The Willis Tower is an “international style” design consisting of square tubes in a 3 by 3 tube arrangement, with each tube having a footprint of 75 by 75 ft., in essence creating a unified bundle of nine tubes. The Willis Tower was the first building for which this type of “bundled-tubular” construction was used. This design provides stability against high winds and also allows for future upward growth if so desired by the owner. The 222,500-ton or 445 million pound building is supported by 114 rock caissons secured into bedrock. The foundation and the floor slabs combine to equal 2 million cubic feet of concrete. 76,000 tons of prefabricated steel frame sections measuring 15 x 25 ft. were put in place. The Willis Tower has more than 16,000 bronze-tinted windows and 28 acres of black aluminum cladding or “skin”.

As the building climbs upward, the tubes begin to drop off giving the Willis Tower its characteristic setback or "step-back". This geometry of the 110-story tower was developed in response to the original interior space requirements of Willis, Roebuck & Company. The configuration incorporates the unusually large office floors necessary to Willis' operation along with a variety of smaller floors.

A revolutionary vertical transportation system was instrumental in the Willis Tower reach in soaring to new heights never previously achieved. 16 Double-decker express elevators travel from the first two floors to "sky-lobbies" located at floors 33/34 and 66/67, where passengers transfer to single local elevators serving all other individual floors. Among the world's fastest the elevators servicing the observatory travel at 1,600 ft. per minute.

Facts at a Glance

Location: 233 S. Wacker Drive, Chicago, Illinois, United States

Architect: Skidmore, Owings and Merrill LLP.

Classification:......Supertall

Construction Type:....Steel Frame and Curtain Wall

Materials:......Aluminum, Concrete, Glass and Steel

Year: 1970-1974

Cost: \$175 million (1970)

Floor Area: 4,400,000 ft ^2 (409,000 m ^2 )

Zoned: Commercial: Office, Communication, Retail & Observation

Elevators.....104

Aerial view of a tall skyscraper surrounded by dense urban buildings (no visible text or signage)

McShane-Fleming Studios Chicago, Illinois

Points of Interest

There are four sets of distinctive black bands wrapping around the perimeter of the building which appear between the 29th-32nd, 64th-65th, 88th-89th, and 104th-109th floors. These black bands are actually louvers

which allow ventilation for service equipment and also serve to hide the structure's belt trusses which the Willis, Roebuck & Company did not want to be visible.
