Product type	Heat gun
Brand	Ferm
Model	HAM1014
Dimensions (L x W x H)	26 x 8 x 9 cm
Weight	0.75 kg
Power supply	230 V ~ 50 Hz, 2000 W
Adjustable temperature	Yes, two levels: 300 °C and 600 °C
Air flow	2 speeds: 300 and 500 L/min
Main functions	Paint stripping, plastic welding, defrosting
Included accessories	Concentrator nozzle, flat nozzle, reflector nozzle
Thermal protection	Automatic shutdown in case of overheating
Kickstand	Integrated for safe placement
LED light	No
Maintenance and cleaning	Clean the air vents with a soft brush after cooling
Housing material	Impact-resistant plastic
Cable length	1.8 m
Spare parts available	Yes, via Ferm after-sales service (fan, heating element, contactor)
Repairability index	7.5/10 (according to European directive)
Safety standards	CE, VDE

Frequently Asked Questions - HAM1014 Ferm

What temperatures can the Ferm HAM1014 heat gun reach?

The Ferm HAM1014 offers two temperature levels: approximately 300 °C on low setting and 600 °C on high setting.

How to use the heat gun to strip paint?

Set the temperature to high (600 °C), keep the nozzle about 10 cm from the surface and move it regularly. Use a flat nozzle for broad diffusion. Protect yourself with gloves and a mask.

Can I use the Ferm HAM1014 to weld plastic?

Yes, to weld plastic, use the concentrator nozzle and set the temperature to 300 °C. Apply heat to the area to be joined while pressing the parts together.

Does the heat gun automatically shut off in case of overheating?

Yes, the Ferm HAM1014 is equipped with overheat protection: the unit automatically turns off to prevent damage. Let it cool down before reusing it.

How to maintain my Ferm heat gun?

After use, let the device cool completely. Clean the air vents with a soft brush to prevent dust buildup. Store in a dry place.

What accessories are included with the Ferm HAM1014?

The kit includes three nozzles: a concentrator nozzle for precise flow, a flat nozzle for wide diffusion, and a reflector nozzle for welding work.

Can I use this device continuously for a long time?

To avoid overheating, it is recommended not to use the heat gun continuously for more than 15 minutes. Take regular breaks.

What to do if the heat gun no longer heats?

First check the power supply. If the cable is intact, the problem may be with the heating element or the contactor. Contact Ferm after-sales service for spare parts.

Is the Ferm HAM1014 suitable for defrosting a freezer?

Yes, use the low temperature (300 °C) and a flat nozzle. Keep the device at a distance to avoid damaging the freezer walls.

How to change the nozzle of the heat gun?

Make sure the device is cold and unplugged. Screw or clip the desired nozzle onto the front of the gun. Do not use tools to avoid damaging the threading.

USER MANUAL HAM1014 Ferm

Black FERM portable hair dryer with a red button, placed on a textured surface (no visible text or symbols on the device body)

EN Original instructions 03
DE Übersetzung der Originalbetriebsanleitung 06
NL Vertaling van de oorspronkelijke gebruiksaanwijzing 11
FR Traduction de la notice originale 14
ES Traducción del manual original 17
PT Tradução do manual original 20
IT Traduzione delle istruzioni originali 23
SV Översättning av bruksanvisning i original 26
FI Alkuperäisten ohjeiden käännös 29
NO Oversatt fra orginal veiledning 32
DA Oversættelse af den originale brugsanvisning 35
HU Eredeti használati utasítás fordítása 38
CS Překlad původního návodu k používání 41
SL Preklad pôvodného návodu na použitie 44

The numbers in the following text correspond with the pictures at page 2

Always read the instruction for electrical products carefully before use. It will help you understand your product more easily and avoid unnecessary risks. Keep this instruction manual in a safe place for future use.

Contents

1. Machine data
2. Safety instructions
3. Using the appliance
4. Maintenance

1. Machine data

Technical specifications

Voltage 220-240 V~

Frequency 50 Hz

Power input 2000 W

Weight 0.62 kg

IP Class IP 20

Position I

Air flow 300 l/min

Air temperature 450 °C

Position II

Air flow 500 l/min

Air temperature 600 °C

Vibration level

The vibration emission level stated in this instruction manual has been measured in accordance with a standardised test given in EN 60745; it may be used to compare one tool with another and as a preliminary assessment of exposure to vibration when using the tool for the applications mentioned

• using the tool for different applications, or with different or poorly maintained accessories, may significantly increase the exposure level
• the times when the tool is switched off or when it is running but not actually doing the job, may significantly reduce the exposure level

Protect yourself against the effects of vibration by maintaining the tool and its accessories, keeping your hands warm, and organizing your work patterns

Contents of packing

1 Hot air gun
1 Deflector nozzle
1 Fishtail nozzle
1 Instruction manual
1 Safety instructions
1 Warranty card

Product information

Fig. A

1. Switch
2. Ventilation slots
3. Nozzle outlet

2. Safety instructions

Explanation of the symbols

Denotes risk of personal injury, loss of life or damage to the tool in case of non-observance of the instructions in this manual.

Indicates electrical shock hazard.

Additional safety instructions

When using electric tools, basic safety precautions should always be followed to reduce the risk of fire, electric shock and personal injury. Read all these instructions before attempting to operate this product and save these instructions.

Before using the appliance

• Check the following:
  • Make sure the voltage of the hot air gun corresponds with the power voltage;
• Are the mains lead and the mains plug in a good state: strong, without ravels or damages.
• Avoid the use of long extension cables;
• Do not use the appliance under moist circumstances;
• The metal mouthpiece gets hot. Watch out and do not touch the metal mouthpiece;
• Prevent damage of the heating element. Do not lock or block the mouth piece;
• Do not leave the appliance when switched on;
• Do not use the appliance for drying hair or for drying living human beings in general;
• Do not use the appliance in a bath, above water or in spaces where easy inflammable liquids are used.

This appliance operates at a temperature of 600 degrees without visible signs of this temperature (no flames), still there is a chance of fire risk. Watch out for the hot air stream from the mouth piece. This air stream can cause burns.

When operating the appliance

• If you are going to use the hot air gun, vapours and gas can be released during a short time. This can be harmful for your health. Asthmatics can suffer hindrance of it;
• Before connecting the plug to the mains voltage you have to check if the switch is in position "0";
• Keep the mains lead always away from the mouthpiece of the hot air gun;
• Keep children and animals away from the appliance if you are using it.

Immediately switch off the appliance when:

• Plug and/or cable are defective or damaged;
  • The switch is defective;
• You smell or see smoke caused by scorched insulation from the hot air gun.

Electrical safety

When using electric machines always observe the safety regulations applicable in your country to reduce the risk of fire, electric shock and personal injury. Read the following safety instructions and also the enclosed safety instructions.

Always check that the power supply corresponds to the voltage on the rating plate.

Class II machine – Double insulation – You don't need any earthed plug

Replacing cables or plugs

Immediately throw away old cables or plugs when they have been replaced by new ones. It is dangerous to insert the plug of a loose cable in the wall outlet.

Using extension cables

Only use an approved extension cable suitable for the power input of the machine. The minimum conductor size is 1.5 mm^2 . When using a cable reel always unwind the reel completely.

3. Using the appliance

The Hot air gun can be used for:

• Plumbing work like tube connections, solder, bowing tubes;
• Removing paint, varnish and lacquer without firerisk;
• Quickly drying of appliances which have become wet;
  • Drying surfaces for quick repairing;
• Removing self-adhesive labels in a clean way placing PVC labels;
• Blistering after sticking PVC materials can be smoothed after heating;
• Easy removing of vinyl carpeting:
• Forming all synthetics with a low temperature (450 degrees) among which polyethylene and PVC;
• Forming all synthetics with a high temperature (580 degrees) among which acryl and plexiglass;
• Smelting synthetics, among which matters and foils with PVC layer;
• Applying heat shrinking tubes;
• Shrinkwrappers;
  • Thawing tubes and engines;
• Repairing finishing layers: email of bath and household appliances;
• Applying epoxypowder coverlayers;
• Repairing of ski's, surf-boards and other sports goods;
• Unscrewing too fast fixed screws and connections.

Operation

Fig. A

You can work manually with this hot air gun or you can put it in a vertical position.

• Check if the mains switch is on position "0" before you connect the apparatus;
• Keep the main lead always away from the hot air stream and the mouth piece;
• Put the mains switch in position 'I or II' to let your hot air gun operate:

“I” = 450 degrees, air flow 300 l/min.

“0” = Off

“II” = 600 degrees, air flow 500 l/min.

When the temperature is excess 600^ C, the heats switches it off automatically, however, the heater continues to run. When the heater has

cooled to operating temperature, the heater is switched on again.

Switching off:

Slide the switch to 0.

Tip: If you want to get the best result, test all appliances on a little part of the workpiece.

Use of accessoires

Fig. B

Deflector nozzle (4)

Deflects air away from glass for example when stripping paint in window frames or softening putty.

Fishtail nozzle (5)

Distributes air equally over small areas

4. Maintenance

Always disconnect the apparatus before carrying out inspection or cleaning. Never use water or other liquids to clean the electrical parts of the hot air gun.

• Never use easy inflammable liquids for cleaning the hot air gun, especially for the mouthpiece.
• Regular maintenance of your hot air gun prevents unnecessary problems. Keep the ventilation slots of the hot air gun clean to prevent overheating.

Troubleshooting

In case the hot air gun does not work well, we give you subjoined some possible causes and their solutions.

• The engine gets overheated.

- The ventilation slots of the hot air gun are dirty.

• Clean the ventilation slots.

- The hot air gun does not start when it is switched on.

• Interruption in the electrical circuit.
• Check the mains lead and the mains plug.
• The switch is defective.
• Pull the mains lead out of the wall socket, because there is a chance of fire risk! Have the hot air gun repaired at your local

dealer.

• The engine does not work, but it does heat.
  • Interruption in the electrical circuit.

- Pull the mains lead out of the wall socket, because there is a chance of fire risk! Have the hot air gun repaired at your local dealer.

Faults

Should a fault occur, e.g. after wear of a part, please contact the service address on the warranty card. In the back of this manual you find an exploded view showing the parts that can be ordered.

Environment

To prevent damage during transport, the appliance is delivered in a solid packaging which consists largely of reusable material. Therefore please make use of options for recycling the packaging.

Faulty and/or discarded electrical or electronic apparatus have to be collected at the appropriate recycling locations.

Guarantee

The guarantee conditions can be found on the separately enclosed guarantee card.

HEISSLUFTGEBLÄSE

$$ 0 = \text { Aus } $$

$$ \mathrm{II} = 6 0 0 ^ {\circ} \mathrm{C}, \text { Luftdurchsatz } 5 0 0 \mathrm{l/min} $$

- De schakelaar is defect.

Specifications techniques

$$ 0 = \text { Off } $$

$$ \text { II } = 6 0 0 ^ {\circ} \mathrm{C}, \text { ilmanvirtaus } 5 0 0 \mathrm{L/min}. $$

Position Description No.

2 till 7 Motor complete 408800

8 till 10 Heating element complete 408801

11 Switch 408802

CE

DECLARATION OF CONFORMITY FHG-2000KN HOT AIR GUN

(GB) We declare under our sole responsibility that this product is in conformity and accordance with the following standards and regulations:
(DE) Der Hersteller erklärt eigenverantwortlich, dass dieses Produkt den folgenden Standards und Vorschriften entspricht:
(NL) Wij verklaren onder onze volledige verantwoordelijkheid dat dit product voldoet aan, en in overeenstem ming is met, de volgende standaarden en reguleringen:
(FR) Nous déclarons sous notre seule responsabilité que ce produit est conforme aux standards et directives suivants:
(ES) Declaramos bajo nuestra exclusiva responsabilidad que este producto cumple con las siguientes normas y estándares de funcionamiento:
(PT) Declaramos por nossa total responsabilida-de que este produto está em conformidade e cumpre as normas e regulamentações que se seguem:
(IT) Dichiariamo, sotto la nostra responsabilità, che questo prodotto è conforme alle normative e ai regolamenti seguenti:
(SV) Vi garanterar på eget ansvar att denna produkt uppfyller och följer följande standarder och bestämmelser:
(FI) Vakuutamme yksinomaan omalla vastuullamme, että tämä tuote täyttää seuraavat standardit ja säädökset:
(NO) Vi erklærer under vårt eget ansvar at dette produktet er i samsvar med følgende standarder og regler:
(DA) Vi erklærer under eget ansvar, at dette produkt er i overensstemmelse med følgende standarder og bestemmelser:
(HU) Felelősségünk teljes tudatában kijelentjük, hogy ez a termék teljes mértékben megfelel az alábbi szabványoknak és előírásoknak:
(CS) Na naši vlastní zodpovědnost prohlašujeme, že je tento výrobek v souladu s následujícími standardy a normami:

(SK) Vyhlasujeme na našu výhradnú zodpovednosť, že tento výrobok je v zhode a súlade s nasledujúcimi normami a predpismi:
(SL) S polno odgovornostjo izjavljamo, da je ta izdelek v skladu in da odgovarja naslednjim standardom terpredpisom:
(PL) Deklarujemy na własną odpowiedzialność, że ten produkt spełnia wymogi zawarte w następujących normach i przepisach:
(LT) Prisiimdami visą atsakomybę deklaruojame, kad śis gaminys atitinka žemiau paminėtus standartus arba nuostatus:
(LV) Apgalvojam ar visu atbildību, ka šis produkts ir saskaņā un atbilst sekojošiem standartiem un nolikumiem:
(ET) Deklareerime meie ainuvastutusel, et see toode on vastavuses ja kooskõlas järgmiste standardite ja määrustega:
(RO) Declarăm prin aceasta cu răspunderea deplină că produsul acesta este în conformitate cu următoarele standarde sau directive:
(HR) Izjavljujemo pod vlastitom odgovornošu da je strojem ukladan sa slijedešim standardima ili standardiziranim dokumentima i u skladu sa odredbama:
(SR) Pod punom odgovornošću izjavljujemo da je usaglašen sa sledećim standardima ili normama:
(RU) Под свою ответственность заявляем, что данное изделие соответствует следующим стандартам и нормам:
(UK) На свою власну відповідальність заявляємо, що дане обладнання відповідає наступним стандартам і нормативам:
(EL) Δηλώνουμε υπεύθυνα ότι προϊόν αυτό συμφωνεί και τηρεί τους παρακάτω κανονισμο ύς και πρότυπα:
(BG) Ние заявяваме, по своя собствена отговорност, че този продукт отговаря на следните стандарти и директиви

EN60335-1, EN60335-2-45, EN55014-1, EN55014-2, EN61000-3-2, EN61000-3-3, EN62233

2006/42/EC, 2006/95/EC, 2004/108/EC, 2002/95/EC, 2002/96/EC

Zwolle, 01-12-2011

I. Mönnink

CEO Ferm BV

It is our policy to continuously improve our products and we therefore reserve the right to change the product specification without prior notice.

Ferm BV • Lingenstraat 6 • 8028 PM • Zwolle The Netherlands
