WAS-623 - Waffle Maker WILFA - Free user manual and instructions

Product Type	Waffle Maker
Brand	Wilfa
Model	WAS-623
Power Supply	220-240 V, 50-60 Hz
Power Consumption	900 W
Dimensions (L x W x H)	25 x 20 x 10 cm
Weight	1.5 kg
Cord Length	0.8 m
Plate Material	Non-stick coated
Number of Waffles per Batch	1 round waffle
Temperature Control	Adjustable thermostat
Indicator Light	Yes (power and ready)
Non-slip Feet	Yes
Cool-touch Handle	Yes
Housing Material	Plastic and stainless steel
Cleaning Method	Wipe with damp cloth; do not immerse
Storage	Vertical storage with cord wrap
Safety Features	Overheat protection
Included Accessories	Instruction manual
Warranty	2 years

Frequently Asked Questions - WAS-623 WILFA

How do I use the Wilfa WAS-623 waffle maker for the first time?

Before first use, wipe the plates with a damp cloth and dry. Close the lid, plug in, set the thermostat to the desired level, and wait for the green ready light. Pour batter onto the center of the lower plate, close the lid, and cook until done.

What is the best temperature setting for crispy waffles?

For golden and crispy waffles, set the thermostat between medium-high (around 4-5 on the dial). Experiment to find your preferred browning level.

Can I use any type of batter?

Yes, but avoid batters with large chunks or excessive sugar as they may burn. For best results, use standard waffle batter or pancake mix.

How do I clean the waffle maker?

Unplug and let it cool completely. Wipe the plates with a soft damp cloth or paper towel. Do not use abrasive cleaners or immerse in water. For stubborn residue, use a non-stick safe brush.

Why is the waffle sticking to the plates?

Ensure the plates are coated with a thin layer of oil before first use and periodically. Also, allow the waffle to cook fully before opening; undercooked waffles tend to stick.

How long should I cook waffles?

Cooking time varies, typically 3-5 minutes depending on batter and desired doneness. The ready light will cycle on/off, but check for golden brown color.

Can I store the waffle maker vertically?

Yes, the design allows vertical storage with a cord wrap feature. Ensure it is completely cool and dry before storing.

What does the red and green light indicate?

The red light indicates power is on. The green light illuminates when the plates have reached the set temperature and goes out during cooking, then turns on again when ready for the next batch.

Is the waffle maker safe to use around children?

The appliance gets very hot. Keep children away during use and until it has cooled down completely. The cool-touch handle helps reduce risk, but adult supervision is required.

What if the waffle maker stops working?

Check the power cord and outlet. If overheat protection has activated, unplug and let it cool for 15 minutes before reuse. If the problem persists, contact Wilfa customer service.

USER MANUAL WAS-623 WILFA

Black and silver electric grill with control panel and green handle (no visible text or symbols)

Black frying pan with control knob and red button (no visible text or symbols)

Bruksanvisning

Bruksanvisning

Brugsanvisning

Käyttöohje

WAS-623, WAS-623B

Instruction manual

WAS-623BELL

BRUKSANVISNING WAS-623 VAFFELJERN N

VIKTIGE SIKKERHETSREGLER

OPPSKRIFTER PÅ VAFLER:

Vaniljevaer

150 g smør eller margarin

200 g sukker

4 egg

Vaniljesukker

1/2 ts salt

250 g hvetemel

1 str. ts bakepulver

1-2 ss øte

Fremgangsmåte: Bland smør, sukker, egg, salt, vaniljesukker, mel, bakepulver og øte. Rør godt sammen. Bland i melk I passe tykk røre.

Ostevaer

200 g smør eller margarin

4 egg

1/2 ts salt

200 g mel

1/2 ts bakepulver

1/2 dl lunkent vann

2 ss reven ost

Paprika

When using electrical appliances, basic safety precautions should always be followed including the following:

1. Read all instrucons.
2. Do not touch hot surfaces. Use the handle or thermostat buon.
3. To protect against risk of electrical shock, do not immerse the cord, plug or appliance in water or other liquid.
4. Close supervision is necessary when any appliance is used by or near children.
5. Unplug from outlet when not in use or before cleaning the appliance.
6. Never use an appliance with a damaged cord or plug, or which is damaged in any way.
7. Use the appliance under a roof.
8. Do not let the cord hang over the edge of a table or counter, or touch hot surfaces, including the stove.
9. Do not place the appliance on or near a gas or electric burner, or other heated oven.
10. To disconnect the appliance, remove plug from wall outlet.
11. Do not use the appliance for things other than for what it was intended.
12. Is the cable damaged, it must be replaced by authorized service personnel.
13. Is there damage to the device or that it does not work, it must be serviced only by authorized personnel.

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instrucon concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. Keep the appliance and its cord out of reach of children aged less than 8 years.

SAVE THESE INSTRUCTIONS

This appliance is intended for domesc use only.

No user-serviceable parts inside.

A short power cord is provided to reduce the hazards resulting from entanglement or tripping over a longer cord. An extension cord may be used with care; however, its marked electrical rang should be at least as great as the electrical rang of this appliance. The extension cord should be posioned such that it does not hang over the counter or tabletop where it can be pulled on by children or tripped over. The electrical rang of this appliance is listed on the appliance's rang plate.

BEFORE USING FOR THE FIRST TIME

Before using for the rst me, the hotplates should be cleaned with a moist cloth.

We recommend lightly greasing the hotplates when using the appliance for the rst me. This will not be necessary on subsequent occasions.

The rst two waes should not be eaten.

MAKING WAFFLES

1. Insert the plug into a standard electrical outlet. Make sure that the voltage to be used agrees with the rated voltage of your appliance.
2. Close the wae iron and prepare wafe batter while the wafe iron heats up. Set the thermostat regulator to the desired seng.
3. The power (red), indicator lights will light up. When the green indicator lights up (aer about 4 minutes), the wae iron is ready for baking.
4. Open the appliance and pour the wae baer onto the centre of the lower hotplates. Using the included ladle will result in the correct amount of baer being used. Close the appliance carefully. Do not force shut. Steam may be ejected from between the hotplates.
5. When the green indicator light turns o, the red indicator light will light. Aer few minutes the green light will light up and the wae is ready.
6. If you think the wae is too light or too dark, adjust the thermostat.

NOTE:

■ Care must be taken to ensure that ngers do not come into contact with the hotplates.
During baking, the ready light will turn on and o as the thermostat keeps the wae iron at the right temperature.
- Your wafe will bake in about 2 minutes or longer depending on your personal tastes. When baking is nished, open the wae iron and remove the wae with a plasc or wooden spatula. Never use a metal knife as this may damage the non-sck coang. The appliance should be kept closed in-between baking waes.
- Aer use, remove the plug from the wall socket.

HELPFUL HINTS

1. Always preheat the wafe iron before baking. Plug the wafe iron in rst, and prepare the baer while the wae iron is heang.
2. If you want lightly colored waes, remove them before the READY light goes off. Or if you prefer darker colored waes, leave them in a lile while longer.
3. If the lid resists liing allow the wae to bake a lile longer, and then try liing the lid again.
4. If the wafe scks to the top cooking plates, remove them with a plasc or wooden spatula.
5. Let wae cool slightly on an oven grate before eang to avoid possible burns.
6. Top baked waes with dierent fruits or ice cream to create your own speciales.
7. The included ladle measures out the correct amount of batter.
8. These wae irons hotplates are a new, revolutionary design. The coned design ensures that the baer is evenly distributed and that all the air is pressed out of the wae iron. It is therefore not necessary to spread out the wae baer using a ladle or similar. This is done automatically when you close the wae iron.

CLEANING

■ Always pull out the plug before any cleaning operaon and allow the appliance to cool down.
■ Never immerse the appliance in water or hold it under running water.
■ Wipe down the casing with a moist cloth only.
■ Clean the hotplates aer they have cooled down with a moist cloth or with a very so brush.
■ Never use sharp or pointed objects or any abrasive cleaning agents for cleaning purposes.

NEVER IMMERSE THE APPLIANCE IN WATER OR OTHER LIQUID.

For more ps and recipes visit www.wilfa.com

According to the Waste Electrical and Electronic Equipment (WEEE) Directive, this type of waste must be collected and treated separately. If it becomes necessary to dispose of this product at some point, kindly make sure that it is not discarded with your everyday household refuse. Instead, bring the product to your closest WEEE collection centre.
