Product Type	Refrigerator with freezer compartment
Model	RSD 083 GW8A
Brand	Goddess
Height	85 cm
Width	50 cm
Depth	55 cm
Weight	30 kg
Power Supply	220-240 V, 50 Hz
Power Consumption	100 W
Energy Class	A+
Annual Energy Consumption	150 kWh
Refrigerant	R600a (isobutane)
Climate Class	N/ST (normal/subtropical)
Freezer Capacity	15 L
Refrigerator Capacity	85 L
Total Net Capacity	100 L
Noise Level	40 dB
Temperature Control	Mechanical thermostat
Interior Light	Yes, LED
Reversible Door	Yes
Defrost Type	Manual (freezer), automatic (fridge)
Shelves	Glass (3)
Warranty	2 years
Included Accessories	Ice cube tray, egg tray

Frequently Asked Questions - RSD 083 GW8A Goddess

What is the ideal temperature setting for the refrigerator?

The recommended temperature for the fridge compartment is between 3°C and 5°C (37°F to 41°F). For the freezer, set it to -18°C (0°F) or lower.

How do I defrost the freezer compartment?

The freezer requires manual defrosting when ice build-up exceeds 5 mm. Unplug the appliance, remove all food, and let the ice melt naturally or use a plastic scraper. Never use sharp objects or heaters.

Why is my refrigerator making unusual noises?

Normal operational noises include humming from the compressor, clicking (thermostat), gurgling (refrigerant flow). If noises are loud or persistent, check leveling, clearance, and ensure no objects vibrate against the appliance.

How often should I clean the condenser coils?

Clean the condenser coils every 6 to 12 months (located at the back of the fridge). Use a vacuum or brush to remove dust and debris to maintain efficiency.

Can I reverse the door opening direction?

Yes, the door is reversible. Follow the instructions in the manual: remove screws, swap hinges, and reattach the door on the opposite side. Tools: screwdriver, possibly wrench.

What should I do if the fridge is not cooling enough?

First, check temperature settings and ensure the door closes properly. Clean the condenser coils, verify there is adequate ventilation (5 cm clearance from walls), and avoid overloading. If problem persists, the thermostat or compressor may need servicing.

How do I change the interior light bulb?

The interior light is an LED type; it is not user-replaceable. Contact service if it fails. If your model uses a bulb, follow manual: unplug, remove cover, replace with same type (e.g., E14 10W).

Is the appliance safe to use with an extension cord?

It is strongly recommended to plug the refrigerator directly into a grounded wall outlet. Do not use extension cords or multi-socket adapters to avoid fire risk.

What does the 'E' symbol on the energy label mean?

The energy class 'A+' indicates high efficiency, meaning low annual energy consumption. This helps reduce electricity bills and environmental impact.

Can I store flammable materials inside the fridge?

No, do not store explosive or flammable substances such as aerosol cans with propellant, gasoline, or alcohol near the appliance. The compressor may ignite fumes.

USER MANUAL RSD 083 GW8A Goddess

Exterior view of a modern stainless steel refrigerator (no visible text or symbols)

NÁVOD K POUŽITÍ / NÁVOD NA POUŽITIE INSTRUKCJA OBSŁUGI / INSTRUCTION MANUAL HASZNÁLATI UTASÍTÁS

Simple line drawing of a mechanical device with a circular component and a handle (no text or symbols)

Simple line drawing of a rectangular frame with a wavy bottom edge and corner dots (no text or symbols)

Simple line drawing of a rectangular container with a side clip and a horizontal bar, no text or symbols present.

Simple line drawing of a rectangular container or enclosure with no text, numbers, or symbols.

Nastavení teploty

Circular dial with numbered positions (0–7) and a central circle, no text or symbols present.

Simple line drawing of a mechanical device with a circular component and base mount (no text or symbols)

Simple line drawing of a rectangular frame with a horizontal base and corner markers (no text or symbols)

Simple line drawing of a mechanical device with a handle and base (no text or symbols)

1. Nasad'te zakrytie otvorov. Hotovo.

Simple line drawing of a rectangular container or enclosure with no text, numbers, or symbols.

Nastavenie teploty

Close-up of a circular mechanical knob with numbered segments (0–7) on a light background, no text or symbols visible.

- Pripojte Váš spotrebič do siete. Vnútorná teplota je riadená termostatom - existuje 8 možností jeho nastavenia:

Simple line drawing of a mechanical component with a circular feature and a base, no text or symbols present.

Simple line drawing of a rectangular frame with a wavy bottom edge and corner dots (no text or symbols)

Simple line drawing of a rectangular container with a side clip and a horizontal bar, no text or symbols present.

Simple line drawing of a rectangular container or enclosure with no text, numbers, or symbols.

Close-up of a circular mechanical knob with numbered segments (0–7) pointing outward from the center, no text or symbols present.

Structure illustration 41

Correct transportation and placement 41

Correct operate and maintenance 41

Door reverse 42

Troubleshooting 45

Information letter 45

SAFETY INFORMATION

• In the interest of your safety and to ensure the correct use, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to ensure that all people using the appliance are thoroughly familiar with its operation and safety features. Save these instructions and make sure that they remain with the appliance if it is moved or sold, so that everyone using it through its life will be properly informed on appliance use and safety.
• For the safety of life and property keep the precautions of these user's instructions as the manufacturer is not responsible for damages caused by omission.

Children and vulnerable people safety

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given super vision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
• Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances.
  • Children should be supervised to ensure that they do not play with the appliance.
• Cleaning and user maintenance shall not be made by children unless they are aged from 8 years and above and supervised.
• Keep all packaging well away from children. There is risk of suffocation.
• If you are discarding the appliance pull the plug out of the socket, cut the connection cable (as close to the appliance as you can) and remove the door to prevent playing children to suffer electric shock or to close themselves into it.
• If this appliance featuring magnetic door seals is to replace an older appliance having a spring lock (latch) on the door or lid, be sure to make that spring lack unusable before you discard the old appliance. This will prevent it from becoming a death trap for a child.

General safety

WARNING! Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

WARNING! Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.

WARNING! Do not damage the refrigerant circuit.

WARNING! Do not use other electrical appliances (such as ice cream makers) inside of refrigerating appliances, unless they are approved for this purpose by the manufacture.

WARNING! Do not touch the light bulb if it has been on for a long period of time because it could be very hot. ^1)

WARNING! When positioning the appliance, ensure the supply cord is not trapped or damaged.

WARNING! Do not locate multiple portable socket-outlets or portable power suppliers at the rear of the appliance.

• Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
• The refrigerant isobutane (R600a) is contained within the refrigerant circuit of the appliance, a natural gas with a high level of environmental compatibility, which is nevertheless flammable.

• During transportation and installation of the appliance, be certain that none of the components of the refrigerant circuit become damaged.

• avoid open flames and sources of ignition

• thoroughly ventilate the room in which the appliance is situated

- It is dangerous to alter the specifications or modify this product in any way. Any damage to the cord may cause a short circuit, fire and/or electric shock.

- This appliance is intended to be used in household and similar applications such as:

• staff kitchen areas in shops, offices and other working environments;
• farm houses and by clients in hotels, motels and other residential type environments;
• bed and breakfast type environments;
• catering and similar non-retail applications.

WARNING! Any electrical components(plug, power cord, compressor and etc.) must be replaced by a certified service agent or qualified service personnel.

WARNING! The light bulb supplied with this appliance is a “special use lamp bulb” usable only with the appliance supplied. This “special use lamp” is not usable for domestic lighting. ^1)

• Power cord must not be lengthened.
- Make sure that the power plug is not squashed or damaged by the back of the appliance. A squashed or damaged power plug may overheat and cause a fire.
- Make sure that you can come to the mains plug of the appliance.

- Do not pull the mains cable.

- If the power plug socket is loose, do not insert the power plug. There is a risk of electric shock or fire.

- You must not operate the appliance without the lamp. ^1)

- This appliance is heavy. Care should be taken when moving it.

- Do not remove nor touch items from the freezer compartment if you hands are damp/wet, as this could cause skin abrasions or frost/freezer burns.

- Avoid prolonged exposure of the appliance to direct sunlight.

Daily use

• Do not put hot on the plastic parts in the appliance.
• Do not place food products directly against the rear wall.
• Frozen food must not be re-frozen once it has been thawed out. ^2)
• Store pre-packed frozen food in accordance with the frozen food, manufacture s instructions. ^2)
• Appliance's manufactures storage recommendations should be strictly adhered to. Refer to relevant instructions.
• Do not place carbonated of fizzy drinks in the freezer compartment as it creates pressure on the container, which may cause it to explode, resulting in damage to the appliance. ^2)
• Ice lollies can cause frost burns if consumed straight from the appliance. ^2)

1) If there is a light in the compartment.
2) If there is a freezer compartment.
^3) If there is a fresh-food storage compartment.

To avoid contamination of food, please respect following instructions:

• Opening the door for long periods can cause a significant increase of the temperature in the compartments of the appliance.
• Clean regularly surfaces, that can come into contact with food and accessible drainage systems.
• Clean water tanks, if they have not been used for 48 h, flush the water system connected to a water supply, if water has not been drawn for 5 days (if they are presented in the appliance).
• Store raw meat and fish in suitable containers in the refrigerator, so that it is not in contact with or drip onto other food.
• Two-star frozen-food compartments (if they are presented in the appliance) are suitable for storing pre-frozen food, storing or making ice cream and making ice cubes.
• One-, two- and three-star compartments (if they are presented in the
• Appliance) are not suitable for freezing of fresh food.
• If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the door open to prevent mould developing within the appliance.

Care and cleaning

• Before maintenance, switch off the appliance and disconnect the mains plug from the mains socket.
• Do not clean the appliance with metal objects.
• Do not use sharp objects to remove frost from the appliance. Use a plastic scraper. ^2)
• Regularly examine the drain in the refrigerator for defrosted water. If necessary, clean the drain. If the drain is blocked, water will collect in te bottom of the appliance. ^3)

Installation

Important! For electrical connection carefully follow the instructions given in specific paragraphs.

• Unpack the appliance and check if there are damages on it. Do not connect the appliance if it is damaged. Report possible damages immediately to the place you bought it. In that case retain packing.
• It is advisable to wait at least four hours before connecting the appliance to allow the oil to flow back in the compressor.
• Adequate air circulation should be around the appliance, lacking this leads to overheating. To achieve sufficient ventilation follow the instructions relevant to installation.
• Wherever possible the spacers of the product should be against a wall to avoid touching or catching warm parts (compressor, con-denser) to prevent possible burn.
• The appliance must not be located close to radiators or cookers.
• Make sure that the mains plug is accessible after the installation of the appliance.

Service

• Any electrical work required to do the servicing of the appliance should be carried out by a qualified electrician or competent person.
• This product must be serviced by an authorized Service Center, and only genuine spare parts must be used.

1) If there is a light in the compartment.
2) If there is a freezer compartment.
^3) If there is a fresh-food storage compartment.

Energysaving

• Don't put hot food in the appliance;
• Don't pack food close together as this prevents air circulating;
• Make sure food don't touch the back of the compartment(s);
• If electricity goes off, don't open the door(s);
• Don't open the door(s) frequently;
• Don't keep the door(s) open for too long time;
• Don't set the thermostat on exceeding cold temperatures;
• Some accessories, such as drawers, can be removed to get larger storage volume and lower energy consumption.

EnvironmentProtection

This appliance does not contain gasses which could damage the ozone layer, in either its refrigerant circuit or insulation materials. The appliance shall not be discarded together with the urban refuse and rubbish. The insulation foam contains flammable gases: the appliance shall be disposed according to the appliance regulations to obtain from your local authorities. Avoid damaging the cooling unit, especially the heat exchanger. The materials used on this appliance marked by the symbol are recyclable.

The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local council, your household waste disposal service or the shop where you purchased the product.

Packaging materials

- The materials with the symbol are recyclable. Dispose the packaging in a suitable collection containers to recycle it.

Disposal of the appliance

1. Disconnect the mains plug from the mains socket.
2. Cut off the mains cable and discard it.

WARNING! During using, service and disposal the appliance, please pay attention to symbol similar as left side, which is located on rear of appliance (rear panel or compressor) and with yellow or orange color. It's risk of fire warning symbol. There are flammable materials in refrigerant pipes and compressor. Please be far away fire source during using, service and disposal.

STRUCTURE ILLUSTRATION

1. Body
2. Crisper
3. Freezer Compartment 6. Adjustable foot
4. Drip Tray 7. Shelf bar
5. Glass shelf 8. Thermostat Knob

CORRECT TRANSPORTATION AND PLACEMENT

1. Lift at the bottom when transportation, don't move it by slide the door.
2. Keep upright and 'keep flat' stow level. Inclination between the body and ground should be no more than 90^ but no less than 45^ .
3. Avoid crashing and violent vibrations during transportation.
4. Place the appliance in a dry and regularly ventilate room. Keep away from heat emitting and oil or coal fired stoves. Behind the appliance there should be a distance no less than 100mm, also the two sides and above, in order to assure adequate ventilation.
5. The appliance should be placed stationary, not on foam or plastic, etc. soft physic.
6. Don't place the appliance near substances which are inflammable or easily eroded.

CORRECT OPERATE AND MAINTENANCE

1. A 10A safety fuse should be installed on the power supply code, and use a single grounded socket.
2. Don't extent the power code or add other electrical load.
3. Operate the appliance emptily at the first time, turn the temperature knob to "1-4", then the compressor start operating. Keep operating 30 minutes, put hands both onto the outside and inside. If hot outside and cool inside, that means the appliance work normally.

4. During operation, turn the temperature to mid position. Turn it to the highest position while need freeze.

5. Clean the frost when it reach 3-4mm on the evaporator. This series refrigerators are semi-automatic defrost; need manually press the thermostat knob (In the middle of the thermostat control). Renewed automatically when finished. The defrost water will drip into the Drip Tray, so pour it after defrost and dry the tray and the inside body.

6. Try not to open the door too often.
7. Don't cool bottle bear or drink in the freezer room, to avoid frost cracking or blasting.
8. Do not store flammable, highly volatile and eroded goods.
9. Do not scratch the evaporator by any sharp substance, for that will broke the evaporator.
10. Disconnect the power bar before cleaning the appliance. Use soft cloth to wipe with warm water or neuter cleaning agent, and then clean it with water.
11. Keep the door gasket clean, on order to maintain well seal.
12. Use soft cloth or soft brush to clean the dust on the compressor and suction tube. Don't wash it by water.
13. Do not use flammable or strong corrosive cleaning agent to clean the appliance.

DOOR REVERSE

Users can change the direction of opening according to one's own needs. The concrete operating sequence is as follows:

1. Remove the hole cover.

Simple line drawing of a mechanical device with a circular component and a handle (no text or symbols)

1. Remove hinge cover and top hinge with a “+” screwdriver, then remove the door.

Simple line drawing of a rectangular frame with a horizontal bar and small circular holes at the top (no text or symbols)

1. Remove the foot and bottom hinge, fix them to oppostie side.

1. Put on the door to bottom hinge, then fix top hinge and cover.

Simple line drawing of a container with a handle and side supports (no text or symbols)

1. Fix the hole cover, completed.

Simple line drawing of a rectangular container or enclosure with no text, numbers, or symbols.

Temperature Setting

Circular dial indicator with numbered positions (0–7) and a central circle, no text or symbols beyond numbers

- Plug on your appliance. The internal temperature is controlled by a thermostat. There are 8 settings:

*1 is warmest setting;

*7 is coldest setting;

*0 is off.

- The appliance may not operate at the correct temperature if it is in a particularly hot or if you open the door often.

Hints for fresh food refrigeration

To obtain the best performance:

• Do not store warm food or evaporating liquids in the refrigerator
• Do cover or wrap the food, particularly if it has a strong flavour
• Make (all types): wrap in polythene bags and place on the glass shelves above the vegetable drawer.
• For safety, store in this way only one or two days at the most.
• Cooked foods, cold dishes, etc...: these should be covered and may be placed on any shelf.
• Fruit and vegetables: these should be thoroughly cleaned and placed in the special drawer(s) provided.

Position different food in different compartments according to below table

Refrigerator compartments Type of food
Door or balconies of fridge compartment	* Food with natural preservatives, such as jams, juices, drinks, condiments* Do not store perishable foods
Crisper drawer (salad drawer)	* Fruit, herbs and vegetables should be placed separately in the crisper bin* Do not store bananas, onions, potatoes, garlic in the refrigerator
Fridge shelf - bottom Chiller (box/drawer)	* Raw meat, poultry, fish (for short-term storage)
Fridge shelf - middle * Dairy products, eggs
Fridge shelf - top	* Foods tha do not need cooking, such as ready-to-eat foods, deli meats, leftovers

NOTICE:

• The freezer compartment (evaporator) in this appliance is not an actual ice-making or freezing area - it is also not intended for storing frozen food.
• The temperature in this area is not low enough to freeze the food safely. A colder setting on the thermostat can be used to partially reduce the temperature in the freezer compartment, but this may also affect the temperature in the appliance's refrigeration compartment.

TROUBLESHOOTING

Problem Possible cause Solution
No frozen	No power supply Check the power	supply
	Socket does not connect well	connect it well
	Thermostat knob on the “Off” position	Turn it on
Frozen does not effect well	Thermostat knob does not on the suitable position	Turn the knob
	Appliance was shine by the sunlight or heat emitting	Keep away from the Heat emitting
Need too long time to start	Open the door too much Reduce	open times
	Doesn’t have enough space between the appliance and anything in the surrounding	Keeping reasonable Distance
Too much noise	Does not place stably Place stably
	Inner accessories loosened Fix them
	Happened crash between the appliance and things surrounding	Keep away from these things
Compressor does not stop	Door does not closed well Close	the door well
	Food loaded too much Store them	timely

Important! There are some sounds during normal use (compressor, refrigerant circulation).

These sounds are not a reason for complaint!

INFORMATION LETTER

Brand	GODDESS
Model	RSD 083 GW8A
Type of appliance3)	3
Energy class(A - low consumption,G - high consumption)	A+
Consumption for 365 days1)	111
Net capacity total(I) 91
thereof : fridge compartment (I) 81
thereof : freezer compartment(I) 10
Designation of freezer compartment (-)
Time of storage in case of the power interruption (hrs)	(-)
Freezing capacity (kg/24 hrs)	(-)
Climatic class2)	N/ST
Noise level (dB(A))	42

1)

Consumption of energy in kWh/year, based on the results of the 24hrs-standard test. Real consumption depends on the way of use and on the allocation of the appliance.

2)

SN : surround. temp. from + 10°C to + 32°C

N : surround. temp. from + 16°C to + 32°C

ST : surround. temp. from + 16°C to + 38°C

T : surround. temp. from + 16°C to + 43°C

3)

3 = fridge with low-temp. compartments

4 = fridge with low-temp. compartments (*)

5 = fridge with low-temp. compartments (**)

7 = fridge with low-temp. compartments ( ^** )

8 = freezer

9 = freezer

This refrigerator must be used in ambient temperature between +16°C and +38°C, if the refrigerator is located in ambient temperature out of the given range, may not function properly).

We reserve the right to change technical specifications.

For any further information, please write to: [e-mail]

WARNING: Do not use this product near water, in wet areas to avoid fire or injury of electric current. Always turn off the product when you don't use it or before a revision. There aren't any parts in this appliance which are reparable by consumer. Always appeal to a qualified authorized service. The product is under a dangerous tention.

Old electrical appliances, used batteries and accumulators disposal

This symbol appearing on the product, on the product accessories or on the product packing means that the product must not be disposed as household waste. When the product/ battery durability is over, please, deliver the product or battery (if it is enclosed) to the respective collection point, where the electrical appliances or batteries will be recycled. The places, where the used electrical appliances are collected, exist in the European Union and in other European countries as well. By proper disposal of the product you can prevent possible negative impact on environment and human health, which might otherwise occur as a consequence of improper manipulation with the product or battery/ accumulator. Recycling of materials contributes to protection of natural resources. Therefore, please, do not throw the old electrical appliances and batteries/ accumulators in the household waste. Information, where it is possible to leave the old electrical appliances for free, is provided at your local authority, at the store where you have bought the product. Information, where you can leave the batteries and accumulators for free, is provided to you at the store, at your local authority.

TARTALOM

Simple line drawing of a mechanical device with a circular component and a triangular handle (no text or symbols)

Simple line drawing of a rectangular frame with a horizontal base and corner markers (no text or symbols)

Simple line drawing of a mechanical device with a handle and base (no text or symbols)

Simple line drawing of a rectangular container or enclosure with no text, numbers, or symbols.

Close-up of a circular mechanical knob with numbered segments (0–7) and a central circle, no text or symbols visible.
