IAN 93591 - Fitness Equipment CRIVIT - Free user manual and instructions

Brand	Crivit
Model	IAN 93591
Product type	Jump rope with electronic counter
Power supply	1 LR44 button cell battery (included)
Package contents	2 handles, 1 rope, 2 cable clips, 2 x 50 g weights, 2 x 100 g weights, 1 countdown timer, 1 battery, 1 carrying case, instructions
Main functions	Adjustable countdown timer from 1 to 60 minutes, end sound signal, weighted handles (50 g or 100 g each), cable clips to secure the rope
Training time setting	From 1 to 60 minutes, via orange button
End sound signal	Yes, emitted when the set time has elapsed
Available weight inserts	50 g and 100 g per handle (2 of each)
Intended use	Exclusively as a jump rope for fitness. Do not use as a towing, pulling, or climbing cable
Safety instructions	Do not leave children unattended, consult a doctor in case of heart problems, stop if nauseous/pain, train on a flat, non-slip surface, do not use near stairs
Care and cleaning	Clean with a damp cloth and a mild detergent, do not use solvents, dry, store dry at room temperature
Warranty	3 years from date of purchase
After-sales service (France)	Tel. [phone], email [e-mail]
After-sales service (Belgium)	Spare parts at www.delta-sport.com (Service section)

Frequently Asked Questions - IAN 93591 CRIVIT

How to adjust the rope length?

Loosen the screws on top of the handles, remove the rope, then cut or move the ends to adjust the length. The ideal length is when the handles reach the middle of your torso. Use the cable clips to hold the ends in place.

How to install the weights on the handles?

Unscrew the bottom cap of the handle, insert the desired weight (50 g or 100 g) and screw the cap back on. Ensure both handles are weighted with the same weight for optimal balance.

How to use the countdown timer?

Press and hold the orange button until numbers appear. Release to start the countdown. The adjustable time ranges from 1 to 60 minutes. An audible signal sounds at the end of the workout.

What to do if the countdown display goes dim?

This indicates a low battery. Replace the battery with a new LR44 (button cell). Follow the replacement instructions in the manual.

How to replace the countdown timer battery?

Turn the compartment cover counterclockwise, remove it, then gently tap to remove the old battery. Insert a new LR44 battery observing polarity (positive side toward the cover) and close by turning clockwise.

What symptoms require stopping the workout?

Stop immediately if you experience nausea, chest pain, dizziness, or a feeling of suffocation. Consult a doctor without delay.

How to clean and maintain the jump rope?

Clean with a damp cloth and a mild detergent. Do not use solvents or harsh detergents. Dry with a dry cloth. Store in a dry place at room temperature. Coil the rope after use and do not hang it.

Can I use the jump rope as a towing or climbing cable?

No, the intended use is strictly limited to a jump rope for fitness. Any other use (towing, pulling, climbing) is prohibited and dangerous.

What is the warranty period?

The warranty is 3 years from the date of purchase. It covers defects in materials and workmanship. Keep your receipt.

Where can I get spare parts?

For Belgium, visit www.delta-sport.com, Service section - Lidl spare parts service. For France, contact customer service at 0800 919270 or by email at [e-mail].

USER MANUAL IAN 93591 CRIVIT

Black jump rope and control device with two lever arms (no text or symbols visible)

Skipping Rope Set

GB IE

Skipping Rope Set

Instructions for use

SE

HoppRep, Set

Bruksanvisning

FR BE

General training instructions 6

Assembly 7

Programming the countdown timer 7

Battery warning 7

Replacing the battery 8

After training 8

Care and storage 8

Instructions for disposal 8

Battery disposal 8

3 Years Warranty 9

SE

Line drawing of a person standing with a resistance band, no text or symbols present

Congratulations!

With your purchase you have decided on a high-quality product. Get to know the product before you start to use it. Carefully read the following operating instructions. Use the product only as described and only for the given areas of application. Keep these instructions safe. When passing the product on to a third party, always make sure that the documentation is included.

Contents (Fig. A)

2 x Handle (1)

1 x Skipping rope (2)

2 x Rope clamp (3)

2 x 50 g Handle weight (4)

2 x 100 g Handle weight (5)

1 x Countdown timer (6)

1 x Battery (7)

1 x Carrying case (8)

1 x Instructions for use

Technical data

Power supply: a

Dimensions: approx. ∅ 5.0mm x L 300cm

Programmable exercise time: 1 - 60 minutes

Intended use

This product is solely intended as a jump rope. It is not approved for any other use, e.g. as a tow- or pull rope, or for abseiling.

Safety notices

• Only use this product for its intended use.

• This product is not a toy for small children. Keep out of the reach of small children. Only allow children to use this product under supervision. Children could become entangled in the rope and stumble or become strangled.

• To prevent damage to the health or minimise potential risks, consult your physician before beginning fitness training. This particularly applies for impairments, e.g. pacemakers, or during pregnancy.

• Stop exercising immediately if you experience nausea, chest pain or other symptoms of illness such as dizziness or shortness of breath. In this event, seek immediate medical attention.
• Safe training requires ample space. Allow sufficient distance to objects and other persons whilst exercising to prevent injuries.
• Only train on a flat, non-slip surface.
• Never use this product near steps or ledges.
• Improper and excessive training can pose a risk to your health.
• Roll up the ropes when not in use. Never hang the ropes from a hook, etc.
• Only use the included weights to weigh down the handles.

Caution - risk of property damage

• Never exert force on this product.
• Do not throw to the ground.
• Do not expose the product to heat or fire.

General training instructions

• Allow adequate time and be sure to include a warm-up and cool-down period.
• Begin with easy exercises and slowly increase your training.
• Do not train immediately following meals, if ill, sick, fatigued, or other symptoms which may be impacted by training.

Assembly

• Remove both handles (1) and the rope (2) from the carrying case (8).
• Loosen the screw at the top end of the handles (Fig. B).
• Feed the rope into the handles as illustrated (Fig. C).
• Important! When you insert the rope, ensure the end of the rope always sits on the left hand side in the handle (Fig. C).
• Tighten the screw on the handle so the rope is secured when tugged.
• Secure the rope clamps (3) around each of the rope lines so the rope ends are firmly seated.

Correct rope length

• Check if the rope is the ideal length for you. Both ends of the rope (incl. handles) should reach from the feet to about the middle of the chest (Fig. F).
• If the rope is not the ideal length for your height, adjust the length.
• To shorten the jump rope, loosen the screws at the upper end of the handle. Remove the rope from the holder and lengthen the ends of the rope, which extend over the handles. To lengthen the jump rope, shorten these ends.
• Note! Be sure the rope clamps are equally spaced from the handles to ensure an even swing.

Inserting handle weights

• The jump rope set includes 2 handles weights each of 50g (4) 100g (5).
• You may train without adding weights, or using 50/100g to each handle.

Note: When using the additional weights, be sure to use the same weight on both handles.

1. Unscrew the end caps from the lower handle end (Fig. D).
2. If applicable, remove the inserted weights and replace with the lighter/heavier weights. Both handles must always have the same weight inserted.
3. Secure the end caps to the handles. Be sure the end caps are tightly secured.

Countdown timer

Programming the countdown timer

The countdown timer (6) can be set for training units of 1 to 60 minutes. Once the programmed training period has ended you will hear a sound.

1. To start the timer press the orange button until numbers appear in the display.
2. Hold the button for a few seconds to start the countdown timer.
3. Once the programmed training time has ended you will hear a sound.
4. To extend the training unit, only hold the button briefly. The timer can be set for training units up to 60 minutes.
   Automatic shut-off: The product will automatically shut off after 8 minutes to conserve battery (7) power.

Attaching the countdown timers

See Fig. E.

Battery warning

• Only use the same brand and type batteries.
• Remove the battery once drained or for extended periods of non-use.
• Warning! Never charge batteries or reactivate with other means, open, throw into fire, or short circuit.
  • Always keep batteries out of the reach of children.
• Never charge non-rechargeable batteries.
• Only charge rechargeable batteries under adult supervision.
• Remove rechargeable batteries from the product before charging.
• Never short circuit the terminals.
• Handle damaged or leaking batteries with extreme care and promptly dispose of according to regulations.
• If you come into contact with battery acid, wash the affected area with water and soap. If battery acid comes into contact with the eye, flush with water and seek immediate medical attention.

Replacing the battery

ATTENTION! Observe the following instructions to prevent mechanical and electrical damage.

Danger!

• Never touch leaked batteries without proper protection!
• Leaking batteries mustn't come into contact with the eyes or mouth. In this event, seek immediate medical attention.

If the display quality is failing, replace the battery with a new battery (button cell) LR44.

1. Turn the battery cover counter-clockwise and turn over to remove the cover.
2. Slightly tap the timer against your palm. The battery will fall out of the compartment.
3. Insert a new battery. Be sure to observe the correct polarity. The plus terminal faces the cover.
4. Insert the cover and turn clockwise.

After training

• Loosen the rope clamps from each end of the jump rope.
• Loosen the screws at the end of the handles.
• Remove the rope from the handles.
• Roll up the rope and store all parts inside the case.

Care and storage

Store this product out of the reach of children. Roll up the ropes when not in use. Never hang the ropes from a hook, etc., and never bend the ropes. This could permanently damage the ropes.

Regularly clean the jump rope set, preferably after each use. Clean with a damp cloth and a suitable cleaner. Never use harsh cleaners or solvents. Dry the set with a dry cloth. Store the set in a dry location at room temperature.

Instructions for disposal

Dispose of the product and all related components through an approved refuse disposal company, or through your municipal waste management company. Please observe the current applicable regulations. When in doubt, please contact your waste management company for environmentally-friendly disposal.

Battery disposal

Batteries do not belong in household refuse! Return to the respective collection sites or to the retailer where they were purchased.

Batteries are marked with a crossed-out refuse bin and the chemical symbols of the toxins, namely "Cd" for cadmium, "Hg" for mercury, and "Pb" for lead.

3 Years Warranty

The product was produced with great care and under constant supervision. You receive a three-year warranty for this product from the date of purchase. Please retain your receipt.

The warranty applies only to material and workmanship and does not apply to misuse or improper handling. Your statutory rights, especially the warranty rights, are not affected by this warranty. With regard to complaints, please contact the following service hotline or contact us by e-mail. Our service employees will advise as to the subsequent procedure as quickly as possible.

We will be personally available to discuss the situation with you.

Any repairs under the warranty, statutory guarantees or through goodwill do not extend the warranty period. This also applies to replaced and repaired parts. Repairs after the warranty are subject to a charge.

IAN: 93591

GB Service Great Britain

Tel.: [phone] (£ 0.10/Min.)

E-Mail: [e-mail]

IE Service Ireland

Tel.: [phone]

(0,08 EUR/Min., (peak))

(0,06 EUR/Min., (off peak))

E-Mail: [e-mail]

You can also find spare parts for your product at:

www.delta-sport.com, category Service - Lidl Spare Parts

Service

Onnittelumme!

Mål: ca. ∅ 5,0 mm x L 300 cm

www.delta-sport.com, rubrik service - reservedelservice Lidl

Félicitations !

env. ∅ 5,0 mm x L 300 cm
