MR-049 - Kettle Maestro - Free user manual and instructions

Product Type	Electric Kettle
Brand	Maestro
Model	MR-049
Capacity	1.7 L
Power Consumption	1850 - 2200 W
Voltage	220 - 240 V AC
Frequency	50 Hz
Protection Class	Class I (earthed)
Ingress Protection	IPX0
Control Panel	Digital display with temperature icon, Boil button, Temperature Increase/Decrease, Keep Warm, preset tea modes (White, Green, Oolong)
Preset Tea Temperatures	White tea 70°C, Green tea 80°C, Oolong tea 90°C
Adjustable Temperature Range	40°C - 100°C (in 5°C increments)
Keep Warm Function	Yes, up to 2 hours, maintains temperature within 5°C of set value
Auto Shut-Off	Yes, after boiling and if no operation for 1 minute (standby)
Boil Dry Protection	Yes, automatic shut-off if water level is below MIN
Base Type	Separate power base with cord
Cordless Operation	Yes, kettle lifts off base for pouring
Water Level Indicator	Yes, on kettle case
Filter	Removable mesh filter (for scale)
Cleaning Instructions	Descale with vinegar solution; clean exterior with damp cloth; do not immerse base or kettle in water
Materials	Plastic body, stainless steel inner lining (implied)
Safety Features	Earthed plug, auto shut-off, boil-dry protection, cool-touch handle
Intended Use	Household only for boiling water and making tea
Storage	Cool, dry place; do not wrap cord around hot kettle
Environmental Disposal	Recycle according to local regulations

Frequently Asked Questions - MR-049 Maestro

How do I use the kettle for the first time?

Before first use, boil water twice and discard to clean the interior. Fill to MAX level, boil, then empty. Repeat once more.

How do I select a specific temperature?

Press the Temperature Increase or Decrease button to adjust from 40°C to 100°C in 5°C steps. Alternatively, press one of the preset tea buttons: White (70°C), Green (80°C), or Oolong (90°C).

What is the Keep Warm function and how does it work?

The Keep Warm function maintains your selected temperature for up to 2 hours. After setting the desired temperature, press the Keep Warm button. The kettle will reheat when the water cools about 5°C below the set value.

How do I clean the kettle and remove limescale?

Use a mixture of 1 part vinegar and 2 parts water, boil, let sit for 10-12 hours, then rinse. Alternatively, use a commercial descaling product. Clean the filter with a nylon brush under running water.

What does the memory function do?

In Keep Warm mode, the kettle remembers the temperature setting for up to 10 times of lifting the kettle off the base, as long as the water temperature does not drop more than 8°C below the set value each time.

Can I use the kettle without water?

No, never switch on the kettle without water or below the MIN mark. The boil-dry protection will shut it off, but you must unplug and let it cool before refilling.

How do I turn off the kettle manually?

Press the Power button for 5 seconds to enter standby mode. The power button indicator will change to a breathing light. To turn off completely, unplug the kettle from the outlet.

What should I do if the kettle does not turn on?

Check that the power cord is properly plugged into a suitable earthed outlet. Ensure the kettle is correctly placed on the base. If it still does not work, contact authorized service.

Is the kettle safe to use around children?

The kettle becomes very hot during operation. Keep out of reach of children and supervise if used nearby. Do not let children operate it without adult supervision.

Can I use the kettle to heat other liquids besides water?

No, the kettle is designed only for boiling and heating water for home use. Do not use it for milk, oil, or other liquids.

USER MANUAL MR-049 Maestro

Black glass coffee maker with digital display and control buttons, no visible text or symbols on the device itself.

Модель/Model: MR-049

091

Dear customer, we thank you for purchase of goods

Functionality, design and conformity to the quality standards guarantee to you reliability and convenience in use of this device. Please read and comply with these original instructions prior to the initial operation of your appliance and store them for later use of subsequent owners.

The kettle is designed only for warming and boiling water for home use.

Under condition of observance of user regulations and a special-purpose designation, a parts of appliance do not contain unhealthy substances.

Technical specifications

Model: MR-049

Capacity: 1,7 L

Electrical supply:

Alternating current- AC;

Rated voltage 220-240V;

Rated frequency 50Hz;

Power consumption 1850-2200 W

Protective class I

Protection class IPX0

Description of the appliance

Picture1 (page 2)

A- Cover
B- Button for cover opening
C- Control Panel
D- Handle
E- Kettle case
F- Base
G- Scale of water level

Safety instructions

When using your appliance, basic safety precautions should always be followed, including the following:

SPECIAL INSTRUCTIONS

ATTENTION!

• Do not allow the ingress of water and moisture on the support and internal electric parts of the device located outside the container for water.
• Always remove the kettle from the support to fill it with water or to clean.
• Do not touch the water in the kettle when it is on the support.
• Only plug the appliance into an outlet with an earthed (ground) contact.

Failure to observe these rules may result in electric shock!

Only plug the appliance into an outlet with an earthed (ground) contact.

- DO NOT let children or untrained persons use the appliance without supervision.

• DO NOT leave the appliance unnecessarily plugged in. Disconnect the plug from the mains when the appliance is not being used.
• DO NOT use the power cord or the appliance in order to pull the plug out of the socket.
• DO NOT leave the appliance exposed to the weather (rain, sun, etc.).
• DO NOT leave the appliance without supervision when it is connected to the power supply.
• Close supervision is necessary when the appliance is used near children.
• Always use the appliance on a dry, level surface.
• Do not put on and take off the kettle from the support when it is switched on. First, turn it off with a switch.
• Always unplug from the plug socket when not in use and before cleaning.
• Do not operate the appliance if damaged, after an appliance malfunctions or it has been damaged in any manner, return to at authorized service engineer for repair.
• In the interest of safety, regular periodic close checks should be carried out on the supply cord to ensure no damage is evident.

Should there be any signs that the cord is damaged in the slightest degree, the entire appliance should be returned be authorized service engineer.

• Do not let the cord hang over the edge of a table or counter or touch hot surfaces. Allow unit to cool before storage.
• Do not touch any hot surfaces, do not store or cover the appliance until it has full cooled down.
• Do not use harsh abrasives, caustic cleaners or oven cleaners when cleaning this appliance.
• This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.
• Do not leave the kettle switched on if the temperature in the room may fall below zero. When the temperature is below zero, the thermostat of the device may spontaneously turn on and switch on the device.

ATTENTION!

• The surface of the device becomes very hot during operation.
  Be careful because you may burn yourself greatly by touching the surfaces of the cover, case, water of vapor.
• Do not open the cover of the kettle during boiling.
• Do not lift the kettle by its cover.
• Take and lift the kettle only keeping it for the handle, touch only the buttons of the device.
• Do not fill the kettle with the water level higher than the mark «MAX».
• Place the kettle only on a dry, stable, even, slip-resistant surface.
• Lift the kettle full with hot water with special care!

In case of failure to observe the above mentioned rules there arises the danger of burning!

• To avoid possible damages by vapor turn the kettle nose away from walls and furniture when it is boiling. Use the support to save the sensitive cover of furniture from damages.
• Do not place the kettle and its support on heating devices.
• Do not close the opening for the exit of vapor near the switch.
• Do not use the kettle without a cover.

- Do not switch the kettle on without water or when the water level is below the mark «MIN». If the kettle is empty or there is not enough water in it, it is automatically turned off by safety device. In such case, disconnect the device from the mains, let it cool down and then fill it with water again and turn it on; the kettle will begin to boil water and after the end of this process it will turn off in the regular regime.

- THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY. DO NOT USE THE APPLIANCE FOR ANYTHING OTHER THAN INTENDED USE.

Purchase industrial devices for commercial use.

Actions in extreme situations:

• If a device tumbled into water, immediately, unplug the device, not touching to the device or water.
• In case of appearance from appliance of smoke, sparkling, strong smell of a burn isolation, immediately stop use the device, unplug the device, appeal to the nearest service center.

Control Panel

1. Temperature Icon
2. White (tea)
3. Green (tea)
4. Oolong (Tea)
5. Boil button
6. Temperature Increase/Decrease button
7. Keep warm
8. Power

Operation Instruction

Please check whether your socket and power is suitable for this product before use

Do not exceed the maximum line of the mark(1700ml)

It is suggested to boil twice to clean the inner pot when first use

1. Place the the kettle on a horizontal surface for use.
2. Open the lid and pour water into the kettle.
3. Connect with power, enter the setting interface, and press the button for boiling water (you can select the setting temperature you need under the setting interface).
4. Take off the kettle for brewing.

Basic Operation:

1. Temperature Icon: Show the real-time and setting temperature.
2. White: Under setting interface, Press (shortly, enter the mode of white tea and relevant temperature 70^ C.

3. Green: Under setting interface, Press Snorny, enter the mode of Green tea and relevant temperature 80^ C.

4. Oolong: Under setting interface, Press

,enter the mode of Oolong tea and relevant temperature 90°C.

1. Boil button: Under Setting interface, press shortly.

And the buzzer sound "DI", and the temperature show 100°C, the three buttons all light on.

The temperature icon show the current real time temperature and enter boiling status. After boiled, The buzzer sounds"DI DI".

These two buttons

lights off, and the

temperature show will be off after 30 seconds.

The power button switch to breath light.

1. Temperature Increase/Decrease button: Single press setting from 40-100°C in every 5°C as level.

1. Keep Warm Key: Under setting interface, press the key once and the buzzer will sound «di» (light) in twinkle status.

At the same time, after selecting the required setting temperature by pressing the increase/decrease button or directly selecting the white tea, green tea and oolong tea button on the setting interface, it will automatically enter the keep warm state. The keep warm time is 2 hours. When the water temperature is lower than the set value of about 5 degrees, the heat will be resumed until 2 hours. (On the setting interface, press the WARM button by mistake without

performing any other operation, and the system returns to the setting interface in 3 seconds later.)

1. Power button: in the power state, the power button indicator will light up. If there is no operation within 1 minute, the kettle will automatically enter the standby state, and the power button light will be changed into the breathing light (in the standby state, only press the power button is effective, other keys are invalid, and enter the setting state; To switch function, you need to press the power button again to switch to the setting interface; Under the setting interface, press it for 5 seconds and the kettle will enter the standby state)

2. In the state of keep warm, after boiling water to the set temperature, the function of memory starts. Within ten times of kettle lifting, the water temperature of the kettle should not be less than 8 degrees below the set value for each time, and the memory is effective, that is, the keep warm continues to work and the time of keep warm continues to the last time. Otherwise exit the keep warm.

Cleaning and maintenance

Regular cleaning improves the performance of the device.

The quantity and the speed of forming the scale, and consequently, the necessity of cleaning depend on the water hardness in your region and the intensity of the device usage. All over fur of scale in your kettle is not allowed!

It is recommended to clean the kettle at least 2 times a year but however until the appearance of all over scale.

ATTENTION!

• Never clean a kettle connected to mains.

• Before cleaning, disconnect the kettle and let it cool down.

• Do not use abrasive and aggressive detergents.

• Never submerge the kettle, its support, power line cord and plug in water or other liquids.

EN

Cleaning the filter (for the models with removable filter)

-Clean the filter from lime scale with a nylon brush under a flow of water. Soak dirty filter in vinegar or special liquid for removing the scale before cleaning.

Cleaning the kettle from scale

Clean the kettle from scale with special agents sold in the open market. Cleaning from scale can be also performed by the methods described below:

METHOD 1

• Fill the kettle to maximal level with a mixture consisting of 1 part of usual vinegar and 2 parts of water. Switch on the kettle and let is boil and automatically switch off.
• Let the mixture settle during 10-12 hours and pour it out.
• Fill the kettle with fresh water up to maximal level and boil it again. Pour out this water too to remove the smell of vinegar.
  -Wash the internal part of the device with clean water, wipe it and dry the kettle.

METHOD 2

• Fill the kettle with the above mentioned mixture of water and vinegar and boil it 2 or 3 times running. Rinse it with water and rub it dry.
• For usual cleaning wipe the kettle case from the inside and outside with a soft wet sponge or cloth. Soapy water can be used.
• Rinse the kettle and wipe it dry.
• Let the device get fully dry before using.
• Any other kinds of maintenance should be performed by qualified personnel in a servicing center.

Storage

• Switch off the kettle and let it completely cool before storage.
• Wipe and dry the kettle before storage.
• Do not wind the power line cord around the kettle until it is completely cooled down.
• Store the kettle in a cool, dry and clean place beyond the assess of children and people with limited physical and mental abilities.

Environmental protection

Old appliances contain valuable materials that can be recycled. Please arrange for the proper recycling of old appliances. Please dispose your old appliances using appropriate collection systems.

Subject to technical modifications!

Current electric alternativ;

Frecventa nominala: 50 Hz;

Made in P.R.C. for Maestro

Apollo Corporation Limited ADD: Room801-2, 8/F.,

Easey Commercial Building, 253-261 Hennessy Road, Wanchai, Hong Kong,
