F-PBJ30M - Air purifier PANASONIC - Free user manual and instructions

Product Type	Air Purifier
Brand	Panasonic
Model	F-PBJ30M
Coverage Area	Up to 30 m²
CADR (Smoke)	200 m³/h
Filtration System	Pre-filter + HEPA filter + Activated Carbon filter
Ionizer	nanoe™ X technology
Fan Speeds	3 (Low, Medium, High)
Noise Level	22 – 48 dB
Power Consumption	30 W (max)
Power Supply	220-240 V, 50 Hz
Dimensions (W x H x D)	455 x 535 x 205 mm
Weight	8.5 kg
Display Type	LED indicators
Timer	1, 2, 4, 8 hours
Air Quality Sensor	Yes (PM2.5)
Filter Replacement Indicator	Yes
Auto Mode	Yes
Sleep Mode	Yes
Cord Length	1.8 m
Filter Lifespan	HEPA: 2 years, Carbon: 2 years (under normal use)
Maintenance	Clean pre-filter every 2 weeks; replace filters as indicated
Safety Features	Auto shut-off when front panel opened
Warranty	2 years

Frequently Asked Questions - F-PBJ30M PANASONIC

How often should I replace the HEPA filter?

The HEPA filter should be replaced approximately every 2 years under normal usage. The filter replacement indicator will alert you when it's time.

How do I clean the pre-filter?

Remove the pre-filter and vacuum it or wash it with water. Let it dry completely before reinstalling. Clean every 2 weeks for best performance.

What is the coverage area of the F-PBJ30M?

The recommended coverage area is up to 30 square meters (approximately 320 square feet) for efficient purification.

Does it have an ionizer or ozone generation?

It uses Panasonic's nanoe™ X technology, which releases hydroxyl radicals to inhibit pollutants, not ozone.

Can I use the purifier all day?

Yes, it is designed for continuous use. Auto mode adjusts fan speed based on air quality, and sleep mode ensures quiet operation at night.

How do I reset the filter replacement indicator?

After replacing the filters, press and hold the filter reset button for 3 seconds until the indicator turns off.

What should I do if the unit makes unusual noise?

Check if the filters are properly installed and clean. Also ensure the fan is not obstructed. If noise persists, contact Panasonic support.

Is the F-PBJ30M suitable for allergy sufferers?

Yes, the HEPA filter captures 99.97% of airborne particles as small as 0.3 microns, including pollen, dust mites, and pet dander.

Where should I place the air purifier?

Place it on a flat, stable surface with at least 30 cm clearance on all sides. Avoid blocking the air intake and outlet.

What is the power consumption in sleep mode?

In sleep mode, the fan runs at the lowest speed, consuming about 5-10 watts, making it energy efficient.

USER MANUAL F-PBJ30M PANASONIC

(※) It consumes around 0.5W electricity when the operation is set to "OFF". (With the power plug inserted) The filter cannot remove the harmful carbon monoxide generated by cigarette.

ال-educated

F-PBJ30M									رقم الطرار
50~240			60~220			50~220			إSundayedd المطقة
Lo	Med	Hi	Lo	Med	Hi	Lo	Med	Hi	إSundayedd المطقة
15	23	32	11	22	34	13	20	28	(أرباح)
23	38	44	20	35	44	21	35	44	(أرباح)
1.0	1.9	2.8	0.6	1.8	2.8	0.8	1.8	2.8	(أرباح)

Optional accessories

ملحقات اختيارية

Operating Instructions

تعليمات التشفيل

Air Purifier

جهاز تنقية الهواء

F-PBJ30M

Model No.

This product is for indoor use only.

Safety precautions

2-8

Parts identification

10

Preparation

10-11

Operating Methods

12-13

Care and maintenance

14

•Reference Time for Filter Replacement......14

• When ide for a long time

14

FAQs

16

Troubleshooting

16

Further information

18

Specifications/Optional accessories · Back cover

الصفحة

المحتويات

Thank you very much for purchasing this Panasonic product.

● Please read these operating instructions carefully in order to use the product correctly and in a safe manner.
● Also, be sure to read the "Safety precautions" section (P.2 8) before use.
- Keep the operating instructions in a safe place for future reference.

「House Dust Catcher」give you clean and fresh air.

■ The 「House Dust Catcher」 completely cleaning dust from the air near the floor.
■ A handle is equipped to facilitate the carrying of the product.

Always observe these precautions

These safety precautions are provided for your protection. Please read and follow them carefully to avoid unnecessary injury and damage to the product itself or other properties.

The following symbols differentiate the levels of danger and injury that may result if the product is not used specifically as instructed.

WARNING

This symbol indicates that improper handling may cause a risk of death or serious injury

CAUTION

This symbol indicates that improper handling may cause a risk of injury or damage to the product or to your properties.

This manual uses a number of other symbols to indicate additional information for a particular item. (The symbols given below are examples)

This symbol indicates an action that must not be performed.

This symbol indicates an action that must be performed.

احتياطات الأمن

Always observe these precautions

WARNING

To prevent accidents such as fires and electric shocks

Do not pull on the power cord when carrying or storing away the unit. (It may cause a short-circuit or damage the wires inside the cord, and fire or electric shocks may occur.)

■ Do not do anything that may damage the power cord or power plug.
- Power cord must not be damaged, modified, bended excessively or pulled. Also do not place heavy objects on it. (electric shock or fire may occur.)
- Consult with distributors to carry out any repairs to the cord and plug.

Do not use overloaded wall socket or wiring equipment, and do not use a power supply other than specification. If the wall socket is overloaded, fire due to overheating may occur.

■ Do not touch the power plug with wet hands. (Electric shock may occur.)

Do not insert your fingers or metal objects into the air inlet or air outlet. (The contact with the inside of the product may cause an electric shock or injury.)

Do not let the unit get wet. (Otherwise a fire and electric shock may be caused due to short circuit.)

Insert the power plug thoroughly. If the power plug is not inserted security, electric shock or fire due to overheating may occur. • Do not use damaged plugs or loose wall sockets.

In case of any exception or failure, stop using the unit immediately and unplug the power cord. (Otherwise, electric shock, fire or smoke may occur.)

- The unit stops running once the power is turned on.

- An abnormal sound or vibration occurs during operation.

• The main unit becomes hot, and a burning smell occurs.

→Please contact the store from which you purchased the product for repair immediately.

Periodically clean the power plug. If dust builds up on the power plug, humidity may cause damage to insulation and may result in fire.

• Disconnect the power plug and wipe it with a dry cloth.
• If not using the unit for long period, disconnect the power plug.

■ Be sure to disconnect the power plug before cleaning the unit.

(The unit may start operating unexpectedly and electric shock or injury may occur.)

Do not disassemble or modify this unit. (Disassembling or modifying the unit may

result in malfunctions or fire.) - Consult with distributors to carry out any inspection.

If any of the following conditions occur, turn off the unit and contact with the dealer or service center immediately.
- If any of the switches doesn't work.
- If the circuit breaker is tripped or a fuse blows. - If the power cord or plug becomes abnormally hot. - If you notice a burning smell or an abnormal sound or vibration.
- If there is any other abnormality or malfunction.

the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons order to avoid a hazard.

This unit is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experiences and knowledge, unless they have been given supervision or instruction concerning use of the unit by a person responsible for the safety.

Children should be supervised to ensure that they do not play with the unit

Always observe these precautions

CAUTION

Do not put the unit in the following places:

● Where safety is not guaranteed. (Causes of falling over and injury)
- Where the temperature or humidity is too high, or water is present, such as a bathroom. (The unit may leak current and electric shock or fire may occur.)
- Places where oil content is airborne, such as in kitchens. (Otherwise, injury may be caused due to cracks.)
● Where oil or inflammable gas is present and may be leaked. (Otherwise, a fire or smoke may be caused due to ignition in the unit.)
● Where the air outlet faces animals or plants. (Causes of dehydration due to wind)

Do not let volatile substances or burning items such as cigarette or incense get inside the unit. (Fire may occur.)

Do not clean the unit with solvents such as alcohol or thinner, and avoid contact with insect sprays. (The unit may become cracked and injury may occur, or the unit may short-circuit and cause electric shock or fire.)

Do not operate this unit in places where indoor fumigation type insecticides are being used.

(Chemical residue may build up inside the unit and become discharged from the air outlet, resulting in a health hazard.)

• Ventilate the room well after using insecticides before operating the unit.

Do not sit on or lean against this unit (Otherwise, injuries may be caused or the unit may be damaged.)

When unplugging the power plug, grasp the power plug instead of the power cord.

(Otherwise, a fire or electric shock may be caused due to wire breakage or short circuit.)

Ventilate the room if using this unit together with a heater.

(Carbon monoxide poisoning may occur.) • This unit cannot remove carbon monoxide.

Always observe these precautions

Operating requirements

Line drawing of a modern living room with TV, sofa, and wall-mounted devices (no text or symbols)

■ Do not put the unit in the following places:

- Where the unit will be exposed to direct sunlight or direct blowing of air conditioner. (Otherwise, deformation, degeneration, discolor and malfunction may be caused.)

●Near a TV set or radio

(Otherwise, visual disturbances or noises may be caused)

→ Keep it 1 m or above away from such devices

If the power plug is inserted into the same outlet as that of these devices, visual disturbances or noises may be caused. In this case, insert the power plug into another outlet.

■ If the unit is used in the same place for a long period.

Using it continuously at the same location may result in the walls or the floor surrounding the unit to become dirty. We recommend that you move the unit away from where it is placed for maintenance.

It would be effective if placed here!

■ Place it low on the floor as a countermeasure against pollen.

Since pollen or dust is likely to float in the air near the floor, we recommend you put the unit on the flat floor in the room.

■ To circulate the air efficiently around the room.

To prevent the air inlet or the air outlet from being blocked, install the equipment with its left, right and the top about 30 cm or more away from walls or furniture, curtains etc. To ensure efficient use of this unit, keep its back at least 1 cm away from the wall.

Interior layout illustration of a modern living room with TV, sofa, and wall-mounted devices (no text or symbols)

Fill in the label with the first date of use.

■ Composite air filter replacement
● About once per 2 years
Replacement filter
Part No. F-ZXJP30Z
Date installed:

■ Deodorizing filter replacement

- Replace a new one when the

deodorizing function becomes less effective.

less effective

(About once 30-1 years)

Replacement filter

Part No. F-ZXJD30Z

Date installed:

Note

ملاحظة

1 Remove the deodorizing filter from the poly bag.

① Remove the front panel.

② Remove the filter (2 types).

(2)

Composite air filter

③ Remove the deodorizing filter from the poly bag.

قَمْ بِلَزَّة مَرْشَحَ إِلَّة الْرُوَاتِحَ لَكَرِيَهَا مِنْ حَفِيَةِ مِنْتَدٍ.

The Ground Truth image displays a single, solid horizontal line. According to Rule 2 (UNDERSCORE & LINE RULES), this is a stylistic or background line, not a placeholder underscore. Therefore, the OCR result must ignore it. The provided OCR content is "____", which consists of four underscores. This is an incorrect interpretation of the line as a placeholder, violating the rule that stylistic lines must be ignored. The OCR has hallucinated text (underscores) where none should exist, violating the rule to ignore such lines. Hence, the OCR result is inconsistent with the Ground Truth.

Poly bag

لعربية للاست

※ Please don't remove the black net of deodorizing filter.

٢٤٠٥٣١٥١٥١٥١٥١٥١٥١٥١٥١٥١٥١٥١٥١٥١٥١٥١٥١٥١٥

2 Install the filters (two types) and front panel. que mit Erkib Mirshhat (nogan) واللوحة الأمسية.

① Instal the deodorizing filter.

② Install the composite air filter. (The inner and outer sides are

differentiated.)

With the black side (front side) as the front, fit into the dent of the equipment.

it the dutch into the indentation

three locations } of the equipment.

with the indentations of the main unit

of the main unit. Otherwise the front

Otherwise the panel may fall

part of the

ت+kد أن البض khác

Push in the protrusion into the

holes (2 places) of the equipment

and press properly.

※ Be sure to attach the front panel for use.

(Otherwise it may be damaged.)

Operating Methods

طرق التشغيل

1

Start the unit.

قم بتشغيل الوحدة.

Power

Off/On

(Air volume indicator

lights up)

● After the "off" button is pressed, and then if you press the [Power pug] button, the operation will begin with the air volume at which it stopped last time. After the power pug is removed and reinserted, the operation will begin with the air volume at which it stopped last time.

● During operation, if the power plug is removed and reinserted, the operation will begin with the state under which it stopped last time.

(Air volume indicator will

be turns off

- When pressing the buttons, please support the body. Depending on the material of the floor, when pressing the buttons, the body may shake.

(The indicator is on) mode will begin After eight hours, the sleep operation will end (sleep indicator is off)

(العربية)

When you want to deactivate it. Press the button again (The indicator turns off.) العربية في قديم تط poles.

الIncreasing on the rear moment (bytouf le mersher en el)

Turbo Timer

Turbo

Timer

(The indicator is on) (الالموزش يعمل) green. After 10 minutes, the turbo operation ends and will return to the previous operation mode.

When you want to deactivate it. Press the button again (The indicator turns off.) جتمان تر عب في العاء فشطيه.

Care and maintenance

■ Be sure to disconnect the power plug before cleaning the unit.

Composite air filter < Once a fortnight or so >

Suck the black side (front side) with a vacuum cleaner.

Lay with newspapers etc.

● Delicate.Do not apply too much pressure.

● The back (white) side is free of maintenance.

● Never wash the filter with water

Reference Time for Filter Replacement

(Optional accessories: Back cover)
	Replacement period	Conditions
Composite air filter	Once every 2 years or so	The indication for replacement of filter is when six cigarettes have been smoked daily. (Japan Electrical Manufacturer's Association JEM1467)
Decodorizing filter

Filter replacement period may be greatly shortened, depending on the using environment and method. (For example, in household where smoking is frequent.) Please replace it immediately when necessary.

● After replacement, fill in the date installed on the label and stick it on the back of the main unit.

- Please dispose the used filter as in flammable garbage.

Requirements

• Do not operate the unit when the composite air filter is removed. Dust will be inhaled into unit inner parts, and causes the unit breakdown. The composite air filter can not function while it is removed
• Do not operate the unit when the deodorizing filter is removed. The deodorizing filter can not function while it is removed
• When cleaning, do not leave the removed parts unattended.(parts left unattended may be cause of tripping or they may be damaged.)

- Do not use the detergents shown on the right.

- When using chemically treated cloth, be sure to follow the instructions carefully.

Deodorizing filter

Needless of caring

(Installation and dismantling→P. 10 to 11) When there is dust surrounding the deodorizing filter, please remove it with a vacuum cleaner.

Illustration of a washing machine with three different cover materials (no text or symbols visible)

The body, the front panel

Please wipe the machine with a well wringed soft cloth.

(Installation and dismantling→P. 10 to 11) Wiping with a hard cloth or too much force may damage the surface.

● Please use a dry cloth to wipe the power plug

When idle for a long time

① Disconnect the power plug. (The unit still consumes power even at rest.)
② Maintain it as usual.
③ Cover them with a poly bag, and keep them in a place with little moisture.(If you keep them fat and then overturn them, malfunction may be caused.)

Illustration of a microwave oven with a door handle and fan, shown in 3D style (no text or symbols)

Please confirm the following before you put questions forward or send the unit for repair.

Q1

Why does the operation begin with the Turbo mode?

A

Thanks to the memory function, the operation will begin with the air volume at which it stopped last time after /on is pressed. Even when the power plug is removed or the product is not used for a long time, the air volume at which the operation stopped last time will still be memorized. Therefore, if the operation stopped at the Turbo mode, it begins with the Turbo mode after /on is pressed.

Troubleshooting

If a problem is encountered, investigate it by referring first to the table below. Please disconnect power plug and connect to the dealer for repairs.

Symptom

The air volume is small

The odor from the unit is unpleasant

Polluted air is difficult to be removed

Cannot set up Sensor Sensitivity

Check point/Solution

- Is the composite air filter dirty? (P.14) → Clean it. If the symptoms persist, replace the filter with a new one.

- Are the main unit, the front panel or the filter dirty? (P.14) → Clean it. If the symptoms persist, replace the filter with a new one. - Has it ever used in a room with strong smells? If the unit is used in a room where people smoke or barbecue, a shorter replacement cycle of filters may be required (P.14) → When the unit is used in such an environment, we recommend you use the ventilation system of the room simultaneous.

- Is the composite air filter dirty? (P.14) → Clean it. If the symptoms persist, replace the filter with a new one.

● Is the purifier turned on? → Sensor Sensitivity cannot be set up unless the air purifier has stopped.

الأستلة الشائعة

Function of the composite air filter

With the bio-sterilization and super allergy buster functions of the dust collection filter, allergic substances (pollen, annoying dung of dead mites), fungus, mold bacteria can be inhibited.

● Bio-sterilization: Inhibit fungus ^1 , mold bacteria ^2

×1 Testing authority:(Foundation)Japan Food Research Laboratory.

Testing method: Confirmation by using Harrow method.

Inhibiting method: Contact with bio-sterilization

Target: Bacteria trapped in the filter

Testing result: More than 99% inhibition. No 204051292-002

2 Testing authority:(Foundation)Japan Food Research Laboratory.

Testing method: Verify the method to prevent mold bacteria(Ha o method).

Inhibiting method: Contact with bio-sterilization Target: Mold-based stored in the filter

Target: Mold bacteria trapped in the filter. Testing result/only the effectiveness of preventing mold bacteria using the Lile Test

Testing result, verify the effectiveness of preventing mild bacteria using the Halo Test No. 207060074-002

NO.257000014652

● Super Anti bacterial: inhibits the activity of allergens (pollen, house dust mites and their waste products).

Testing authority:Osaka Municipal Technical Research Institute

Testing method: Check the decrease of refined house dust mite allergen, by using enzyme immune

measuring method.

Inhibiting method: Contact with Super allergy buster.

Target : Allergy substances trapped by the filter (mites,pollen)

Testing result: More than 99% inhibition. Daiku research report No.2127

- The composite air filter can give off unique and harmless smell of "Green Tea Catechin", "Anti - bacterial Enzymes" and "Super Alleru buster".

المزيد من المعلومات

2.14 shall be done. 3.15 shall be done, and shall not
