| Product Type | Two-way radio (Walkie-Talkie) |
| Brand | Motorola |
| Model | Mag One X10D |
| Frequency Band | UHF 400-470 MHz |
| Number of Channels | 16 |
| RF Power Output | 2 W |
| Battery Type | Lithium-Ion (Li-Ion) 1100 mAh |
| Battery Life | Up to 10 hours (typical) |
| Dimensions (H x W x D) | 115 x 57 x 33 mm |
| Weight (with battery) | 210 g |
| Display | None |
| Audio Output Power | 500 mW |
| Ingress Protection (IP) Rating | IP54 (dust and splash resistant) |
| Key Features | Emergency button, monitor button, channel scan, programmable side buttons |
| Included Accessories | Belt clip, drop-in charger, Li-Ion battery pack |
| Cable Programming | Support via optional programming cable and software |
| Operating Temperature | -20°C to 60°C |
| Warranty | 1 year (limited) |
Frequently Asked Questions - Mag One X10D MOTOROLA
How do I charge the battery for the Mag One X10D?
Place the radio with battery attached into the drop-in charger. Ensure the charger is connected to a power outlet. The LED indicator will turn red during charging and green when fully charged. Full charge takes approximately 2-3 hours.
What is the range of the Mag One X10D?
The typical range in optimal conditions (flat terrain, no obstructions) is up to 5 kilometers. Urban environments with buildings may reduce range to 1-2 kilometers. Actual range depends on environmental factors.
How do I program channels on the Mag One X10D?
Programming is done via a PC using Motorola's CPS software and an optional programming cable (PMLN5707). The radio can store up to 16 channels. Basic settings like channel frequency and squelch codes can be adjusted.
Can I use the Mag One X10D with other brands of two-way radios?
Yes, if the other radios operate on the same frequency band (UHF 400-470 MHz) and are set to the same channel and analog signaling (CTCSS/DCS tones). It can communicate with compatible analog radios.
How do I adjust the volume on the Mag One X10D?
Turn the volume knob on top of the radio clockwise to increase volume, counterclockwise to decrease. The radio emits a beep when power is turned on to indicate audio level.
What does the emergency button do?
The programmable orange emergency button, when pressed, can be configured to transmit an alert or switch to a pre-set emergency channel. It helps in urgent situations to signal for help.
Is the Mag One X10D waterproof?
It has an IP54 rating, meaning it is protected against limited dust ingress and splashing water. It is not fully waterproof or submersible. Avoid immersion or heavy rain.
How do I set a privacy code (CTCSS/DCS)?
Privacy codes are programmed via the CPS software on a computer. Select the desired channel and assign a CTCSS tone or DCS code. The radio will only unmute when receiving the same code.
What accessories are compatible with the Mag One X10D?
Compatible accessories include earphones, speaker microphones, vehicle adapters, and replacement belt clips. All accessories must be Motorola-approved for proper fit and performance.
How do I perform a factory reset on the Mag One X10D?
Factory reset is done via the CPS software. Connect the radio to a computer, open CPS, and select 'Reset to Defaults' option. This restores all channels and settings to original factory values.
