USER MANUAL KOM0706 Quer
EN
Instrukcja obsługi
PL
Description
- Previous song
- Charging port
- Multifunction button (MFB)
- Volume -
- Microphone
- Volume +
- Speaker
- LED indicator
- Next song
Switching on/off
To turn on the device, press MFB button for 3 seconds, and release it till the blue LED is on. To turn off the device, press MFB button for 3 seconds, and release it till the red LED is on.
Pairing
- Please keep the headset and mobile phone in the range 1 meter when pairing.
- The device must be turned off.
- Press MFB button for 6 seconds, and release it till the blue/red LED is blinking.
- Start the Bluetooth function of mobile phone and search for new Bluetooth devices.
- After searched, select „BH-2013“ in the Bluetooth device list.
- If necessary, enter the PIN code „0000”. After connect successfully, the blue LED of the headset will keep blinking.
EN
Specification
- Bluetooth: 3.0 + EDR
- Bluetooth profiles: A2DP, AVRCP, Headset, Handfree
• Effective range: do 10 m - Standby time: up to 250 h
• Music time: up to 9 h - Charge time: approx 3 h
- Input power: DC 5 V / 130 mAh
- Built-in battery
Notice: Specifications are subject to change without notice.
The Lechpol company declares that product KOM0706 / KOM0707 is consistent with the essential requirements and other relevant provisions of directive 1999/5/EC. The proper declaration for download from www.lechpol.eu
English
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal
Made in China for LECHPOL Zbigniew Leszek, Miętne, 1 Garwolińska Street 08-400 Garwolin.
