinch of salt ( 116 teaspoon)

In a small mixing bowl, cream shortening and sugar until well blended. Add egg and vanilla and blend until smooth. Add remaining ingredients and mix until well blended. Spray grids with cooking spray. Pour batter onto waffle baker. Remove and serve topped with vanilla ice cream Makes 2 cups batter.

Easy Cake Waffles

9 oz. box 1-layer yellow cake mix

In a medium bowl, mix cake mix according to package directions. Pour onto waffle baker. Remove and serve topped with ice cream and fudge sauce.

Start with a Mix

Try these waffle variations made easy prepared with a packaged mix.

When using packaged pancake and waffle mix, the package directions for waffles call for 2 cups of the dry packaged mix. Mix according to the package directions then try the following.

Banana-Pecan Waffles

Stir in 1 mashed banana and 13 cup chopped pecans.

Cinnamon-Sugar Waffles

Combine 1 tablespoon sugar and 1 teaspoon cinnamon. Spray grids with cooking spray. Pour batter onto grids. Sprinkle batter with some cinnamon-sugar before closing lid.

Customer Service

If you have a question about your waffle baker, call our toll-free customer service number. Before calling, please note the model, type, and series numbers and fill in that information below. These numbers can be found on the bottom of your waffle baker. This information will help us answer your question much more quickly.

MODEL: ____

TYPE: ____

SERIES: ____

Proctor Silex

LIMITED WARRANTY

This warranty applies to products purchased in the U.S. and Canada. This is the only express warranty for this product and is in lieu of any other warranty or condition.

This product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of original purchase. During this period, your exclusive remedy is repair or replacement of this product or any component found to be defective, at our option; however, you are responsible for all costs associated with returning the product to us and our returning a product or component under this warranty to you. If the product or component is no longer available, we will replace with a similar one of equal or greater value.

This warranty does not cover glass, filters, wear from normal use, use not in conformity with the printed directions, or damage to the product resulting from accident, alteration, abuse, or misuse. This warranty extends only to the original consumer purchaser or gift recipient. Keep the original sales receipt, as proof of purchase is required to make a warranty claim. This warranty is void if the product is used for other than single-family household use.

We exclude all claims for special, incidental, and consequential damages caused by breach of express or implied warranty. All liability is limited to the amount of the purchase price. Every implied warranty, including any statutory warranty or condition of merchantability or fitness for a particular purpose, is disclaimed except to the extent prohibited by law, in which case such warranty or condition is limited to the duration of this written warranty. This warranty gives you specific legal rights. You may have other legal rights that vary depending on where you live. Some states or provinces do not allow limitations on implied warranties or special, incidental, or consequential damages, so the foregoing limitations may not apply to you.

To make a warranty claim, do not return this appliance to the store. Please call 1.800.851.8900 in the U.S. or 1.800.267.2826 in Canada or visit proctorsilex.com in the U.S. or proctorsilex.ca in Canada. For faster service, locate the model, type, and series numbers on your appliance.

INSTRUCTIONSMIMPORTANTES

Illustration of a mitten with polka-dot texture and textured band (no text or symbols)

Illustration of a hand pouring liquid into a griddle oven using a pan (no text or symbols)

Line drawing of a cabinet with a bag hanging from the side shelf (no text or symbols)

1 tasse de crème sure
