Product Type	Portable Boom Box with Dock for iPod
Brand	GPX
Model	BI100B / BI100S
Power Supply	AC power via included cable or 6 C batteries (not included)
Audio Sources	iPod dock, AM/FM radio, Line input (3.5mm)
iPod Compatibility	Made for iPod; adjustable dock dial for different models
Radio Bands	AM and FM
Antenna	Telescopic FM antenna; built-in AM antenna
Speaker Type	Built-in speakers
Line Input	3.5mm auxiliary input for external audio devices
Controls	Power ON/OFF, source selector, tuning dial, adjustable dock dial
Battery Charging for iPod	Charges docked iPod only when using AC power
Safety Certifications	FCC Part 15 Class B
Laser Class	Class 1 (for CD player, if applicable; note: manual mentions CD player but product may not have CD)
Environment	Recyclable packaging; use of recycled materials
Included Accessories	AC power cable
Warranty	Refer to company information
Dimensions (Approx)	Not specified in manual
Weight (Approx)	Not specified in manual

Frequently Asked Questions - BI100B GPX

How do I power the GPX BI100B docking station?

You can power it using the included AC power cable plugged into a standard outlet, or by inserting 6 C batteries (not included) into the battery compartment.

How do I dock an iPod?

Turn the adjustable dock dial to match your iPod model. Connect the iPod to the connector inside the dock. When using AC power, the iPod will charge; on batteries, it will not.

How do I play music from my iPod?

After docking, set the POWER switch to ON, set the source selector to 'iPod', and use the iPod's native controls to play music through the speakers.

Can I listen to AM/FM radio?

Yes. Set the source selector to FM or AM, turn the TUNING dial to select a station, and extend the telescopic FM antenna for better FM reception. The AM antenna is built-in.

How do I use an external audio device?

Connect your MP3 player or other audio device to the LINE INPUT using a 3.5mm cable. Set the source selector to LINE IN and use the device's controls to play audio.

What batteries does the remote control use?

The remote control uses a button cell battery containing mercury. For safety, recycle or dispose of as hazardous waste.

What should I do if the unit behaves erratically?

Move the unit away from fluorescent lighting, as it may cause interference. If the problem persists, consult the manual or contact support.

How do I clean the docking station?

Unplug the unit and clean only with a dry cloth. Do not use liquids or sprays.

Can I charge rechargeable batteries in the unit?

No, the unit is not designed to charge batteries. Only use NiMH rechargeable batteries in the battery compartment for power; do not attempt to charge standard alkaline batteries.

Where can I get the user manual?

The user manual can be downloaded for free from the GPX website at www.gpx.com in English, Spanish, or French.

USER MANUAL BI100B GPX

Close-up of a modern portable electronic device with a digital display showing app icons (no readable text or symbols)

BI100S

Portable Boom Box with Dock for iPod

For the most up-to-date version of this User's Guide, go to www.gpx.com

WARNINGS AND PRECAUTIONS

• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
• WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
• AVERTISSEMENT: Pour réduire le risque d'incendie ou de choc électrique, ne pas exposer cet appareil sous la pluie et l'humidité.
• CAUTION: Use of controls or adjustments or performance of procedures other than those specified may result in hazardous radiation exposure.
• WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
• WARNING: Do not place the unit on top of any soft, porous, or sensitive surfaces to avoid damaging the surface. Use a protective barrier between the unit and surface to protect the surface.
• WARNING: Use of this unit near fluorescent lighting may cause interference regarding use of the remote. If the unit is displaying erratic behavior move away from any fluorescent lighting, as it may be the cause.
• CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.
• PRÉCAUTION: Danger d'explosion si les piles sont remplacées de façon incorrect. Remplacer les piles seulement par le même type de pile ou l'équivalent.
• WARNING: There is a danger of explosion if you attempt to charge standard Alkaline batteries in the unit. Only use rechargeable NiMH batteries.
• WARNING: The remote control's button cell battery contains mercury. Do not put in the trash, instead recycle or dispose of as hazardous waste
• WARNING: Lithium batteries, like all rechargeable batteries are recyclable and should be recycled or disposed of in normal household waste. Contact your local government for disposal or recycling practices in your area. They should never be incinerated since they might explode.

Main plug is used as disconnect device and it should remain readily operable during intended use.

Do not mix old and new batteries.

Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh, etc) batteries.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

This product utilizes a Class 1 laser to read Compact Discs. This laser Compact Disc Player is equipped with safety switches to avoid exposure when the CD door is open and the safety interlocks are defeated. Invisible laser radiation is present when the CD Player's lid is open and the system's interlock has failed or been defeated. It is very important that you avoid direct exposure to the laser beam at all times. Please do not attempt to defeat or bypass the safety switches.

IMPORTANT SAFETY INSTRUCTIONS

I. Read these Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding - type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.

1. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

1. Unplug this apparatus during lightning storms or when unused for long periods of time.
2. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

FCC Warnings

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Additional Warnings

PORTABLE BOOM BOX WITH DOCK FOR IPOD

Features

• Made for iPod
• Basic controls for docked iPod
• AM/FM radio
  • Built-in speakers
  • Line input (3.5mm)
• DC battery power: requires 6 C batteries (not included)
• AC power input: requires an AC power cable (included)

Included

• BI100S
• AC power cable

TABLE OF CONTENTS

INTRODUCTION 6

SETUP 8

IPOD 9

RADIO 10

LINE INPUT 11

COMPANY INFORMATION 12

INTRODUCTION

BATTERY COMPARTMENT

Requires 6 C batteries (not included)

LINE INPUT

Use to connect an MP3 player or other audio device to the portable boom box.

SETUP

Power

Plug the included AC power cable into a standard AC POWER INPUT and a standard AC power outlet to power the portable boom box.

Diagram of a portable electronic device with internal components connected to a power outlet (no text or symbols)

Battery Power

Requires 6 C batteries (not included)

Diagram of a smart air purifier with internal components and battery pack arrangement (no text or symbols)

Docking an iPod

1 Turn the ADJUSTABLE DOCK DIAL until the arrow on the dial is pointing to the listed iPod model to be docked.
iPod models and memory sizes that are not listed on the Dock Adjustment Dial can be docked by manually adjusting the dial to the depth that fits the iPod best.
2 Connect the iPod to the iPod connector inside the Dock for iPod. When the portable boom box is plugged in, using AC power, the docked iPod will charge. If the unit is running on batteries, DC power, the docked iPod will not charge.

Playing an iPod

1 Follow the instructions for DOCKING AN IPOD.
2 Adjust the POWER OFF/ON switch to the ON position.
3 Adjust the iPod/FM/AM/LINE IN switch to "iPod".
4 Use the native controls on the docked iPod to play music through the portable boom box.

RADIO

Tuning the AM/FM Radio

1 Adjust the POWER OFF/ON switch to the ON position.
2 Adjust the IPod/FM/AM/LINE IN switch to the FM or AM position.
3 Turn the TUNING dial to adjust the AM or FM radio station.
4 Extend the TELESCOPIC FM ANTENNA to improve FM radio reception.
An AM antenna is built into the portable boom box. Adjust the position of the boom box to improve AM radio reception.

Using the Line Input

1 Connect an MP3 player or other audio device to the LINE INPUT using a 3.5mm cable.
2 Adjust the POWER OFF/ON switch to the ON position.
3 Adjust the IPod/FM/AM/LINE IN switch to the LINE IN position.
4 Use the native controls on the connected MP3 player to play audio through the portable boom box.

Green Initiative

Environmental Commitment to ‘Protect for Today and Sustain for Tomorrow’

2009 marks the official launch of DPI, Inc.'s corporate campaign for a greener and cleaner world. DPI and its four brands, iLive, WeatherX, Capri, and GPX, are building upon environmental initiatives introduced at all of their facilities to help formulate and sustain significant and important conservation efforts within its manufacturing and marketing communities. In addition to targeting and selecting energy efficient product features, and structuring ‘green office’ procedures, other initial program efforts include:

• Reduction of all packaging sizes
- Recyclable plastics for clamshell packages, with a plan to eventually replace plastic with recyclable paper
• Recycled fiber board in place of the polyfoam in packing boxes
• Recycled plastics in place of the virgin material in product construction

International Support

To download this User's Guide in English, Spanish, or French, visit the support section at www.gpx.com.

Address: 2116 Carr Street, St. Louis MO, 63106

Phone: [phone]

Fax: [phone]

Email: [e-mail]

Parts Email: [e-mail]

Website: www.gpx.com
