| Product Type | Layer 3 managed network switch |
| Number of ports | 48 ports 10/100/1000BASE-T |
| Uplink ports | 4 SFP+ slots (10 Gigabit) |
| Form factor | 1U rack-mountable |
| Dimensions (W x D x H) | 440 x 270 x 44 mm |
| Weight | 4.5 kg |
| Power supply | 100-240 VAC, 50-60 Hz, 100W max |
| Power consumption | 85W (typical) |
| Cooling | Internal fans, front-to-back airflow |
| Operating temperature | 0 °C to 45 °C |
| Operating humidity | 10 % to 85 % (non-condensing) |
| Key features | VLAN, QoS, link aggregation, spanning tree, ACL, static and dynamic IP routing, SNMP management, Web interface |
| Maintenance and cleaning | Unplug before cleaning; use a dry, lint-free cloth; avoid chemicals |
| Safety | Use a grounded outlet; do not open the case; risk of electric shock |
| Spare parts and repairability | Parts available through Dell; repair by certified technician; replaceable power supply |
| General information | Brand: Dell, model: PowerConnect 7048R, category: network switch, warranty: 3 years |
Frequently Asked Questions - PowerConnect 7048R DELL
How do I reset the switch to factory defaults?
Press and hold the Reset button on the front panel for at least 5 seconds until the LEDs flash. The switch will reboot with factory default settings.
How do I access the web management interface?
Make sure your computer is on the same network as the switch. Open a browser and enter the default IP address of the switch (192.168.0.2). Log in with the username admin and password password.
What should I do if the switch does not start?
Check the power cable and electrical outlet. Make sure the switch is powered on (power LED lit). If the problem persists, contact Dell technical support.
How do I configure a VLAN on the PowerConnect 7048R?
Access the web interface, go to Switching > VLAN > 802.1Q VLAN. Create a new VLAN with an ID and name, then assign the desired ports as tagged or untagged.
What is the difference between SFP+ ports and copper ports?
SFP+ ports accept optical or copper modules for 10 Gigabit connections. Copper ports (RJ45) support up to 1 Gigabit. SFP+ ports are used for long-distance or high-speed links.
How do I update the switch firmware?
Download the latest firmware from Dell's website. In the web interface, go to Maintenance > File Management > Firmware Upgrade. Select the file and click Apply. The switch will reboot.
The switch gets very hot, is this normal?
Some heat is normal, especially in an enclosed rack. Ensure ventilation openings are not blocked and ambient temperature is below 45°C. If the fan is noisy or inactive, contact support.
How do I secure access to the switch?
Change the default password, enable SSH instead of Telnet, and configure ACLs to limit IP addresses allowed to manage the switch.
Can I use non-Dell SFP+ modules?
Dell recommends using certified compatible modules. Third-party modules may work, but this could void the warranty or cause compatibility issues.
How do I diagnose a network link that fails to establish?
Check the cable, port status (LED lit), and VLAN configuration. Use the show interfaces status command via SSH or the web interface to see if the port is up and if errors are counted.
