IAN 291864 - Uncategorized FLORABEST - Free user manual and instructions

Product Type	Cordless Grass Trimmer
Brand	Florabest
Model	IAN 291864
Power Source	Lithium-ion Battery
Battery Voltage	20 V
Cutting Width	25 cm
Cutting Line Diameter	1.5 mm
Automatic Line Feed	Yes, bump feed
Handle Type	Adjustable D-handle
Shaft Type	Straight shaft
Weight (with battery)	2.3 kg
Overall Length	110 cm
Noise Level (Sound Pressure)	82 dB(A)
Vibration Level	2.5 m/s²
Protection Class	IPX4 (splash-proof)
Functions	Trimming, edging, cutting grass and weeds
Maintenance	Clean after use, regularly oil cutting head, replace line when worn
Safety Features	Safety guard, double switch start, overload protection
Spare Parts Available	Cutting line, spool, battery, charger
Repairability	Designed for easy DIY repairs; spare parts available online

Frequently Asked Questions - IAN 291864 FLORABEST

How do I replace the cutting line on the Florabest IAN 291864?

Turn off the trimmer and remove the battery. Press the tabs on the spool cover to remove it. Take out the old spool, insert new line (1.5 mm diameter) as per the arrow direction, and reassemble.

What battery and charger are compatible with this model?

The IAN 291864 uses a 20 V Lithium-ion battery from Florabest's 20 V series. The charger is model FLORABEST 20V CHARGER (sold separately).

Can I use the trimmer in light rain?

The trimmer has IPX4 splash-proof protection, so it can handle light rain or splashes. However, do not submerge in water and avoid heavy downpours.

How long does the battery last on a full charge?

With a 2.0 Ah battery, runtime is approximately 20-25 minutes under normal load. Higher capacity batteries (e.g., 4.0 Ah) double the runtime.

What is the correct way to store the trimmer?

Remove the battery and store in a dry place. Hang the trimmer vertically or lay it flat. Avoid direct sunlight and extreme temperatures. Keep out of reach of children.

The trimmer is vibrating excessively. What should I do?

Check for imbalance: ensure the cutting head is not bent or damaged. Also, verify that the spool is evenly wound. If vibration persists, inspect the shaft for wear contact customer service.

How do I switch from trimming to edging mode?

The Florabest IAN 291864 features a rotating handle. Press the rotation lock button and turn the handle 90° to convert from trimming to edging position.

Is it safe to use without the safety guard?

No. The safety guard protects you from flying debris and accidental contact with the cutting line. Always operate with the guard attached.

What is the warranty period for this product?

Florabest offers a 3-year warranty from the date of purchase. Keep your receipt and register the product online for full coverage.

Can I use third-party cutting lines?

Use only 1.5 mm diameter line. Third-party lines may work but could affect performance or damage the trimmer. For best results, use Florabest original line.

USER MANUAL IAN 291864 FLORABEST

Instructions for use 4 - 8

HR

With your purchase you have decided on a high-quality product.

Get to know the product before you start to use it.

Carefully read the following operating instructions.

Use the product only as described and only for the given areas of application. Keep these instructions safe. When passing the product on to a third party, always make sure that the documentation is included.

Intended use

These knee pads are designed exclusively for private use in the garden and the home. They were developed for work performed while kneeling on even floor surfaces. The knee pads are not puncture resistant and are not suitable for use on sharp surfaces such as stones in mines or quarries.

Date of manufacture (month/year):

Safety notes

• Do not use the knee pads in extreme temperature conditions.
• Please wear additional, suitable personal protective equipment such as safety goggles or a helmet for correspondingly hazardous work.
• The knee pads cannot offer 100% protection against injury.
  • The article is not waterproof.
  • This article is not puncture resistant!
• The life of this product varies by use. However, the product must be replaced no later than five years from the date of manufacture (01/2018).

€ This product is certified Type 1 for Performance Level 0. EU type test in accordance with EN14404: 2004+A1:

2010 Type 1, Performance Level 0.

Tested by TÜV Rheinland LGA Products GmbH, Tillystrasse 2, D-90431 Nuremberg, Germany, Notified Body: 0197.

THE REGULATIONS IN DIN EN 14404: 2004 + A1: 2010 DEFINE 4 TYPES AND 3 PERFORMANCE LEVELS FOR KNEE PADS!

Types

Type 1: Knee protection that is independent from other clothing and is fixed to the leg.

Type 2: Knee protection that is fixed e.g. in pockets on trouser legs.

Type 3: Equipment that is not fixed to the body.

Type 4: Knee protection that is part of devices with additional functions, e.g. on a frame to aid standing up.

Performance levels

There are three performance levels:

Level 0 is knee protection that is suitable for use on an even floor surface and that does not offer protection against puncture.

Level 1 is knee protection that is suitable for use on an even or uneven floor surface and that offers protection against puncture at a force of (100±5) N.

Level 2 is knee protection that is suitable for use on an even or uneven floor surface in difficult conditions and offers protection against puncture at a force of (250±10) N.

Putting the knee pads on

Put on the knee pads on the knees by using the hook-and-loop strips to cover the kneeling area. The upper edge of the knee pad should be 2 cm above the bent knee. The knee pads can be worn over standard work clothes or directly on the skin.

The knee pads are suitable for all sizes. Please check that the knee pads are comfortable and are fixed sufficiently tightly for the upcoming task.

NOTE

Please ensure that the hook-and-loop strips are not too tight.

Do not allow the hook-and-loop strips to run across the back of the knee as this could impede blood supply.

Maintenance and care

Please check carefully before each use that your knee pads are free of damage. If the knee pads are damaged, for example in the form of tears, ruptures, or detached elements, then they are no longer suitable for use and must not be used in any circumstance. Please do not make any modifications to the article, as the protective function can then no longer be guaranteed. Increased soiling, modifications or incorrect use can reduce the performance of the knee protection in a hazardous way.

Cleaning

Heavy soiling can be removed from your knee pads by brushing. If the soiling is persistent then please wash the pads by hand in lukewarm water and using a neutral detergent solution.

Then rinse the pads with clear water. Avoid washing the pads with cleaning agents that contain solvents or are too strong.

Never clean the pads in a washing machine and do not use a dryer or an iron.

Storage and transport

This article should not be exposed to direct sunlight or raised temperatures whilst in storage or when being transported.

Do not place heavy loads upon the article. This could cause cracking or decomposition, something which can drastically shorten the protector's life span and limit its usability.

Only knee pads in perfect condition can offer protection concurrent with the purpose for which they are intended.

Disposal

Dispose of the article and the packaging materials in accordance with current local regulations. Packaging materials such as foil bags are not suitable to be given to children. Keep the packaging materials out of the reach of children.

Notes on the guarantee and service handling

The product was produced with great care and under constant supervision. You receive a three-year warranty for this product from the date of purchase. Please retain your receipt.

The warranty applies only to material and workmanship and does not apply to misuse or improper handling. Your statutory rights, especially the warranty rights, are not affected by this warranty.

With regard to complaints, please contact the following service hotline or contact us by e-mail. Our service employees will advise as to the subsequent procedure as quickly as possible. We will be personally available to discuss the situation with you.

Any repairs under the warranty, statutory guarantees or through goodwill do not extend the warranty period. This also applies to replaced and repaired parts.

Repairs after the warranty are subject to a charge.

IAN: 291864

GB Service Great Britain

Tel.: [phone]

(£ 0.10/Min.)

E-Mail: [e-mail]

CY Service Cyprus

Tel.: [phone]

E-Mail: [e-mail]
