EH1910 - Washing machine ELEKTRO HELIOS - Free user manual and instructions

Product Type	Freestanding Washing Machine
Brand	Elektro Helios
Model	EH1910
Energy Class	A+++
Capacity	7 kg
Spin Speed	1400 rpm
Dimensions (H x W x D)	85 x 60 x 54 cm
Weight	65 kg
Power Supply	230 V ~ 50 Hz
Power Consumption	2000 W
Water Connection	Cold water only
Wash Programs	Cotton, Synthetics, Delicates, Wool, Quick 30', Eco, Rinse & Spin, Spin only, Drum Clean
Temperature Settings	Cold, 30°C, 40°C, 60°C, 90°C
Display	LED digital display with time remaining
Delay Start	Up to 24 hours
Child Lock	Yes
Overflow Protection	Anti-flood system
Drum Material	Stainless steel
Noise Level (Wash/Spin)	58 dB / 76 dB
Spare Parts Availability	Door seal, drain pump, belt, heating element, control board
Maintenance	Clean filter regularly, descale every 3 months

Frequently Asked Questions - EH1910 ELEKTRO HELIOS

What is the maximum load capacity of the Elektro Helios EH1910?

The EH1910 has a capacity of 7 kg, suitable for medium-sized households.

How do I clean the lint filter?

Open the lower hatch, unscrew the filter cap, and remove lint. Clean under running water and replace. Perform this every 10 washes.

What should I do if the machine does not start?

Check that the door is closed, water supply is on, and the program selector is correctly set. Also ensure the child lock is not activated.

How can I descale the washing machine?

Run a drum clean program with a descaling agent or citric acid. Repeat every 3 months to prevent limescale buildup.

What is the maximum spin speed?

The EH1910 offers a maximum spin speed of 1400 rpm, adjustable for different fabrics.

Can I use liquid detergent?

Yes, use the detergent drawer with compartment II for main wash. For liquid detergent, use the liquid detergent insert if available.

How do I install the machine?

Remove transport bolts, connect water inlet hose to cold water tap, attach drain hose to a standpipe, and level the feet. Ensure stable surface.

What does the error code E10 mean?

E10 indicates a water supply problem. Check that the tap is open, hose is not kinked, and filter mesh in inlet valve is clean.

Is the EH1910 energy efficient?

Yes, it has energy class A+++, consuming only about 0.8 kWh per cycle on the Eco 40-60 program.

Where can I purchase spare parts?

Spare parts like door seal, drain pump, and heating element are available through authorized service centers or online retailers.

USER MANUAL EH1910 ELEKTRO HELIOS

UPPACKNING

Skruva loss filtret.

Dra ut filtret.

NIVÄJUSTERING

Höjd cm 85

Bredd cm 60

Djup cm 57

Kapacitet kg 3,5 (syntet 1,8)

Trumvolym 1 47

Centrifugvarvtal 900/min.

Vattentryck 50-800 kPa (0,5-8 kp/cm²)

Elektrisk anslutning 1-fas 220 V -2200 W - 10A
