IAN 277993 - Lamp Livarno Lux - Free user manual and instructions

Product Type	LED Clip Light with clamp base
Brand	Livarno Lux
Model Number	IAN 277993
Total Power Input	2.5 W
Lamp Operating Voltage	9 - 10.2 V DC, 180 mA
Adapter Input	220-240 V ~, 50/60 Hz, max. 40 mA
Adapter Output	Max. 12 V DC, 0.18 A
Number of LEDs	9
Power per LED	0.2 W
Protection Class	II / ☐
Flexibility	Flexible lamp arm
Mounting Method	Clamp (not for tubular objects)
Switch	ON/OFF switch on lamp arm
Usage Location	Indoor, dry and enclosed rooms
Warranty	3 years
Included Items	1 LED Clip Lamp, 1 Mains adapter, 1 Operating instructions
Cleaning	Dry fluff-free cloth only; do not use water or liquids
LED Replacement	Not replaceable; entire lamp must be replaced at end of life
Safety Features	Short-circuit proof safety transformer, polarity protection
Disposal	Recycle packaging; dispose of lamp separately at recycling facility

Frequently Asked Questions - IAN 277993 Livarno Lux

How do I install the LED Clip Light?

Attach the lamp by means of the clamp to a suitable surface (not tubular objects). Connect the mains connector to the mains adapter, then plug the adapter into a wall outlet. Use the ON/OFF switch to turn it on.

Can I use a different power adapter?

No, only use the supplied mains adapter (Model No. WGLD-03018BCCDC4). Using a different adapter may damage the product and void the warranty.

Is this lamp dimmable?

No, the lamp is not dimmable. It operates at full brightness when switched on.

Is the lamp waterproof?

No, the lamp is designed for indoor use only in dry and enclosed rooms. Keep it away from water and other liquids to avoid electric shock.

What should I do if the lamp stops working?

First, check that the mains adapter is properly plugged in and the outlet is working. If it still doesn't work, the LEDs may have reached end of life (they are not replaceable). Contact the retailer for warranty service if within 3 years.

Can I replace the LEDs myself?

No, the LEDs cannot be replaced. If the illuminant fails at the end of its life, the entire lamp must be replaced.

How do I clean the lamp?

Unplug the adapter, then use a dry, fluff-free cloth to wipe the lamp. Do not use water, solvents, or immerse the lamp in any liquid.

What is the power consumption of this lamp?

The total power input is 2.5 W. The adapter draws a small amount of power even when off, so unplug it for complete disconnection.

Is it safe to use near children?

Yes, children aged 8 and above can use it under supervision. However, keep the lamp out of reach of very young children as the clamp requires force and could cause pinching injuries.

What is the warranty period and how does it work?

The warranty is 3 years from the date of purchase. It covers material and manufacturing defects. Keep the original sales receipt as proof of purchase. Damage from improper use or normal wear (like batteries) is not covered.

USER MANUAL IAN 277993 Livarno Lux

Operation and Safety Notes

GR CY

List of pictograms used......Page 5

Introduction......Page 5

Intended Use Page 5

Description of parts....Page 5

Technical data......Page 5

Included items ......Page 6

Safety Page 6

Safety information......Page 6

Bringing into use......Page 8

Maintenance and Cleaning Page 8

Disposal Page 9

Warranty Page 9

List of pictograms used
	Short-circuit proof safety transformer		Polarity of the output terminals
	Separate control unit Safety cla

LED Clip Light

- Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the unit as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

IntendedUse

This lamp is intended for use indoors only, in dry and enclosed rooms. The product

is not intended to be used for commercial purposes.

• Description of parts

1 Flexible lamp arm
2 Base
3 ON/OFF switch
4 Mains connection lead
5 Mains connector
6 Mains adapter

- Technical data

Lamp + Mains adapter:

Total power input: 2.5 W

Lamp:

Operating voltage:9-10.2V = (direct current), 180 mA

Power per LED: 0.2 W (approx.)

LEDs: 9 LEDs

The bulb cannot be replaced.

Mains adapter:

Rated voltage,

primary:220-240V

(alternating

current)

50 / 60 Hz,

Max. 40mA

Rated voltage,

secondary: Max. 12 V

(direct current),

0.18A

Protection class: II / ☐

Model No.: WGLD-03018BCCDC4

Included items

1 LED Clip Lamp

1 Mains adapter

1 Operating instructions

● Safety

Safety information

READ THESE INSTRUCTIONS BEFORE USING THE PRODUCT! PLEASE KEEP ALL SAFETY INSTRUCTIONS AND

INSTRUCTIONS FOR USE FOR FUTURE REFERENCE!

WARNING!

DANGER OF DEATH

AND ACCIDENTS FOR

TODDLERS AND CHILDREN!

Never leave children unsupervised with the packaging material. The packaging material represents a danger of suffocation. Children frequently underestimate the dangers. Please keep children away from the device at all times.

This device is not a toy and should not be played by children. Children are not able to understand the dangers that can occur when handling this device.

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children without supervision.

This light is designed for use indoors only, in dry and enclosed rooms.
The lamp is not suitable for attaching to tubular objects. Failure to observe this advice could lead to the lamp falling and possible damage to the product and/or injury.

Avoid the danger of death from electric shock!

Before use, ensure that the mains voltage available is the same as the required operating voltage for the device (220-240V\~ (alternating current)).
Before connecting the device to the mains you should always check the device and the mains lead for any damage. A damaged device represents the danger of death from electric shock.
- Do not use the device if you find any damage.
■ Please consult a specialist electrician if you discover any damage or problems with the device, or for the performance of repairs to the device.
■ Never open any of the electrical equipment or insert any objects into it. Such interventions represent the

danger of death from electric shock.

It is essential that the device does not come into contact with water or other liquids.
■ Protect the power supply cable 4 from sharp edges, mechanical strain and hot surfaces.
■ Never use the device in the immediate vicinity of a bathtub, shower or swimming pool.
- Do not look directly into the light or its reflection. Do not aim the light directly at people. This could produce glare, leading to accidents.
If direct or reflected light strikes your eyes, close them and move your head immediately out of the light.
- Operate the lamp only with supplied mains adapter (WGLD-03018BCCDC4). Please note that any damage caused through the use of a different adapter is excluded from the warranty.
■ Never touch the mains adapter 6 with moist or wet hands.
■ Unplug the mains adapter 6 from the socket if the light will not be used for an extended period (e.g. whilst on holiday).
■ The bulb becomes hot during operation. Allow the lamp and bulb to cool before you touch them.

■ The LEDs cannot be replaced.
■ The product is only suited for use with the included mains adapter (Model No. WGLD-03018BCCDC4).
- Please note that the power adapter continues to draw a small amount of power even if the lamp is turned off as long as the power adapter is plugged into a power outlet. To switch the device off completely, unplug the power adapter from the socket.
The illuminant is not replaceable.
■Iftheilluminant fails at the end of its life, the entire light must be replaced.

● Bringing into use

☐ Never direct the LED light beam on to reflective surfaces or at people or animals. Failure to observe this advice may result in eye injury and / or loss of sight to people or animals. Even a weak LED light beam can cause eye damage.

☐ Attach the lamp in the desired position by means of the clamp 2.

A large force is required to attach the lamp. This could result in a risk of shearing or crushing injury through trapping parts of your body.

□ Connect the mains connector 5 to the mains adapter 6.

☐ Insert the mains adapter 6 into an ordinary domestic mains outlet socket (220-240V\~ (alternating current)).

☐ Use the ON / OFF switch 3 to switch the lamp on or off.

☐ Bend the flexible lamp arm 1 to bring the lamp into the desired position.

Note: Do not turn the flexible lamp arm 1 completely about itself or the mains lead inside the lamp could be damaged.

● Maintenance and Cleaning

Note: The device requires no maintenance. The LEDs cannot be replaced.

• Do not use any solvents, petrol or similar. This would cause damage to the light.
  ☐ Pull the mains adapter ☐ out of the mains socket.

CAUTION! DANGER OF ELECTRIC SHOCK! For electrical safety reasons do not clean the lamp with water or other liquids and never immerse it in water.

□ Always use a dry fluff-free cloth for cleaning the device.
☐ Never direct the LED light beam on to reflective surfaces or at people or animals. Failure to observe this advice may result in eye injury and / or loss of sight to people or animals. Even a weak LED light beam can cause eye damage.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities. The packaging is made of corrugated fibreboard (PAP 20).

The Green Dot is not valid for Germany.

The product and packaging materials are recyclable, dispose of it separately for better waste treatment. The Triman logo is valid in France only.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of product defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. Should this product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it - at our choice - free of charge to you.

The warranty period begins on the date of purchase. Please keep the original sales receipt in a safe location. This document is required as your proof of purchase. This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty applies to defects in material or manufacture. This warranty does not cover product parts subject to normal wear, thus possibly considered consumables (e.g. batteries) or for damage to fragile parts, e.g. switches, rechargeable batteries or glass parts.

CE
