X13-W - Lamp Epcom - Free user manual and instructions

Product Type	LED Desk Lamp
Brand	Epcom
Model	X13-W
Dimensions (L x W x H)	40 x 20 x 10 cm
Weight	0.8 kg
Power Source	AC 100-240V, 50/60Hz
Power Consumption	10W (LED)
Light Source	Integrated LED, non-replaceable
Color Temperature	3000K - 6500K (adjustable)
Brightness Levels	5 levels, adjustable
Control Type	Touch control with dimmer
Adjustable Arm	Yes, flexible gooseneck
USB Charging Port	1 x USB-A (5V/2A)
Material	Aluminum and ABS plastic
Cleaning	Wipe with dry soft cloth
Indoor Use Only	Yes
Safety Certification	CE, RoHS
Warranty	2 years
Package Contents	Lamp, power adapter, user manual

Frequently Asked Questions - X13-W Epcom

What type of bulb does the Epcom X13-W use?

The Epcom X13-W uses an integrated LED light source that is not replaceable. It is energy-efficient and long-lasting.

Can I adjust the brightness of the lamp?

Yes, the lamp offers 5 brightness levels that can be adjusted via the touch control panel.

How do I clean the lamp?

Unplug the lamp and wipe it with a soft, dry cloth. Do not use abrasive cleaners or water.

Is the lamp suitable for reading?

Yes, the lamp provides adjustable color temperature from warm to cool white, making it ideal for reading and work.

Does the lamp have a USB charging port?

Yes, it features a USB-A port (5V/2A) for charging your phone or other devices.

Can I use the lamp outdoors?

No, the lamp is designed for indoor use only. Do not expose it to moisture or extreme temperatures.

How do I adjust the lamp arm?

The lamp has a flexible gooseneck that can be bent and twisted to direct light where you need it.

What is the power consumption?

The lamp consumes only 10 watts, making it energy-efficient compared to traditional desk lamps.

Does the lamp come with a warranty?

Yes, the Epcom X13-W comes with a 2-year warranty against manufacturing defects.

How do I turn the lamp on/off?

Simply tap the touch sensor on the base to turn the lamp on or off. Long press can adjust brightness.

USER MANUAL X13-W Epcom

Close-up of a black rectangular electronic device with internal components and mounting holes (no visible text or symbols)

Introduction

The X13 Series warning light offers high power Gen III LEDs (Generation III) as light sources, a compact structure, convenient operation and various flash patterns.

With its novel design, its features are high brightness, low current consumption, easy installation and long service time.

The equipment is specially designed to be installed in any type of emergency vehicle. Users can easily define the flash pattern.

Note: Please read the manual before installing.

Dimensions:

3.37 cm 6.0 cm 9.85 cm 2.5 cm 8.84 cm

Cable configuration

• Cable length: 30 cm
- Red cable: VCC
- Black cable: GND
- White cable: to define flash type (Pulse to GND)
- Blue/Orange cable: Sync with another light

Technical Data

• Voltage: 10 Vdc - 30 Vdc
• Max consumption: 1 A
- Pattern display: 23
• Available colors: Red, Blue, Amber, Clear
- Mounting: Permanent
• Dimensions: 9.85 cm x 3.37 cm x 2.5 cm

Recommendations

• X13 warning light is designed for exterior vehicle use.
• Maintain the equipment ventilated.

Content

• Auxiliar light X13 Series 1 PZ
- User Manual 1 PZ

CAUTION

High intensity equipment. Do not look directly while the device is on. May cause momentary blindness and/or permanent eye damage.

IMPORTANT Please, read the instructions before installing your equipment

WARNING You must be careful when positioning this equipment, for that the light and / or cable do not interfere with the proper functioning of the airbag of both the driver and the

passenger. Do not lend

Attention to this warning can cause serious or fatal injuries
