Product Type	Electric toothbrush
Model	Philips Sonicare Elite HX3285
Brand	Philips
Power Source	Rechargeable battery (charger included)
Charging Time	Up to 24 hours for full charge
Battery Life	At least 20 brushing sessions (2 minutes each)
Brushing Modes	Single mode with Easy-start ramp-up
Smartimer	Automatically turns off after 2 minutes
Quadpacer	Interval timer with beep every 30 seconds for 4 quadrants
Easy-start Feature	Gradually increases power over first 14 brushings (can be deactivated)
Battery Level Indicator	Green (20-6 sessions), Orange (5-2 sessions), Flashing orange (1 session)
Brush Head Replacement	Every 3 months or sooner if bristles fray
Compatible Brush Heads	Philips Sonicare replacement brush heads only
Handle Dimensions (approx.)	Length: 20 cm, Diameter: 2.5 cm
Weight (approx.)	130 g
Cleaning Instructions	Rinse brush head and metal shaft; wipe handle and charger with damp cloth. Do not dishwasher.
Safety Features	Water-resistant handle; charger not waterproof; automatic shut-off
Warranty	International guarantee (excluding brush heads and damage from misuse)
Included Accessories	1 handle, 1 brush head, 1 charger, 1 travel cap

Frequently Asked Questions - Sonicare Elite HX3285 PHILIPS

How long does it take to fully charge the Philips Sonicare Elite HX3285?

It takes up to 24 hours to fully charge the battery. You can use the toothbrush before it is fully charged.

How do I know when the battery is low?

The battery level indicator shows green for 20-6 sessions, orange for 5-2 sessions, and flashes orange with beeps for 1 session remaining. When the battery is empty, the toothbrush turns off.

What is the Easy-start feature and how do I use it?

Easy-start gently increases power over the first 14 brushings to help you adjust. It is activated by default. To activate or deactivate, place the handle on a plugged-in charger and press and hold the power button for 2 seconds. Two beeps and green light indicate activation; one beep and yellow light indicate deactivation.

How does the Quadpacer work?

The Quadpacer is an interval timer that beeps and pauses every 30 seconds to remind you to brush four sections of your mouth evenly. It is activated by default.

How often should I replace the brush head?

Replace the brush head every 3 months or sooner if the bristles become frayed. Stop using a brush head with crushed or bent bristles. Only use Philips Sonicare replacement brush heads.

Can I clean the toothbrush in the dishwasher?

No, do not clean the brush head, handle, or charger in the dishwasher. Rinse the brush head and metal shaft with warm water after each use, and wipe the handle and charger with a damp cloth.

Is the Philips Sonicare Elite HX3285 safe to use with braces or dental restorations?

Yes, it is safe for braces, fillings, crowns, and veneers. However, ensure that braces or restorations are properly adhered. Brush heads may wear out sooner when used on braces.

What should I do if I experience bleeding gums while using the toothbrush?

If bleeding occurs, consult your dentist if it continues after 1 week of use or if excessive bleeding occurs. Also consult your dentist if you have had oral surgery in the past 2 months.

How do I store the toothbrush when not in use?

Store the toothbrush in a cool, dry place away from direct sunlight. If not using for a long time, unplug the charger, clean the appliance, and store it. The travel cap can be used to protect the brush head.

Can I use other brands of brush heads on this toothbrush?

No, only use Philips Sonicare replacement brush heads recommended by the manufacturer. Using unauthorized brush heads may cause damage and void the warranty.

USER MANUAL Sonicare Elite HX3285 PHILIPS

Elite+ 4235 021 0686 1 BOOKLET A6 bl.pdf 1 07-12-15 11:39

Always here to help you

Register your product and get support at www.philips.com/welcome

Elite+

White Philips sonicare electric toothbrush with toothbrush and power button (no text or symbols on body)

PHILIPS sonicare

Diagram of a folded paper or document with grid patterns and directional arrows indicating orientation (no text or symbols)

Pure geometric lines forming a cross shape (no text or symbols)

Completely blank white image with no visible content, text, or symbols.

Completely blank white image with no visible content, text, or symbols.

English 6

한국의 16

Introduction

Congratulations on your purchase and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome.

Important

Read this user manual carefully before you use the appliance and save it for future reference.

Danger

- Keep the charger away from water. Do not place or store it over or near water contained in a bathtub, washbasin, sink etc. Do not immerse the charger in water or any other liquid. After cleaning, make sure the charger is completely dry before you connect it to the mains.

Warning

- The mains cord cannot be replaced. If the mains cord is damaged, discard the charger.

- Always have the charger replaced with one of the original type in order to avoid a hazard.

- Do not use the charger outdoors or near heated surfaces.

- If the appliance is damaged in any way (brush head, toothbrush handle or charger), stop using it. This appliance contains no serviceable parts. If the appliance is damaged, contact the Consumer Care Centre in your country (see chapter ‘Guarantee and support’).

- This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

- Children should be supervised to ensure that they do not play with the appliance.

Caution

- Do not clean the brush head, the handle or the charger in the dishwasher.

- If you have had oral or gum surgery in the previous 2 months, consult your dentist before you use the toothbrush.

- Consult your dentist if excessive bleeding occurs after using this toothbrush or if bleeding continues to occur after 1 week of use. Also consult your dentist if you experience discomfort or pain when you use the Philips Sonicare.

- The Philips Sonicare toothbrush complies with the safety standards for electromagnetic devices. If you have a pacemaker or other implanted device, contact your physician or the device manufacturer of the implanted device prior to use.

- If you have medical concerns, consult your doctor before you use the Philips Sonicare.

- This appliance has only been designed for cleaning teeth, gums and tongue. Do not use it for any other purpose. Stop using the appliance and contact your doctor if you experience any discomfort or pain.

- The Philips Sonicare toothbrush is a personal care device and is not intended for use on multiple patients in a dental practice or institution.

- Stop using a brush head with crushed or bent bristles. Replace the brush head every 3 months or sooner if signs of wear appear. Do not use other brush heads than the ones recommended by the manufacturer.

- If your toothpaste contains peroxide, baking soda or bicarbonate (common in whitening toothpastes), thoroughly clean the brush head with soap and water after each use. This prevents possible cracking of the plastic.

English

Electromagnetic fields (EMF)

This Philips appliance complies with all applicable standards and regulations regarding exposure to electromagnetic fields.

General description (Fig. 1)

1 Hygienic travel cap
2 Brush head
3 Handle
4 Power on/off button
5 Battery level indicator
6 Charger

Note: The content of the box may vary based on the model purchased.

Preparing for use

Attaching the brush head

1 Align the brush head so the bristles point in the same direction as the front of the handle (Fig. 2).
2 Firmly press the brush head down onto the metal shaft until it stops.

Note: Philips Sonicare brush heads are imprinted with icons to easily identify your brush head (Fig. 3).

Charging your Philips Sonicare

1 Plug the charger into a live electrical outlet.
2 Place the handle on the charger.
- The light of the battery level indicator flashes and the appliance beeps twice. This indicates that the toothbrush is charging.

Note: It can take up to 24 hours to fully charge the battery, but you can use the Philips Sonicare toothbrush before it is fully charged.

Using your Philips Sonicare toothbrush

Brushing instructions

1 Wet the bristles and apply a small amount of toothpaste.
2 Place the toothbrush bristles against the teeth at a slight angle (45 degrees), pressing firmly to make the bristles reach the gumline or slightly beneath the gumline (Fig. 4).

Note: Keep the center of the brush in contact with the teeth at all times.

3 Press the power on/off and mode button to turn on the Philips Sonicare.

4 Gently keep the bristles placed on the teeth and in the gumline. Brush your teeth with small back and forth motion so the bristles reach between the teeth. Continue this motion throughout your brushing cycle.

Note: The bristles should slightly flare. Do not scrub.

5 To clean the inside surfaces of the front teeth, tilt the brush handle semi-upright and make several vertical overlapping brushing strokes on each tooth (Fig. 5).

Note: To make sure you brush evenly throughout the mouth, divide your mouth into 4 sections using the Quadpacer feature (see chapter 'Features').

6 Begin brushing in section 1 (outside upper teeth) and brush for 30 seconds before you move to section 2 (inside upper teeth). Continue brushing in section 3 (outside lower teeth) and brush for 30 seconds before you move to section 4 (inside lower teeth (Fig. 6)).

10 English

7 After you have completed the brushing cycle, you can spend additional time brushing the chewing surfaces of your teeth and areas where staining occurs. You can also brush your tongue, with the toothbrush turned on or off, as you prefer (Fig. 7).

Your Philips Sonicare toothbrush is safe to use on:

• Braces (brush heads wear out sooner when used on braces)
• Dental restorations (fillings, crowns, veneers)

Note: Ensure that braces or dental restorations are properly adhered and not compromised. If not, braces or dental restorations may be damaged when they come into contact with the brush head.

Note: When the Philips Sonicare toothbrush is used in clinical studies, the handle should be fully charged and the Easy-start feature deactivated.

Battery status (when handle is not on charger)

This Philips Sonicare toothbrush is designed to provide at least 20 brushing sessions, each session lasting 2 minutes. The battery level indicator shows the battery status when you complete the 2-minute brushing session, or when you pause the Philips Sonicare toothbrush for 30 seconds while brushing by pressing the power on/off button.

Brushing sessions

Battery status color

Light Beeps

20-6 Green Solid -

5-2 Orange Flashing 3 beeps

1 Orange Flashing 2 sets of 3

beeps

Note: When the battery is completely empty, the Philips Sonicare toothbrush turns off. Place the Philips Sonicare toothbrush on the charger to charge it.

Note: To keep the battery fully charged at all times, you may keep your Philips Sonicare toothbrush on the charger when not in use.

Features

Smartimer

The Smartimer indicates that your brushing cycle is complete by automatically turning off the toothbrush at the end of the brushing cycle.

Dental professionals recommend brushing no less than 2 minutes twice a day.

Note: If you press the power on/off button after you started the brushing cycle, the toothbrush will pause. After a pause of 30 seconds, the Smartimer resets.

Easy-start

The Easy-start feature gently increases power over the first 14 brushings to help you get used to brushing with the Philips Sonicare toothbrush. This Philips Sonicare toothbrush comes with the Easy-start feature activated.

Activating or deactivating the Easy-start feature:

Place the handle in the plugged-in charger.

- To activate Easy-start:

Press and hold the power on/off button for 2 seconds. You hear 2 beeps and the battery level indicator lights up green to indicate that the Easy-start feature has been activated.

12 English

- To deactivate Easy-start:

Press and hold the power on/off button for 2 seconds. You hear 1 beep and the battery level indicator lights up yellow to indicate that the Easy-start feature has been deactivated.

Note: Each of the first 14 brushings must last at least 1 minute to move through the Easy-start ramp-up cycle properly.

Note: Use of the Easy-start feature beyond the initial ramp-up period is not recommended and reduces the effectiveness of the Philips Sonicare toothbrush in removing plaque.

Quadpacer

- The Quadpacer is an interval timer that has a short beep and pause to remind you to brush the 4 sections of your mouth evenly and thoroughly. This Philips Sonicare toothbrush comes with the Quadpacer feature activated (Fig. 8).

Charger confirmation

The handle beeps and vibrates briefly when it is placed on the charger base. This Philips Sonicare toothbrush comes with the charger confirmation feature activated.

Cleaning

You should clean your Philips Sonicare toothbrush regularly to remove toothpaste and other residue. Failure to clean your Philips Sonicare toothbrush may result in an unhygienic product and damage to it may occur.

Warning: Do not clean brush heads, the handle or the charger in the dishwasher.

Toothbrush handle

1 Remove the brush head and rinse the metal shaft area with warm water. Make sure you remove any residual toothpaste (Fig. 9).

Caution: Do not push on the rubber seal on the metal shaft with sharp objects, as this may cause damage.

2 Wipe the entire surface of the handle with a damp cloth.

Brush head

1 Rinse the brush head and bristles after each use (Fig. 10).
2 Remove the brush head from the handle and rinse the brush head connection with warm water at least once a week. Rinse the travel cap as often as needed.

Charger

1 Unplug the charger before you clean it.
2 Wipe the surface of the charger with a damp cloth.

Storage

If you are not going to use the product for a long time, unplug it, clean it (see chapter 'Cleaning') and store it in a cool and dry place away from direct sunlight.

Replacement

Brush head

Replace Philips Sonicare brush heads every 3 months to achieve optimal results. Use only Philips Sonicare replacement brush heads.

Recycling

- Do not throw away the product with the normal household waste at the end of its life, but hand it in at an official collection point for recycling. By doing this, you help to preserve the environment.

Removing the rechargeable battery

Warning: Only remove the rechargeable battery when you discard the appliance. Make sure the battery is completely empty when you remove it.

Warning: Please note that this process is not reversible.

To remove the rechargeable battery, you need a towel or cloth, a hammer and a flat-head (standard) screwdriver. Observe basic safety precautions when you follow the procedure outlined below. Be sure to protect your eyes, hands, fingers, and the surface on which you work.

1 To deplete the rechargeable battery of any charge, remove the handle from the charger, turn on the Philips Sonicare toothbrush and let it run until it stops. Repeat this step until you can no longer turn on the Philips Sonicare toothbrush.

2 Remove and discard the brush head. Cover the entire handle with a towel or cloth (Fig. 11).

3 Hold the top of the handle with one hand and strike the handle housing 0.5 inch above the bottom end. Strike firmly with a hammer on all 4 sides to eject the end cap (Fig. 12).

Note: You may have to hit on the end several times to break the internal snap connections.

4 Remove the end cap from the toothbrush handle. If the end cap does not release easily from the housing, repeat step 3 until the end cap is released (Fig. 13).

5 Holding the handle upside down, press the shaft down on a hard surface. If the internal components do not easily release from the housing, repeat step 3 until the internal components are released (Fig. 14).
6 Remove the inner assembly from the housing by fully inserting a small flat-head screwdriver into the slot opposite the circuit board and pry until it comes apart (Fig. 15).
7 Grab the battery and pull it out of the internal assembly (Fig. 16).

Caution: Be aware of the sharp edges of the battery tabs so as to avoid injury to your fingers.

8 Cut the battery wires from the circuit board close to the battery (Fig. 17).
9 Cover the battery contacts with tape to prevent any electrical short from residual battery charge. The rechargeable battery can now be recycled and the rest of the product discarded appropriately.

Guarantee and support

If you need information or support, please visit

www.philips.com/support or read the separate worldwide guarantee leaflet.

Guarantee restrictions

The terms of the international guarantee do not cover the following:

• Brush heads.
• Damage caused by use of unauthorised replacement parts.
• Damage caused by misuse, abuse, neglect, alterations or unauthorised repair.
• Normal wear and tear, including chips, scratches, abrasions, discolouration or fading.
