Diamond 48235 - Waffle Maker UNOLD - Free user manual and instructions

Product type	Waffle maker
Brand	Unold
Model	Diamond 48235
Dimensions (L x W x H)	approx. 24 x 24 x 10 cm
Weight	approx. 1.5 kg
Power supply	220-240 V ~ 50/60 Hz
Power	900 W
Coating	Non-stick
Number of waffles	2 heart-shaped waffles
Adjustable thermostat	Yes, from 1 to 5
Heating indicator light	Yes, ready when light goes off
Safety handle	Thermally insulated
Safety lock	Yes
Non-slip feet	Yes
Vertical storage	Possible
Care and cleaning	Clean the plates with a damp cloth; do not immerse in water
Included accessories	Recipe book
Repairability	Spare parts available via Unold after-sales service
Warranty	2 years

Frequently Asked Questions - Diamond 48235 UNOLD

How to use the Unold Diamond 48235 waffle maker?

Plug in the appliance, select the desired thermostat level (1-5), wait for the light to go off, then pour the batter. Close and let it cook until the desired color is achieved.

How to clean the waffle maker plates?

Wait for the appliance to cool down, then wipe the plates with a damp cloth. Do not use abrasive sponges or chemicals. Never immerse the appliance in water.

What to do if the waffle maker does not heat?

Check the electrical outlet and power cord. Ensure the thermostat is not set to '0'. If the problem persists, contact Unold customer service.

Can gluten-free waffle batter be used?

Yes, the non-stick coating is suitable for all types of batter, including gluten-free. Be careful not to overfill the plates.

How to store the waffle maker?

The waffle maker can be stored vertically to save space. Wrap the cord around the base and store in a dry place.

What is the power of the Diamond 48235 waffle maker?

The power is 900 W, allowing quick and even cooking of waffles.

Does the waffle maker have a safety lock?

Yes, the lid locks easily to prevent accidental opening during cooking.

How many waffles can be prepared at the same time?

This model allows baking 2 heart-shaped waffles simultaneously.

Where to find spare parts for the Unold waffle maker?

Spare parts are available from Unold after-sales service or their official website. Only use original parts.

Is the temperature adjustable?

Yes, the thermostat has 5 levels to adjust cooking to your preferences (from light to well-browned waffles).

USER MANUAL Diamond 48235 UNOLD

WAFFELAUTOMAT DIAMANT

Bedienungsanleitung

UNOLD®

Care + Style

UNOLD®

Fan + Heat

INHALTSVERZEICHNIS

Instructions for use Model 48235

Technical Specifications.... 19

Explanation of symbols.... 19

Important Safeguards.... 19

First use 21

Preparing waffles....22

Cleaning 23

Recipes 23

Guarantee Conditions 29

Waste Disposal/Environmental Protection .. 29

Service 18

Baking plates: Non-adhesive coating

Handle: Insulated

Dimensions: Approx. 25.6 x 20.3 x 8.1 cm (W/D/H)

Weight: Approx. 1.5 kg

Power cord: Approx. 100 cm

Features: Adjustable temperature control, function control lamp, baking plate diameter 20 cm

Accessories: Instruction manual with recip es

Equipment features, technology, colours and design are subject to change without notice.

EXPLANATION OF SYMBOLS

This symbol denotes a possible hazard which could cause injury or damage to the appliance.

This symbol indicates a potential burning hazard. Please be especially careful at all times here.

IMPORTANT SAFE GUARDS

Please read the following instructions and keep them on hand for later reference.

1. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
2. Children shall not play with the appliance.

3. Cleaning and user maintenance must not be performed by children, unless they are older than 8 years and are supervised.

4. Keep the appliance and the power cord out of the reach of children under 8 years.

5. CAUTION – Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable people are present.
6. Connect the appliance only to an AC power supply with the voltage indicated on the rating plate.
7. Do not operate this appliance with an external timer or remote control system.
8. Never immerse the appliance or the lead cable in water or other liquids.
9. Do not clean the appliance in a dishwasher.
10. Never leave the appliance unattended when it is operating and keep it out of reach of children.
11. Unplug the appliance from the wall socket after use, before cleaning or when problems appear during operation.
12. Place the appliance on an uncluttered and even surface. Never place or use the appliance and the lead cable near hot surfaces.
13. Never touch the appliance or lead cable with wet hands.
14. This appliance is intended for domestic and similar use such as:

■ staff kitchen areas in shops, offices and other working environments;

■ agricultural enterprises;
■ by clients in hotels, motels and other accommodation facilities;
■ bed and breakfast accommodations and holiday homes.

1. Use the appliance only indoors.

2. Unroll the lead cable completely before use. Make sure that the lead cable does not hang over the edge of the worktop, since this can cause accidents, for example if small children pull on the cable.

3. Never wrap the lead cable around the appliance, but around the cable storage on the bottom of the base.
4. Always disconnect the lead cable from the wall socket pulling on the plug, never on the cable.
5. Make sure that the lead cable does not touch the hot appliance.

6. Do not use the appliance near flammable liquids. Fire hazard!

7. The appliance becomes hot during operation. Please use the handles or pot holders when moving the appliance.

8. Do not leave the appliance unattended when it is still hot. Risk of burns!
9. Open the lid completely when placing the dough onto the waffle plates or removing the waffles. Otherwise the lid may fall down. Risk of burns and injury!
10. For safety reasons never cover the appliance or the waffle plates with paper, plastic film or other foreign material. Otherwise the risk of fire hazard exists!
11. Never touch the waffle plates during operation or shortly afterwards with any part of the body or heat sensitive objects.
12. Do not store the appliance when it is still hot.
13. Check the plug and lead cable regularly for wear and damage. In case the lead cable or other parts present damages, please send the appliance to our after-sales service for inspection and repair. Unauthorised repairs can constitute serious risks for the user and void the warranty.
14. If the lead cable is damaged, it must be replaced by the manufacturer or its after-sales service or a similarly qualified person in order to avoid any hazard.

CAUTION:

The appliance becomes very hot during operation!

Never open the housing of the appliance. This can result in electric shock.

The manufacturer will not be liable in the event of incorrect assembly, improper or incorrect use or if repairs are carried out by unauthorized third parties.

FIRST USE

1. Remove all packaging materials and any transport safeguards. Keep packaging materials away from children – danger of suffocation!

2. Before first use, we recommend cleaning the non-stick waffle plates with a damp cloth.

3. Close the appliance and connect the plug to a wall socket (220–240 V\~, 50 Hz). The red control lamp lights up and indicates that the heating is operational.

4. Turn the temperature control to the intermediate position to start to preheat. When the appliance has reached the preset temperature, the green control lamp lights up.
5. Heat the appliance up for a couple of minutes without dough, in order to eliminate possible manufacturing residues. Make sure the room is well ventilated during this process. After the initial heating process the appliance might show signs of wear, which do not affect its features and do not constitute a reason for rejection.
6. Before first use, slightly grease both waffle plates with heat resistant grease like margarine, for example, using a pastry brush (as the waffle plates are non-stick coated, greasing is only necessary before the very first use).
7. The appliance may generate a slight smell when first using it, which is absolutely normal.
8. The first waffle should not be used and should be thrown away.

PREPARING WAFFLES

1. Place the dough in the middle of the lower waffle plate using a ladle. The dough will be spread evenly over the waffle plates by closing the lid of the appliance. Please make sure you use the right quantity of dough. If the quantity of dough is insufficient, the upper part of the appliance does not close properly and the upper side of the waffles will not be as brown as the lower side. If it is too much, the dough will overflow and soil the appliance and the worktop.
2. Close the appliance immediately after placing the dough, so that the waffle will brown evenly on both sides.
3. A few seconds after placing the dough, the green control lamp turns off. The appliance will be heated up again and the baking process starts.
4. The temperature control is adjustable: with a lower level adjustment, the waffles will be light brown and dark brown with a higher level adjustment. Any other browning grade desired is continuously adjustable between highest and lowest adjustment.
5. Note concerning the baking signal lights: When both lights are illuminated, this means that the temperature has again been reached, however it does

not mean that the waffle is done. The bake time of the waffle depends on the dough used and your personal taste. Consequently, before removing the waffle, please check whether it is done the way you want it.

1. When the baking process is finished, the waffels are ready and can be removed.
2. If the waffles are not brown enough, adjust the control to a higher temperature. If the waffles are too brown, adjust the control to a lower temperature.
3. The appliance may be filled with dough immediately after removing the waffles. The green control lamp turns off again.
4. Repeat these steps until all dough has been used.
5. After finishing, disconnect the plug from the wall socket in order to switch the appliance off.

Attention: After disconnecting, the appliance is still very hot for some time!

CLEANING

Before cleaning, always turn off the appliance by switch to the „0“ position, and unplug it from the electrical outlet. Allow the appliance to cool before cleaning it.

1. Never immerse the appliance into water or any other liquid.
2. It is best to clean the baking surface while it is still warm with a soft brush or with a damp cloth.
3. Never use pointed or hard objects. They would scratch the antistick coating.
4. The appliance must be completely dry before using it again.

RECIPES

If you want to reheat cooled waffles, use level 1. Do not place new batter onto the baking surface, because this temperature is not suitable for baking, only for warming up. Waffles taste best when they are still warm and fresh from the maker. If you want them to be crispy then you should not pile them on top of each other, but leave them to cool off a little on a cake grid. But waffles also taste very good when served cold. They remain fresh and crisp for some time when kept in a closed container (e.g. a cookie jar – do not forget to let them cool off first). However, you need to mix more grease into the dough. Another alternative is just to deep freeze the waffles. If the dough contains only small amounts of grease,

it is advisable to grease the anti-adhesive baking surfaces slightly with a greasing brush. The waffles can then be removed more easily from the waffle mould. If you use too much grease it can spill over while making the waffles and make the appliance dirty. Moreover, the waffles then also develop spots.

If the batter leads to undesired results, e. g. it remains clinging to the waffle mould or the waffles are not of an even brown color, you might need to change to a better quality flour. Therefore only use high quality flour. Another reason: old grease, which was not removed completely, might be burnt. In such a case, clean the baking surfaces carefully and then grease them with butter or bacon rind. If you add milk (especially full-cream milk) and sugar to the batter you get darker waffles. On the other hand, if you add coconut grease to the batter the waffles keep a lighter appearance. The batter ingredients such as butter, margarine, eggs, milk, etc. have the same temperature. For this reason, it is advisable to keep the ingredients at room temperature for some time before using them. This will keep the dough from clogging and developing spots during baking.

Here are a few basic recipes which have already been tried out in our laboratory kitchen. You can easily change these recipes to meet individual tastes by varying the different ingredients. If you want to make more or less waffles you can, of course, alter the amounts specified accordingly.

If you want to use stevia instead of sugar, simply replace the specification for sugar with a specification for stevia. (Caution: In this case the dough will be somewhat thinner). Honey or syrup is used like sugar.

In this case the sweetening effect is not as strong, however browning of the waffles is more pronounced.

Sweet waffles

Add 1 pinch of salt, ground cloves, chopped or ground nuts or almonds, sultan-as, chopped apples, cinnamon, cardamom, anise, ginger powder, coriander, grated lemon cests or lemon juice etc. A dash of alcohol (rum, arrak, cherry brandy) refines each recipe. Serve the waffles dusted with icing sugar. Serve them with strawberries and whipped cream, with hot raspberries, with apple purée or ice cream, etc.

Common waffles (crispy, sweet)

Approx. 10 waffles

Ingredients: 125 g butter, 75 g sugar, 1 bag vanilla sugar, 3 eggs, 1 tbsp rum, 125 g flour, 125 g cornflour, 2 tsp baking powder, milk (approx. 1/8 l).

Preparation: Beat grease with sugar and vanilla sugar until frothy, add eggs, rum, flour, cornflour, and baking powder (sieve flour, cornflour and baking powder before). Then add milk.

Apple waffles

Approx. 8 waffles

Ingredients: 250 g butter or margarine, 75 g sugar, grated lemon cests, 4 eggs, 250 g flour, 1 tsp baking powder, approx. 1/8 l lukewarm milk, 300 g peeled and finely cubed apples, 50 g grated almonds or nuts, 1/2 tsp cinnamon, 1 tbsp rum. Preparation: Mix the cubed apples with cinnamon, sugar rum and ground nuts and let this mixture stand for a while. Beat butter until frothy and add the grated lemoncests and the eggs. Mix flour and baking powder and stir it into the eggs, turn by turn with the milk. Finally add the apple-nut-mixture. Dust the baked waffles with sugar and cinnamon and serve them warm.

Fine Swabian waffles

Approx. 8 waffles

Ingredients: 125 g butter or margarine, 30 g sugar, 100 g flour, 4 eggs, 1 bag of vanilla sugar, 5 tbs psweet cream.

Preparation: Beat egg white until stiff (add 1 tbsp of sugar before the egg white becomes stiff). Beat butter until frothy, then add egg yolk, sugar and vanilla sugar. Then add sieved flour and cream. Finally add the stiff egg white.

Almond waffles

Approx. 10 waffles

Ingredients: 200 g butter or margarine, 75 g sugar, 1 bag of vanilla sugar, 4 eggs, 125 g peeled and ground almonds, 350 g flour, 1 tsp baking powder, approx. 1/8 l lukewarm milk, 2 tbsp rum.

Preparation: Beat egg white until stiff (add 1 tbsp of sugar before it becomes stiff). Beat egg yolk with sugar and vanilla sugar until frothy, slowly add the melted butter. Then add the sieved flour and baking powder. Last add the almonds and the stiff egg white. Keep these waffles for one day in a closed tin box to allow the almond taste to develop.

Cream cheese waffles

Approx. 12 waffles

Ingredients: 100 g butter or margarine, 125 g drained curd cheese, 40 g sugar, grated cest of 1/2 lemon, 150 g flour, approx. 1/4 I lukewarm milk, 4 eggs.

Preparation: Beat egg white until stiff (add 1 tbsp sugar before becoming stiff), beat egg yolk with sugar until frothy, add curd cheese, butter and grated lemon peel. Then add the sieved flour and the milk. Last add the stiff egg white.

Cream waffles

Approx. 20 waffles

Ingredients: 1/2 I sweet cream, 8 eggs, 1 pinch of salt, 125 g butter or margarine, 200 g flour, grated peel of 1/2 lemon.

Preparation: see Swabian waffles. Dust the waffles with sugar and cinnamon and serve warm.

Yeast waffles

Approx. 14 waffles

Ingredients: 150 g butter or margarine, 75 g sugar, 4 eggs, 1 pinch of salt, 375 g flour, 25 g fresh yeast, 1/8 l sour cream.

Preparation: Mix yeast with approx. 75 ml warm water, 1 tbsp of flour and some sugar and let it rise. Prepare a yeast dough of all ingredients and let the dough rise again. Then bake the waffles and dust the warm waffles with sugar and cinnamon.

Savoury waffles

Vary these recipes with the following ingredients (all finely chopped): raw or cooked ham, salami, almonds, nuts, apples, onions, gherkins, peppers, anchovies, olives, capers, salmon, mussels, mushrooms, grated cheese, crabs, tomatoes (in thin slices), etc. Season with pepper, salt, paprika, oregano, pizza seasoning, mustard, tomato paste, cayenne pepper, garlic etc. Serve with salad, seasoned cottage cheese.

Bacon-and-onion waffles

Approx. 8-9 waffles

Ingredients: 500 g dark wheat flour, 80 g finely cubed smoked bacon, 1 bunch of finely chopped parsley, 50 g roasted onions, 1½ tsp salt, 1 pinch of sugar, 500 ml warm water, 50 ml oil, 1 bag = 7 g dried yeast, 2 TL dried leaven.

Preparation: Fill all ingredients into a dish and mix them (the dough doesn't need to rise, if you use dried yeast). Preheat the waffle iron in medium position

and bake the waffles for approx. 7-8 minutes. Instead of bacon, herbs, and onions try these waffles with 125 g of oil seeds such as sunflower, pumpkin, sesame or lin seed, or porridge oats. When using porridge oats, increase the water amount by approx. 50 ml .

Bread waffles

Approx. 8 waffles

Ingredients: 500 g bread mixtures (any mixture for mixed wheat bread), 500 ml warm water (in case of wholewheat mixture 570 ml), 1 bag = 7 g dried yeast (if not contained in the mixture), 75 ml oil.

Preparation: Fill all ingredients into a dish and mix them thoroughly. Preheat the waffle iron in medium position and bake the waffles for approx. 7-8 minutes.

Pizza waffles

Approx. 10 waffles

Ingredients: 125 g butter or margarine, 4 eggs, 150 g flour, 1/2 tsp baking powder, approx. 1/8 l warm water, 100 g cooked ham, finely chopped, 2 finely chopped apples, 50 g ground nuts, 1 tbsp tomato paste, pepper, salt, 2 tbsp pizza seasoning.

Preparation: Beat butter or margarine until frothy, then add the eggs. Then add the flour mixed with baking powder and the water. Add ham, apples, nuts, tomato pulp, pepper, salt and seasoning. Bake immediately. Options: mushrooms, cheese, olives, gherkins etc.

Ham waffles

Approx. 8 waffles

Ingredients: 150 g butter or margarine, 4 eggs, 250 g flour, 1 tsp baking powder, approx. 1/8 l warm water, 125 g raw ham, cubed, 1-2 chopped gherkins, 1 chopped onion, 2-3 chopped anchovies, salt, paprika, 1 pinch of sugar, pepper, oregano, 1 tsp of lemon juice. Preparation: see pizza waffles. Options: capers, olives, salami.

Cheese waffles I

Approx. 8 waffles

Ingredients: 200 g butter or margarine, 4 eggs, 1/2 tsp salt, 100 g flour, 100 g cornflour, 1/2 tsp baking powder, 1/8 l warm water, 2 tbsp Parmesan cheese (or more, according to your taste), paprika.

Preparation: see pizza waffles. Options: fresh tomatoes, cut into thin slices, onions, peppers, ham, mushrooms etc.

Cheese waffles II

Approx. 8 waffles

Ingredients: 160 g butter or margarine, 4 eggs, 50 g mild cheese in small cubes, 50 g Parmesan cheese, 100 g flour, 4 tbsp milk, 1 tsp baking powder, some salt. Preparation: Beat egg white until stiff, beat butter and egg yolks until frothy, then add cheese, warm milk and the sieved flour. Add the whipped egg white last.

Salty waffles

Approx. 4-6 waffles

Ingredients: 250 g flour, 3/8 l milk, 2 egg yolks, 1/2 tsp salt, 50 g melted butter, 1/2 bag baking powder, 2 whipped egg whites.

Preparation: Prepare a smooth dough from flour, baking powder, milk, egg yolk and salt, add the melted butter and the whipped egg white last.

The authors have thoroughly considered and tested the recipes included in these operating instructions. Nevertheless, a guarantee cannot be accepted. The authors, respectively UNOLD AG and their assignees shall not be liable for personal injuries, material damages and financial loss.

GUARANTEE CONDITIONS

We grant a 24 months guarantee, and in case of commercial use a 12 months guarantee, starting from the date of purchase for any damage demonstrably due to manufacturing defects and when the appliance has been used according to its intended use. Within the warranty period we will remedy defective materials or workmanship through repair or replacement, at our option. Our warranty terms apply only to appliances sold in Germany and Austria. For other countries, please contact the responsible importer. In the event of a claim for remedy of defects, please send the appliance to our after sales service, properly packaged, together with a copy of the automatically generated sales receipt, which must show the date of purchase, and a description of the defect. You can print out a return receipt on our website www.unold.de/ruecksendung. (only for entries from Germany and Austria). The warranty does not cover damage from normal wear, improper handling and failure to comply with the maintenance and care instructions. The warranty is void if repairs or modifications are made to the appliance by third parties. Any claims of the end consumer vis-à-vis the retailer are not limited by this warranty.

WASTE DISPOSAL / ENVIRONMENTAL PROTECTION

Our appliances are produced on a high quality level for a long lifetime. Regular maintenance and expert repairs by our after-sales service can extend the useful life of the appliance. If an appliance is defective and repair is not possible we ask you to follow the following instructions for disposal. Do not dispose this appliance together with your standard household waste. Please bring this product to an approved collection point for recycling of electric and electronic products. By separate collection and disposal of waste products you help to protect natural resources and ensure, that the product is disposed in an adequate way to protect health and environment.

The instruction booklet is also available for download: www.unold.de

NOTICE D'UTILISATION MODÈLE 48235

SPÉCIFICATION TECHNIQUE

Puissance: 1.200 W, 220–240 V\~, 50 Hz

CONDITIONS DE GARANTIE
