Product Type	Warning Light for Emergency Vehicles
Brand	Epcom
Model	X13-R
Dimensions	9.85 cm x 3.37 cm x 2.5 cm
Voltage Range	10 Vdc - 30 Vdc
Maximum Current Consumption	1 A
Light Source	High Power Gen III LEDs
Number of Flash Patterns	23
Available Colors	Red, Blue, Amber, Clear
Mounting Type	Permanent
Cable Length	30 cm
Cable Configuration	Red (VCC), Black (GND), White (Pulse to GND for pattern), Blue/Orange (Sync)
Synchronization	Yes, via Blue/Orange cable with another light
Design	Compact, high brightness, low current consumption, easy installation
Intended Use	Exterior vehicle use (emergency vehicles)
Safety Warning	Do not look directly at light; may cause blindness or eye damage
Airbag Safety	Ensure light and cables do not interfere with airbag deployment
Included Accessories	1 x Auxiliary Light X13 Series, 1 x User Manual
Ventilation	Keep equipment ventilated

Frequently Asked Questions - X13-R Epcom

What is the voltage requirement for the Epcom X13-R warning light?

The Epcom X13-R operates on a voltage range of 10 Vdc to 30 Vdc, making it suitable for most vehicle electrical systems.

How many flash patterns does the X13-R support?

The X13-R offers 23 different flash patterns, which can be selected via the white wire by pulsing to ground.

Can I synchronize two X13-R lights together?

Yes, use the blue/orange cable to connect two X13-R lights for synchronized flashing.

What are the available colors for the X13-R?

The X13-R is available in Red, Blue, Amber, and Clear lens options.

Is the X13-R suitable for interior use?

No, the X13-R is designed for exterior vehicle use, typically on emergency vehicles. Ensure proper ventilation.

How do I change the flash pattern?

Briefly connect the white wire to ground (GND) to cycle through the 23 patterns. Each pulse advances to the next pattern.

What is the maximum current draw of the X13-R?

The maximum current consumption is 1 A at full brightness.

Can the X13-R be mounted permanently?

Yes, the X13-R is designed for permanent mounting on vehicles.

What safety precautions should I take when installing?

Ensure the light and cables do not interfere with airbag deployment. Avoid looking directly at the light to prevent eye damage.

What is the cable length and configuration?

The cable is 30 cm long with four wires: Red (VCC), Black (GND), White (pattern select), Blue/Orange (sync).

USER MANUAL X13-R Epcom

Close-up of a black rectangular electronic device with internal components and mounting holes (no visible text or symbols)

Introduction

The X13 Series warning light offers high power Gen III LEDs (Generation III) as light sources, a compact structure, convenient operation and various flash patterns.

With its novel design, its features are high brightness, low current consumption, easy installation and long service time.

The equipment is specially designed to be installed in any type of emergency vehicle. Users can easily define the flash pattern.

Note: Please read the manual before installing.

Dimensions:

Cable configuration

• Cable length: 30 cm
- Red cable: VCC
- Black cable: GND
- White cable: to define flash type (Pulse to GND)
- Blue/Orange cable: Sync with another light

Technical Data

• Voltage: 10 Vdc - 30 Vdc
• Max consumption: 1 A
- Pattern display: 23
• Available colors: Red, Blue, Amber, Clear
- Mounting: Permanent
• Dimensions: 9.85 cm x 3.37 cm x 2.5 cm

Recommendations

• X13 warning light is designed for exterior vehicle use.
• Maintain the equipment ventilated.

Content

• Auxiliar light X13 Series 1 PZ
- User Manual 1 PZ

High intensity equipment. Do not look directly while the device is on. May cause momentary blindness and/or permanent eye damage.

IMPORTANT Please, read the instructions before installing your equipment

WARNING You must be careful when positioning this equipment, for that the light and / or cable do not interfere with the proper functioning of the airbag of both the driver and the

passenger. Do not lend

Attention to this warning can cause serious or fatal injuries
