Product Type	Convector Heater
Model	IC-HEAT003
Brand	Techly
Power (Nominal Heat Output)	2000 W (2.0 kW)
Minimum Heat Output	700 W (0.7 kW)
Maximum Continuous Heat Output	1900 W (1.9 kW)
Heat Output Control	Mechanical Thermostat (single stage with thermostat)
Power Control	Mechanical (likely two stages: low/high)
Assembly Required	Yes – attach feet using supplied self-tapping screws
Cleaning Method	Unplug, cool, wipe with damp cloth, dry; no detergents
Storage	Store in clean, dry place when not in use
Safety Warning	Do not cover; keep away from water, flammable materials
Intended Use	Indoor, well-insulated spaces or occasional use; not for outdoor
Certification	CE marked, WEEE compliant
Warranty	Covers material and workmanship defects; requires original purchase receipt
Contact	Techly – Viale Europa 33, 33077 Sacile (PN), Italy – www.techly.com
Included Accessories	Heater body, feet, screws, user manual
Special Feature	First use may emit temporary odor; normal

Frequently Asked Questions - IC-HEAT003 Techly

How do I clean the heater?

Always unplug the heater and let it cool completely. Wipe the exterior with a damp cloth and buff with a dry cloth. Do not use detergents or abrasives, and prevent water from entering the heater.

How do I assemble the feet?

The feet come separately. Attach them to the base of the heater using the two self-tapping screws provided. Ensure they are correctly positioned in the bottom ends of the side mouldings.

Why does the heater smell when first used?

A temporary smell or fumes are normal when the heater is first used or after long storage. This will disappear after a short period of operation.

Can I use an extension cord with this heater?

No, avoid extension cords as they may overheat and cause a fire risk. Plug the heater directly into a suitable earthed wall socket.

Is the heater safe for bathrooms or near water?

No, do not use the heater in the immediate surroundings of a bath, shower, or swimming pool. Never locate it where it could fall into water.

Where should I place the heater?

Place the heater on a stable, level surface away from curtains, furniture, and flammable materials. Do not position it directly below a wall socket and ensure air intake/outlet grilles are not obstructed.

What is the power consumption?

The nominal heat output is 2000 W (2.0 kW). The minimum heat output is 700 W (0.7 kW) and maximum continuous is 1900 W (1.9 kW). Auxiliary electricity consumption at nominal heat output is 0.000 kW.

How should I store the heater when not in use?

Unplug and let it cool. Store in a clean, dry place, protected from dust. If not used for long periods, keep it in its original packaging if possible.

What does the warranty cover?

The warranty covers defects in material and workmanship. Repairs must be carried out by an authorized service centre, and you need to provide the original purchase receipt with date.

Can children use this heater?

Children aged 8 and above can use it under supervision. Children aged 3-8 may only turn it on/off if positioned normally and supervised. Children must not play with or clean the heater unattended. Some parts become very hot – keep children and vulnerable people away.

USER MANUAL IC-HEAT003 Techly

TECHly® The Modern IT brand

2000W

CONVECTOR HEATER

Exterior view of a silver electric heater with black control knobs and ventilation slots (no text or symbols visible)

Technical features

2000 WATT

ADJUSTABLE

HANDLES & FEET

P/N: IC-HEAT003

8059018369960

EN

This product is only suitable for well insulated spaces or occasional use.

IT

Read these instructions fully before using the heater. Retain these instructions for future reference.

NOTE: It is for use within the home or for similar purposes.

It is not for outdoor use!

SAFETY INSTRUCTIONS

(To be read before operating the heater)

1. Check whether or not the local power supply mains matches the appliance electric rating printed on the label before operation.
2. Children should be supervised to ensure that they do not play with the appliance. If the appliance is damaged, do not use it any more.
3. Ensure the power supply to the socket into which the heater is plugged is in accordance with the rating label on the heater and that the socket is earthed.
4. When the appliance is not in operation, please remove plug from supply mains.
5. The plug must be removed from the socket-outlet before cleaning or maintaining the appliance
6. Don't remove the plug by pulling the power cord.
7. Avoid the use of an extension cord as this may overheat and cause a risk of fire.
8. Keep the mains lead away from the hot body of the heater.
9. WARNING: In order to avoid overheating, do not cover heater.
10. Don't use this heater in the immediate surroundings of a bath, a shower or a swimming pool. Never locate the heater where it may fall into bathtub or other water container.
11. The device is intended for household use. Do not use outdoors.
12. Do not cover or obstruct any of the heat outlet grilles or the air intake openings of the heater.
13. Always ensure that the heater is not positioned close to curtains or furniture as this could create a fire hazard.
14. The heater must not be located immediately below an electrical socket-outlet.
15. Do not insert any object through the heat outlet or air intake grilles of the heater.
16. Do not place this heater near flammable materials, surfaces or substances, as there may be a risk of fire.
17. Particular care should be taken when the heater is situated in areas occupied by children or invalids.
18. Always unplug the heater when moving it from one location to another.
19. The room which is to be heated should not contain any easy inflammable materials (e.g., petrol, solvents, spray canisters etc.) or other easy combustible materials (e.g., wood or paper). Keep such materials away form equipment. Risk of fire!!
20. Do not operate the heater with a damaged cord or plug, or after the heater malfunctions, has been dropped, or damaged in any manner.
21. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.
22. CAUTION: Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable people are present.
23. WARNING: This heater is not equipped with a device to control the room temperature. Do not use this heater in small rooms when they are occupied by people not capable of leaving the room on their own, unless constant supervision is provided.
24. The meaning of figure ⚪ in marking is "WARNING: DO NOT COVER".
25. Do not touch the appliance with wet hands.
26. Do not introduce any objects inside the appliance (for example needles).

FOR COUNTRIES SUBJECT TO EUROPEAN REGULATIONS

• Children aged between 3 and 8 years must only activate or deactivate the appliance, provided that it has been positioned or installed in its normal operating position and that they are supervised or have received instructions regarding the safe use of the appliance and are aware of the potential risks. Children aged between 3 and 8 years must not connect, adjust or clean the appliance or carry out maintenance operations.
• WARNING: some parts of the appliance can overheat and cause burns. Pay particular attention in the presence of children or vulnerable people.
• This appliance can be used by children aged 8 or over and by people whose physical, sensory or mental abilities are reduced or who lack the necessary experience and knowledge, provided that these people are properly supervised or have been instructed on the safe use of the appliance and related risks. Children must not play with the appliance. Cleaning and maintenance operations must not be carried out by children left unattended.

ASSEMBLY OF THE HEATER

Before using the heater, the feet (supplied separately in the carton), must be fitted to the unit. These must be fixed to the base of the heater using the 2 self-tapping screws provided, taking care to ensure that they are located correctly in the bottom ends of the heater side mouldings

Technical line drawing of a mechanical device with a tool inserted, showing internal components and a directional arrow (no text or symbols)

NOTE: It is normal when the heaters are turned on for the first time or when they are turned on after having not been used for a long period of time the heaters may emit some smell and fumes. This will disappear when the heater has been on a short while.

OVERVIEW

TEMPERATURE CONTROL

POWER CONTROL

CLEANING THE HEATER

1. Always un-plug the heater from the wall socket and allow it to cool down before cleaning.
2. Clean the outside of the heater by wiping with a damp cloth and buff with a dry cloth.
3. Do not use any detergents or abrasives and do not allow any water to enter the heater.

STORING THE HEATER

When the heater is not used for long periods of time it should be protected from dust and stored in a clean dry place.

WARRANTY INFORMATION

The warranty only covers defects in material or workmanship.

The repairs under warranty may only be carried out by an authorized service centre. When making a claim under the warranty, the original bill of purchase (with purchase date) must be submitted.

The warranty will not apply in cases of:

• Normal wear and tear
- Incorrect use, e.g. overloading of the appliance, use of non-approved accessories
- Use of force, damage caused by external influences
- Damage caused by non-observance of the user manual, e.g. connection to an unsuitable mains supply or non-compliance with the installation instructions
- Partially or completely dismantled appliances

INFORMATION REQUIREMENT FOR THE ELECTRIC LOCAL SPACE HEATERS
Model identifier(s): IC-HEAT003
Item Symbol Value Unit Item Unit
Heat output				Type of heat input, for electric storage local space heaters only (select one)
Nominal heat output Pnom 2,0 kW				manual heat charge control, with integrated thermostat	N/A
Minimum heat output (indicative)	Pmin 0,7 kW			manual heat charge control with room and/or outdoor temperature feedback	N/A
Maximum continuous heat output	Pmax,c 1,9 kW			electronic heat charge control with room and/or outdoor temperature feedback	N/A
Auxiliary electricity consumption				fan assisted heat output N/A
At nominal heat output elmax 0,000 kW				Type of heat output/room temperature control (select one)
At minimum heat output	elmin	0,000 kW		single stage heat output and no room temperature control	No
In standby mode	eISB	N/A	kW	Two or more manual stages, no room temperature control	No
				with mechanic thermostat room temperature control	Yes
				with electronic room temperature control	No
				electronic room temperature control plus day timer	No
				electronic room temperature control plus week timer	No
				Other control options (multiple selections possible)
				room temperature control, with presence detection	No
				room temperature control, with open window detection	No
				with distance control option	No
				with adaptive start control	No
				with working time limitation	No
				with black bulb sensor	No
Contact details	TECHLY® - Viale Europa 33 - 33077 Sacile (PN) - Italy - WWW.TECHLY.COM

In compliance with EU Directive WEEE this product is marked with this symbol. It means that used electrical and electronic products should not be mixed with general household waste. There is a separate collections system for these products in compliance with WEEE directive, otherwise contaminative and hazardous substances can pollute the

environment.

CE

With the CE sign, Techly® ensures that the product is conformed to the basic European standards and directives.

TERMOCONVETTORE DA 2000 W

Technical line drawing of a computer hardware component with a screwdriver inserted, showing internal grid and mounting slots (no text or symbols)

OPERAZIONE DEL TERMOCONVETTORE
