X126B - Surveillance Camera Epcom - Free user manual and instructions

Product Type	Warning Light (Surveillance Camera)
Brand	Epcom
Model	X126B
Light Source	High Power LEDs Gen III
Number of LEDs	8
Power	4W
Operating Voltage	10 Vdc - 16 Vdc
Current Consumption	500 mA max
Flash Patterns	1 (fixed)
Cable Length	30 cm ± 10 cm
Cable Colors	Red (Vcc), Black (Gnd)
Mounting Type	Permanent mount
Intended Use	Exterior vehicle warning light
Package Contents	1x Bubble X126 Series, 1x User Manual
Safety Warning	Do not look directly at light; may cause eye damage
Installation Note	Ensure light and cable do not interfere with airbag deployment
Ventilation	Keep device ventilated during use
Dimensions (Approx.)	100 x 60 x 30 mm (estimated)
Weight (Approx.)	0.2 kg (estimated)

Frequently Asked Questions - X126B Epcom

What is the Epcom X126B used for?

The Epcom X126B is a compact warning light designed for exterior use on emergency vehicles such as police cars, ambulances, and fire trucks. It provides high-intensity LED illumination with a single flash pattern.

What voltage does the X126B require?

The X126B operates on a 10 Vdc to 16 Vdc power supply, making it compatible with most vehicle electrical systems. It draws a maximum current of 500 mA.

How many LEDs does the X126B have?

The X126B features 8 high-power Gen III LEDs, providing bright and reliable light output with a total power consumption of 4W.

Can I change the flash pattern on the X126B?

The X126B comes with a single fixed flash pattern. It does not support pattern selection, ensuring consistent visibility in emergency situations.

How do I install the X126B warning light?

The X126B is designed for permanent mounting. Connect the red wire to the positive (Vcc) and the black wire to ground (Gnd). Ensure the cable does not interfere with airbag deployment zones. Refer to the user manual for detailed instructions.

Is the X126B waterproof?

The user manual does not specify an IP rating, but the device is designed for exterior vehicle use. It is likely weather-resistant but should not be submerged. Keep the unit ventilated and avoid direct water jets.

Can I use the X126B indoors?

While technically operable indoors, the X126B is intended for exterior vehicle use. Its high intensity may be overwhelming indoors, and it lacks features for indoor surveillance.

What safety precautions should I take?

Never look directly at the light when it is on, as it may cause temporary or permanent eye damage. Ensure the device is installed away from airbag deployment paths to avoid serious injury.

Does the X126B come with a mounting bracket?

The package includes the Bubble X126 Series light unit and a user manual. A separate mounting bracket is not listed; the device likely attaches directly to a surface via screws or adhesive (not included). Consult the manual for specifics.

How long is the warranty for the Epcom X126B?

The warranty period is not specified in the provided manual. Please contact Epcom or your retailer for warranty information. Generally, such products carry a 1-2 year limited warranty.

USER MANUAL X126B Epcom

Orange warning light fixture mounted on a black base (no text or symbols visible)

Introduction

The bright bubble X126 Series offers high power LEDs Gen III as light sources, a compact structure and convenient operation.

With its novel design, its features are high brightness, low current consumption, easy installation and long service time.

The equipment is specially designed to be installed in any type of emergency vehicle.

Note: Please read the manual before installing

Dimensions

Cable Configuration

• Length: 30 cm +/- 10 cm
- Red Cable: Vcc
- Black Cable: Gnd

Technical Data

• Voltage: 10 Vdc - 16 Vdc
• Consumption: 500 mA max
- LED quantity: 8
- Power: 4W
- Mounting permanent
- Flash pattern: 1

Recommendations

• The warning light is designed for exterior vehicle use.
• Keep the device ventilated.

Content

• Bubble X126 Series 1 Pz

- User Manual 1 Pz

High intensity equipment. Do not look directly while the device is on. May cause momentary blindness and/or permanent eye damage.

IMPORTANT Please, read the instructions before installing your equipment

WARNING You must be careful when positioning this equipment, for that the light and / or cable do not interfere with the proper functioning of the airbag of both the driver and the

passenger. Not paying attention to this warning can cause serious or fatal injuries
